Sida 1/24

English, 1

WASHING MACHINE

Contents

Installation, 2-3

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Description of the washing machine, 4-5

Control panel

Display

Running a wash cycle, 6

Wash cycles and options, 7

Table of programmes and wash cycles

Wash options

Detergents and laundry, 8

Detergent dispenser drawer

Preparing the laundry

Special wash cycles

Precautions and advice, 9

General safety

Disposal

Opening the porthole door manually

Care and maintenance, 10

Cutting off the water and electricity supplies

Cleaning the washing machine

Cleaning the detergent dispenser drawer

Cleaning the pump

Checking the water inlet hose

Troubleshooting, 11

Service, 12

PWSE 6108 S

Instructions for use

CIS

Русский,13

Installation

! This instruction manual should be kept in a safe place for

future reference. If the washing machine is sold, transferred

or moved, make sure that the instruction manual remains

with the machine so that the new owner is able to

familiarise himself/herself with its operation and features.

! Read these instructions carefully: they contain vital

information relating to the safe installation and operation of

the appliance.

Unpacking and levelling

Unpacking

1. Remove the washing machine from its packaging.

2. Make sure that the washing machine has not been

damaged during the transportation process. If it has been

damaged, contact the retailer and do not proceed any

further with the installation process.

3. Remove the 4 protective

screws (used during

transportation) and the

rubber washer with the

corresponding spacer,

located on the rear part of

the appliance ( ).see figure

4. Close off the holes using the plastic plugs provided.

5. Keep all the parts in a safe place: you will need them

again if the washing machine needs to be moved to

another location.

! Packaging materials should not be used as toys for

children.

Levelling

1. Install the washing machine on a flat sturdy floor, without

resting it up against walls, furniture cabinets or anything

else.

2. If the floor is not perfectly

level, compensate for any

unevenness by tightening or

loosening the adjustable front

feet (see figure); the angle

of inclination, measured in

relation to the worktop, must

not exceed 2°.

Levelling the machine correctly will provide it with stability,

help to avoid vibrations and excessive noise and prevent it

from shifting while it is operating. If it is placed on carpet or

a rug, adjust the feet in such a way as to allow a sufficient

ventilation space underneath the washing machine.

Connecting the electricity and water

supplies

Connecting the water inlet hose

1. Connect the inlet hose

by screwing it to a cold

water tab using a 3/4 gas

threaded connection (see

figure).

Before performing the

connection, allow the

water to run freely until it is

perfectly clear.

2. Connect the inlet hose

to the washing machine

by screwing it onto the

corresponding water inlet

of the appliance, which is

situated on the top right-

hand side of the rear part of

the appliance . (see figure)

3. Make sure that the hose is not folded over or bent.

! The water pressure at the tap must fall within the range of

values indicated in the Technical data table (see next page).

! If the inlet hose is not long enough, contact a specialised

shop or an authorised technician.

! Never use second-hand hoses.

! Use the ones supplied with the machine.

Connecting the drain hose

Connect the drain hose,

without bending it, to a

drain duct or a wall drain

situated between 65 and

100 cm from the floor;

alternatively, place it over

the edge of a basin, sink

or tub, fastening the duct

supplied to the tap (see

figure). The free end of

the hose should not be

underwater.

! We advise against the use of hose extensions; if it is

absolutely necessary, the extension must have the same

diameter as the original hose and must not exceed 150 cm

in length.

Electrical connections

Before plugging the appliance into the electricity socket,

make sure that:

• thesocketisearthedandcomplieswithallapplicable

laws;

• thesocketisabletowithstandthemaximumpower

load of the appliance as indicated in the Technical data

table (see opposite);

• thepowersupplyvoltagefallswithinthevalues

indicated in the Technical data table ( );see opposite

• thesocketiscompatiblewiththeplugofthewashing

machine. If this is not the case, replace the socket or the

plug.

! The washing machine must not be installed outdoors,

even in covered areas. It is extremely dangerous to leave

the appliance exposed to rain, storms and other weather

conditions.

! When the washing machine has been installed, the

electricity socket must remain within easy reach.

! Do not use extension cords or multiple sockets.

65 - 100 cm

! The cable should not be bent or compressed.

! The power supply cable must only be replaced by

authorised technicians.

Warning! The company shall not be held responsible in the

event that these standards are not observed.

The first wash cycle

Once the appliance has been installed, and before you use

it for the first time, run a wash cycle with detergent and no

laundry, using wash cycle number 2.

Technical data

Model PWSE 6108 S

Dimensions

width 59.5 cm

height 85 cm

depth 44,5 cm

Capacity from 1 to 6 kg

Electrical

connections

please refer to the technical data plate

fixed to the machine

Water connections

maximum pressure 1 MPa (10 bar)

minimum pressure 0.05 MPa (0.5 bar)

drum capacity 40 litres

Spin speed up to 1000 rotations per minute

Energy rated

programmes

according to

regulation

EN 60456

programme 2; temperature 60°C;

using a load of 6 kg.

This appliance conforms to the following

EC Directives:

- 2004/108/EC (Electromagnetic Compa-

tibility)

- 2006/95/EC (Low Voltage)

- 2002/96/EC
