Operating instructions

Contents

Installation, 2-3-4

Positioning and levelling

Connecting the water and electricity supplies

Advice regarding the first wash cycle

Technical data

Ecodesign Regulation

Electrical Connection

Description of the appliance, 5

Overall view

Control panel

Loading the racks, 6

Lower rack

Cutlery basket

Upper rack

Start-up and use, 7-8

Starting the dishwasher

Measuring out the detergent

Wash options

Wash cycles, 9

Table of wash cycles

Rinse aid and refined salt, 10

Measuring out the rinse aid

Measuring out the refined salt

Care and maintenance, 11

Shutting off the water and electricity supplies

Cleaning the dishwasher

Preventing unpleasant odours

Cleaning the sprayer arms

Cleaning the water inlet filter

Cleaning the filters

Leaving the machine unused for extended periods

Precautions and advice, 12

General safety

Disposal

Saving energy and respecting the environment

Troubleshooting, 13

Guarantee, 14

After Sales Service, 15

IDP 127B D

DISHWASHER

English, 1

Installation

Keep this instruction manual in a safe place for future

reference. If the appliance is sold, given away or moved,

please ensure the manual is kept with the machine, so that

the new owner may benefit from the advice contained within

it.

Please read this instruction manual carefully: it

contains important information regarding the safe

installation, use and maintenance of the appliance.

If the appliance must be moved at any time, keep it in

an upright position; if absolutely necessary, it may be tilted

onto its back.

This appliance is intended to be used in household and

similar applications such as:

- staff kitchen areas in shops, offices and other working

environments;

- farm houses;

- by clients in hotels, motels and other residential type

environments;

- bed and breakfast type environments.

Positioning and levelling

1. Remove the appliance from all packaging and check

that it has not been damaged during transportation.

If it has been damaged, contact the retailer and do not

proceed any further with the installation process.

2. Check the dishwasher by placing it so that its sides or

back panel are in contact with the adjacent cabinets or

even with the wall. This appliance can also be recessed

under a single worktop* (

see the Assembly instruction

sheet

3. Position the dishwasher on a level and sturdy floor. If the

floor is uneven, the front feet of the appliance may be

adjusted until it reaches a horizontal position. If the

appliance is levelled correctly, it will be more stable and

much less likely to move or cause vibrations and noise

while it is operating.

4. Adjust the height of the rear foot from the front of the appliance*

on the central lower part of the dishwasher, turning a hexagonal

spanner (red color) with an opening of 8 mm in a clockwise

direction to increase the height or in an anticlockwise direction to

decrease the height.

Connecting the water and electricity

supplies

Connection to the water and electricity supplies should

only be performed by a qualified technician.

The dishwasher should not stand on top of the water

hoses or the electricity supply cable.

The appliance must be connected to the water supply

network using new hoses.

Do not use old hoses.

The water inlet and outlet hoses and the electricity supply

cable may be positioned towards the right or the left in

order to achieve the best possible installation.

Connecting the water inlet hose

• To a suitable cold water connection point: before

attaching the hose, run the water until it is perfectly clear

so that any impurities that may be present in the water

do not clog the appliance; after performing this

operation, screw the inlet hose tightly onto a tap with a

¾ gas threaded connection.

• To a suitable hot water connection point: your

dishwasher may be supplied with hot water from the

mains supply (if you have a central heating system with

radiators) provided that it does not exceed a temperature

of 60°C.

Screw the hose to the tap as described for connection

to a cold water supply.

If the inlet hose is not long enough, contact a specialist

store or an authorised technician (

see Assistance

The water pressure must be within the values indicated

in the Technical data table (

see adjacent information

The hose should not be bent or compressed.

Connecting the water outlet hose

Connect the outlet hose (without bending it) to a drain

duct with a minimum diameter of 4 cm.

The outlet hose must be at a height ranging from 40 to 80

cm from the floor / surface where the dishwasher rests (A).

Before connecting the water outlet hose to the sink drain,

remove the plastic plug (B).

Anti-flooding protection

To ensure floods do not occur, the dishwasher:

- is provided with a special system which blocks the water

supply in the event of anomalies or leaks from inside the

appliance.

Some models are also equipped with the supplementary

safety device

New Acqua Stop

*, which guarantees anti-

flooding protection even in the event of a supply hose

rupture.

WARNING: HAZARDOUS VOLTAGE!

Under no circumstance should the water inlet hose be cut

as it contains live electrical parts.

* Only available in selected models.

Electrical connection

Before inserting the plug into the electrical socket, make

sure that:

• The socket is earthed and complies with current

regulations.

• The socket can withstand the maximum load of the

appliance, which is indicated on the data plate located

on the inside of the door (

see chapter entitled

Description of the appliance

• The power supply voltage falls within the values

indicated on the data plate on the inside of the door.

• The socket is compatible with the plug of the appliance.

If this is not the case, ask an authorised technician to

replace the plug (

see Assistance

); do not use extension

cables or multiple sockets.

Once the appliance has been installed, the power

supply cable and the electrical socket should be easily

accessible.

The cable should not be bent or compressed.

If the power supply cable is damaged, it must be re-

placed by the manufacturer or its Technical Assistance

Service in order to prevent all potential hazards. (See As-

sistance)

The Company shall not be held responsible for any

incidents that occur if these regulations are not observed.

Technical data

Dimensions

width 60 cm

height 85 cm

depth 60 cm

Capacity 12 standard place-settings

Water supply

pressure

0,05 ÷ 1MPa (0.5 ÷ 10 bar)

7,25 – 145 psi

Power supply voltage See appliance data plate

Total absorbed power See appliance data plate

Fuse See appliance data plate

This dishwasher conforms to the

following European Community

Directives:

-2006/95/EC (Low Voltage)

-2004/108/EC (Electromagnetic

Compatibility)

-2005/32/EC (Comm. Reg.

1275/2008) (Ecodesign)

-97/17/EC (Labelling)

-2002/96/EC (Waste Electrical

and Electronic Equipment)

(WEEE)

Anti-condensation strip*

After installing the dishwasher, open the door and stick the

adhesive transparent strip under the wooden shelf in order

to protect it from any condensation which may form.

Advice regarding the first wash cycle

After the appliance has been installed, immediately before

running the first wash cycle, completely fill the salt

dispenser with water and add only then approximately 1 kg

of salt (

see chapter entitled Rinse aid and refined salt

). The

water may overflow: this is normal and is not a cause for

concern. Select the water hardness value (

see chapter

entitled Rinse aid and refined salt

). - After the salt has been

poured into the machine, the LOW SALT indicator light*

switches off.

If the salt container is not filled, the water softener and

the heating element may be damaged as a result.

ECODESIGN REGULATION

ECO wash cycle is the standard cycle to which the energy label data refers; this cycle can be used to wash crockery with a normal

soil level and is the most efficient in terms of energy and water consumption for this type of crockery. To reduce consumption even

further, only run the dishwasher when it is full.

Standby consumption: Left-on mode consumption: 3 W – Off mode consumption: 1,3 W

Consumption data table for the main cycles

* Cycle data refers to the values recorded in a laboratory, in accordance with European standard EN 50242.

** Data is obtained by recording values when the appliance is operational and loaded with user crockery.

Standard conditions* User conditions**

Energy consumption

(kWh/cycle) Water consumption

(l/cycle) Duration

(min/cycle) Energy consumption

(kWh/cycle) Water consumption

(l/cycle) Duration

(min/cycle)

INTENSIVE 1,60 16 150 1,40 15 135

NORMAL 1,30 16 120 1,10 15 110
