English,1

Contents

Installation, 2-3

Unpacking and levelling, 2

Electric and water connections, 2-3

The first wash cycle, 3

Technical details, 3

Washer-dryer description, 4-5

Control panel, 4

Leds, 5

Starting and Programmes, 6

Briefly: how to start a programme, 6

Programme table, 6

Personalisations, 7

Setting the temperature, 7

Setting the drying cycle, 7

Functions, 7

Detergents and laundry, 8

Detergent dispenser, 8

Preparing your laundry, 8

Special items, 8

Precautions and advice, 9

General safety, 9

Disposal, 9

Saving energy and respecting the environment, 9

Care and maintenance, 10

Cutting off the water or electricity supply, 10

Cleaning your appliance, 10

Cleaning the detergent dispenser, 10

Caring for your appliance door and drum, 10

Cleaning the pump, 10

Checking the water inlet hose, 10

Troubleshooting, 11

Service, 12

Before calling for Assistance, 12

WASHER-DRYER

WIDL 126 S

Instructions for use

Hrvatski,13

Espanol,25

Português,3 7

 Keep this instruction manual in a safe place for

future reference. Should the appliance be sold,

transferred or moved, make sure the instruction

manual accompanies the Washer-dryer to inform the

new owner as to its operation and features.

Read these instructions carefully: they contain vital

information on installation, use and safety.

Unpacking and levelling

Unpacking

1. Unpack the Washer-dryer.

2. Check whether the Washer-dryer has been

damaged during transport. If this is the case, do not

install it and contact your retailer.

3. Remove the four

protective screws and

the rubber washer with

the respective spacer,

situated on the rear of

the appliance (see

figure).

4. Seal the gaps using the plastic plugs provided.

5. Keep all the parts: you will need them again if the

Washer-dryer needs to be moved to another

location.

Packaging materials are not children's toys.

Levelling

1. Install the Washer-dryer on a flat sturdy floor,

without resting it up against walls, furniture cabinets

or other.

2. If the floor is not

perfectly level, compen-

sate for any unevenness

by tightening or

loosening the adjustable

front feet (see figure);

the angle of inclination,

measured according to

the worktop, must not

exceed 2°.

Levelling your appliance correctly will provide it with

stability and avoid any vibrations, noise and shifting

during operation. If it is placed on a fitted or loose

carpet, adjust the feet in such a way as to allow

enough room for ventilation beneath the Washer-

dryer.

Electric and water connections

Connecting the water inlet hose

1. Insert seal A into the

end of the inlet hose

and screw the latter

onto a cold water tap

with a 3/4 gas threaded

mouth (see figure).

Before making the

connection, allow the

water to run freely until

it is perfectly clear.

2. Connect the other end

of the water inlet hose to

the Washer-dryer,

screwing it onto t he

appliance's cold water

inlet, situated on the top

right-hand side on the

rear of t he appli ance

(see figure).

3. Make sure there are no kinks or bends in the

hose.

 The water pressure at the tap must be within the

values indicated in the Technical details table

(on the next page).

 If the water inlet hose is not long enough, contact

a specialist store or an authorised serviceman.

Installation

ServiceTroubleshooting

Precautions

Care

Programmes

Detergentsation Description

Connecting the drain hose

Connect the drain hose,

without bending it, to a

draining duct or a wall

drain situated between

65 and 100 cm from

the floor;

alternatively, place it

over the edge of a

basin, sink or tub,

fastening the duct

supplied to the tap (see

figure). The free end of

the hose should not be

underwater.

 We advise against the use of hose extensions; in

case of absolute need, the extension must have the

same diameter as the original hose and must not

exceed 150 cm in length.

Electric connection

Before plugging the appliance into the mains

socket, make sure that:

 the socket is earthed and in compliance with the

applicable law;

 the socket is able to sustain the appliance's

maximum power load indicated in the Technical

details table (on the right);

 the supply voltage is included within the values i

ndicated on the Technical details table

(on the right);

 the socket is compatible with the washing

machine's plug. If this is not the case, replace

the socket or the plug.

 The washing machine should not be installed in an

outdoor environment, not even when the area is

sheltered, because it may be very dangerous to

leave it exposed to rain and thunderstorms.

 When the washing machine is installed, the mains

socket must be within easy reach.

 Do not use extensions or multiple sockets.

 The power supply cable must never be bent or

dangerously compressed.

 The power supply cable must only be replaced by

an authorised serviceman.

Warning! The company denies all liability if and when

these norms are not respected.

The first wash cycle

Once the appliance has been installed, and before

you use it for the first time, run a wash cycle with

detergent and no laundry, setting the 90°C

programme without a pre-wash cycle.

65 - 100 cm

Technical details

Model WIDL 126 S

Dimensions

59.5 cm wide

85 cm high

53.5 cm deep

Capacity from 1 to 5 kg for the wash programme;

from 1 to 4 kg for the drying programme

Electric

connections

voltage 220/230 Volts 50 Hz

maximum absorbed power 1850 W

Water

connections

maximum pressure 1 MPa (10 bar)

minimum pressure 0.05 MPa (0.5 bar)

drum capacity 46 litres

Spin speed up to 1200 rpm

Control

programmes

according to

IEC456 directive

Wash: programme 2; temperature 60°C;

run with a load of 5 kg.

DrDryi

yiyin

nng

gg:

: : first drying cycle performed with

a 1 kg load, by selecting a drying time

of 40 min;

Second drying cycle performed with a 4

kg load and the DRYING knob on

the setting.

This appliance is compliant with the

following European Community

Directives:

- 73/23/CEE of 19/02/73 (Low

Voltage) and subsequent amendments

- 89/336/CEE of 03/05/89

(Electromagnetic Compatibility) and

subsequent amendments

- 2002/96/CE
