Washer-dryer

Instructions for use

! This symbol reminds you to read this instruc-

tion manual.

Contents

Installation, 2-3-4-5

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Care and maintenance, 6

Cutting off the water and electricity supplies

Cleaning the washer-dryer

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Precautions and tips, 7

General safety

Disposal

Description of the washer-dryer, 8-9

Control panel

Display

How to run a wash cycle or a drying cycle, 10

Wash cycles and options, 11-12

Table of wash cycles

Wash options

Push&Wash+Dry

Detergents and laundry, 13-14

Detergent dispenser drawer

Preparing the laundry

Special wash cycles

Load balancing system

Troubleshooting, 15-16

Product Guarantee and Repair Information, 17

XWDE 961680

English,1

! This instruction manual should be kept in a safe

place for future reference. If the washer-dryer is

sold, transferred or moved, make sure that the

instruction manual remains with the machine so

that the new owner is able to familiarise himself/

herself with its operation and features.

! Read these instructions carefully: they contain

vital information relating to the safe installation

and operation of the appliance.

Unpacking and levelling

Unpacking

1. Remove the washer-dryer from its packaging.

2. Make sure that the washer-dryer has not been

damaged during the transportation process. If

it has been damaged, contact the retailer and

do not proceed any further with the installation

process.

3. R e m o v e t h e 4

protective screws (used

during transportation)

and the rubber washer

with the corresponding

spacer, located on

the rear part of the

appliance ( ).see figure

4. Close off the holes using the plastic plugs

provided.

5. Keep all the parts in a safe place: you will

need them again if the washer-dryer needs to

be moved to another location.

! Packaging materials should not be used as

toys for children.

Levelling

1. Install the washer-dryer on a flat sturdy floor,

without resting it up against walls, furniture

cabinets or anything else.

2. If the floor is not

p e r f e c t l y l e v e l ,

c o m p e n s a t e f o r

any unevenness by

tightening or loosening

the adjustable front

feet ( ); the see figure

angle of inclination,

measured in relation to

the worktop, must not

exceed 2°.

Levelling the machine correctly will provide it with

stability, help to avoid vibrations and excessive

noise and prevent it from shifting while it is

operating. If it is placed on carpet or a rug, adjust

the feet in such a way as to allow a sufficient

ventilation space underneath the washer-dryer.

Connecting the electricity and

water supplies

Connecting the water inlet hose

1. Connect the supply

pipe by screwing it

to a cold water tap

using a ¾ gas threaded

connection (see figure).

Before performing the

connection, allow the

water to run freely until

it is perfectly clear.

2. Connect the inlet

hose to the washer-

dryer by screwing it

onto the corresponding

water inl et of t he

appliance, which is

situated on the top

right-hand side of

the rear part of the

appliance . (see figure)

3. Make sure that the hose is not folded over

or bent.

! The water pressure at the tap must fall within

the values indicated in the Technical details table

(see next page).

! If the inlet hose is not long enough, contact a

specialised shop or an authorised technician.

! Never use second-hand hoses.

! Use the ones supplied with the machine.

Installation

Connecting the drain hose

Connect the drain

hose, without bending

it, to a draining duct or

a wall drain situated

between 65 and 100

cm from the floor;

The drain hose may

b e c o n n e c t e d t o

an under-sink trap.

Before connecting

the drain hose from

the machine ensure

that any blanks or

removable ends have

been taken off the

spigot.

If it is placed over the

edge of a basin or sink

be sure the free end of

the hose should not

be underwater.

! We advise against the use of hose extensions; in

case of absolute need, the extension must have the

same diameter as the original hose and must not

exceed 150 cm in length. Ensure that if the drain

hose is pushed into a standpipe, that the end does

not go down more than 15cms (6 inches). If the hose

is pushed down too far, this may cause the machine

to self -syphon ie. continuously empty as it is filling.

Electric connection

Before plugging the appliance into the mains

socket, make sure that:

• the socket is earthed and in compliance with

the applicable law;

• the socket is able to sustain the appliance’s

maximum power load indicated on the Technical

Data Plate fixed on the machine;

65 - 100 cm

Where it connects to

the waste water pipe

cut end off spigot or

remove the blanking cap

• the supply voltage is included within the values

indicated on the Technical Data Plate fixed on

the machine.

• the socket is compatible with the washing

machine’s plug. If this is not the case, replace

the socket or the plug.

Your appliance is now supplied with a 13 amp

fused plug it can be plugged into a 13 amp

socket for immediate use. Before using the

appliance please read the instructions below.

WARNING - THIS APPLIANCE MUST BE EARTHED.

THE FOLLOWING OPERATIONS SHOULD BE

CARRIED OUT BY A QUALIFIED ELECTRICIAN.

Replacing the fuse:

When replacing a faulty fuse, a 13 amp ASTA

approved fuse to BS 1362 should always be

used, and the fuse cover re-fitted. If the fuse

cover is lost, the plug must not be used until a

replacement is obtained.

Replacement fuse covers:

If a replacement fuse cover is fitted, it must be of

the correct colour as indicated by the coloured

marking or the colour that is embossed in words

on the base of the plug. Replacements can be

obtained directly from your nearest Service Depot.

Removing the plug:

If your appliance has a non-rewireable moulded

plug and you should wish to re-route the mains

cable through partitions, units etc., please

ensure that either:

the plug is replaced by a fused 13 ampere

rewireable plug bearing the BSI mark of approval.

or:

the mains cable is wired directly into a 13

amp cable outlet, controlled by a switch, (in

compliance with BS 5733) which is accessible

without moving the appliance.

Disposing of the plug:

Ensure that before disposing of the plug itself,

you make the pins unusable so that it cannot be

accidentally inserted into a socket.

Instructions for connecting cable to an alternative

plug:

Important: the wires in the mains lead are

coloured in accordance with the following code:

Green & Yellow Earth

Blue Neutral

Brown Live
