Sida 1/12
1
EN
INSTRUCTION FOR USE
THANK YOU FOR PURCHASING A HOTPOINT-ARISTON PRODUCT.
To receive more comprehensive help and support, please register your product at:
www.hotpoint.eu/register
Before using the appliance carefully read Health and Safety guide.
PRODUCT DESCRIPTION
APPLIANCE
1. Upper rack
2. Foldable flaps
3. Upper rack height adjuster
4. Upper spray arm
5. Space Zone
6. Lower rack
7. Cutlery basket
8. Lower spray arm
9. Filter Assembly
10. Salt reservoir
11. Detergent and Rinse Aid dispensers
12. Rating plate
13. Control panel
1
4
6
5
11
13
7
12
10
8
2
0000 000 00000
Service:
3
9
CONTROL PANEL
1. ON/OFF button
2. PREVIOUS button
3. NEXT button
4. Tablet Detergent (All-in-one) button
5. Zone Wash button
6. Zone Wash
indicator light
7. Display
8. Eco program indicator light
9. Start Delay indicator light
10. Program number and remaining time indicator
11. Closed water tap indicator light
12. Rinse Aid refill indicator light
13. Salt refill indicator light
14. Tablet Detergent (All-in-one) indicator light
15. Zone Wash 3D button with indicator light
16. Turbo button with indicator light
17. Extra Dry button with indicator light
18. Start Delay button with indicator light
19. START button with indicator light
5 6 7 8 9 10 11 13121
234
14 15 16 17 18 19
2
FIRST TIME USE
SETTING MENU AND SALT
ADVICE REGARDING THE FIRST TIME USE
After installation, remove the stoppers from the racks and the retaining
elastic elements from the upper rack.
SETTING MENU
1. Switch on the appliance by pressing the ON/OFF button.
2. Switch off the appliance by pressing the ON/OFF button.
3. Hold down START button for 5 seconds, until you hear a beep.
4. The display shows the first available setting (letter "A"), followed by
its value (for example: 3).
5. Press PREVIOUS/NEXT to scroll the list of the available settings
and to see their value (see the below table), then press START if
you want to change the value of the displayed setting: its value will
start blinking.
6. Use PREVIOUS/NEXT buttons to change the blinking value of the
selected settings, then press START to save the new value: it will
stop blinking.
7. To change another settings repeat steps 5-6.
8. To exit settings menu - press ON/OFF button.
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and
on the machine’s functional components.
• It is important that the salt reservoir be never empty.
• It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher (see
PRODUCT DESCRIPTION) and should be filled when the SALT REFILL
indicator light in the control panel is lit.
1.Remove the lower rack and unscrew
the reservoir cap (anticlockwise).
2.Only the first time you do this: fill the
salt reservoir with water.
3.Position the funnel
(see figure)
and fill
the salt reservoir right up to its edge
(approximately 1 kg); it is not unusual
for a little water to leak out.
4.Remove the funnel and wipe any salt
residue away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get
into the container during the wash program (this could damage the
water softener beyond repair).
As soon as this procedure is complete, run a program without loading.
The “Soak” program alone is NOT sufficient.
Residual saline solution or grains of salt can lead to corrosion,
irreparably damaging the stainless steel components.
The guarantee is not applicable if faults are caused by such
circumstances.
After the salt has been poured into the machine, the SALT REFILL
indicator light switches off.
Only use salt that has been specifically designed for dishwashers.
If the salt container is not filled, the water softener and the heating
element may be damaged as a result.
Whenever you need to add salt, it is mandatory to complete the
procedure before the beginning of the washing cycle.
SETTING THE WATER HARDNESS
To allow the water softener to work in a perfect way, it is essential that
the water hardness setting is based on the actual water hardness in
your house. This information can be obtained from your local water
supplier.
The factory setting is “3” for average water hardness.
To change, follow instructions in section “SETTING MENU”.
LETTER SETTING VALUES
(Default - in bold)
Water Hardness Level
(see “Setting the Water Hardness”
and “Water Hardness Table”)
1 | 2 | 3 | 4 | 5
Rinse Aid Level
(see “Adjusting the dosage of Rinse Aid”) 1 | 2 | 3 | 4 | 5
Start Program
To set the cycle to show at switch on of the
appliance.
“E”= Eco, “L”= Last cycle run
E | L
Brightness Level
To adjust the brightness
level of the display.
“Lo”=Low, “Hi”= High
Lo | Hi
Sound Level
To adjust the volume of the sounds.
“OF” = sounds off, “Lo” = low volume,
“Hi” = high volume.
OF | Lo | Hi
Internal Lights
(see “Options and Functions”)
“On” = On, “OF” = Off
On | OF
Light on the Floor
(see “Options and Functions”)
“On” = On, “OF” = Off
On | OF
Factory Settings
To restore to the factory default all the
values of the settings included in the
settings menu. After the activation of this
setting (ON), the machine switches OFF and
restores the factory settings.
“On” = On, “OF” = Off
On | OF
Water Hardness Table
Level °dH
German degrees
°fH
French degrees
1 Soft 0 - 6 0 - 10
2 Medium 7 - 11 11 - 20
3 Average 12 - 17 21 - 30
4 Hard 18 - 34 31 - 60
5 Very hard 35 - 50 61 - 90
3
EN
FIRST TIME USE
RINSE AID AND DETERGENT
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid dispenser A should
be filled when the RINSE AID REFILL indicator light in the control
panel is lit.
1. Open the dispenser
B
by pressing and pulling up the tab on the lid.
2. Carefully introduce the rinse aid as far as the maximum (110 ml)
reference notch of the filling space - avoid spilling it. If this happens,
clean the spill immediately with a dry cloth.
3. Press the lid down until you hear a click to close it.
NEVER pour the rinse aid directly into the tub.
ADJUSTING THE DOSAGE OF RINSE AID
If you are not completely satisfied with the drying results, you can ad-
just the quantity of rinse aid used.
To change, follow instructions in section “SETTING MENU”.
If the rinse aid level is set to 1, no rinse aid will be supplied. The LOW
RINSE AID indicator light will not be lit if you run out of rinse aid.
A maximum of 5 levels can be set according to the dishwasher model.
The factory setting is “5”.
• If you see bluish streaks on the dishes, set a low number (2-3).
• If there are drops of water or limescale marks on the dishes, set a
high number (4-5).
FILLING THE DETERGENT DISPENSER
Only use detergent which has been specifically designed for
dishwashers.
To achieve the best washing and drying results, the combined use
of detergent, rinse aid liquid and refined salt is required.
We recommend using detergents that do not contain phosphates
or chlorine, as these products are harmful to the environment.
Good washing results also depend on the correct amount
of detergent being used.
Exceeding the stated amount does not result in a more effective
wash and increases environmental pollution.
The amount can be adjusted to the soil level. In the case of normal-
ly soiled items, use approximately either 35g (powder detergent)
or 35ml (liquid detergent) and additional tea spoon of detergent
directly inside the tub. If tablets are used, one tablet will be enough.
If the crockery is only lightly soiled or if it has been rinsed with
water before being placed in the dishwasher, reduce the amount
of detergent used accordingly (minimum 25 g/ml) e.g. skip the
powder/gel putted inside the tub.
To open the detergent dispenser
press button A. Introduce the
detergent into the dry dispenser B
only. Place the amount of detergent
for pre-washing directly inside the
tub.
1. When measuring out the detergent
refer to the mentioned earlier
information to add the proper
quantity.
Inside the dispenser
B
there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser and
close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until the
closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program.
If all-in-one detergents are used, we recommend using the
TABLET
DETERGENT
button, because it adjusts the program so that the best
washing and drying results are always achieved.
If you are using a all-in-one detergents, we recommend that you
add salt in any case, especially if the water is hard or very hard
(follow the instructions given on the packaging).
M
A
X
A
B
35
25
A
B
