Sida 1/56
English
Sheet of household washing machines
The design and specifications are subject to change without notice for quality improvement purposes.
According to Regulation (EU) No. 1061/2010
Samsung
Model Name
WF80F5E*U4*
WF80F5E*UH*
WF80F5E*P4*
WF80F5E*PH*
WF80F5E*U2*
WF80F5E*UM*
WF80F5E*P2*
WF80F5E*PM*
WF70F5E*U4*
WF70F5E*UH*
WF70F5E*P4*
WF70F5E*PH*
WF70F5E*U2*
WF70F5E*UM*
WF70F5E*P2*
WF70F5E*PM*
Capacity kg 8 7
Energy Eciency
A + + + (highest efficiency) to D (least efficient) A+++ A+++
Energy Consumption
Annual Energy Consumption (AE_C) 1) kWh/yr 157 122
Energy consumption (E_t.60) Cotton 60 °C at full load kWh 0.88 0.68
Energy consumption (E_t.60.1/2) Cotton 60 °C with
partial load kWh 0.68 0.52
Energy consumption (E_t.40.1/2) Cotton 40 °C with
partial load kWh 0.41 0.34
Weighted power off-mode (P_o) W 0.48 0.48
Weighted Power in left-on mode (P_l) W 5 5
Annual water consumption (AW_c) 2) L/yr 10500 9400
Spin eciency class 3)
A (most efficient) to G (least efficient) B B
Maximum Spin Speed rpm 1400 1200 1400 1200
Residual moisture % 53 56 53 56
Programs to which the information on the label and the Sheet relate Cotton 60 °C and 40 °C + Intensive 4)
Program duration of the standard program
Cotton 60 °C at full load min 242 242
Cotton 60 °C for partial load min 194 214
Cotton 40 °C with partial load min 174 174
Weighted time in left-on mode min 2 2
Airborne noise emissions
Wash dB (A) re 1 pW 53 54
Spin dB (A) re 1 pW 74 74
Dimensions
Unit dimensions
Height mm 850 850
Width mm 600 600
Depth 5) mm 550 550
Net weight kg 61 61
Gross weight kg 63 63
Package weight kg 2 2
Water Pressure kPa 50–800 50–800
Electrical connection
Voltage V 220–240 220–240
Power consumption W 2000–2400 2000–2400
Frequency Hz 50 50
Name of company Samsung Electronics Co., Ltd.
" * " Asterisk(s) means variant model and can be varied (0-9) or (A-Z).
English
The design and specifications are subject to change without notice for quality improvement purposes.
According to Regulation (EU) No. 1061/2010
Samsung
Model Name
WF80F5E*Q4*
WF80F5E*QH*
WF80F5E*W4*
WF80F5E*WH*
WF80F5E*Q2*
WF80F5E*QM*
WF80F5E*W2*
WF80F5E*WM*
WF70F5E*Q4*
WF70F5E*QH*
WF70F5E*W4*
WF70F5E*WH*
WF70F5E*Q2*
WF70F5E*QM*
WF70F5E*W2*
WF70F5E*WM*
Capacity kg 8 7
Energy Eciency
A + + + (highest efficiency) to D (least efficient) A+++ A+++
Energy Consumption
Annual Energy Consumption (AE_C) 1) kWh/yr 195 173
Energy consumption (E_t.60) Cotton 60 °C at full load kWh 1.06 0.94
Energy consumption (E_t.60.1/2) Cotton 60 °C with
partial load kWh 0.86 0.80
Energy consumption (E_t.40.1/2) Cotton 40 °C with
partial load kWh 0.58 0.59
Weighted power off-mode (P_o) W 0.48 0.48
Weighted Power in left-on mode (P_l) W 5 5
Annual water consumption (AW_c) 2) L/yr 10500 9400
Spin eciency class 3)
A (most efficient) to G (least efficient) B B
Maximum Spin Speed rpm 1400 1200 1400 1200
Residual moisture % 53 56 53 56
Programs to which the information on the label and the Sheet relate Cotton 60 °C and 40 °C + Intensive 4)
Program duration of the standard program
Cotton 60 °C at full load min 239 239
Cotton 60 °C for partial load min 191 211
Cotton 40 °C with partial load min 171 171
Weighted time in left-on mode min 2 2
Airborne noise emissions
Wash dB (A) re 1 pW 62 62
Spin dB (A) re 1 pW 79 76 79 76
Dimensions
Unit dimensions
Height mm 850 850
Width mm 600 600
Depth 5) mm 550 550
Net weight kg 64 64
Gross weight kg 66 66
Package weight kg 2 2
Water Pressure kPa 50–800 50–800
Electrical connection
Voltage V 220–240 220–240
Power consumption W 2000–2400 2000–2400
Frequency Hz 50 50
Name of company Samsung Electronics Co., Ltd.
" * " Asterisk(s) means variant model and can be varied (0-9) or (A-Z).
English
The design and specifications are subject to change without notice for quality improvement purposes.
According to Regulation (EU) No. 1061/2010
Samsung
Model Name
WF60F4E*Q2*
WF60F4E*QM*
WF60F4E*W2*
WF60F4E*WM*
WF60F4E*Q0*
WF60F4E*QL*
WF60F4E*W0*
WF60F4E*WL*
Capacity kg 6
Energy Eciency
A + + + (highest efficiency) to D (least efficient) A++
Energy Consumption
Annual Energy Consumption (AE_C) 1) kWh/yr 170
Energy consumption (E_t.60) Cotton 60 °C at full load kWh 1.02
Energy consumption (E_t.60.1/2) Cotton 60 °C with partial
load kWh 0.65
Energy consumption (E_t.40.1/2) Cotton 40 °C with partial
load kWh 0.46
Weighted power off-mode (P_o) W 0.48
Weighted Power in left-on mode (P_l) W 5
Annual water consumption (AW_c) 2) L/yr 8580
Spin eciency class 3)
A (most efficient) to G (least efficient) B C
Maximum Spin Speed rpm 1200 1000
Residual moisture % 56 65
Programs to which the information on the label and the Sheet relate Cotton 60 °C and 40 °C + Intensive 4)
Program duration of the standard program
Cotton 60 °C at full load min 249
Cotton 60 °C for partial load min 191
Cotton 40 °C with partial load min 171
Weighted time in left-on mode min 2
Airborne noise emissions
Wash dB (A) re 1 pW 61 61
Spin dB (A) re 1 pW 76 74
Dimensions
Unit dimensions
Height mm 850
Width mm 600
Depth 5) mm 400
Net weight kg 54
Gross weight kg 56
Package weight kg 2
Water Pressure kPa 50-800
Electrical connection
Voltage V 220-240
Power consumption W 2000-2400
Frequency Hz 50
Name of company Samsung Electronics Co., Ltd.
" * " Asterisk(s) means variant model and can be varied (0-9) or (A-Z).
