Sida 1/16

Contents

Installation, 2-3-4-5

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Description of the washing machine

and starting a wash cycle, 6-7

Control panel

Indicator lights

Starting a wash cycle

Wash cycles, 8

Table of wash cycles

Personalisation, 9

Setting the temperature

Setting the spin speed

Functions

Detergents and laundry, 10

Detergent dispenser drawer

Preparing the laundry

Garments requiring special care

Load balancing system

Precautions and tips, 11

General safety

Disposal

Care and maintenance, 12

Cutting off the water or electricity supply

Cleaning the washing machine

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Troubleshooting, 13-14

Assistance, 15-16

IWSC 51051

Instructions for use

WASHING MACHINE

English,1

Installation

Levelling the machine correctly will provide it with stability,

help to avoid vibrations and excessive noise and prevent it

from shifting while it is operating. If it is placed on carpet or

a rug, adjust the feet in such a way as to allow a sufficient

ventilation space underneath the washing machine.

Connecting the electricity and water

supplies

Connecting the water inlet hose

1. Connect the supply pipe

by screwing it to a cold

water tap using a ¾ gas

threaded connection (see

figure).

Before performing the con-

nection, allow the water to

run freely until it is perfectly

clear.

2. Connect the inlet hose

to the washing machine by

screwing it onto the corre-

sponding water inlet of the

appliance, which is situa-

ted on the top right-hand

side of the rear part of the

appliance . (see figure)

3. Make sure that the hose is not folded over or bent.

! The water pressure at the tap must fall within the values

indicated in the Technical details table (see page 5).

! If the inlet hose is not long enough, contact a specialised

shop or an authorised technician.

! Never use second-hand hoses.

! Use the ones supplied with the machine.

! This instruction manual should be kept in a safe place for

future reference. If the washing machine is sold, transferred

or moved, make sure that the instruction manual remains

with the machine so that the new owner is able to familiari-

se himself/herself with its operation and features.

! Read these instructions carefully: they contain vital infor-

mation relating to the safe installation and operation of the

appliance.

Unpacking and levelling

Unpacking

1. Remove the washing machine from its packaging.

2. Make sure that the washing machine has not been

damaged during the transportation process. If it has been

damaged, contact the retailer and do not proceed any

further with the installation process.

3. Remove the protective 3

screws (used during tran-

sportation) and the rubber

washer with the correspon-

ding spacer, located on the

rear part of the appliance

( ).see figure

4. Close off the holes using the plastic plugs provided.

5. Keep all the parts in a safe place: you will need them

again if the washing machine needs to be moved to ano-

ther location.

! Packaging materials should not be used as toys for

children.

Levelling

1. Install the washing machine on a flat sturdy floor, without

resting it up against walls, furniture cabinets or anything

else.

2. If the floor is not perfectly

level, compensate for any

unevenness by tightening

or loosening the adjusta-

ble front feet ( ); see figure

the angle of inclination,

measured in relation to the

worktop, must not exceed

2°.

Connecting the drain hose

Connect the drain hose, wi-

thout bending it, to a draining

duct or a wall drain situated

between 65 and 100 cm

from the floor;

The drain hose may be

connected to an under-sink

trap. Before connecting the

drain hose from the machine

ensure that any blanks or

removable ends have been

taken off the spigot.

If it is placed over the edge

of a basin or sink be sure the

free end of the hose should

not be underwater.

! We advise against the use of hose extensions; in case of

absolute need, the extension must have the same diameter

as the original hose and must not exceed 150 cm in length.

Ensure that if the drain hose is pushed into a standpipe, that

the end does not go down more than 15cms (6 inches). If the

hose is pushed down too far, this may cause the machine to

self -syphon ie. continuously empty as it is filling.

Electric connection

Before plugging the appliance into the mains socket, make

sure that:

• the socket is earthed and in compliance with the appli-

cable law;

• the socket is able to sustain the appliance’s maximum

power load indicated on the Technical Data Plate fixed

on the machine;

• the supply voltage is included within the values indica-

ted on the Technical Data Plate fixed on the machine.

• the socket is compatible with the washing machine’s plug.

If this is not the case, replace the socket or the plug.

Your appliance is now supplied with a 13 amp fused plug

it can be plugged into a 13 amp socket for immediate use.

Before using the appliance please read the instructions below.

WARNING - THIS APPLIANCE MUST BE EARTHED.

THE FOLLOWING OPERATIONS SHOULD BE CARRIED

OUT BY A QUALIFIED ELECTRICIAN.

Replacing the fuse:

When replacing a faulty fuse, a 13 amp ASTA approved fuse

to BS 1362 should always be used, and the fuse cover re-

fitted. If the fuse cover is lost, the plug must not be used until

a replacement is obtained.

Replacement fuse covers:

If a replacement fuse cover is fitted, it must be of the correct

colour as indicated by the coloured marking or the colour that

is embossed in words on the base of the plug. Replacements

can be obtained directly from your nearest Service Depot.

Removing the plug:

If your appliance has a non-rewireable moulded plug and you

should wish to re-route the mains cable through partitions,

units etc., please ensure that either:

the plug is replaced by a fused 13 ampere re-wearable plug

bearing the BSI mark of approval.

or:

the mains cable is wired directly into a 13 amp cable outlet,

controlled by a switch, (in compliance with BS 5733) which

is accessible without moving the appliance.

Disposing of the plug:

Ensure that before disposing of the plug itself, you make

the pins unusable so that it cannot be accidentally inserted

into a socket.

Instructions for connecting cable to an alternative plug:

Important: the wires in the mains lead are coloured in accor-

dance with the following code:

Green & Yellow Earth

Blue Neutral

Brown Live

65 - 100 cm

Where it connects to

the waste water pipe

cut end off spigot or

remove the blanking cap
