Operating instructions
Contents
Installation, 2-3
Positioning and levelling
Connecting the water and electricity supplies
Advice regarding the first wash cycle
Technical data
Description of the appliance, 4
Overall view
Control panel
Loading the racks, 5
Lower rack
Cutlery basket
Upper rack
Start-up and use, 6-7
Starting the dishwasher
Measuring out the detergent
Wash options
Wash cycles, 8
Table of wash cycles
Rinse aid and refined salt, 9
Measuring out the rinse aid
Measuring out the refined salt
Care and maintenance, 10
Shutting off the water and electricity supplies
Cleaning the dishwasher
Preventing unpleasant odours
Cleaning the sprayer arms
Cleaning the water inlet filter
Cleaning the filters
Leaving the machine unused for extended periods
Precautions and advice, 11
General safety
Disposal
Saving energy and respecting the environment
Troubleshooting, 12
DFP 5841
DISHWASHER
English,1
EN
Nederland, 25
PT
Español, 37
ES
NL
Português, 49 Polski, 61
PL
CS
Èesky, 73
Deutsch, 13
DE
tion. At this position the lever should be re-
leased and the seat rocked to and fro to
ensure that the mechanism has locked.
WARNING:
To ensure the seat is locked securely,
attempt to move the seat forward or rear-
ward without using the lock release lever.
B080B02FC-EAT
FRONT SEATS
Front Seat Rake Adjustment
HFC2024-D B080A01FC-EAT
SEAT ADJUSTMENT
WARNING:
Front seat adjustments must not be under-
taken whilst the vehicle is in motion. Loss
of control of the vehicle may result if seat
adjustments are made whilst the vehicle is
in motion.
WARNING:
1) Be careful that someone's head, hands
and body are not trapped by a closing
window.
2)Never try to operate the main switch on
the driver's door and the individual door
window switch in opposing directions
at the same time. If this is done, the
window will stop and cannot be opened
or closed.
3) Do not leave children alone in the car.
Always remove the ignition key for their
safety.
In order to prevent operation of the passenger
front and rear windows, a window lock switch
is provided on the armrest of the driver's door.
To disable the power windows, press the
window lock switch.
To return to normal operation, press the
window lock switch a second time.
Auto-Down Window (Driver's Side)
The Auto-Down window is moved to its fully
open position by pushing the switch. To stop
at the desired loction, the switch must be
pulled up. HFC2013-D
EN
2
Installation
Keep this instruction manual in a safe place for
future reference. If the appliance is sold, given away or
moved, please ensure the manual is kept with the
machine, so that the new owner may benefit from the
advice contained within it.
Please read this instruction manual carefully: it
contains important information regarding the safe
installation, use and maintenance of the appliance.
If the appliance must be moved at any time, keep it in
an upright position; if absolutely necessary, it may be
tilted onto its back.
This appliance is intended to be used in household and
similar applications such as:
- staff kitchen areas in shops, offices and other working
environments;
- farm houses;
- by clients in hotels, motels and other residential type
environments;
- bed and breakfast type environments.
Positioning and levelling
1. Remove the appliance from all packaging and check
that it has not been damaged during transportation.
If it has been damaged, contact the retailer and do not
proceed any further with the installation process.
2. Check the dishwasher by placing it so that its sides or
back panel are in contact with the adjacent cabinets or
even with the wall. This appliance can also be recessed
under a single worktop* (see the Assembly instruction
sheet).
3. Position the dishwasher on a level and sturdy floor. If
the floor is uneven, the front feet of the appliance may be
adjusted until it reaches a horizontal position. If the
appliance is levelled correctly, it will be more stable and
much less likely to move or cause vibrations and noise
while it is operating.
4. Adjust the height of the rear foot from the front of the
appliance* on the central lower part of the dishwasher, turning
a hexagonal spanner (red color) with an opening of 8 mm in a
clockwise direction to increase the height or in an
anticlockwise direction to decrease the height.
Connecting the water and electricity
supplies
Connection to the water and electricity supplies
should only be performed by a qualified technician.
The dishwasher should not stand on top of the water
hoses or the electricity supply cable.
The appliance must be connected to the water
supply network using new hoses.
Do not use old hoses.
The water inlet and outlet hoses and the electricity
supply cable may be positioned towards the right or the
left in order to achieve the best possible installation.
Connecting the water inlet hose
To a suitable cold water connection point: before
attaching the hose, run the water until it is perfectly
clear so that any impurities that may be present in the
water do not clog the appliance; after performing this
operation, screw the inlet hose tightly onto a tap with
a ¾ gas threaded connection.
To a suitable hot water connection point: your
dishwasher may be supplied with hot water from the
mains supply (if you have a central heating system
with radiators) provided that it does not exceed a
temperature of 60°C.
Screw the hose to the tap as described for connection
to a cold water supply.
If the inlet hose is not long enough, contact a
specialist store or an authorised technician (see
Assistance).
The water pressure must be within the values
indicated in the Technical data table (see adjacent
information).
The hose should not be bent or compressed.
Connecting the water outlet hose
Connect the outlet hose (without bending it) to a drain
duct with a minimum diameter of 4 cm.
The outlet hose must be at a height ranging from 40 to
80 cm from the floor / surface where the dishwasher
rests (A).
Before connecting the water outlet hose to the sink
drain, remove the plastic plug (B).
* Only available in selected models.
1- 9
CONTROLS
SB070E1-E
Lumbar Support Adjustment
(Not all models) (Driver's seat only)
Some models are fitted with adjustable driver
seat lumbar support which may be used to
increase the amount of lumbar support of-
fered by the seat back. Adjustment is per-
formed by moving the handle at the side of the
backrest in a forward direction to increase the
support. SB070D3-E
Head Restraint Adjustment
To raise the head restraint, pull it up. To lower
it, push it down whilst pressing the lock knob.
For maximum effectiveness in the event of an
accident, the restraint must be adjusted so
that the restraint is approximately at the level
of the seat occupant's eyes. The restraint
must never be so adjusted that it is centred
about the level of the seat occupant's neck.
WARNING:
o For maximum effectiveness in case of
an accident the head restraint should
be adjusted so the middle of the head
restraint is at the same height as the
top of the occupant's eyes. For this
reason, the use of a cushion that holds
the body away from the seatback
should not be recommended.
SB070C1-E
Front Seat Recline Adjustment
The front seat back recline angle may be
adjusted by leaning forward slightly and rais-
ing the recline adjustment lever at the side of
the seat. When the seatback is at the desired
angle, the lever should be released. Ensure
that the seatback is locked before driving the
vehicle. HFC2027-D
HFC2025-D
HFC2028-D
Lock knob
o Do not operate vehicle with the head
restraints removed as injury to the oc-
cupants may occur in the event of an
accident. Head restraints may provide
protection against neck injuries when
properly adjusted.
o Do not adjust the head restraint height
whilst the vehicle is in motion.
EN
3
Anti-flooding protection
To ensure floods do not occur, the dishwasher:
- is provided with a special system which blocks the
water supply in the event of anomalies or leaks from
inside the appliance.
Some models are also equipped with the supplementary
safety device New Acqua Stop*, which guarantees anti-
flooding protection even in the event of a supply hose
rupture.
WARNING: HAZARDOUS VOLTAGE!
Under no circumstance should the water inlet hose be
cut as it contains live electrical parts.
Electrical connection
Before inserting the plug into the electrical socket, make
sure that:
The socket is earthed and complies with current
regulations.
The socket can withstand the maximum load of the
appliance, which is indicated on the data plate
located on the inside of the door (see chapter entitled
Description of the appliance).
The power supply voltage falls within the values
indicated on the data plate on the inside of the door.
The socket is compatible with the plug of the
appliance. If this is not the case, ask an authorised
technician to replace the plug (see Assistance); do
not use extension cables or multiple sockets.
Once the appliance has been installed, the power
supply cable and the electrical socket should be easily
accessible.
The cable should not be bent or compressed.
If the power supply cable is damaged, it must be re-
placed by the manufacturer or its Technical Assistance
Service in order to prevent all potential hazards. (See As-
sistance)
The Company shall not be held responsible for any
incidents that occur if these regulations are not
observed.
Anti-condensation strip*
After installing the dishwasher, open the door and stick
the adhesive transparent strip under the wooden shelf in
order to protect it from any condensation which may
form.
Advice regarding the first wash cycle
After the appliance has been installed, immediately
before running the first wash cycle, completely fill the
salt dispenser with water and add only then
approximately 1 kg of salt (see chapter entitled Rinse aid
and refined salt). The water may overflow: this is normal
and is not a cause for concern. Select the water
hardness value (see chapter entitled Rinse aid and
refined salt). - After the salt has been poured into the
machine, the LOW SALT indicator light* switches off.
If the salt container is not filled, the water softener
and the heating element may be damaged as a result.
* Only available in selected models.
Technical data
Dimensions
width 60 cm
height 85 cm
depth 60 cm
Capacity 14 standard place-settings
Water supply
pressure
0,05 ÷ 1MPa (0.5 ÷ 10 bar)
7,25 – 145 psi
Power supply
voltage See appliance data plate
Total absorbed
power See appliance data plate
Fuse See appliance data plate
This dishwasher conforms to the
following European Community
Directives:
-2006/95/EC (Low Voltage)
-2004/108/EC (Electromagnetic
Compatibility)
-2005/32/EC (Comm. Reg.
1275/2008) (Ecodesign)
-97/17/EC (Labelling)
-2002/96/EC Waste Electrical
and Electronic Equipment
(WEEE)
CONTROLS AND EQUIPMENT
1- 10
HFC2060
The front seat rake adjustment is performed
by raising the lever at the front of the seat
base and sliding the seat to the desired posi-
tion. At this position the lever should be re-
leased and the seat rocked to and fro to
ensure that the mechanism has locked.
B080H01FC-GAT
REAR SEAT
Seat Rake Adjustment B080G01FC-EAT
UNDER TRAY (Not all models)
The tray is located under the front passenger
seat. It is opened by up and pulling forward.
WARNING:
To avoid the possibility of injury in case
of an accident or a sudden stop, the tray
should be kept closed when the car is in
motion.
HFC2059-D
SB070F1-F
Seat Cushion Height Adjustment
(Not all models) (Driver's seat only)
To raise or lower the front part of the seat
cushion, turn the front knob forward or rear-
ward.
To raise or lower the rear part of the seat
cushion, turn the rear knob forward or rear-
ward. HFC2026-D
Produktspecifikationer
| Varumärke: | Indesit |
| Kategori: | Diskmaskin |
| Modell: | DFP 5841 NX |
Behöver du hjälp?
Om du behöver hjälp med Indesit DFP 5841 NX ställ en fråga nedan och andra användare kommer att svara dig
Diskmaskin Indesit Manualer
19 Oktober 2024
19 Oktober 2024
11 Oktober 2024
25 September 2024
24 September 2024
24 September 2024
23 September 2024
23 September 2024
22 September 2024
18 September 2024
Diskmaskin Manualer
- Diskmaskin Candy
- Diskmaskin Electrolux
- Diskmaskin Samsung
- Diskmaskin ATAG
- Diskmaskin LG
- Diskmaskin Bosch
- Diskmaskin AEG
- Diskmaskin IKEA
- Diskmaskin AEG Electrolux
- Diskmaskin Bauknecht
- Diskmaskin BEKO
- Diskmaskin Delonghi
- Diskmaskin Daewoo
- Diskmaskin Etna
- Diskmaskin Grundig
- Diskmaskin Inventum
- Diskmaskin Kenwood
- Diskmaskin Miele
- Diskmaskin Medion
- Diskmaskin Siemens
- Diskmaskin Whirlpool
- Diskmaskin Zanussi
- Diskmaskin Zanker
- Diskmaskin Amica
- Diskmaskin Amana
- Diskmaskin Ardo
- Diskmaskin Ariston
- Diskmaskin Arcelik
- Diskmaskin Asko
- Diskmaskin Bartscher
- Diskmaskin GE
- Diskmaskin Sharp
- Diskmaskin Fisher And Paykel
- Diskmaskin Bertazzoni
- Diskmaskin Klarstein
- Diskmaskin Fagor
- Diskmaskin Brandt
- Diskmaskin Omega
- Diskmaskin Smeg
- Diskmaskin Telefunken
- Diskmaskin Gorenje
- Diskmaskin Neff
- Diskmaskin Baumatic
- Diskmaskin Thomson
- Diskmaskin Hoover
- Diskmaskin Black And Decker
- Diskmaskin KitchenAid
- Diskmaskin Teka
- Diskmaskin Nordland
- Diskmaskin Saba
- Diskmaskin Progress
- Diskmaskin Cata
- Diskmaskin Gaggenau
- Diskmaskin Hotpoint-Ariston
- Diskmaskin Zanussi-electrolux
- Diskmaskin Ignis
- Diskmaskin Maytag
- Diskmaskin Thermador
- Diskmaskin Hisense
- Diskmaskin Hyundai
- Diskmaskin Hanseatic
- Diskmaskin Vox
- Diskmaskin Cylinda
- Diskmaskin Bellini
- Diskmaskin Avanti
- Diskmaskin Westinghouse
- Diskmaskin Vestel
- Diskmaskin ECG
- Diskmaskin Pelgrim
- Diskmaskin Blomberg
- Diskmaskin Bush
- Diskmaskin Magic Chef
- Diskmaskin Swan
- Diskmaskin Russell Hobbs
- Diskmaskin Constructa
- Diskmaskin John Lewis
- Diskmaskin Summit
- Diskmaskin Hotpoint
- Diskmaskin Midea
- Diskmaskin De Dietrich
- Diskmaskin Junker
- Diskmaskin Blaupunkt
- Diskmaskin Concept
- Diskmaskin Gram
- Diskmaskin Monogram
- Diskmaskin Frigidaire
- Diskmaskin Iberna
- Diskmaskin Svan
- Diskmaskin Logik
- Diskmaskin Danby
- Diskmaskin Balay
- Diskmaskin Stirling
- Diskmaskin PKM
- Diskmaskin Frilec
- Diskmaskin Rosieres
- Diskmaskin Scholtes
- Diskmaskin Profilo
- Diskmaskin KKT Kolbe
- Diskmaskin CDA
- Diskmaskin Imperial
- Diskmaskin Castor
- Diskmaskin Schneider
- Diskmaskin Bella
- Diskmaskin Kenmore
- Diskmaskin Philco
- Diskmaskin Juno
- Diskmaskin Nabo
- Diskmaskin Guzzanti
- Diskmaskin Defy
- Diskmaskin Infiniton
- Diskmaskin Aspes
- Diskmaskin White Knight
- Diskmaskin Sunny
- Diskmaskin Blanco
- Diskmaskin Orima
- Diskmaskin Luxor
- Diskmaskin Nordmende
- Diskmaskin Koenic
- Diskmaskin Mach
- Diskmaskin Haier
- Diskmaskin Friac
- Diskmaskin Boretti
- Diskmaskin Ariston Thermo
- Diskmaskin Viking
- Diskmaskin Hansa
- Diskmaskin Rhima
- Diskmaskin Thor
- Diskmaskin Benavent
- Diskmaskin Exquisit
- Diskmaskin Elba
- Diskmaskin Proline
- Diskmaskin Euromaid
- Diskmaskin Corberó
- Diskmaskin Crosley
- Diskmaskin WLA
- Diskmaskin New Pol
- Diskmaskin Ansonic
- Diskmaskin Kelvinator
- Diskmaskin ETA
- Diskmaskin Element
- Diskmaskin Qilive
- Diskmaskin Bomann
- Diskmaskin Zerowatt
- Diskmaskin Kuppersbusch
- Diskmaskin Continental Edison
- Diskmaskin Jenn-Air
- Diskmaskin Freggia
- Diskmaskin Insignia
- Diskmaskin Edesa
- Diskmaskin Milectric
- Diskmaskin Leonard
- Diskmaskin Kaiser
- Diskmaskin Franke
- Diskmaskin New World
- Diskmaskin AYA
- Diskmaskin Nodor
- Diskmaskin Sammic
- Diskmaskin Jocel
- Diskmaskin Respekta
- Diskmaskin Rex
- Diskmaskin Comfee
- Diskmaskin Meireles
- Diskmaskin Dacor
- Diskmaskin Technika
- Diskmaskin Scandomestic
- Diskmaskin V-Zug
- Diskmaskin Godrej
- Diskmaskin Sauber
- Diskmaskin MPM
- Diskmaskin Zenith
- Diskmaskin Esatto
- Diskmaskin Belling
- Diskmaskin Hobart
- Diskmaskin Essentiel B
- Diskmaskin Team
- Diskmaskin Privileg
- Diskmaskin Vivax
- Diskmaskin Edy
- Diskmaskin Ilve
- Diskmaskin Altus
- Diskmaskin Edgestar
- Diskmaskin CaterChef
- Diskmaskin Parmco
- Diskmaskin Eurotech
- Diskmaskin Equator
- Diskmaskin Vestfrost
- Diskmaskin Kunft
- Diskmaskin EKU
- Diskmaskin Upo
- Diskmaskin Elettrobar
- Diskmaskin Trieste
- Diskmaskin Lynx
- Diskmaskin Barazza
- Diskmaskin Teco
- Diskmaskin Cecotec
- Diskmaskin Otsein
- Diskmaskin Winterhalter
- Diskmaskin Tisira
- Diskmaskin Marynen
- Diskmaskin Therma
- Diskmaskin La Germania
- Diskmaskin Oranier
- Diskmaskin Foster
- Diskmaskin Eudora
- Diskmaskin Hoonved
- Diskmaskin Kucht
- Diskmaskin Kogan
- Diskmaskin Signature
- Diskmaskin Romo
- Diskmaskin JennAir
- Diskmaskin General Electric
- Diskmaskin Elin
- Diskmaskin Fulgor Milano
- Diskmaskin High One
- Diskmaskin Meiko
- Diskmaskin Vedette
- Diskmaskin Winia
- Diskmaskin Artusi
- Diskmaskin Elektron
- Diskmaskin Casselin
- Diskmaskin Hiberg
- Diskmaskin Cosmo
- Diskmaskin ARC
- Diskmaskin Emilia
- Diskmaskin Miele Professional
- Diskmaskin Home Electronics
- Diskmaskin IFB
- Diskmaskin Newpol
- Diskmaskin Royal Catering
- Diskmaskin SEIKI
- Diskmaskin Cookology
- Diskmaskin Eurolux
- Diskmaskin Euro Appliances
- Diskmaskin Dishlex
- Diskmaskin Arthur Martin-Electrolux
- Diskmaskin Elektra Bregenz
- Diskmaskin InAlto
- Diskmaskin Tuscany
- Diskmaskin Porter & Charles
- Diskmaskin Classique
- Diskmaskin Kluge
- Diskmaskin Imarflex
- Diskmaskin Koldfront
- Diskmaskin Master Kitchen
- Diskmaskin Pitsos
Nyaste Diskmaskin Manualer
27 Oktober 2024
27 Oktober 2024
27 Oktober 2024
26 Oktober 2024
26 Oktober 2024
26 Oktober 2024
26 Oktober 2024
26 Oktober 2024
26 Oktober 2024
24 Oktober 2024
