Sida 1/16

DISR 14B1

GB English

Operating instructions

DISHWASHER - Contents

Operating instructions,1

Precautions and advice, 2-3

Product Data, 3

Installation, 4-5

Electrical connection, 6

Description of the appliance, 7

Refined salt and rinse aid, 8

Loading the racks, 9-10

Detergent and dishwasher use, 11

Wash cycles, 12

Care and maintenance, 13

Troubleshooting, 14

Product Guarantee and Repair Information,15

GB Precautions and advice

This appliance was designed and

manufactured in compliance with international

safety standards. The following information

has been provided for safety reasons and

should be read carefully.

Keep this instruction manual in a safe place

for future reference. If the appliance is sold,

given away or moved, make sure the manual

is kept with the machine.

Read the instructions carefully, as they

include important information on safe

installation, use and maintenance.

This appliance was designed for domestic

use or similar applications, for example:

- use by guests in hotels, motels and other

residential settings;

- bed & breakfasts.

Remove the appliance from all packaging

and make sure it was not damaged during

transportation. If it was damaged, contact

the retailer and do not proceed any further

with the installation process.

General safety

• This appliance should not be operated

by children younger than 8 years, people

with reduced physical, sensory or mental

capacities, or inexperienced people

who are not familiar with the product,

unless they are given close supervision

or instructions on how to use it safely and

are made aware by a responsible person

of the dangers its use might entail.

• Children must not play with the appliance.

• It is the user's responsibility to clean and

maintain the appliance. Children should

never clean or maintain it unless they are

given supervision.

• The appliance was designed for domestic

use inside the home and is not intended

for commercial or industrial use.

• The appliance must be used to wash

domestic crockery in accordance with the

instructions in this manual.

• The appliance must not be installed

outdoors, even in covered areas. It is

extremely dangerous to leave the machine

exposed to rain and storms.

• Do not touch the appliance when barefoot.

• When unplugging the appliance always

pull the plug from the mains socket. Do

not pull on the cable.

• The water supply tap must be shut off

and the plug should be removed from

the electrical socket at the end of every

cycle and before cleaning the appliance

or carrying out any maintenance work.

• The maximum number of place settings is

shown in the product sheet.

• If the appliance breaks down, do not under

any circumstances touch the internal parts

in an attempt to perform the repair work

yourself.

• Do not lean or sit on the open door: this

may cause the appliance to overturn.

• The door should not be left open as it may

create a dangerous obstacle.

• Keep detergent and rinse aid out of reach

of children.

• The packaging material should not be

used as a toy.

• Knives and other utensils with sharp

edges must be placed either with the

points/blades facing downwards in the

cutlery basket or horizontally on the tip-up

compartments or in the tray/third basket,

if available.

• Connect the appliance to the water mains

using the new supply hose provided with

the appliance. Do not re-use the old hose.

• Install the back side of a free-standing

dishwasher against a wall.

Disposal

• To dispose of any packaging materials,

follow local legislation so that the

packagings may be reused.

• The European Directive 2012/19/EU

relating to Waste Electrical and Electronic

Equipment (WEEE) states that household

appliances should not be disposed of

using the normal solid urban waste cycle.

Exhausted appliances should be collected

separately in order to optimise the cost of

reusing and recycling the materials inside

the machine, while preventing potential

damage to the atmosphere and public

health. The crossed-out dustbin symbol

shown on all products reminds the owners

of their obligations regarding separated

waste collection.

For further information relating to the

correct disposal of household appliances,

owners may contact the relevant public

authority or the local appliance dealer.

Precautions and advice

Saving energy and respecting the

environment

Saving water and energy

• Only begin a wash cycle when the

dishwasher is full. While waiting for the

dishwasher to be filled, prevent unpleasant

odours with the Soak cycle

(if available, see

Wash Cycles).

• Select a wash cycle that is suited to the

type of crockery and to the soil level using

the Table of Wash Cycles:

- For dishes with a normal soil level, use

the Eco wash cycle, which guarantees low

energy and water consumption levels.

- If the load is smaller than usual activate

the Half Load option

(see Special wash cycles

and options, if available).

• If your electricity supply contract gives

details of electricity-saving time bands, run

the wash cycles when electricity prices are

lower. The Delayed Start option can help

you organise the wash cycles accordingly

(see Special wash cycles and options, if available).

Product Fiche

Brand INDESIT

Model DISR 14B1

Rated capacity in standard place settings (1) 10

Energy efciency class on a scale from A+++ (low consumption) to D (high consumption) A+

Energy consumption per year in kWh (2) 237

Energy consumption of the standard cleaning cycle in kWh 0.83

Power consumption of the off-mode in W 0.5

Power consumption of the left-on mode in W 5.0

Water consumption per year in litres (3) 2800

Drying efcacy class on a scale from G (low efcacy) to A (high efcacy) A

Programme time for standard cleaning cycle in minutes 130

The duration of the left-on mode in minutes 12

Noise in dB(A) Re 1pW 51

Built-in model Yes

NOTES

1) The information on the label and che relates to the standard cleaning cycle, this programme is suitable to clean normally soiled

tableware and it is the most efcient programme in terms of combined energy and water consumption. The standard cleaning cycle

corresponds to the Eco cycle.

2) Based on 280 standard cleaning cycles using cold water ll and the consumption of the low power modes. Actual energy

consumption depends on how the appliance is used.

3) Based on 280 standard cleaning cycles. Actual water consumption depends on how the appliance is used.

Product Data (product fiche)
