Sida 1/16
GB
1
! This symbol reminds you to read this instruction manual.
Contents
Installation, 2-3-4-5
Unpacking and levelling
Connecting the electricity and water supplies
The first wash cycle
Technical data
Description of the washer-dryer, 6-7
Control panel
Display
How to run a wash cycle or a drying cycle, 8
Wash cycles and functions, 9
Table of wash cycles
Wash functions
Detergents and laundry, 10
Detergent dispenser drawer
Preparing the laundry
Special wash cycles
Load balancing system
Precautions and tips, 11
General safety
Disposal
Opening the porthole door manually
Care and maintenance, 12
Cutting off the water or electricity supply
Cleaning the washer-dryer
Cleaning the detergent dispenser drawer
Caring for the door and drum of your appliance
Cleaning the pump
Checking the water inlet hose
Troubleshooting, 13-14
Assistance, 15-16
WDUD 9640
Instructions for use
WASHER-DRYER
English,1
GB
2
GB
Installation
Levelling your appliance correctly will provide it with sta-
bility and avoid any vibrations, noise and shifting during
operation. If it is placed on a fitted or loose carpet, adjust
the feet in such a way as to allow enough room for ventila-
tion beneath the washer-dryer.
Electric and water connections
Connecting the water inlet hose
1. Connect the supply pipe
by screwing it to a cold
water tap using a
3/4 gas threaded connec-
tion (see figure).
Before performing the con-
nection, allow the water to
run freely until it is perfectly
clear.
2. Connect the other end of
the water inlet hose to the
washer-dryer,
screwing it onto the ap-
pliance’s cold water inlet,
situated on the top right-
hand side on the rear of the
appliance (see figure).
3. Make sure there are no kinks or bends in the hose.
! The water pressure at the tap must be within the values
indicated in the Technical details table (on the page 5).
! If the water inlet hose is not long enough, contact a spe-
cialist store or an authorised serviceman.
! Ensure that the supply taps are allowing water through.
Old taps may seize in the closed position and thus pre-
vent water reaching the machine.
! Never use second-hand or old inlet hoses; use the pro-
ducts supplied with the machine.
! Keep this instruction manual in a safe place for future
reference. Should the appliance be sold, transferred or
moved, make sure the instruction manual accompanies the
washer-dryer to inform the new owner as to its operation and
features.
! Read these instructions carefully: they contain vital infor-
mation on installation, use and safety.
Unpacking and levelling
Unpacking
! This is a separate part of
the polystyrene base and
should be removed with
the base.
! IMPORTANT check
when unpacking your
machine.
1. Unpack the washer-dryer.
2. Check whether the washer-dryer has been damaged
during transport. If this is the case, do not install it and
contact your retailer.
3. Remove the 4 protective
screws and the rubber bush
with the respective spacer,
situated on the rear of the
appliance (see also the
installation leaflet).
4. Seal the gaps using the plastic plugs provided.
5. Keep all the parts: you will need them again if the
washer-dryer needs to be moved to another location.
! Packaging materials are not children’s toys.
Levelling
Your machine may make a considerable amount of noise if
the two front feet have not been adjusted correctly.
1. Install the washer-dryer
on a flat sturdy floor, without
resting it up against walls,
furniture cabinets or other.
2. If the floor is not perfectly level, compensate for any
unevenness by tightening or loosening the adjustable front
feet (see figure); the angle of inclination, measured accor-
ding to the worktop, must not exceed 2°.
GB
3
Connecting the drain hose
Connect the drain hose,
without bending it, to a
draining duct or a wall drain
situated between 65 and
100 cm from the floor;
The drain hose may be
connected to an under-
sink trap. Before connec-
ting the drain hose from
the machine ensure that
any blanks or removable
ends have been taken off
the spigot.
If it is placed over the edge
of a basin or sink be sure
the free end of the hose
should not be underwater.
! We advise against the use of hose extensions; in case of
absolute need, the extension must have the same diameter
as the original hose and must not exceed 150 cm in length.
Ensure that if the drain hose is pushed into a standpipe, that
the end does not go down more than 15cms (6 inches). If
the hose is pushed down too far, this may cause the machi-
ne to self -syphon ie. continuously empty as it is filling.
Electric connection
Before plugging the appliance into the mains socket, make
sure that:
• the socket is earthed and in compliance with the appli-
cable law;
• the socket is able to sustain the appliance’s maximum
power load indicated on the Technical Data Plate fixed
on the machine;
• the supply voltage is included within the values indica-
ted on the Technical Data Plate fixed on the machine.
• the socket is compatible with the washer-dryer’s plug. If
this is not the case, replace the socket or the plug.
Your appliance is now supplied with a 13 amp fused plug
it can be plugged into a 13 amp socket for immediate use.
Before using the appliance please read the instructions
below.
WARNING - THIS APPLIANCE MUST BE EARTHED.
THE FOLLOWING OPERATIONS SHOULD BE CARRIED
OUT BY A QUALIFIED ELECTRICIAN.
Replacing the fuse:
When replacing a faulty fuse, a 13 amp ASTA approved
fuse to BS 1362 should always be used, and the fuse
cover re-fitted. If the fuse cover is lost, the plug must not
be used until a replacement is obtained.
Replacement fuse covers:
If a replacement fuse cover is fitted, it must be of the
correct colour as indicated by the coloured marking or the
colour that is embossed in words on the base of the plug.
Replacements can be obtained directly from your nearest
Service Depot.
Removing the plug:
If your appliance has a non-rewireable moulded plug and
you should wish to re-route the mains cable through parti-
tions, units etc., please ensure that either:
the plug is replaced by a fused 13 ampere rewireable plug
bearing the BSI mark of approval.
or:
the mains cable is wired directly into a 13 amp cable out-
let, controlled by a switch, (in compliance with BS 5733)
which is accessible without moving the appliance.
Disposing of the plug:
Ensure that before disposing of the plug itself, you make
the pins unusable so that it cannot be accidentally inserted
into a socket.
Instructions for connecting cable to an alternative plug:
Important: the wires in the mains lead are coloured in
accordance with the following code:
Green & Yellow Earth
Blue Neutral
Brown Live
65 - 100 cm
Where it connects to
the waste water pipe
cut end off spigot or
remove the blanking cap
