Sida 1/12

www.hotpoint.eu/register

User Manual

Quick Guide

THANK YOU FOR PURCHASING A HOTPOINT PRODUCT.

To receive more comprehensive assistance, register the

appliance on

www.hotpoint.eu/register

Before using the appliance carefully read the Health and Safety guide.

Before using the machine, it is imperative that the transport bolts are removed. For more

detailed instructions on how to remove them, see the Installation Guide.

CONTROL PANEL

WASH CYCLE TABLE

For all testing institutes:

2) Long cotton cycle: set wash cycle 3 with a temperature of 40°C.

3) Long synthetics cycle: set wash cycle 4 with a temperature of 40°C.

* By selecting the cycle and excluding the spin cycle, the washing machine will drain only. 14

** The duration of the wash cycles can be checked on the display.

*** For Prewash press the “Temp.” button until the symbol lights up (only 90°).

The cycle duration indicated on the display or instruction manual is an estimate based on

standard conditions. The actual duration may vary in relation to several factors, such as

the temperature and pressure of the incoming water, ambient temperature, amount of

detergent, load quantity and type, load balancing and any additional options selected.

1) Test wash cycle in compliance with regulation 1061/2010:

This cycle is designed for normally soiled cotton loads and is the most ecient in terms of

both electricity and water consumption; it should be used for garments washable at 60°C or

at 40°C. The actual washing temperature may dier from the indicated value.

PRODUCT DESCRIPTION

1. Top

2. Detergent dispenser drawer

3. Control panel

4. Handle

5. Porthole door

6. Drain pump (behind the plinth)

7. Plinth (removable)

8. Adjustable feet (2)

Maximum load 9 kg

Power input in o mode 0.5 W / in left-on mode 8 W

Active

Care

Add

Gar-

ments

( )

Detergents and

Additives

Recommended

detergent

Residual damp-

ness %

Energy consump-

tion kWh

Total water l

Wash cycle Temperature Max.

spin speed

(rpm)

Max.

load

(kg)

Duration

(min-

utes)

Pre-

wash Wash Fabric

softener Powder Liquid

Default Range 1 2 3

1 Mixed 40°C - 40°C 1400 9 **   –   – – – –

2 Eco Cotton (1) 60°C 60°C 1400 9 225 ––     53 0,87 57,5

40°C 1400 9 235 ––     53 1,24 94

3 Cotton (2) 40°C - 60°C 1400 9 235 ––     53 1,24 94

4 Synthetics (3) 40°C - 60°C 1200 4,5 175 ––     53 0,54 55

5 Delicates 40°C - 40°C 1000 4,5 **   –   – – – –

6 Wool 40°C - 40°C 800 2 ** – –   – – – –

7 Anti Allergy 60°C 40°C - 60°C 1400 5 ** – –     – – –

8 Anti Stain 40° 40°C - 40°C 1000 4,5 **   –     – – –

9 White 40°C - 90°C 1400 9 **       (***) – – –

10 Steam Refresh – – – 2 ** – – – – – – – – – –

11 Rapid 30 min 30°C - 30°C 800 4,5 **   –   – – – –

12 Bed & Bath 60°C - 60°C 1400 9 **   –     – – –

13 Shirts 40°C - 40°C 600 2 ** – –   – – – –

14 Spin & Drain * – – 1400 9 ** – – – – – – – – – –

15 Rinse & Spin – – 1400 9 ** – – – –  – – – – –

  Required dosage Optional dosage

DETERGENT DISPENSER DRAWER

compartment 1: Pre-wash detergent

(powder)

compartment 2: Detergent for the wash

cycle (powder or liquid)

If liquid detergent is used, it is recommended

that the removable plastic partition A

(supplied) be used for proper dosage.

If powder detergent is used, place the partition

into slot B.

compartment 3: Additives (fabric softeners,

etc.)

The fabric softener should not overow the grid.

! Use powder detergent for white cotton garments, for pre-washing, and

for washing at temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

1. STEAM HYGIENE / MUTE button

2. FINAL CARE / KEY LOCK button

3. ON/OFF button

4. ACTIVE CARE button and indicator light

5. START/PAUSE button

6. RAPID / ECO button

7. SPIN button

8. START DELAY button

9. TEMPERATURE button

10. WASH CYCLE SELECTOR KNOB

1 2

56789

DISPLAY

WASH CYCLES

Follow the instructions on the symbols of the garment’s wash

care label. The value indicated in the symbol is the maximum

recommended temperature for washing the garment.

Mixed

For washing lightly to normally soiled resilient garments in cotton, linen,

synthetic bres and mixed bres.

Eco Cotton 60°/40°

Suitable for washing moderately soiled cotton garments. At 40°C and

60°C it is the standard cycle for washing cotton garments, and is the most

ecient in terms of combined water and electricity consumption.

Cotton

Normally to heavily soiled and robust cottons .

Synthetics

Suitable for washing moderately soiled garments made of synthetic bres

(e.g. polyester, polyacrylic, viscose, etc.) or mixed synthetic-cotton bres.

Delicates

For washing very delicate garments. It is advisable to turn the garments

inside out before washing them. For best results, use liquid detergent on

delicate garments.

Wool - Woolmark Apparel Care - Green:

The “Wool” wash cycle is approved by the Woolmark Company for

washing wool garments classied as “hand-washable”, provided that the

wash complies with the instructions appearing on the garment’s label

and with those provided by the manufacturer of this washing machine.

(M1127)

In UK, Eire, Hong Kong and India the Woolmark trade mark is a Certication

trade mark.

Anti Allergy

Suitable for removing major allergens such as pollen, mites and cat or dog hair.

Anti Stain 40°

The programme is suitable to heavily-soiled garments with resistant

colours. It ensures a washing class that is higher than the standard class (A

class). When running the programme, do not mix garments of dierent

colours. We recommend the use of powder detergent. Pre-treatment with

special additives is recommended if there are obstinate stains.

White

For washing normally to heavily soiled towels, underwear, table and bed

linen, etc in resilient cotton and linen. Only when the temperature is

selected at 90°C the cycle is provided with a prewash phase before main

washing phase. In this case it is recommended to add detergent both, in

the prewash and main wash section.

Steam Refresh

The garments will be damp once the cycle is completed, so we recommend

hanging them to dry (2 kg, roughly 3 items). This programme refreshes

garments by removing bad odours and relaxing the bres. Insert dry items

only (that are not dirty) and select programme “ ”. Garments Steam Refresh

will be a little damp at the end of the cycle and can be worn after a few

minutes. The “Steam Refresh” programme makes ironing easier.

! Do not add softeners or detergents.

! Not recommended for wool or silk garments.

Rapid 30 min

For washing lightly soiled garments quickly. This cycle lasts only 30

minutes, saving time and energy.

Bed & Bath

For washing home linen in a single cycle. It optimises the use of fabric

softener and allows for saving time and electricity. We recommend the

use of powder detergent.

Shirts

Use the special wash cycle to wash shirts in dierent fabrics and colours

to guarantee they receive the best possible care.

Spin & Drain

Spins the load then empties the water. For resilient garments. If you

exclude the spin cycle, the machine will drain only

Rinse & Spin

Rinses and then spins. For resilient garments.

DISPLAY

The display is useful when programming the washing machine and

provides plenty of information.

The duration of the available wash cycles and the remaining time of a

running cycle appear in section (the display will show the maximum A

duration of the cycle chosen, which may decrease after several minutes,

since the eective duration of the programme varies depending on the

wash load and the settings chosen); if the DELAYED START option has been

set, the countdown to the start of the selected wash cycle will appear.

Pressing the corresponding button allows you to view the maximum spin

speed and temperature values attained by the machine during the set

wash cycle, or the values selected most recently, if these are compatible

with the set wash cycle.

The “wash cycle phases” corresponding to the selected wash cycle and the

“wash cycle phase” of the running wash cycle appear in section :B

Main wash

Rinse

Spin + Pump out

References indicate the wash options available (See “Options” section). C

The “Start Delay” symbol , when lit, indicates that the set “delayed start”

value has appeared on the display.

The symbol indicates the possibility of inserting an additional garments

load with the washing program started (See “Adding Garments” section).

The symbol indicates the possibility to silence the key tones

While the mute is active, almost all sounds will be turned o. Only the sound

signals and the alarms remain active, as well as the sound of the end of cycle.

For activate/deactivate the mute press and hold button.

DISPLAY INDICATORS

Failure: Call Service

Refer to Troubleshooting section

Failure: Water lter clogged

Water cannot be drained; water lter might be blocked

Failure: No water

No or not sucient inlet water.

In the event of any failure, refer to the “Troubleshooting” section.

Key Lock

To lock the control panel, press and hold the “Key lock” button for

approximately 3 seconds. The symbol will light up on the display to

indicate that the control panel has been locked (with the exception of the

“ON/OFF“ button). This prevents unintentional changes to programmes,

especially with children near the machine. To unlock the control panel,

press and hold the “Key lock” button for approximately 3 seconds .

Locked door indicator

When lit, the symbol indicates that the door is locked. To prevent any

damage, wait until the symbol turns o before opening the door.

To open the door while a cycle is in progress, press the START/PAUSE

button ; if the symbol is o, the door can be opened.

FIRSTTIME USE

Once the appliance has been installed, and before you use it for the rst

time, run a wash cycle with detergent and no laundry, using the wash

cycle .9 (60°)

DAILY USE

Prepare the laundry by following the suggestions appearing under the

“TIPS AND SUGGESTIONS” section.

- Press the ON/OFF button .

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the wash cycle table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments, as described in the “DETERGENT DISPENSER

DRAWER” section.

- Close the door.

- The machine automatically displays the default temperature and spin

speed values for the selected cycle, or the most recently used settings if

they are compatible with the selected cycle.

- Select the desired wash cycle.

- Select the desired options.

- Press the START/PAUSE button to start the wash cycle; the door will

lock ( symbol on).

END

DEM O

Produktspecifikationer

Varumärke:	Hotpoint
Kategori:	tvättmaskin
Modell:	NM11 946 BC A UK

Behöver du hjälp?

Om du behöver hjälp med Hotpoint NM11 946 BC A UK ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

tvättmaskin Hotpoint Manualer

Hotpoint WMG 942BV EU Bruksanvisning

19 Oktober 2024

Hotpoint NSWM 963C W UK Bruksanvisning

14 Oktober 2024

Hotpoint HDA3420ZBB Bruksanvisning

9 Oktober 2024

Hotpoint VLXR1020DWO Bruksanvisning

8 Oktober 2024

Hotpoint NBT 1048 WD A IT Bruksanvisning

7 Oktober 2024

Hotpoint NBT 108 BLACK IT Bruksanvisning

6 Oktober 2024

Hotpoint HDA3600NBB Bruksanvisning

6 Oktober 2024

Hotpoint NM11 946 BC A UK Bruksanvisning

6 Oktober 2024

Hotpoint NM10 944 GS UK Bruksanvisning

6 Oktober 2024

Hotpoint NSWR 963C WK UK Bruksanvisning

4 Oktober 2024

tvättmaskin Manualer

Nyaste tvättmaskin Manualer

AEG LTR8C6152A Bruksanvisning

27 Oktober 2024

Samsung WW90T534ATW Bruksanvisning

27 Oktober 2024

Samsung WW10T754DBX Bruksanvisning

27 Oktober 2024

New Pol XF6600EL Bruksanvisning

27 Oktober 2024

Zanussi ZR8441WF Bruksanvisning

27 Oktober 2024

Philco PLDS 1063 Crown Bruksanvisning

27 Oktober 2024

Candy CO 4104TWM/1-S Bruksanvisning

27 Oktober 2024

New Pol XS 271EV Bruksanvisning

27 Oktober 2024

Corberó CLAV822 Bruksanvisning

27 Oktober 2024

Candy CBD485D2CE/1-80 Bruksanvisning

27 Oktober 2024
