Sida 1/16
VDLP56SBS / VDLP56LBS / VDLP56SCS / VDLP56LCS 1 VELLEMAN
VDLP56SBS / VDLP56LBS / VDLP56SCS / VDLP56LCS – PAR56 PROJECTOR
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm
the environment.
Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialised
company for recycling.
This device should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for buying the VDLP56SBS / VDLP56LBS / VDLP56SCS / VDLP56LCS! Please read the manual
thoroughly before bringing this device into service. Unpack your device carefully. It should come with: 1 x short or long
PAR56 spot, 1 x clamp, 1 x safety cable and 4 x colour filter. If the device was damaged in transit, don't install or use it
and contact your dealer.
2. Safety Instructions
• Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and the dealer
will not accept responsibility for any ensuing defects or problems.
• A qualified technician should install and service this device.
• Do not switch the device on immediately after it has been exposed to changes in temperature. Protect the device
against damage by leaving it switched off until it has reached room temperature.
• This device falls under protection class I. It is therefore essential that the device be earthed. Have a qualified
person carry out the electric connection.
• Make sure that the available voltage does not exceed the voltage stated in the specifications of this manual.
• Do not crimp the power cord and protect it against damage. Have an authorised dealer replace it if necessary.
• Disconnect the device from the mains to clean it or when it is not in use. Handle the power cord by the plug only.
• There may be some smoke or a particular smell when the device is activated for the first time. This is normal and
any smoke or smell will gradually disappear.
• Do not look directly at the light source as sensitive people may go into epileptic seizure if they do.
• Note that damage caused by user modifications to the device is not covered by the warranty.
• Keep the device away from children and unauthorised users.
3. General Guidelines
• This device is designed for professional use on stage, in discos, theatres etc. The VDLP56SBS / VDLP56LBS /
VDLP56SCS / VDLP56LSC should only be used indoors with an alternating current of max. 230VAC / 50-60Hz.
• Lighting effects are not designed for permanent operation: regular operation breaks will prolong their lives.
• Do not shake the device. Avoid brute force when installing or operating the device.
Be very careful during the installation: touching live wires can cause life-threatening electroshocks.
Do not touch the device during operation as the housing heats up.
Keep this device away from rain and moisture.
Unplug the mains lead before opening the housing.
VDLP56SBS / VDLP56LBS / VDLP56SCS / VDLP56LCS 2 VELLEMAN
• Select a location where the device is protected against extreme heat (see “ ”), dust and Technical Specifications
moisture. Respect a minimum distance of 1m between the device’s light output and any illuminated surface.
• Use the included safety cable to fix the device.
• Familiarise yourself with the functions of the device before actually using it. Do not allow operation by unqualified
people. Any damage that may occur will most probably be due to unprofessional use of the device.
• Use the original packaging if the device is to be transported.
• All modifications of the device are forbidden for safety reasons.
• Only use the device for its intended purpose. All other uses may lead to short circuits, burns, electroshocks, crash
etc. Using the device in an unauthorised way will void the warranty.
4. Installation
a) Lamps
• Only fit or replace a lamp when the device is unplugged from the mains.
• Let a lamp cool down before replacing it as the temperature of a lamp can reach 700°C during operation.
• When handling a halogen lamp, do not touch it with your bare hands. Use a cloth to insert or remove it.
• Do not install lamps with a higher wattage. They get hotter than this device was designed for.
• Replace any deformed or damaged lamp with a lamp of the same type (see “ ”): Technical Specifications
1. Pull the extension spring and open the housing.
2. Remove the old lamp and unplug the lamp socket.
3. Insert the lamp in the housing.
4. Fix the socket on the lamp and close the device.
Remark: Do not operate the device when the cover is open.
b) Mounting the Device
• Have the device installed by a qualified person, respecting EN 60598-2-17 and all other applicable norms.
• The construction to which the device is attached should be able to support 10 times the weight of the device for
one hour without deformation.
• The installation must always be secured with a secondary attachment e.g. a safety cable (e.g. VDLSC7 or VDLSC8).
• Never stand directly below the device when it is being mounted, removed or serviced. Have a qualified technician
check the device once a year and once before you bring it into service.
• Install the device in a location with few passers-by that is inaccessible to unauthorised persons.
• Overhead mounting requires extensive experience: calculating work load limits, determining the installation
material to be used. Have the material and the device itself checked regularly. Do not attempt to install the device
yourself if you lack these qualifications as improper installation may result in injuries.
• Adjust the desired inclination angle via the mounting bracket and tighten the bracket screws.
• Make sure there is no flammable material within a 0.5m radius of the device.
• Have a qualified electrician carry out the electric connection.
• Connect the device to the mains with the power plug. Don’t connect it to a dimming pack.
• The installation has to be approved by an expert before the device is taken into service.
In order to connect the fixture to the mains, you have to install a power plug.
Brown = live, blue = neutral, yellow/green = earth.
Connect the fixture to the mains with the power plug. If the device will be directly connected with the local power
supply network, a disconnection switch with a minimum opening of 3mm at every pole has to be included in the
permanent electrical installation.
VDLP56SBS / VDLP56LBS / VDLP56SCS / VDLP56LCS 3 VELLEMAN
5. Cleaning and Maintenance
1. All screws should be tightened and free of corrosion.
2. The housing, visible parts, mounting supports and the installation location (e.g. ceiling, suspension, trussing)
should not be deformed, modified or tampered with e.g. do not drill extra holes in mounting supports, do not
change the location of the connections.
3. Moving mechanic parts must not show any signs of wear and tear.
4. The electric power supply cables must not show any damage. Have a qualified technician maintain the device.
5. Disconnect the device from the mains prior to maintenance activities.
6. Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol or solvents.
7. There are no user-serviceable parts except for the lamp.
8. Contact your dealer for spare parts if necessary.
6. Technical Specifications
Power Supply max. 230VAC / 50-60Hz
Power Consumption max. 500W
Lamp MFL 300W / 240V GX16D (incl.) or GE 300W / 240V GX16D
( , not incl.) or M40 500W / 240V GY9.5 + PAR56 LAMP300P56S
reflector ( + , not incl.) LAMP500P VDL56RF
Dimensions 400 x 210 x 210mm
Total Weight 2kg
Max. Ambient Temperature 45°C
Max. Housing Temperature 190°C
The information in this manual is subject to change without prior notice.
VDLP56SBS / VDLP56LBS / VDLP56SCS / VDLP56LCS – PAR56 PROJECTOR
1. Inleiding
Aan alle ingezetenen van de Europese Unie
Belangrijke milieu-informatie betreffende dit product
Dit symbool op het toestel of de verpakking geeft aan dat, als het na zijn levenscyclus wordt weggeworpen,
dit toestel schade kan toebrengen aan het milieu.
Gooi dit toestel (en eventuele batterijen) niet bij het gewone huishoudelijke afval; het moet bij een
gespecialiseerd bedrijf terechtkomen voor recyclage.
U moet dit toestel naar uw verdeler of naar een lokaal recyclagepunt brengen.
Respecteer de plaatselijke milieuwetgeving.
Hebt u vragen, contacteer dan de plaatselijke autoriteiten inzake verwijdering.
Dank u voor uw aankoop! Lees deze handleiding grondig voor u het toestel in gebruik neemt. Haal het toestel
voorzichtig uit de verpakking. Uw VDLP56SBS / VDLP56LBS / VDLP56SCS / VDLP56LSC wordt geleverd met: 1 x
korte of lange PAR56 spot, 1 x ophanghaak, 1 x veiligheidskabel en 4 x kleurenfilter. Als het toestel werd beschadigd
tijdens het transport, installeer het dan niet en raadpleeg uw dealer.
