Indesit DFP 27B+96 Z Bruksanvisning

Indesit Diskmaskin DFP 27B+96 Z

Läs nedan 📖 manual på svenska för Indesit DFP 27B+96 Z (8 sidor) i kategorin Diskmaskin. Denna guide var användbar för 7 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/8
EN
1
DAILY REFERENCE
GUIDE
Before using the appliance carefully read Health and Safety guide.
APPLIANCE
PRODUCT DESCRIPTION
CONTROL PANEL
0000 000 00000
Service:
1
2
3
4
5
6
10
12
7
11
9
8
1. Upper rack
2. Foldable aps
3. Upper rack height adjuster
4. Upper spray arm
5. Lower rack
6. Cutlery basket
7. Lower spray arm
8. Filter Assembly
9. Salt reservoir
10. Detergent and Rinse Aid dispensers
11. Rating plate
12. Control panel
THANK YOU FOR BUYING A INDESIT PRODUCT.
In order to receive a more complete assistance, please
register your appliance on:
www.indesit.com
You can download the Safety Instructions and the
Use and Care Guide, by visiting our website
docs.indesit.eu and following the Instructions on
the back of this booklet.
1. On-O/Reset button
2. Program selection knob
3. Half load/Extra Light button with indicator light
4. Delay button with indicator light
5. Start/Pause button with indicator light
6. Washing and Delayed Start 3h. indicator light
7. Drying and Delayed Start 6h. indicator light
8. Wash Cycle End and Delayed Start 9h. Indicator light
9. Rinse Aid rell indicator light
10. Salt rell indicator light
1 2
3 4 5
6 7 8 9 10
2
FIRST TIME USE
SALT, RINSE AID AND DETERGENT
ADVICE REGARDING THE FIRST TIME USE
After installation, remove the stoppers from the racks and the reta-
ining elastic elements from the upper rack.
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and
on the machine’s functional components.
• It is important that the salt reservoir be never empty.
• It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher (see Pro-
duct Description) and should be lled when the SALT REFILL indicator
light in the control panel is lit .
1. Remove the lower rack and unscrew the
reservoir cap (anticlockwise).
2. -Only the rst time you do this: ll the salt re
servoir with water.
3. Position the funnel (see gure) and ll the salt
reservoir right up to its edge (approximately
1 kg); it is not unusual for a little water to leak
out.
4. Remove the funnel and wipe any salt residue
away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get
into the container during the wash program (this could damage the
water softener beyond repair).
Whenever you need to add salt, it is mandatory to complete the
procedure before the beginning of the washing cycle.
SETTING THE WATER HARDNESS
To allow the water softener to work in a perfect way, it is essential that
the water hardness setting is based on the actual water hardness in
your house. This information can be obtained from your local water
supplier.
The factory setting is for avarage (3) water hardness.
•SwitchontheappliancebypressingtheON/OFF button.
•SwitchotheappliancebypressingtheON/OFF button.
•HolddownbuttonSTART/PAUSE for 5 seconds, until you hear a beep.
•SwitchontheappliancebypressingtheON/OFF button.
•Thesaltindicatorlightashes(asmanytimesasthecurrentselection).
•SetthePROGRAM SELECTION knob to the desired hardness level
number (see WATER HARDNESS TABLE).
•SwitchotheappliancebypressingtheON/OFFbutton.
Setting is complete!
As soon as this procedure is complete, run a program without loading.
Only use salt that has been specically designed for dishwashers.
After the salt has been poured into the machine, the SALT REFILL indi-
cator light switches o.
If the salt container is not lled, the water softener and the
heating element may be damaged as a result.
Water Hardness Table
Level °dH
German degrees
°fH
French degrees
1 Soft 0 - 6 0 - 10
2 Medium 7 - 11 11 - 20
3 Average 12 - 17 21 - 30
4 Hard 18 - 34 31 - 60
5 Very hard 35 - 50 61 - 90
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid dispenser shouldA
be lled when the in the controlRINSE AID REFILL indicator light
panel is lit.
1. Open the dispenser by pressing and pulling up the tab on the lidB .
2. Pour in the rinse aid (max.110 ml), making sure it does not overow
from the dispenser. If this happens, clean the spill immediately with a
dry cloth.
3. Press the lid down until you hear a click to close it.
NEVER pour the rinse aid directly into the appliance tub.
ADJUSTING THE DOSAGE OF RINSE AID
If you are not completely satised with the drying results, you can ad-
just the quantity of rinse aid used.
•SwitchthedishwasheronusingtheON/OFF button.
•SwitchitousingtheON/OFF button.
•PressbuttonSTART/PAUSE three times - a beep will be heard.
•SwitchitonusingtheON/OFF button.
•Therinse-aidindicatorlightwillash(as many times as the current se-
lection).
•SetthePROGRAM SELECTION knob to the level number of rinse aid
quantity to be supplied.
• Switch it o using the buttonON/OFF
Setting is complete!
If the rinse aid level is set to ZERO (ECO), no rinse aid will be supplied. The
LOW RINSE AID indicator light will not be lit if you run out of rinse aid.
A maximum of 5 levels can be set according to the dishwasher model. The
factory setting is specic to the model, please follow instruction above
to check this for your machine.
• If you see bluish streaks on the dishes, set a low number (1-2).
• If there are drops of water or limescale marks on the dishes, set a
mid-range number (3-4).
FILLING THE DETERGENT DISPENSER
A
B
To open the detergent dispenser
use the opening device A. Introduce
the detergent into the dry dispenser
B only. Place the amount of
detergent for pre-washing directly
inside the tub.
1. When measuring out the detergent re-
fer to the mentioned earlier information
to add the proper quantity. Inside the
dispenser B there are indications to help
the detergent dosing.
2. Remove detergent residues from the edges of the dispenser and
close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until the
closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program.
M
A
X
A
B
35
25
EN
3
PROGRAMS TABLE
PROGRAMS DESCRIPTION
Instructions on wash cycle selection.
ECO
Normally soiled crockery. Standard program, the most ecient in
terms of its combined energy and water consumption.
AUTO INTENSIVE
Automatic program for heavily soiled dishes and pans (not to be used
for delicate items).
AUTO NORMAL
Automatic program for normally soiled pans and dishes.
RAPID 40’
Program to be used for lightly-soiled dishes with no dried food
residues.
SOAK
Use to refresh crockery planned to be washed later. No detergent to be
used with this program.
BABY CARE
Program combined with the Baby Care specially-designed basket en-
sures the best cleaning results and sanitization of baby accessories
(soother, paciers, teats) while washing also normally or heavily soiled
crockery.
EXTRA
Program that allows to wash very big items loaded in the lower rack.
Notes:
Please note that cycles like Fast Rapid or are most eective for lightly
soiled dishes.
To reduce consumption even further, only run the dishwasher
when it is full.
Program
Drying
CoolDry
Available
options *)
Detergent
container Duration
of wash
program
(h:min)**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
Tub B
1. Eco 50° 3:10 9,5 0,93
2. Auto Intensive 65° - -2:00 - 3:10 14,0 - 17,0 1,50 - 1,85
3. Auto Normal 55° - 1:30 - 2:30 14,5 - 16,0 1,15 - 1,30
4. Rapid 40’ 50° - - - 0:40 9,0 0,90
5. Soak - - - -- 0:12 4,5 0,01
6. Baby Care 65° - - 1:40 10,0 1,30
7. Extra 65° - - -1:00 11,0 1,20
ECO program data is measured under laboratory conditions according to European Standard EN 50242. Note for Test Laboratories: For information on
comparative EN testing conditions, please send an email to the following address: assistenza_en_lvs@indesitcompany.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) The duration of the program shown on the display or in the booklet is an estimate calculated on standard conditions. The actual time may vary
depending on many factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load,
load balancing, additional selected options and sensor calibration. The sensor calibration can increase program duration up to 20 min.
Standby consumption: Left-on mode consumption: 6 W - O mode consumption: 0.5 W
