food, the unit is hot.
8. Turn the timer switch to desired cooking time.
NOTE: Cooking time may vary to size and amount of food to be cooked.
The result of the food to be cooked may depend on the amount and size,
trial is advisable to get the desired setting and doneness of the food.
9. A beep sound will be heard and the oven toaster will stop cooking once the set
time is nished.
NOTE: Never turn OFF the Timer Switch forcibly, it may damage the
switch. The switch will automatically return to the OFF position even
without turning.
CAUTION The unit gets hot during use, please do not touch. :
HOW TO USE THE ROTISSERIE:
1. Plug the unit into the convenience outlet.
2. Set the Variable Temperature to max.
3. Set the Heat Selector Knob.
4. Pre-heat the unit for at least 5 minutes .
5. Insert the pointed end of the spit through Skewer, making sure the points of Skewer
face in the same direction as pointed end of the Spit. Slide Skewer towards square
of the Spit and secure the thumbscrew.
6. Place food to be cooked on the Spit by running the Spit directly through the center
of the food.
7. Place the second Skewer into the other end of the Spit and secure with the
Thumbscrew.
8. Insert the point end of the Spit into the Drive Socket. Make sure that the Square
Skewer end of the Spit rests on the Spit Support.
9. Switch ON the Rotisserie Switch.
10. Turn the Timer Switch to desired cooking time.
11. Once the cooking cycle ends, remove the spit by placing the Hooks of the Skewer
holder under the grooves on other side of the Spit. Lift the left side of the Spit first
by lifting it up and out, then pull out of the Drive Socket and carefully remove the
roasted food and place it on the platter.
12. Unplug the oven after every use.
HOW TO USE THE CONVECTION:
1. Set the Temperature to your desired temperature.
2. Set the Heat Selector knob (up, down or all).
3. Switch ON the Convection/Rotisserie Switch.
4. Set the Timer to desired cooking time.
CLEANING AND MAINTENANCE
1. Always make sure to unplug the unit from the convenience outlet before cleaning.
2. Allow the unit to cool down.
3. Use damp cloth in cleaning the unit.
4. Wash tray, rack, tray handle, skewer and skewer handle with soap and water, let it
dry.
5. Do not use abrasive materials to avoid scratches.
6. Always clean the inner part of the unit after every use.
7. Do not immerse the unit with water or any other liquid.
Reminder: Please do not forget to ll up and send the warranty card with receipt to our
email address imarflexfb@evergoodinc.com
Distributed : Evergood Unlimited Corp. by
901 G.Masangkay St., Manila
Made in China
SPECIFICATION:
MODEL NO. : -281CRS IT
RATED VOLTAGE : Va.c. 60Hz 230
POWER CONSUMPTION : 1500 watts
BOX DIMENSION : ___________ __
UNIT DIMENSION : _____________
GROSS WEIGHT : _____________
UNIT WEIGHT : _____________
IMPORTANT SAFEGUARDS:
When using electrical appliances, basic safety precautions should always be followed,
including the following:
1. Read all instructions carefully.
2. Before using the oven toaster, check if the voltage indicated corresponds with the
convenience outlet (230Va.c.).
3. Do not use a two-way socket with other appliance.
4. Do not use any appliance with a damaged cord or plug. If the cord is damaged it
should be replaced with the same type and size or bring the unit to the nearest
authorized service center.
5. Put the unit on stable surface; keep it away from the edge of counter to avoid
accident.
6. Keep curtains, furniture, flammable materials, etc. away from the unit and from the
convenience outlet where the unit is plugged in.
7. To protect against electric shock, do not immerse the unit in water or any other
liquid.
8. Do not place the oven toaster near gas stove or electric stove.
9. The unit needs at least 10 cm clearance space on all sides and at least 30 cm
above. This is to allow adequate air circulation.
10. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliances by a person responsible for their safety.
11. Children should be supervised to ensure that they do not play with the appliance.
12. Do not immerse the unit in water.
13. Do not use this unit other than its intended use.
14. Avoid touching the oven surface while cooking is in progress or even after use.
While the oven is in use avoid the glass from getting wet to avoid breakage.
15. Use of accessories or equipment not supplied by the manufacturer may cause
damage or malfunctioning of your appliance or result in injuries.
16. Switch o the appliance before removing or replacing its accessories.
17. Minor metal contraction sound may occur during operation but this is normal.
18. For household use only; not intended for any business purposes.
19. In case of malfunctions, please bring the unit to the nearest Authorized Imarflex
Service Center.
20. This appliance is not intended for outdoor use.
21. Save this instruction for future reference.
22. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal
cutout, this appliance must not be supplied through an external switching device,
such as a timer, or connected to a circuit that is regularly switched on and o by the
utility.
DESCRIPTION OF PARTS:
CONTROL PANEL
1. Upper Heater - It is normally use for cooking top part of
the foods, reheating, pizza, broil, etc.
2. Lower Heater - Use for baking breads.
3. Up & Down Heater - Use for grilling meats, seafood, etc.
4. Rotisserie + Convection + Both Heaters - This
setting is normally use for roasting chicken etc; the fan and
the rotisserie is working together with the upper and lower
heater.
Tips: If you want to use the Convection and upper heater only, do
not place the skewer on the unit.
5. Convection + Both Heaters - this setting is use for
baking cakes.
HOW TO USE:
NOTE: For the rst use, preheat the oven toaster for at least 3 to
5 minutes until burnt smell and light smoke is gone. This is to
prevent this smell and smoke mix to the food to be cooked.
1. Place the unit on flat surface.
2. Check if the timer and heat selector switch is at OFF
position before plugging the oven toaster into the
convenience outlet. Plug the unit.
3. Set the Variable Temperature Control to desired
temperature.
NOTE: The temperature that been set may not be reach exactly
as the room temperature aects the unit when in used.
4. Set the heat selector switch (up, down or all).
5. For baking, use edible oil or butter to keep the food from
sticking into the pan. Switch ON the Convection/Rotisserie
Control Switch.
6. Turn the Timer to preheat the oven for at least 5 minutes
or as required by the cooking recipe.
NOTE: If you need to set the time below 10 minutes, set the timer switch to
maximum rst then set to desired time setting.
The time that been set may not be reach exactly, it may be ±60 seconds of the
set time.
7. Place the food on the grill rack or tray and close the door. Be careful when putting
