Instruction booklet
,1509)50-4
Contents
Installation, 2-5
Positioning and levelling
Technical data
Electrical connection
Connecting the water supply
Description of the appliance, 6
Overall view
Control panel
Loading the racks, 7
Lower rack
Cutlery basket
Upper rack
Start-up and use, 8-9
Starting the dishwasher
Loading the detergent
Washing options
Wash cycles, 10
Wash cycle table
Rinse aid and refined salt, 11
Loading the rinse aid
Loading the refined salt
Care and maintenance, 12
Shutting off the water and electricity supplies
Cleaning the dishwasher
Preventing unpleasant odours
Cleaning the sprayer arms
Cleaning the water inlet filter
Cleaning the filters
Leaving the machine unused for extended periods
Precautions and advice, 13-14
General safety
Disposal
Saving energy and respecting the environment
Troubleshooting, 15
After Sales Service, 16
After Sales Service
Essential Contact Information
Parts and Accessories
Appliance Registration
Hotpoint Guarantee, 17
.,. %&"
EN
English, 1
2
EN
Positioning and levelling
1. Remove the appliance from all packaging and
check that it has not been damaged during
transportation.
If it has been damaged, contact the retailer and do not
proceed any further with the installation process.
2. Check the dishwasher by placing it so that its sides
or back panel are in contact with the adjacent
cabinets or even with the wall. This appliance can also
be recessed under a single worktop* (see the
Assembly instruction sheet).
3. Position the dishwasher on a level and sturdy floor. If
the floor is uneven, the front feet of the appliance may
be adjusted until it reaches a horizontal position (the
angle of inclination must not exceed 2 degrees). If the
appliance is levelled correctly, it will be more stable
and much less likely to move or cause vibrations and
noise while it is operating.
4*. Adjust the height of the rear foot from the front of
the appliance* on the central lower part of the
dishwasher, turning a hexagonal spanner (red color)
with an opening of 8 mm in a clockwise direction to
increase the height or in an anticlockwise direction to
decrease the height.
Anti-condensation strip*
After installing the dishwasher, open the door and
stick the adhesive transparent strip under the
wooden shelf in order to protect it from any
condensation that may form.
Keep this instruction manual in a safe place for
future reference. If the appliance is sold, given away
or moved, please ensure the manual is kept with the
machine, so that the new owner may benefit from the
advice contained within it.
Please read this instruction manual carefully: it
contains important information regarding the safe
installation, use and maintenance of the appliance.
If the appliance must be moved at any time,
keep it in an upright position; if absolutely
necessary, it may be tilted onto its back.
Advice regarding the first wash cycle
After the appliance has been installed, immediately
before running the first wash cycle, completely fill
the salt dispenser with water and add only then
approximately 1 kg of salt (see chapter entitled
Rinse aid and refined salt). The water may overflow:
this is normal and is not a cause for concern. Select
the water hardness value (see chapter entitled Rinse
aid and refined salt). - After the salt has been
poured into the machine, the LOW SALT indicator
light* switches off.
If the salt container is not filled, the water
softener and the heating element may be damaged
as a result.
* Only available in selected models.
Installation
Technical data
Dimensions
width 60 cm
height 85 cm
depth 60 cm
Capacity 14 standard place-settings
Water supply
pressure
0,05 ÷ 1MPa (0.5 ÷ 10 bar)
7,25 – 145 psi
Power supply
voltage See appliance data plate
Total absorbed
power See appliance data plate
Fuse See appliance data plate
This dishwasher conforms to
the following European
Community Directives:
-2006/95/CE dated 16/01/2007
(Low Voltage) and subsequent
modifications
-89/336/EEC dated 03/05/89
(Electromagnetic Compatibility)
and subsequent modifications
-97/17/EC (Labelling)
-2002/96/ CE Waste Electrical
and Electronic Equipment
(WEEE)
3
EN
The dishwasher meets the requirements set out
by the regulations in force concerning safety and
electrical equipment.
Any technical checks should be conducted
exclusively by a trained and authorised technician:
Repairs carried out by unaithorised persons will
invalidate the guarantee, as well as posing a
potential hazard to the user.
The manufacturer declines all responsibility for
damage to persons or property resulting from failure
to observe the above precautions, from tampering
with even a single component or from the use of
non-original spare parts.
Electrical Connection
Before inserting the plug into the electrical socket,
make sure that:
the socket is earthed and complies with current
regulations;
the socket can withstand the maximum load of
the appliance, which is indicated on the data
plate located on the inside of the door (see
Description of the appliance);
the power supply voltage falls within the values
indicated on the data plate on the inside of the
door;
the socket is compatible with the plug of the
appliance. If this is not the case, ask an
authorised technician to replace the plug (see
Assistance); do not use extension cables or
multiple sockets.
Once the appliance has been installed, the
power supply cable and the electrical socket should
be easily accessible.
The cable should not be bent or compressed.
If the power supply cable is damaged, it must
be replaced by the manufacturer or its Technical
Assistance Service in order to prevent all potential
hazards. (See Assistance)
This appliance must be earthed.
Fuses:your appliance comes fitted with a plug and a
13A fuse. If you need to replace the fuse, only those
rated at 13A and ASTA approved to BS1362 should
be used. If you lose the fuse cover, a replacement
may be obtained from your local authorised Service
Centre or Electrical company. Correct replacement is
identified by colour coding or the marking on base
of plug.
DO NOT use the plug unless the fuse cover is
fitted.
Changing the Plug
Cut off and dispose of the supplied plug if it
does not fit your socket.
To avoid a shock hazard DO NOT insert the
discarded plug into a socket anywhere else.
Wires in the mains lead are coloured accordance
with the following code:
Green/Yellow - Earth
Blue - Neutral
Brown - Live
If you change the plug, the colour of the wires in the
mains lead may not correspond with the terminal
markings in the plug, which if not coloured, could
be:
EARTH E or
NEUTRAL N
LIVE L
Changing the Mains Lead
A lead can be ordered from Hotpoint Service
UK: 08709 066 066 or
Republic of Ireland: 1850 302 220
- If you have damaged the existing lead or require a
longer one a charge will be made. It is strongly
advised that this work is carried out by a qualified
electrician.
- If the domestic wiring includes a residual current-
operated circuit breaker, ensure that it conforms to
the latest regulations.
The dishwasher must not be connected to the
electricity supply while installation is being carried
out.
- This appliance should only be connected to a 230/
240V AC source, via a properly installed earthed
socket.
- Use the dishwasher solely in a domestic
environment.
- DO NOT stand or place heavy objects on the door
when it is open, this could damage the door or
cause the appliance to tip forward.
The Company shall not be held responsible for
any incidents that occur if these regulations are not
observed.
