Sida 1/48

English,1

Contents

Installation, 2-3

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Description of the washing machine, 4-5

Control panel

Display

Running a wash cycle, 6

Wash cycles and functions, 7

Table of wash cycles

Wash functions

Detergents and laundry, 8

Detergent dispenser drawer

Preparing the laundry

Special wash cycles

Load balancing system

Precautions and tips, 9

General safety

Disposal

Opening the porthole door manually

Care and maintenance, 10

Cutting off the water or electricity supply

Cleaning the washing machine

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Troubleshooting, 11

Service, 12

WMD 962

Instructions for use

WASHING MACHINE

Français,13

Deutsch,25

Nederlands,37

Levelling the machine correctly will provide it with stability,

help to avoid vibrations and excessive noise and prevent it

from shifting while it is operating. If it is placed on carpet or

a rug, adjust the feet in such a way as to allow a sufficient

ventilation space underneath the washing machine.

Connecting the electricity and water

supplies

Connecting the water inlet hose

1. Connect the supply pipe

by screwing it to a cold

water tap using a ¾ gas

threaded connection (see

figure).

Before performing the con-

nection, allow the water to

run freely until it is perfectly

clear.

2. Connect the inlet hose

to the washing machine by

screwing it onto the corre-

sponding water inlet of the

appliance, which is situa-

ted on the top right-hand

side of the rear part of the

appliance . (see figure)

3. Make sure that the hose is not folded over or bent.

! The water pressure at the tap must fall within the values

indicated in the Technical details table (see next page).

! If the inlet hose is not long enough, contact a specialised

shop or an authorised technician.

! Never use second-hand hoses.

! Use the ones supplied with the machine.

Installation

! This instruction manual should be kept in a safe place for

future reference. If the washing machine is sold, transferred

or moved, make sure that the instruction manual remains

with the machine so that the new owner is able to familiari-

se himself/herself with its operation and features.

! Read these instructions carefully: they contain vital infor-

mation relating to the safe installation and operation of the

appliance.

Unpacking and levelling

Unpacking

1. Remove the washing machine from its packaging.

2. Make sure that the washing machine has not been

damaged during the transportation process. If it has been

damaged, contact the retailer and do not proceed any

further with the installation process.

3. Remove the protective 4

screws (used during tran-

sportation) and the rubber

washer with the correspon-

ding spacer, located on the

rear part of the appliance

( ).see figure

4. Close off the holes using the plastic plugs provided.

5. Keep all the parts in a safe place: you will need them

again if the washing machine needs to be moved to ano-

ther location.

! Packaging materials should not be used as toys for

children.

Levelling

1. Install the washing machine on a flat sturdy floor, without

resting it up against walls, furniture cabinets or anything

else.

2. If the floor is not perfectly

level, compensate for any

unevenness by tightening

or loosening the adjusta-

ble front feet ( ); see figure

the angle of inclination,

measured in relation to the

worktop, must not exceed

2°.

65 - 100 cm

Connecting the drain hose

Connect the drain hose,

without bending it, to a drai-

nage duct or a wall drain

located at a height between

65 and 100 cm from the

floor;

alternatively, rest it on

the side of a washbasin

or bathtub, fastening the

duct supplied to the tap

( ). The free end see figure

of the hose should not be

underwater.

! We advise against the use of hose extensions; if it is

absolutely necessary, the extension must have the same

diameter as the original hose and must not exceed 150 cm

in length.

Electrical connections

Before plugging the appliance into the electricity socket,

make sure that:

• thesocketisearthedandcomplieswithallapplicable

laws;

• thesocketisabletowithstandthemaximumpowerload

of the appliance as indicated on the Technical Data Plate

fixed on the machine;

• thepowersupplyvoltagefallswithinthevaluesindicated

on the Technical Data Plate fixed on the machine;

• thesocketiscompatiblewiththeplugofthewashing

machine. If this is not the case, replace the socket or the

plug.

! The washing machine must not be installed outdoors,

even in covered areas. It is extremely dangerous to leave

the appliance exposed to rain, storms and other weather

conditions.

! When the washing machine has been installed, the elec-

tricity socket must be within easy reach.

! Do not use extension cords or multiple sockets.

! The cable should not be bent or compressed.

! The power supply cable must only be replaced by autho-

rised technicians.

Warning! The company shall not be held responsible in the

event that these regulations are not respected.

The first wash cycle

Once the appliance has been installed, and before you use

it for the first time, run a wash cycle with detergent and no

laundry, using the wash cycle (60°C).

Technical data

Model WMD 962

Dimensions

width 59.5 cm

height 85 cm

depth 60,5 cm

Capacity from 1 to 9 kg

Electrical

connections

please refer to the technical data plate

fixed to the machine

Water connections

maximum pressure 1 MPa (10 bar)

minimum pressure 0.05 MPa (0.5 bar)

drum capacity 62 litres

Spin speed up to 1600 rotations per minute

Test Program-

mes according to

2010/1061

programme ;

temperature 60°C (2 press of the button);nd

temperature 40°C (3 press of the button).rd

This appliance conforms to the following

EC Directives:

- 2004/108/EC (Electromagnetic Compatibility)

- 2006/95/EC (Low Voltage)

- 2002/96/EC
