Sida 1/36

English,1

Contents

Installation, 2-3

Unpacking and levelling

Connecting the electricity and water supplies

Technical details

Description of the machine, 4-5

Self-cleaning detergent dispenser drawer

Control panel

Load balancing system

Running a wash cycle, 6

Wash programmes, 7

Detergents and laundry, 8

Preparing the laundry

Washing recommendations

Precautions and advice, 9

General safety

Disposal

Saving energy and respecting the environment

Drip-tray system

Care and maintenance, 10

Cutting off the water or electricity supply

Cleaning the machine

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Troubleshooting, 11

Service, 12

WASHING MACHINE

SISL 126 S

Instructions for use

Italiano,13

Français,25

Installation

 This instruction manual should be kept in a safe

place for future reference. If the appliance is sold,

transferred or moved, make sure that the instruction

manual remains with the machine so that the new

owner is able to familiarise himself/herself with its

operation and features.

 Read these instructions carefully: they contain vital

information relating to the safe installation and

operation of the appliance.

Unpacking and levelling

Unpacking

1. Unpack the washing machine.

2. Make sure that the machine has not been

damaged during the transportation process. If it has

been damaged, contact the retailer and do not

proceed any further with the installation process.

3. Remove the 4

protective screws (used

during transportation)

and the rubber washer

with the corresponding

spacer, located on the

rear part of the appliance

(see figure).

4. Close off the holes using the plastic plugs

provided.

5. Keep all the parts in a safe place: they will be

needed again if the washing machine is moved to

another location.

 Packaging materials should not be used as toys for

children.

Levelling

Your machine may make a considerable amount of

noise if the two front feet have not been adjusted

correctly.

1. Install the washing machine on a flat and sturdy

floor, without placing it against walls, cabinets or

other furniture.

2. If the floor is not

perfectly level, compen-

sate for any unevenness

by tightening or loosening

the adjustable front feet

(see figure); the angle of

inclination, measured in

relation to the worktop,

must not exceed 2°.

Levelling the machine correctly will provide it with

stability, help to avoid vibrations and excessive noise

and prevent it from shifting while it is operating. If it is

placed on carpet or a rug, adjust the feet in such a

way as to allow a sufficient ventilation space

underneath the machine.

Connecting the electricity and water

supplies

Connecting the water inlet hose

1. Insert seal A into the

end of the inlet hose and

screw the latter onto a

cold water tap with a 3/4

gas threaded opening

(see figure).

Before performing the

connection, allow the

water to run freely until it

is perfectly clear.

2. Connect the inlet hose

to the machine by

screwing it onto the cold

water inlet of the

appliance, which is

situated on the top right-

hand side of the rear part

of the appliance(see

figure).

3. Make sure that the hose is not folded over or bent.

 The water pressure at the tap must fall within the

values indicated in the Technical details table (see

next page).

If the inlet hose is not long enough, contact a

specialised shop or an authorised technician.

Technical details

Model SISL 126 S

Dimensions

59.5 cm wide

85 cm high

40 cm deep

Capacity from 1 to 4,5 kg

Electric

connections

please refer to the technical data plate

fixed to the machine

Water

connections

maximum pressure 1 MPa (10 bar)

minimum pressure 0.05 MPa (0.5 bar)

drum capacity 40 litres

Spin speed up to 1200 rpm

Control

programmes

according to

EN 60456

directive

programme ;

run with a load of 4,5 kg.

This appliance is compliant with the

following European Community

Directives:

- 73/23/CEE of 19/02/73 (Low

Voltage) and subsequent amendments

- 89/336/CEE of 03/05/89

(Electromagnetic Compatibility) and

subsequent amendments

- 2002/96/CE

65 - 100 cm

Connecting the drain hose

Connect the drain hose,

without bending it, to a

draining duct or a wall

drain situated between

65 and 100 cm from the

floor;

alternatively, place it

over the edge of a

basin, sink or tub,

fastening the duct

supplied to the tap (see

figure). The free end of

the hose should not be

underwater.

 We advise against the use of hose extensions; if it

is absolutely necessary, the extension must have the

same diameter as the original hose and must not

exceed 150 cm in length.

Electrical connections

Before plugging the appliance into the electricity

socket, make sure that:

 the socket is earthed and complies with all

applicable laws;

 the socket is able to withstand the maximum

power load of the appliance as indicated in the

Technical data table (see opposite);

 the power supply voltage falls within the values

indicated in the Technical data table(see opposite);

 the socket is compatible with the plug of the

appliance. If this is not the case, replace the

socket or the plug.

 The machine must not be installed outdoors, even

in covered areas. It is extremely dangerous to leave

the appliance exposed to rain, storms and other

weather conditions.

 The mains socket must remain within easy reach

after the washing machine has been installed.

 Do not use extension cords or multiple sockets.

 The cable should not be bent or compressed.

 The power supply cable must only be replaced by

authorised technicians.

Warning! The company shall not be held responsible

in the event that these regulations are not respected.
