Sida 1/16

English,1

Contents

Installation, 2-3-4-5

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Care and maintenance, 6

Cutting off the water or electricity supply

Cleaning the washing machine

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Precautions and tips, 7

General safety

Disposal

Description of the washing machine, 8-9

Control panel

Display

Running a wash cycle, 10

Wash cycles and functions, 11

Table of wash cycles

Wash functions

Detergents and laundry, 12

Detergent dispenser drawer

Preparing the laundry

Special wash cycles

Load balancing system

Troubleshooting, 13-14

Assistance, 15-16

WMAO 963

Instructions for use

WASHING MACHINE

Installation

2. If the floor is not perfectly level, compensate

for any unevenness by tightening or loosening

the adjustable front feet the an-(see figure);

gle of inclination, measured according to the

worktop, must not exceed 2°.

Levelling your appliance correctly will provide

it with stability and avoid any vibrations, noise

and shifting during operation. If it is placed on

a fitted or loose carpet, adjust the feet in such

a way as to allow enough room for ventilation

beneath the washing machine.

Electric and water connections

Connecting the water inlet hose

1. Connect the supply

pipe by screwing it to

a cold water tap using

a 3/4 gas threaded

connection (see figu-

re).

Before performing the

connection, allow the

water to run freely until

it is perfectly clear.

2. Connect the other

end of the water inlet

hose to the washing

machine,

screwing it onto the

appliance’s cold water

inlet, situated on the

top right-hand side on

the rear of the ap-

pliance (see figure).

3. Make sure there are no kinks or bends in the

hose.

! The water pressure at the tap must be within

the values indicated in the Technical details

table (on the page 5).

! If the water inlet hose is not long enough,

contact a specialist store or an authorised

serviceman.

! Ensure that the supply taps are allowing wa-

ter through. Old taps may seize in the closed

position and thus prevent water reaching the

machine.

! Never use second-hand or old inlet hoses;

use the products supplied with the machine.

! Keep this instruction manual in a safe place

for future reference. Should the appliance be

sold, transferred or moved, make sure the

instruction manual accompanies the washing

machine to inform the new owner as to its

operation and features.

! Read these instructions carefully: they contain

vital information on installation, use and safety.

Unpacking and levelling

Unpacking

! This is a separate

part of the polystyre-

ne base and should

be removed with the

base.

! IMPORTANT check

when unpacking

your machine.

1. Unpack the washing

machine.

2. Check whether the

washing machine has

been damaged during

transport. If this is the

case, do not install

it and contact your

retailer.

3. Remove the 4 pro-

tective screws and the rubber bush with the

respective spacer, situated on the rear of the

appliance (see also the installation leaflet).

4. Seal the gaps using the plastic plugs provi-

ded.

5. Keep all the parts: you will need them again

if the washing machine needs to be moved to

another location.

! Packaging materials are not children’s toys.

Levelling

Your machine may

make a considerable

amount of noise if the

two front feet have not

been adjusted correct-

ly.

1. Install the washing

machine on a flat sturdy

floor, without resting it up

against walls, cabinets

or anything else.

Connecting the drain hose

Connect the drain

hose, without bending

it, to a draining duct

or a wall drain situa-

ted between 65 and

100 cm from the floor;

The drain hose may

be connected to an

under-sink trap. Be-

fore connecting the

drain hose from the

machine ensure that

any blanks or remo-

vable ends have been

taken off the spigot.

If it is placed over

the edge of a basin

or sink be sure the

free end of the hose

should not be under-

water.

! We advise against the use of hose extensions;

in case of absolute need, the extension must

have the same diameter as the original hose

and must not exceed 150 cm in length.

Ensure that if the drain hose is pushed into

a standpipe, that the end does not go down

more than 15cms (6 inches). If the hose is pu-

shed down too far, this may cause the machine

to self -syphon ie. continuously empty as it is

filling.

Electric connection

Before plugging the appliance into the mains

socket, make sure that:

• the socket is earthed and in compliance with

the applicable law;

• the socket is able to sustain the appliance’s

maximum power load indicated on the Tech-

nical Data Plate fixed on the machine;

• the supply voltage is included within the

values indicated on the Technical Data Plate

fixed on the machine.

• the socket is compatible with the washing

machine’s plug. If this is not the case, repla-

ce the socket or the plug.

Your appliance is now supplied with a 13 amp

fused plug it can be plugged into a 13 amp

socket for immediate use. Before using the

appliance please read the instructions below.

WARNING - THIS APPLIANCE MUST BE

EARTHED.

THE FOLLOWING OPERATIONS SHOULD

BE CARRIED OUT BY A QUALIFIED ELECTRI-

CIAN.

Replacing the fuse:

When replacing a faulty fuse, a 13 amp ASTA

approved fuse to BS 1362 should always be

used, and the fuse cover re-fitted. If the fuse

cover is lost, the plug must not be used until a

replacement is obtained.

Replacement fuse covers:

If a replacement fuse cover is fitted, it must be

of the correct colour as indicated by the colou-

red marking or the colour that is embossed in

words on the base of the plug. Replacements

can be obtained directly from your nearest

Service Depot.

Removing the plug:

If your appliance has a non-rewireable moul-

ded plug and you should wish to re-route the

mains cable through partitions, units etc.,

please ensure that either:

the plug is replaced by a fused 13 ampere

rewireable plug bearing the BSI mark of ap-

proval.

or:

the mains cable is wired directly into a 13

amp cable outlet, controlled by a switch, (in

compliance with BS 5733) which is accessible

without moving the appliance.

Disposing of the plug:

Ensure that before disposing of the plug itself,

you make the pins unusable so that it cannot

be accidentally inserted into a socket.

Instructions for connecting cable to an alternati-

ve plug:

Important: the wires in the mains lead are co-

loured in accordance with the following code:

Green & Yellow Earth

Blue Neutral

Brown Live

65 - 100 cm

Where it connects to

the waste water pipe

cut end off spigot or

remove the blanking cap
