Contents

Installation, 2-3

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Care and maintenance, 4

Cutting off the water or electricity supply

Cleaning the washing machine

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Precautions and tips, 5

General safety

Disposal

Description of the washing machine

and starting a wash cycle, 6-7

Control panel

Indicator lights

Starting a wash cycle

Wash cycles, 8

Table of wash cycles

Personalisation, 9

Setting the temperature

Setting the spin speed

Functions

Detergents and laundry, 10

Detergent dispenser drawer

Preparing the laundry

Garments requiring special care

Load balancing system

Troubleshooting, 11

Service, 12

IWC 71281

Instructions for use

WASHING MACHINE

English,1

GB IT

Italiano,13

Italiano,25

! This instruction manual should be kept in a safe

place for future reference. If the washing machine

is sold, transferred or moved, make sure that the

instruction manual remains with the machine so

that the new owner is able to familiarise himself/

herself with its operation and features.

! Read these instructions carefully: they contain

vital information relating to the safe installation

and operation of the appliance.

Unpacking and levelling

Unpacking

1. Remove the washing machine from its packaging.

2. Make sure that the washing machine has not

been damaged during the transportation process.

If it has been damaged, contact the retailer and do

not proceed any further with the installation process.

3. Remove the 4 pro-

tective screws (used

during transportation)

and the rubber wa-

sher with the cor-

responding spacer,

located on the rear

part of the appliance

( ).see figure

4. Close off the holes using the plastic plugs

provided.

5. Keep all the parts in a safe place: you will need

them again if the washing machine needs to be

moved to another location.

! Packaging materials should not be used as

toys for children.

Levelling

1. Install the washing

machine on a flat stur-

dy floor, without resting

it up against walls,

furniture cabinets or

anything else.

2. If the floor is not

perfectly level, com-

pensate for any une-

venness by tightening

or loosening the adjustable front feet (see figure);

the angle of inclination, measured in relation to

the worktop, must not exceed 2°.

Levelling the machine correctly will provide it with

stability, help to avoid vibrations and excessive

noise and prevent it from shifting while it is ope-

rating. If it is placed on carpet or a rug, adjust the

feet in such a way as to allow a sufficient venti-

lation space underneath the washing machine.

Connecting the electricity and wa-

ter supplies

Connecting the water inlet hose

1. Connect the supply

pipe by screwing it to

a cold water tab using

a ¾ gas threaded con-

nection (see figure).

Before performing the

connection, allow the

water to run freely until

it is perfectly clear.

2. Connect the inlet

hose to the washing

machine by screwing

it onto the correspon-

ding water inlet of the

appliance, which is si-

tuated on the top right-

hand side of the rear

part of the appliance

(see figure).

3. Make sure that the hose is not folded over

or bent.

! The water pressure at the tap must fall within

the values indicated in the Technical details table

(see next page).

! If the inlet hose is not long enough, contact a

specialised shop or an authorised technician.

! Never use second-hand hoses.

! Use the ones supplied with the machine.

Installation

Connecting the drain hose

Connect the drain

hose, without bending

it, to a drainage duct

or a wall drain located

at a height between

65 and 100 cm from

the floor;

Alternatively, place

the drain hose over

the edge of a wa-

shbasin or bathtub,

by fastening the

guide (which

can be purchased at

the technical assi-

stance centre) to the

tap (see figure).The

free end of the hose

should not be underwater.

! We advise against the use of hose exten-

sions; if it is absolutely necessary, the exten-

sion must have the same diameter as the

original hose and must not exceed 150 cm in

length.

! We advise against the use of hose extensions;

if it is absolutely necessary, the extension must

have the same diameter as the original hose and

must not exceed 150 cm in length.

Electrical connections

Before plugging the appliance into the electricity

socket, make sure that:

•the socket is earthed and complies with all

applicable laws;

•thesocketisabletowithstandthemaximum

power load of the appliance as indicated in the

Technical data table (see opposite);

•thepowersupplyvoltagefallswithinthevalues

indicated in the Technical data table (see opposite);

•thesocketiscompatiblewiththeplugofthe

washing machine. If this is not the case, repla-

ce the socket or the plug.

! The washing machine must not be installed

outdoors, even in covered areas. It is extremely

dangerous to leave the appliance exposed to

rain, storms and other weather conditions.

! When the washing machine has been installed,

the electricity socket must be within easy reach.

! Do not use extension cords or multiple sockets.

! The cable should not be bent or compressed.

! The power supply cable must only be replaced

by authorised technicians.

Warning! The company shall not be held responsible

in the event that these regulations are not respected.

The first wash cycle

Once the appliance has been installed, and

before you use it for the first time, run a wash

cycle with detergent and no laundry, using the

wash cycle .2

65 - 100 cm

Technical data

Model IWC 71281

Dimensions

width 59,5 cm

height 85 cm

depth 53,5 cm

Capacity from 1 to 7 kg

Electrical

connections

please refer to the technical

data plate fixed to the machine

Water

connection

maximum pressure

1 MPa (10 bar)

minimum pressure

0.05 MPa (0.5 bar)

drum capacity 52 litres

Spin speed up to 1200 rotations per

minute

Test wash

cycles in ac-

cordance with

regulations

1061/2010

and

1015/2010

Programme 6: Eco Cotton 60°.

Programme 6: Eco Cotton 40°.

This appliance conforms to

the following EC Directives:

- EMC 2014/30/EU (Electro-

magnetic Compatibility)

- LVD 2014/35/EU (Low

Voltage)

- 2012/19/EU (WEEE)
