Sida 1/60

WASHING MACHINE

WITXL 109

Instructions for use

Contents

Installation, 2-3

Unpacking and levelling, 2

Electric and water connections, 2-3

The first wash cycle, 3

Technical details, 3

Washing machine description, 4-5

Control panel, 4

How to open and shut the drum, 5

Leds, 5

Starting and Programmes, 6

Briefly: how to start a programme, 6

Programme table, 6

Personalisations, 7

Setting the temperature, 7

Setting the spin cycle, 7

Functions, 7

Detergents and laundry, 8

Detergent dispenser, 8

Bleach cycle, 8

Preparing your laundry, 8

Special items, 8

Precautions and advice, 9

General safety, 9

Disposal, 9

Saving energy and respecting the environment, 9

Care and maintenance, 10

Cutting off the water or electricity supply, 10

Cleaning your appliance, 10

Caring for your appliance door and drum, 10

Cleaning the pump, 10

Checking the water inlet hose, 10

Cleaning the detergent dispenser, 10

Troubleshooting, 11

Service, 12

Before calling for Assistance, 12

English, 1

ÅËËÇÍÉÊÁ, 25

Français, 13

Italiano, 37

Magyar,49

Keep this instruction manual in a safe place for future

reference. Should the appliance be sold, transferred or

moved, make sure the instruction manual accompanies

the washing machine to inform the new owner as to its

operation and features.

Read these instructions carefully: they contain vital

information on installation, use and safety.

Unpacking and levelling

Unpacking

1. Unpack the washing

machine.

2. Check whether the

washing machine has

been damaged during

transport. If this is the

case, do not install it and

contact your retailer.

3. Remove the four

protective screws and the

rubber washer with the

respective spacer, situated

on the rear of the

appliance (see figure).

4. Seal the gaps using the

plastic plugs provided.

5. Keep all the parts: you will need them again if the

washing machine needs to be moved to another location.

Warning: should the screws be re-used, make sure you

fasten the shorter ones at the top.

Packaging materials are not children's toys.

Levelling

Your machine may make a considerable amount of noise if

the two front feet have not been adjusted correctly.

1. Install the washing

machine on a flat sturdy

floor, without resting it up

against walls, furniture

cabinets or other.

2. If the floor is not perfectly

level, compensate for any

unevenness by tightening or

loosening the adjustable front

feet (see figure); the angle of

inclination, measured according to the worktop, must not

exceed 2°.

Levelling your appliance correctly will provide it with

stability and avoid any vibrations, noise and shifting during

operation. If it is placed on a fitted or loose carpet,

adjust the feet in such a way as to allow enough

room for ventilation beneath the washing machine.

Putting your appliance in place and moving it.

If your washing

machine is equipped

with a special set of

retractable wheels you

can easy move it. To

lower the wheels and

thus move the

appliance effortlessly,

just pull the lever,

situated on the left-

hand side beneath the

base. Once the appliance is in the required position,

put the lever back in place. The washing machine is

now firmly in place (see figure).

Electric and water connections

Connecting the water inlet hose

1. Insert seal A into the

end of the inlet hose

and screw the latter

onto a cold water tap

with a 3/4 gas

threaded mouth (see

figure).

Before making the

connection, allow the

water to run freely until

it is perfectly clear.

2. Connect the other end

of the water inlet hose to

the washing machine,

screwing it onto the

appliance's cold water

inlet, situated on the top

right-hand side on the

rear of the appliance

(see figure).

3. Make sure there are no kinks or bends in the

hose.

The water pressure at the tap must be within the

values indicated in the Technical details table

(on the next page).

If the water inlet hose is not long enough, contact

a specialist store or an authorised serviceman.

 Never use hoses that have already been used.

Installation

ServiceTroubleshootingPrecautions CareProgrammes DetergentsInstallation Description

Connecting the drain hose

Connect the drain hose,

without bending it, to a

draining duct or a wall

drain situated between

65 and 100 cm from

the floor;

alternatively, place it

over the edge of a

basin, sink or tub,

fastening the duct

supplied to the tap (see

figure). The free end of

the hose should not be

underwater.

 We advise against the use of hose extensions; in

case of absolute need, the extension must have the

same diameter as the original hose and must not

exceed 150 cm in length.

Electric connection

Before plugging the appliance into the mains

socket, make sure that:

 the socket is earthed and in compliance with the

applicable law;

 the socket is able to sustain the appliance's

maximum power load indicated in the Technical

details table (on the right);

 the supply voltage is included within the values i

ndicated on the Technical details table

(on the right);

 the socket is compatible with the washing

machine's plug. If this is not the case, replace

the socket or the plug.

 The washing machine should not be installed in an

outdoor environment, not even when the area is

sheltered, because it may be very dangerous to

leave it exposed to rain and thunderstorms.

 When the washing machine is installed, the mains

socket must be within easy reach.

 Do not use extensions or multiple sockets.

 The power supply cable must never be bent or

dangerously compressed.

 The power supply cable must only be replaced by

an authorised serviceman.

Warning! The company denies all liability if and when

these norms are not respected.

The first wash cycle

Once the appliance has been installed, and before

you use it for the first time, run a wash cycle with

detergent and no laundry, setting the 90°C

programme without a pre-wash cycle.

65 - 100 cm

Technical details

Model WITXL 109

Dimensions

40 cm wid e

85 cm high

60 cm deep

Capacity from 1 to 6 kg

Electric

connections

Please refer to the technical data p late

fixed to the machine

Water

connections

maximum p ressu re 1 MPa (10 b ar)

minimum pressure 0.05 MPa (0.5 bar)

drum cap acity 42 litres

Spin speed up to 1000 rpm

Control

programmes

according to EN

60456 directive

pr ogramme 3; temp eratu re 60°C ;

ru n with a load of 6 kg.

Th is app liance is compliant with the

following Euro pean Community

Directives :

- 89/336/CEE of 03/05/89

(Elect ro magnetic Com patibilit y) and

sub sequent amendments

- 2006/95/CE (Low Voltage)

- 2002/96/CE
