2020 Rider’s Manual

Indian Challenger™

All information contained within this publication is based on the latest product information available at the time of publication. Product

improvements or other changes may result in differences between this manual and the motorcycle. Depictions and/or procedures in this

publication are intended for reference use only.

No liability can be accepted for omissions or inaccuracies. Indian Motorcycle Company reserves the right to make changes at any time,

without notice and without incurring obligation to make the same or similar changes to motorcycles previously built. Any reprinting or

reuse of the depictions and/or procedures contained within, whether whole or in part, is expressly prohibited.

INDIAN®, INDIAN MOTORCYCLE, and INDIAN CHALLENGER™ are trademarks of Indian Motorcycle Company.

iPhone®, iPod®, iPod nano®, and iPod touch® are trademarks of Apple Inc., registered in the U.S. and other countries.

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by INDIAN

MOTORCYCLE is under license. Other trademarks and trade names are those of their respective owners.

Garmin® and zumo® are registered trademarks of Garmin Ltd. or its subsidiaries.

JCASE® is a registered trademark of Littelfuse, Inc.

9931163

Congratulations on your purchase of a new INDIAN motorcycle. You have joined an elite family of motorcycle riders who have acquired a

celebrated piece of American history by choosing to own an INDIAN motorcycle.

Your new motorcycle is the end result of true dedication and craftsmanship by our engineering, design and assembly teams. It was

designed and manufactured to meet our goal of providing you with a high quality motorcycle that you can ride trouble-free for many years

to come. We hope you will take as much pride in riding your new motorcycle as our team did in building it for you.

We urge you to read this rider’s manual thoroughly. It contains information essential to safe riding and proper maintenance of your

motorcycle.

Your authorized INDIAN MOTORCYCLE dealer knows your motorcycle best and should be consulted for service and assistance. Skilled

technicians using advanced equipment and methods are best qualified to perform all major repairs and service your motorcycle may

require.

INDIAN motorcycles comply with all federal, state and local safety and emission regulations for the area of intended sale.

CONGRATULATIONS!

The following signal words and symbols appear throughout this manual. Your safety and the safety of others is involved when these words

and symbols are used. Become familiar with their meanings before reading the manual.

DANGER

DANGER indicates a hazardous situation which, if not avoided, WILL result in death or serious injury.

WARNING

WARNING indicates a hazardous situation that, if not avoided, result in death to the operator, bystanders or person(s) inspecting or may

servicing the vehicle.

CAUTION

SAFETY ALERT CAUTION indicates a potential hazard that may result in minor personal injury or damage to the vehicle.

CAUTION

CAUTION indicates special precautions that must be taken to avoid vehicle damage or property damage.

IMPORTANT

IMPORTANT provides key reminders during disassembly, assembly, and inspection of components.

SAFETY SYMBOLS AND SIGNAL WORDS

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Reporting Safety Defects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Instruments, Features and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Pre-Ride Inspections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Cleaning and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157

Maintenance Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169

TABLE OF CONTENTS

IINNTTRROODDUUCCTTIIOONN

IIDDEENNTTIIFFIICCAATTIIOONN NNUUMMBBEERR RREECCOORRDDSS

Record important identification numbers below:

Vehicle Identification

Number (VIN)

Engine Identification

Number

Master PIN

Rider PIN

Key Fob #1 Serial Number

Key Fob #2 Serial Number

(optional)

SSEERRVVIICCEE AANNDD WWAARRRRAANNTTYY IINNFFOORRMMAATTIIOONN

Some procedures are beyond the scope of this manual. See your

dealer to purchase an INDIAN MOTORCYCLE Service Manual. Some

procedures provided in the service manual require specialized

knowledge, equipment, and training. Be sure you have the

required technical skills and tools that are needed before you

attempt ANY service on your motorcycle. Please contact your

authorized dealer before attempting any service work that is

beyond your level of technical knowledge or experience, or if the

work requires specialized equipment.

OOPPEERRAATTIINNGG MMOOTTOORRCCYYCCLLEE OOUUTTSSIIDDEE TTHHEE UU..SS..AA..

If you plan to operate your motorcycle in countries other than the

USA and Canada:

• Service facilities or replacement parts may not be readily

available.

• Unleaded gasoline may not be available. The use of leaded fuels

will cause engine damage, damage to your emissions systems

and voiding of your warranty.

• Gasoline may have a considerably lower octane rating.

Improper fuel can cause engine damage.

INTRODUCTION

EENNGGIINNEE IIDDEENNTTIIFFIICCAATTIIOONN NNUUMMBBEERR

The engine number q

is stamped into the right crankcase beneath

the balance shaft cover. The engine number is positioned behind

the right floorboard with the engine installed in the frame. Record

the number in the space provided on page 7.

INTRODUCTION

SSAAFFEETTYY

AABBOOUUTT TTHHEE RRIIDDEERR’’SS MMAANNUUAALL

WARNING

Failure to follow all recommended precautions and procedures

could result in severe injury or death. Always heed all safety

precautions and follow all operation, inspection and maintenance

procedures outlined in this manual.

All references to RIGHT, LEFT, FRONT or REAR are from the

operator’s perspective when seated in a normal riding position. If

you have questions about the operation or maintenance of your

motorcycle after you've read this manual, please see your

authorized dealer. To locate the nearest authorized INDIAN

MOTORCYCLE dealer, visit the INDIAN MOTORCYCLE web site at

www.indianmotorcycle.com.

Carefully read and understand the information found in the Safety

section beginning on this page. To keep your motorcycle in peak

condition on the road or in storage, understand and follow the

procedures outlined in the section beginning on page Maintenance

79.

Bring the manual along when you ride. Following the precautions

and procedures in the manual will add to your enjoyment and help

keep you safe. If you lose or damage this manual, please purchase

a new one through any authorized INDIAN MOTORCYCLE dealer.

This rider’s manual should be considered part of the motorcycle

and should remain with the motorcycle when ownership changes.

SSAAFFEE RRIIDDIINNGG PPRRAACCTTIICCEESS

WARNING

Improper use of a motorcycle can result in serious injury or death

to you, your passenger and others. To minimize the risk of injury,

read and understand the information contained in this section

before operating the motorcycle. This section contains safety

information specific to the INDIAN motorcycle, as well as

information about general motorcycle safety. Anyone who rides

the motorcycle (operators and passengers) must follow these

safety precautions.

MMOOTTOORRCCYYCCLLIINNGG HHAASS IINNHHEERREENNTT RRIISSKKSS

You can minimize those risks, but you can't eliminate them

completely. Even if you’re an experienced motorcycle operator or

passenger, read all of the safety information in this manual before

operating the motorcycle.

• Take a rider education course from the Motorcycle Safety

Foundation or another qualified instructor. The course will help

you develop or refresh your expertise in safe riding habits

through instruction and riding. For information on Motorcycle

Safety Foundation rider education courses in your area, call 1-

800-446-9227 or visit www.msf-usa.org.

• Read and understand all information in this rider’s manual.

• Observe all maintenance requirements specified in this manual.

See the INDIAN MOTORCYCLE Service Manual or an authorized

INDIAN MOTORCYCLE dealer.

SAFETY

• Do not move or operate the motorcycle with the steering locked

(if equipped), as the severely restricted steering could result in

loss of control.

• Reduce speed when:

– The road has potholes or is otherwise rough or uneven.

– The road contains sand, dirt, gravel or other loose

substances.

– The road is wet, icy or oily.

– The road contains painted surfaces, manhole covers, metal

grating, railway crossings or other slippery surfaces.

– The weather is windy, rainy or otherwise causing slippery or

rapidly changing conditions.

– Traffic is heavy, congested, not allowing sufficient space

between vehicles or otherwise not flowing smoothly.

– You are being passed in either direction by a large vehicle

that may produce a wind blast in its wake.

• When approaching a curve, choose a speed and lean angle that

allows you to pass through the curve in your own lane without

applying the brakes. Excessive speed, improper lean angle or

braking in a curve can cause loss of control.

• Ground clearance is reduced when the motorcycle leans. Do not

allow components to contact the road surface when leaning the

motorcycle in a curve, as this could cause loss of control.

• Do not tow a trailer. Towing a trailer can make the motorcycle

hard to handle.

• Retract the sidestand fully before riding. If the sidestand is not

fully retracted, it could contact the road surface and cause loss

of control.

• To maximize braking effectiveness, use the front and rear brakes

together. Be aware of the following braking facts and practices:

– The rear brake provides 40% of the motorcycle's stopping

power, at most. Use the front and rear brakes together.

– To avoid skidding, apply the brakes gradually when the road

is wet or rough, or contains loose or other slippery

substances.

– If possible, avoid applying the brakes while making a turn.

Motorcycle tires have less traction during turns, so braking

will increase the possibility of skidding. Bring the motorcycle

to the upright position before applying the brakes.

– With new pads and rotors, allow up to 250 miles (500 km) of

operation in urban driving conditions (not highway cruising)

to allow pads to mate with new rotors. Brakes should be used

frequently. During this time brake performance will be less

effective. Avoid using brakes harshly unless in an

emergency. Brake efficiency will gradually increase during

this seating period.

• Hot engine and exhaust components can cause burns to skin

and can ignite a fire if exposed to flammable materials. Always

park the motorcycle clear of flammable materials and where

people are not likely to contact hot components.

SAFETY

PPRROOTTEECCTTIIVVEE AAPPPPAARREELL

Wear protective apparel to decrease the risk of injury and increase

riding comfort.

• Always wear a helmet that meets or exceeds established safety

standards. Approved helmets in the USA and Canada bear a U.S.

Department of Transportation (DOT) label. Approved helmets in

Europe, Asia and Oceania bear the ECE 22.05 label. The ECE

mark consists of a circle surrounding the letter E, followed by

the distinguishing number of the country which has granted

approval. The approval number and serial number will also be

displayed on the label. Laws in some areas that you wear require

an approved helmet. Head injuries are the leading cause of

fatalities in accidents involving motorcycles. Statistics prove that

an approved helmet is the most effective protection in

preventing or reducing head injuries. The helmet should fit

snugly, be securely fastened, have no obvious defects, and have

not previously been involved in an accident/crash.

• Wear eye protection to protect eyes from wind or airborne

particles and objects. Wearing a face shield can help protect

your face in an accident/crash and protect face from wind or

airborne particles or objects. Laws in some areas that require

you wear eye protection. We recommend that you wear

approved Personal Protective Equipment (PPE) bearing

markings such as VESC 8, V-8, Z87.1, or CE. Make sure

protective eyewear is kept clean.

• All riders should wear bright or light-colored and/or reflective

clothing to improve visibility to other motorists. A motorist's

failure to see or recognize a motorcycle is the leading cause of

automobile/motorcycle accidents.

• Wear gloves, a jacket, heavy boots and long pants to prevent or

reduce injury from abrasions, lacerations or burns should the

motorcycle fall. Wear boots with low heels, as high heels can

catch on pedals or footrests. The combination of boots and pants

should completely cover legs, ankles and feet, protecting skin

from engine and exhaust system heat.

• Do not wear loose, flowing clothing or long boot laces, as they

can catch on handlebars, levers or footrests, or they can become

entangled in the wheels, causing loss of control and serious

injury.

CCAARRRRYYIINNGG AA PPAASSSSEENNGGEERR

WARNING

Do not carry a passenger unless the motorcycle is equipped with

passenger seat and passenger footrests.

CCAARRRRYYIINNGG CCAARRGGOO

Use the following guidelines when attaching cargo or accessories

to the motorcycle. Where applicable, these guidelines also refer to

the contents of any accessories.

• Keep cargo and accessory weight to a minimum, and keep items

as close to the motorcycle as possible to minimize a change in

the motorcycle’s center of gravity. Changing the center of grav-

ity can cause loss of stability and handling and could cause loss

of control.

• Adjust ride height as needed. See page 110.

SAFETY

• Do not install accessories that impair operator visibility or the

stability, handling or operation of the motorcycle. Before

installing an accessory, be sure that it does not:

– reduce ground clearance when the motorcycle is either

leaned or in a vertical position;

– limit suspension or steering travel or your ability to operate

controls;

– displace you from your normal riding position;

– obscure lights or reflectors.

• Bulky, heavy or large accessories can cause instability (due to

the lifting or buffeting effects of wind) and loss of control.

• Do not install electrical accessories that exceed the capacity of

the motorcycle’s electrical system. Never install higher wattage

light bulbs than those supplied as original equipment. An

electrical failure could result and cause hazardous loss of engine

power or lights, or damage to the electrical system.

• Use only genuine INDIAN MOTORCYCLE accessories designed

for your model.

• Do not exceed the gross vehicle weight rating (GVWR) for your

motorcycle.

• Adjust ride height as needed. See page 110.

MMOODDIIFFIICCAATTIIOONNSS

Modifying the motorcycle by removing any equipment or by

adding equipment not approved by the manufacturer may void

your warranty. Such modifications could make the motorcycle

unsafe to ride and could result in severe injury to operator or

passenger, as well as damage to the motorcycle. Some

modifications may not be legal in your area of operation. If in

doubt, contact your authorized INDIAN MOTORCYCLE dealer.

PPAARRKKIINNGG TTHHEE MMOOTTOORRCCYYCCLLEE

When leaving the motorcycle unattended, turn the engine off.

NOTE

Do not store your key fob near the motorcycle.

Park the motorcycle where people are not likely to touch the hot

engine or exhaust system or place combustible materials near

these hot areas. Do not park near a flammable source such as a

kerosene heater or an open flame, where hot components could

ignite combustible materials.

Park the motorcycle on a firm, level surface. Sloped or soft

surfaces may not support the motorcycle. If you must park on a

slope or soft surface, follow the precautions outlined on page 77.

AANNTTII--LLOOCCKK BBRRAAKKEE SSYYSSTTEEMM RREESSPPOONNSSEE

When the anti-lock brakes engage during a braking event, the

rider will feel pulsing at the brake levers. Continue to apply steady

pressure to the brakes for the best stopping performance.

SAFETY

FFUUEELL AANNDD EEXXHHAAUUSSTT SSAAFFEETTYY

Always heed these fuel safety warnings when refueling or

servicing the fuel system.

WARNING

Gasoline is highly flammable and explosive under certain

conditions.

• Always exercise extreme caution whenever handling gasoline.

• Always turn off the engine before refueling.

• Always refuel outdoors or in a well-ventilated area.

• Open the fuel cap slowly. Do not overfill the tank. Do not fill the

tank neck.

• Do not smoke or allow open flames or sparks in or near the

area where refueling is performed or where gasoline is stored.

WARNING

Gasoline and gasoline vapors are poisonous and can cause

severe injury.

• Do not swallow gasoline, inhale gasoline vapors, or spill

gasoline. If you swallow gasoline, inhale more than a few

breaths of gasoline vapor, or get gasoline in your eyes, see a

physician immediately.

• If gasoline spills on your skin or clothing, immediately wash it

off with soap and water and change clothing.

• Exhaust gases contain carbon monoxide, a colorless, odorless

gas that can cause loss of consciousness or death in a short

time.

• Never start the engine or let it run in an enclosed area.

• Never inhale exhaust gases.

SSAAFFEETTYY MMAAIINNTTEENNAANNCCEE

WARNING

Failure to perform safety maintenance as recommended can

result in difficult handling and loss of control, which could result

in serious injury or death. Always perform the safety

maintenance procedures as recommended in this manual.

Perform maintenance and repairs promptly. See the INDIAN

MOTORCYCLE Service Manual or an authorized INDIAN

MOTORCYCLE dealer or other qualified dealer.

SAFETY

• Before each ride, perform the on page 57.Pre-Ride Inspections

• Perform all periodic maintenance at the recommended intervals

outlined in the section.Periodic Maintenance

• Always maintain proper tire pressure, tread condition and wheel

and tire balance. Inspect tires regularly and replace worn or

damaged tires promptly. Use only approved replacement tires.

See the section. Specifications

• Always ensure proper steering head bearing adjustment.

Regularly inspect the rear shock absorber and the front forks for

fluid leaks or damage. Make any necessary repairs promptly.

See page 112.

• Clean the motorcycle thoroughly to reveal items in need of

repair.

• Fasteners must meet original specifications for quality, finish

and type to ensure safety. Use only genuine INDIAN

MOTORCYCLE replacement parts, and ensure that all fasteners

are tightened to the proper torque.

TTRRAANNSSPPOORRTTIINNGG TTHHEE MMOOTTOORRCCYYCCLLEE

If you must transport the motorcycle:

• Use a truck or trailer. Do not tow the motorcycle with another

vehicle, as towing will impair the motorcycle’s steering and

handling.

• Position and restrain the motorcycle in an upright position.

• Do not restrain the motorcycle using the handlebars.

• Loop tiedown straps (from the front) up and over the lower triple

clamp, using care to not interfere with wiring and brake lines.

Place tiedowns as wide apart as possible on the truck or trailer

bed for best stability.

• Do not engage the side stand during truck or trailer

transportation.

EELLEECCTTRROOMMAAGGNNEETTIICC IINNTTEERRFFEERREENNCCEE

This vehicle complies with UN ECE Regulation 10 requirements

and Canadian ICES-002.

FFOOBB CCOOMMPPLLIIAANNCCEE SSTTAATTEEMMEENNTT

This vehicle contains some or all of the following radio equipment:

COMPONENT COMPONENT ID MANUFACTURER

TPMS 2412417 Schrader

WCM 4017762 Marquardt

Remote Control

Keyfob

4017761 Marquardt

Ride Command

Display

3280849 Polaris Industries

Hereby, Polaris Industries Inc. declares that the above radio

equipment is in compliance with EU Directive 2014/53/EU.

SAFETY

The full text of the EU declaration of conformity is available at the

following internet address:

https://www.polaris.com/en-us/radio-conformity/

FFOORR EEUU CCOOMMPPLLIIAANNCCEE

SE1 (WCM):

Hereby, Marquardt GmbH declares that the radio equipment type

SE1 is in compliance with Directive 2014/53/EU.

The full text of the EU declaration of conformity is available at the

following internet address: https://www.polaris.com/en-us/radio-

conformity/

Technical Information

Operating frequency: 21.85 kHz

Maximum field strength: <42 dBµA/m @ 10 m

Manufacturer and Address:

Marquardt GmbH

Schloss-Str. 16

78604 Rietheim-Weilheim

GERMANY

SK1 (Keyfob):

Hereby, Marquardt GmbH declares that the radio equipment type

SK1 is in compliance with Directive 2014/53/EU.

The full text of the EU declaration of conformity is available at the

following internet address: https://www.polaris.com/en-us/radio-

conformity/

Technical Information

Frquency band: 433.05 – 434.70 MHz

Maximum output power: < 10 mW

Manufacturer and Address:

Marquardt GmbH

Schloss-Str. 16

78604 Rietheim-Weilheim

GERMANY

WARNING

This product contains a lithium button cell. If the button cell is

swallowed, severe internal burns can occur within a mere two

hours and lead to death. Keep new or removed batteries away

from children. If the battery compartment does not close

securely, discontinue use and keep away from children. If you

think that batteries have been swallowed or are stuck in any part

of the body, seek medical help immediately.

FFOORR UU..SS.. CCOOMMPPLLIIAANNCCEE

NOTICE:

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including

interference that may cause undesired operation.

SAFETY

Changes or modifications made to this equipment not expressly

approved by Marquardt GmbH may void the FCC authorization to

operate this equipment.

Radiofrequency radiation exposure Information:

The radiated output power of the device is far below the FCC radio

frequency exposure limits. Nevertheless, the device shall be used

in such a manner that the potential for human contact during

normal operation is minimized.

FFOORR CCAANNAADDIIAANN CCOOMMPPLLIIAANNCCEE

NOTICE:

This device complies with Part 15 of the FCC Rules and with

Industry Canada license-exempt RSS standard. Operation is

subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including

interference that may cause undesired operation.

Le présent appareil est conforme aux CNR d'Industrie Canada

applicables aux appareils radio exempts de licence. L'exploitation

est autorisée aux deux conditions suivantes:

1. l'appareil ne doit pas produire de brouillage, et

2. l'appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d'en compromettre le

fonctionnement.

FFOORR MMEEXXIICCOO CCOOMMPPLLIIAANNCCEE

Model SK1:

RLVPOSK19-1418

Model SE1:

RLVPOSE19-1419

GGRROOSSSS VVEEHHIICCLLEE WWEEIIGGHHTT RRAATTIINNGG ((GGVVWWRR))

WARNING

Exceeding the gross vehicle weight rating of your motorcycle can

reduce stability and handling and could cause loss of control.

NEVER exceed the GVWR of your motorcycle.

The maximum load capacity of your motorcycle is the maximum

weight you may add to your motorcycle without exceeding the

GVWR. This capacity is determined by calculating the difference

between your motorcycle’s GVWR and wet weight.

Refer to the Specifications section of this manual or the

Manufacturing Information/VIN label on the motorcycle frame for

model-specific information.

When determining the weight you will be adding to your

motorcycle, and to ensure you do not exceed the maximum load

capacity, include the following:

• Operator body weight

• Passenger body weight

• Weight of all rider’s apparel and items in or on apparel

SAFETY

• Weight of any post-production accessories and their contents

• Weight of any additional cargo on the motorcycle

RREEPPOORRTTIINNGG SSAAFFEETTYY DDEEFFEECCTTSS

If you believe that your vehicle has a defect that could result in a

crash or cause injury or death, you should immediately inform the

National Highway Traffic Safety Administration (NHTSA) in

addition to notifying INDIAN MOTORCYCLE in writing.

If NHTSA receives similar complaints, it may open an investigation,

and if it finds that a safety defect exists in a group of vehicles, it

may order a recall and remedy campaign. However, NHTSA cannot

become involved in individual problems between you, your

INDIAN MOTORCYCLE dealer or Indian Motorcycle Company.

To contact NHTSA, or obtain other information about motor vehicle

safety, you may either call the Vehicle Safety Hotline toll-free at 1-

888-327-4236 (TTY: 1-800-424-9153), visit the NHTSA web site at

www.safercar.gov, or write to:

ADMINISTRATOR, NHTSA

1200 New Jersey Avenue, SE

West Building

Washington, DC 20590

SSAAFFEETTYY AANNDD IINNFFOORRMMAATTIIOONN LLAABBEELLSS

VVEEHHIICCLLEE IIDDEENNTTIIFFIICCAATTIIOONN NNUUMMBBEERR ((VVIINN))

The Vehicle Identification Number (VIN) label

is stamped on the

right side of steering head.

SAFETY

VVEEHHIICCLLEE EEMMIISSSSIIOONN CCOONNTTRROOLL IINNFFOORRMMAATTIIOONN

((VVEECCII))

The Vehicle Emission Control Information (VECI) label

located on the left-hand side of the motorcycle.

NNOOIISSEE EEMMIISSSSIIOONN CCOONNTTRROOLL IINNFFOORRMMAATTIIOONN

The Noise Emission Control Information label

is located on the

left-hand side of the motorcycle.

SAFETY

OOPPEERRAATTOORR WWAARRNNIINNGG//FFUUEELL RREECCOOMMMMEENNDDAATTIIOONN

The Operator Warning/Fuel Recommendation safety label

located on the fuel tank.

WARNING

• Read Owner’s Manual and, during use, follow all safety

precautions.

• Always wear an approved helmet, eye protection and protective

clothing.

• If your Owner’s Manual is missing, contact an Indian Motorcycle

dealer for a replacement.

Never overfill fuel tank. Fuel level should not rise into fill neck

funnel. Overfilling may result in degraded performance of engine

and evaporative emission control system.

PREMIUM UNLEADED FUEL RECOMMENDED 91 OCTANE

MINIMUM

SAFETY

SSHHOOCCKK PPRREESSSSUURREE WWAARRNNIINNGG

The Shock Pressure Warning

is located under the side cover.

Total Cargo + Riders (lbs) Adjustment Setting CAUTION: DO NOT

USE IMPACT TOOLS

OR EXCEED 10 FT-LBS

OF TORQUE WHEN

ADJUSTING. DAMAGE

TO COMPONENTS

MAY OCCUR.

0 - 175 1

175 - 250 2

250 - 325 3

325 - 425 4

425 - 500 5

CCAARRGGOO LLIIMMIITT WWAARRNNIINNGG

The Cargo Limit warning label

is located inside the saddlebag.

WARNING

CARGO LIMIT: 10kg/22.0 lbs.

Including optional lid rack cargo. Lid rack cargo limit 2.2 kg/5.0

lbs. Including any optional accessory. Distribute weight evenly on

both sides of the vehicle. Total weight of rider, passenger,

accessories, and cargo must not exceed gross vehicle rating in

owner’s manual.

WARNING

Fairing Storage Cargo Limit: 1.5 lbs/0.7 kg (Per Compartment)

SAFETY

WWIINNDDSSHHIIEELLDD WWAARRNNIINNGG

The windshield warning label u

is located on the vehicle’s

windshield.

ATTENTION: This item to be removed by customer only.

WARNING

• Do not ride with a damaged, loose, or improperly fitted

windshield/wind-deflector. These conditions can reduce

visibility, affect handling, or cause a loss of control.

• Regularly check the parts for damage and looseness. If you

encounter an issue, contact your dealer.

• Windshields/wind-deflectors will not protect the rider in a

collision.

• Dark/Smoked wind-deflectors will reduce visibility in low-light

riding conditions.

CAUTION

• Brake fluid and alcohol will permanently damage the

polycarbonate windshield.

• Do not clean the windshield/wind-deflector with glass cleaners

or rain protective products.

CLEANING

• Clean windshield or wind-deflector with a soft cloth and plenty

of warm water. Dry with a soft clean cloth. Remove minor

scratches with a quality plastic polishing compound.

• See windshield/wind-deflector installation instructions and the

Owner’s Manual for complete instructions on the proper care of

your windshield or wind-deflector.

SAFETY

TTOOGGGGLLEE SSWWIITTCCHHEESS

All models are equipped with toggle switches on the front side of

the left q

and right handlebar controls.

The power switch must be ON for the toggle switches to function.

Use the right-hand switch to navigate through menus or accept

dialog boxes on the Ride Command display. Use the left-hand

switch to back out of menus, decline dialog boxes, hang up phone

calls, and toggle through display screens.

SSWWIITTCCHH SSYYMMBBOOLLSS

SYMBOL SWITCH DESCRIPTION

Horn Switch Press the horn switch to sound the horn.

High Headlight

Beam Switch

The high headlight beam switch activates the high

headlight beam. See page 31.

Low Headlight

Beam Switch

The low headlight beam switch activates the low

headlight beam. Press down momentarily to

activate Flash to Pass. See page 31.

Turn Signal

Switch

Move the switch to the left to activate the left turn

signals. Move the switch to the right to activate the

right turn signals. A signal will deactivate

automatically when speed or distance reach

predetermined levels. To cancel a signal manually,

move the switch to the center position and push it

inward.Momentary Feature: Move the turn signal

switch left or right and hold it in that position for at

least one second. The momentary feature will

activate and the signal will then cancel when the

switch is released.

Emergency

Flasher Switch

(Hazard Switch)

The hazard switch activates and cancels the

emergency flashers. See page 29.

Screen List

Select Switch

The Screen List Select Switch (if equipped) is used

to navigate through rider screens.

INSTRUMENTS, FEATURES AND CONTROLS

SYMBOL SWITCH DESCRIPTION

Audio Control

Switch

The Audio Control Switch allows users to control

the audio system features from the left control

block.

Stop Switch Press the bottom of the switch (RUN) to allow the

engine to start and run. Press the top of the switch

(STOP) to stop the engine. See page 29.

Starter Switch Use the starter switch to start the engine. The

engine stop/run switch must be in the RUN

position. See page 29.

Power Switch On cruiser models the power switch is located

above the instrument cluster. On touring models

the starter switch is located on the fairing, below

the tachometer. Press and release the power switch

to enable or disable all electrical power to the

vehicle. See page 28.

Left-Hand

Trigger Switch

Use the left-hand switch to back out of menus,

decline dialog boxes, hang up phone calls, and

toggle through display screens. See page 27.

Right-Hand

Trigger Switch

Use the right-hand switch to navigate through

menus or accept dialog boxes on Ride Command

display.

SSWWIITTCCHHEESS

PPOOWWEERR SSWWIITTCCHH

The power switch is located on the dash. Press and release the

power switch to enable or disable all electrical power to the

vehicle. The power switch does not have to be on to start the

engine.

To disable all electrical power if the motorcycle is moving and the

engine is running, press and hold the power switch for more than

three (3) seconds.

TIP

To save battery power, the vehicle will automatically power off

after five minutes of inactivity. Automatic power down can be

overridden on bikes with Ride Command through the settings

menu.

TIP

The headlights and any accessories plugged into power ports

will remain on until the power switch is turned off.

INSTRUMENTS, FEATURES AND CONTROLS

SSPPEEEEDDOOMMEETTEERR

The speedometer displays forward vehicle speed in either miles

per hour or kilometers per hour.

TTAACCHHOOMMEETTEERR

The tachometer displays engine speed in revolutions per minute

(RPM). A red line on the face of the gauge indicates the maximum

safe engine speed.

Excessive engine speed can cause engine damage or failure,

which could result in serious injury or death. Do not allow engine

speed to exceed the red line.

FFUUEELL GGAAUUGGEE DDIISSPPLLAAYY

The fuel gauge displays fuel level. For the most accurate reading,

sit on the motorcycle and bring it to the upright position.

The segments of the fuel gauge show the level of fuel in the fuel

tank. When the last segment clears, a low fuel warning is activated.

All segments including the fuel icon will flash. Refuel promptly.

RREEAARR CCYYLLIINNDDEERR DDEEAACCTTIIVVAATTIIOONN ((IIFF EEQQUU

Designed as an aid to reduce engine and exhaust heat to the rider,

Rear Cylinder Deactivation turns off the rear cylinder when the

engine gets hot.

The following condition must be met for Rear Cylinder

Deactivation to be enabled.

• Engine must be up to operating temperature

• Ambient Temperature must exceed 15°C (59°F)

• Engine speed must remain below 1000 rpm

• Gear position must be 1, 2, or N

• Throttle must be in the closed position (0% throttle)

Cylinder Deactivation can be turned off by accessing the settings

menu in the drop-down from the top of the screen. Cylinder

Deactivation controls are in the Vehicle menu. When Rear Cylinder

Deactivation is functioning, an icon will illuminate at the top of the

Ride Command display screen.

INSTRUMENTS, FEATURES AND CONTROLS

RRIIDDEE CCOOMMMMAANNDD BBUUTTTTOONNSS

BUTTON FUNCTION

Rider Screen Press the Rider Screen button to access the

customizable split screen menu system,

access to ride data, vehicle status, and

vehicle information.

Navigation Press the Navigation button to access Ride

Command navigation features (if equipped),

find directions, and look up addresses, gas

stations, and other points of interest.

Controls Press the Controls Button to access the

INDIAN Badge Panel and additional settings.

Device

Manager

Press the Device Manger button to pair a

phone or headset to the Ride Command

display.

Audio Press the Audio Button to change the audio

source, adjust volume level, and set radio

presets.

RRIIDDEERR SSCCRREEEENN

The Rider Screen is a customizable

split screen menu system that

provides unique access to ride

data, vehicle status, and vehicle

information. The Rider Screen also

provides easy access to other

often used features, such as Audio

controls, Bluetooth features, and

Maps.

NNAAVVIIGGAATTIIOONN

Press the Navigation button to

access Ride Command navigation

features (if equipped), find

directions, and look up addresses,

gas stations, and other points of

interest.

INSTRUMENTS, FEATURES AND CONTROLS

TTRRIIGGGGEERR SSWWIITTCCHHEESS

There are trigger switches located on the reverse side of both the

right and left e

switch cubes.

Use the trigger switches to do the following:

• Press the right trigger switch to confirm selection.

• Press the left trigger switch to back out of menu screens.

RRIIDDEE CCOOMMMMAANNDD RRIIDDEE MMOODDEESS

You can choose between three ride modes, Rain, Standard, or

Sport for an experience customized to your riding style. The

throttle map for each ride mode was designed with a specific

application in mind, resulting in one motorcycle with three distinct

personalities.

INSTRUMENTS, FEATURES AND CONTROLS

NOTE

For the ride mode to change the throttle must be fully

disengaged. If you change the ride mode while the throttle is

engaged, a spinning icon will appear indicating that the ride

mode has not yet changed. Once the throttle is disengaged the

icon will disappear and the ride mode will change.

RRAAIINN

Rain mode is ideal for rainy conditions, or when the road is wet.

The throttle response is decreased, giving you more control and

traction.

SSTTAANNDDAARRDD

Standard mode features a crisp throttle response and well-

balanced power delivery for responsive passing power and

predictable, slow-speed handling.

SSPPOORRTT

Sport mode is designed for situations when instant response is

needed. Sport mode quickens the throttle response and has a

more aggressive power delivery for increased acceleration.

TTRRAACCTTIIOONN CCOONNTTRROOLL

To disable the Traction Control, do the following:

1. Press the Menu/Control button to bring up the Control Panel.

2. Tap on the Traction Control toggle switch to disable Traction

Control.

INSTRUMENTS, FEATURES AND CONTROLS

3. A prompt will appear asking you to confirm that you want to

disable the Traction Control. Press DISABLE to confirm.

NOTE

Traction Control will not become disabled until vehicle speed is

at zero.

4. To re-enable Traction Control, press the Traction Control

toggle switch again.

NOTE

Traction Control is automatically enabled after every power cycle

of the bike.

RRIIDDEE CCOOMMMMAANNDD SSEETTTTIINNGGSS

From the Settings Menu you can view important details about your

vehicle and personalize your touchscreen display. The settings

menu is comprised of four categories: Information, General, Time,

and Vehicle.

GGEENNEERRAALL IINNFFOORRMMAATTIIOONN

From the Information settings menu you can view the following:

• Vehicle Identification Number (VIN)

• Mileage

• Installed Software Version

• Oil Change Interval

GGEENNEERRAALL SSEETTTTIINNGGSS

From the General settings menu you can do the following:

• Themes (Day/Night/Auto)

• Manage Bluetooth Devices

• Change the Language

• Set the Speed Units of Measure (MPH or KPH)

• Set the Temperature Units (F or C)

• Update Software

CCLLOOCCKK

From the Time Settings you can do the following:

• Set the Time Format (12 hour or 24 hour)

• Enable GPS Time (automatically sets the time to the time zone

you are currently in)

• Set Time (if GPS Time is not enabled)

VVEEHHIICCLLEE IINNFFOORRMMAATTIIOONN

From the Vehicle Settings you can do the following:

• Oil Life/ Service Reset

• Access Vehicle Diagnostics

INSTRUMENTS, FEATURES AND CONTROLS

UUSSBB PPOORRTT

The USB Port makes it easy to power devices, such as phones,

audio sources, or GPS units, in addition to allowing you to stream

music through the LCD display to your Bluetooth headset. On

models equipped with a Ride Command display, the USB port is

also used to update the display software. The USB port is located in

the right-hand storage compartment. For the latest software, go to

https://ridecommand.indianmotorcycle.com.

MMIISSFFIIRREE DDEETTEECCTTIIOONN

If a misfire is detected, the check engine indicator lamp will begin

to flash and fuel will be cut to the affected cylinder(s). The check

engine indicator lamp will continue to flash until the ignition switch

has been moved to the off position. Restarting the engine will clear

the flashing indicator and restore fuel to both cylinders. If another

misfire occurs, the check engine indicator lamp will resume

flashing and fuel will once again be cut to the affected cylinder(s).

After the 3rd misfire, P0314 misfire fault is determined & set, the

check engine light will remain on and fuel will be cut to the

affected cylinder(s). If this occurs, your INDIAN dealer can assist.

HHEEAATTEEDD GGRRIIPPSS HHEEAATT LLEEVVEELL SSEETTTTIINNGG ((IIFF

EEQQUUIIPPPPEEDD))

The heated grips heat level displays momentarily after changing

the heat level. A brief pop-up will appear on the touchscreen

display when heat level is changed.

INSTRUMENTS, FEATURES AND CONTROLS

BBAATTTTEERRYY CCHHAARRGGEE PPOORRTT//HHEEAATTEEDD GGEEAARR

PPLLUUGG

The Battery Charge Port/Heated Gear plug is located under the

left side panel.

HHEEAADDLLIIGGHHTTSS

The headlights automatically come on when the engine is started.

WARNING

Motorcycle riders must remain as visible as possible at all times.

To aid in this, the headlight must be on at all times. Do not modify

the ignition/headlight wiring to circumvent the automatic

headlight feature.

The headlights operate only when the engine is running. You can

use the high/low headlight beam switch to override this function

and allow the headlights to operate when the engine is not

running. Turn the power switch on, then toggle the high/low

headlight beam switch to turn the headlights on.

INSTRUMENTS, FEATURES AND CONTROLS

TTHHRROOTTTTLLEE CCOONNTTRROOLL GGRRIIPP

The throttle control grip is located on the right handlebar. Use the

throttle control grip to control engine speed.

While seated in the proper riding position:

• Roll the grip rearward q to open the throttle (increase engine

speed and power).

• Roll the grip forward w to close the throttle (decrease engine

speed and power), and cancel cruise control.

The control grip is spring loaded. When you release the grip, the

throttle returns to the idle position.

CCLLUUTTCCHH LLEEVVEERR

The clutch lever q is located on the left handlebar. Disengage the

clutch before shifting gears. For smooth clutch operation, pull the

lever quickly and release it in a brisk but controlled manner.

• To disengage the clutch, pull the lever toward the handlebar.

• To engage the clutch, release the lever in a brisk but controlled

manner.

INSTRUMENTS, FEATURES AND CONTROLS

GGEEAARR SSHHIIFFTT LLEEVVEERR

The gear shift lever is located on the left side of the motorcycle.

Operate the lever with your foot.

• Press downward on the toe lever to shift to a lower gear.

• Lift upward on the toe lever to shift to a higher gear.

• Release the lever after each gear shift.

• See page 72, for gear shifting procedures.

TTIIRREE PPRREESSSSUURREE MMOONNIITTOORRIINNGG SSYYSSTTEEMM

NOTICE

On models equipped with a Tire Pressure Monitoring System

(TPMS), the sensors are located 180° from the valve stem. Use

caution when servicing tires. To avoid damaging a sensor, break

the bead at the valve stem, then at 90° and 270° from the valve

stem as required.

On models equipped with TPMS, the pressure of each tire can be

viewed on the Ride Command display. If dashes display instead of

a pressure value while traveling above 15 MPH (24 km/h), the

system may not be functioning properly. See your dealer for

service.

The TPMS warning indicator will illuminate if low tire pressure is

detected. Always correct low tire pressure promptly. Always

inspect tire pressure and condition before each ride. See page 61.

The TPMS display may indicate an increase in tire pressure while

riding, a normal occurrence as tires warm up. Riding into colder

conditions may result in a drop in tire pressure as tires cool down.

Regardless of conditions, low tire pressures should always be

corrected promptly.

SSAADDDDLLEEBBAAGGSS

Do not exceed the weight limit of each saddlebag. Always

distribute weight evenly in each of the saddlebags. Refer to the

saddlebag/cargo warning label on or near the saddlebag for

cargo capacity.

Hard bag capacity is 22 lbs. (10 kg) of cargo per side.

INSTRUMENTS, FEATURES AND CONTROLS

HHAARRDD BBAAGG RREEMMOOVVAALL

1. Remove the side cover. See page 127.

2. Unlock the electric saddlebag locks (if equipped).

TIP

The provided key can also be used in the saddlebag latch

buttons to unlock the saddlebag lids.

3. Disconnect the saddlebag lock wiring near the seat q.

4. Press the lid latch release button and lift the lid.

5. Remove the saddlebag fastener bolts w.

6. Tilt the saddlebag away from the frame of the vehicle to remove

it.

7. To reinstall, place the hard bag in a fully seated position on the

muffler.

8. Insert saddlebag fastener bolts and torque to specification.

TORQUE

18 ft-lbs (24 Nm)

INSTRUMENTS, FEATURES AND CONTROLS

9. Reconnect the electrical wiring.

10. Reinstall the side panel, using care to avoid damaging

electrical wires.

WARNING

Improper saddlebag installation can result in loss of control,

accident and driving hazards for other motorists (if saddlebag

falls from the motorcycle). Always make sure saddlebag are

mounted properly.

SSIIDDEESSTTAANNDD

The sidestand is equipped with a safety switch that prevents

operation of the motorcycle if the sidestand is deployed.

WARNING

An improperly retracted sidestand could contact the ground and

cause a loss of control resulting in serious injury or death. Always

retract the sidestand fully before operating the motorcycle.

To park the motorcycle, swing the end of the sidestand downward

and away from the motorcycle until it is fully extended. Always

turn the handlebars to the left for maximum stability. Lean the

motorcycle to the left until the sidestand firmly supports the

motorcycle.

CAUTION

If the motorcycle weight is not resting on the sidestand, it will not

lock. In this situation, any movement of the motorcycle could

cause the sidestand to retract slightly. If the sidestand is not in the

full forward position when the motorcycle weight is rested on it,

the motorcycle could fall over, possibly causing injury and

damage to the motorcycle.

To retract the sidestand, straddle the motorcycle and bring it to the

fully upright position. Swing the end of the sidestand upward and

toward the motorcycle until it is fully retracted.

INSTRUMENTS, FEATURES AND CONTROLS

• If the lamp continues to illuminate after vehicle speed exceeds 6

MPH (10 km/h), the ABS system is not functioning. See your

INDIAN MOTORCYCLE dealer or other dealer promptly for

service.

• Operating with non-recommended tires or improper tire

pressure may reduce the effectiveness of the anti-lock brake

system. Always use the recommended size and type of tires

specified for your vehicle. Always maintain the recommended

tire pressure.

• The anti-lock brake system will not prevent wheel lockup, loss of

traction or loss of control under all conditions. Always adhere to

all safe motorcycle-riding practices as recommended.

• It is not unusual to leave tire marks on the road surface during a

hard braking event.

• The anti-lock brake system does not compensate for or reduce

the risks associated with:

– excessive speed

– reduced traction on rough, uneven or loose surfaces

– poor judgment

– improper operation

FFRROONNTT BBRRAAKKEE LLEEVVEERR

The front brake lever is located on the right handlebar. This lever

controls only the front brakes. The front brakes should be applied

simultaneously with the rear brakes. To apply the front brake, pull

the lever toward the handlebar. See page 74 for braking

procedures. Front brake lever reach (distance to the hand grip) is

adjustable.

INSTRUMENTS, FEATURES AND CONTROLS

1. the lever away from the hand grip. The Gently push and hold

adjuster wheel q is located on top of the lever.

2. To increase reach distance, rotate the adjuster to a lower

number.

3. To decrease the reach distance, rotate the adjuster to a higher

number.

RREEAARR BBRRAAKKEE PPEEDDAALL

The rear brake pedal q is located on the right side of the

motorcycle. Press downward on the rear brake pedal to apply the

rear brake.

WARNING

Resting your foot on the brake pedal will cause excessive and

premature wear of brake pads and reduced braking efficiency,

which could result in severe injury or death.

See page 74 for braking procedures.

FFUUEELL CCAAPP

The fuel filler cap q is located on the center of the fuel tank.

To open the fuel cap, do the following:

INSTRUMENTS, FEATURES AND CONTROLS

NOTE

The fuel cap automatically locks when you start the engine.

1. Press the center of fuel cap unlock button located on the lower

right fairing.

2. Press the fuel cap release button w (previous page) to release

spring loaded cap.

NOTE

The fuel cap will not release if the engine is running.

3. See page 68 for fueling instructions.

4. To close, press fuel cap downward until it clicks.

MMAANNUUAALL OOVVEERRRRIIDDEE

NOTE

The manual override process should only be used in case of

system lock issues or loss of bike electric power. You should use

the electric unlock process detailed on page 54, or have a

authorize dealer repair the system if it does not work. The

manual override process shows you how to perform a 1 time

manual reset of the cap lock to add fuel if stranded.

INSTRUMENTS, FEATURES AND CONTROLS

EELLEECCTTRRIICCAALL IINNSSPPEECCTTIIOONNSS

Turn the power switch on and move the stop/run switch to RUN

before performing the following electrical inspections. Turn the

power switch off after completing these inspections. If inspection

of any electrical item reveals component failure, repair or replace

the component before operating the motorcycle.

ITEM INSPECTION PROCEDURE

Head-

lamp

Move the headlight switch from low beam to high beam

to turn the lights on and verify operation of both

beams. Start the engine. Switch to high beam. Verify

that the high beam indicator comes on and that lamp

brightness increases. Press and hold the low beam

switch to verify “Flash to Pass” functionality.

Tail-

lights/

Brake-

light

Verify that the taillights and license plate light

illuminate. Verify that the taillight lamps increase in

brightness when the front brake lever is applied and

also when the rear brake pedal is applied.

Turn

Signals

Move the turn signal switch to the left. Verify that front

and rear left turn signals flash, as well as the

corresponding light on the indicator panel. Move the

switch to the center position and push it inward to

cancel the signal. Verify that the signals and the

indicator light stop flashing. Repeat the procedure for

the right turn signals.

Emer-

gency

Flashers

Press and hold the turn signal switch in for 1 second to

activate flashers. Verify that all four turn signals flash,

as well as the lamps on the indicator panel. Turn the

flashers off. Verify that all signals and indicator lamps

stop flashing.

ITEM INSPECTION PROCEDURE

Horn Press the horn switch. Verify that the horn sounds

loudly.

Neutral

Indica-

tor

Place the transmission in neutral. Verify that the neutral

indicator lamp illuminates and that the letter "N"

displays in the gear position display.

Low Oil

Pressure

Display

Start the engine. Verify that the low oil pressure

indicator is not illuminated.

Engine

Stop/

Run

Switch

Start the engine. Move the stop/run switch to the STOP

position. Verify that the engine stops.

GGEENNEERRAALL IINNSSPPEECCTTIIOONNSS

ITEM INSPECTION PROCEDURE

Engine Oil Check the oil level. See page 59.

Fuel Check the fuel level. See page 35.

Coolant Check coolant level. See page 104.

Fluid Leaks Check the vehicle and the ground/floor for any fuel, oil,

coolant, or hydraulic fluid leaks.

Tires Inspect condition, pressure and tread depth. See page

61.

Brake

Operation

Inspect pedal and lever movement.

Brake Fluid

Levels

Check front and rear brake fluid levels.

PRE-RIDE INSPECTIONS

ITEM INSPECTION PROCEDURE

Brake

Components

Inspect hoses and connections.

Throttle Inspect hand grip and throttle movement.

Clutch Check lever operation and freeplay.

Front

Suspension

Check for leaks, debris and damage.

Steering Check for smooth operation by turning handlebars full

left and full right.

Rear

Suspension

Inspect for leaks.

Ride Height Make sure preload is adjusted properly for load.

Rear Drive

Belt

Check for wear or damage. Check drive belt tension. See

page 105.

Sidestand Verify smooth operation, inspect pivot bolt and spring.

Fasteners Inspect for loose, damaged or missing fasteners.

Mirrors Adjust for proper rear view.

Trunk/

Saddlebags

If equipped, make sure the trunk and saddlebags are

properly installed and that lids are securely closed.

EENNGGIINNEE OOIILL LLEEVVEELL

With the semi-dry sump lubrication system, the engine oil level on

the dipstick will fluctuate, depending on the motorcycle’s position

and engine temperature when checked. To ensure a proper

reading of the engine oil level, follow all inspection procedures

closely.

WARNING

Operating with insufficient, deteriorated or contaminated engine

oil will cause accelerated wear and may result in engine or

transmission seizure, which could result in loss of control and

serious injury or death. Check the oil level frequently.

Always check the oil after running a cold engine at idle for 30

seconds. The oil fill/dipstick is located on the left side of the

motorcycle. Always use the recommended oil. See page 155.

1. Position the motorcycle on level ground in the fully upright and

centered position.

2. Start the engine (from cold) and allow it to idle for 30 seconds.

Stop the engine.

PRE-RIDE INSPECTIONS

3. Remove the dipstick q and wipe it clean.

4. Thread the dipstick until fully seated.

5. Remove the dipstick and view the oil level.

NOTICE

Do not overfill. Overfilling can result in loss of engine

performance and an oil-saturated air filter. Use a suction device

to remove excess oil if overfilled.

6. Add the recommended oil as needed to bring the level within

the safe operating range (anywhere between the two marks on

the dipstick). If the oil level on the dipstick is anywhere in the

safe range, do not add oil. Oil should be added only if the

proper oil check procedure is followed and the level is below

safe mark.

NOTICE

Oil should be added only if the proper oil check procedure is

followed and the level is below the safe mark.

TIP

The approximate volume between the FULL w and ADD e marks

on the dipstick is 0.5 qts. (.47 L).

7. Reinstall the dipstick securely.

8. Repeat steps 3–7 to ensure the level is within the safe operating

range.

PRE-RIDE INSPECTIONS

FFRROONNTT BBRRAAKKEE FFLLUUIIDD LLEEVVEELL

1. Bring the motorcycle to the fully upright position. Position the

handlebars so that the fluid reservoir is level.

2. View the fluid level through the sight glass q. The fluid should

be clear. Replace cloudy or contaminated fluid.

3. The fluid level should be above the minimum indicator mark w

in the sight glass.

4. If the fluid level is low, inspect brake pads as outlined on page

122. If pads are not worn beyond the service limit, inspect the

brake system for leaks. Check for signs of brake fluid leaks

around hoses, fittings, reservoir, and brake calipers.

5. Add brake fluid if necessary. See page 120.

FFRROONNTT BBRRAAKKEE LLEEVVEERR

1. Pull the front brake lever toward the handlebar and hold it. The

lever should move freely and smoothly. The lever should feel

firm and continue to feel firm until released.

2. Release the lever. It should return to its rest position quickly

when released.

3. If the front brake lever fails to perform as stated, service the

brake lever before riding.

RREEAARR BBRRAAKKEE PPEEDDAALL

1. Press downward on the rear brake pedal. It should move freely

and smoothly. The pedal should feel firm and continue to feel

firm until released.

2. Release the pedal. It should return to its rest position quickly

when released.

3. If the rear brake pedal fails to perform as stated or travels too

far before beginning to engage the brake, service the brakes

before riding.

PRE-RIDE INSPECTIONS

RREEAARR BBRRAAKKEE FFLLUUIIDD LLEEVVEELL

The rear brake fluid reservoir is located near the rear brake pedal.

View the reservoir level from the right side of the vehicle.

1. Position the motorcycle on level ground in the fully upright

position.

2. View the brake fluid through the reservoir

3. The fluid should be clear. Replace cloudy or contaminated

fluid.

4. The fluid level should be above the minimum indicator mark

on the reservoir body. Add brake fluid as needed.

BBRRAAKKEE LLIINNEESS

Inspect all brake hoses and connections for dampness or stains

from leaking or dried fluid. Tighten any leaking connections to the

proper torque values and replace components as necessary. See

the INDIAN MOTORCYCLE Service Manual or an authorized INDIAN

MOTORCYCLE dealer or other qualified dealer.

WARNING

Brake fluid leaks or low brake fluid levels could cause brake

system failure, which could result in serious injury or death. Do

not operate the vehicle with low brake fluid levels or when leaks

are evident (dampness or stains from dried fluid). See your

authorized INDIAN MOTORCYCLE dealer or other qualified

dealer.

TTHHRROOTTTTLLEE

Rotate the throttle control grip. It should rotate smoothly from the

rest position to the completely open position. It should return to

the rest position quickly when released.

PRE-RIDE INSPECTIONS

FFAASSTTEENNEERRSS

1. Inspect the entire motorcycle chassis and engine for loose,

damaged or missing fasteners.

2. Tighten loose fasteners to the proper torque. See the INDIAN

MOTORCYCLE Service Manual or an authorized INDIAN

MOTORCYCLE dealer or other qualified dealer.

TIP

Always replace stripped, damaged or broken fasteners before

riding. Use genuine INDIAN MOTORCYCLE fasteners of equal

size and strength.

FFRROONNTT SSUUSSPPEENNSSIIOONN

Inspect the front forks for oil leaks or damage, and verify smooth

suspension operation. See page 111.

SSTTEEEERRIINNGG

1. On level ground, straddle the motorcycle and bring it to the

fully upright position. Turn the handlebars from stop to stop.

The action should be smooth, but not loose.

2. Make sure wires, hoses and control cables do not interfere with

smooth steering.

RREEAARR SSUUSSPPEENNSSIIOONN

Check the rear shock absorber mounting and inspect for leaks.

See your dealer for service if you discover leaks or malfunction of

any kind. See page 110.

WARNING

Inadequate ground clearance could result in components

contacting the ground, causing loss of control and serious injury

or death. Always ensure ground clearance is at specification.

RREEAARR DDRRIIVVEE BBEELLTT

1. Check drive belt tension. See page 106

TIP

The drive belt system must be cool, clean and dry to accurately

measure belt tension (deflection). Do not measure belt tension

when the belt or drive system is wet or when it is hot (such as

immediately after riding).

2. Check the drive belt for debris.

3. Inspect drive belt condition. See page 106. If you discover

cracks, broken teeth or frayed edges, replace the drive belt

before riding. See the INDIAN MOTORCYCLE Service Manual or

an authorized INDIAN MOTORCYCLE dealer can assist.

PRE-RIDE INSPECTIONS

FFUUEELL LLEEVVEELL

For the most accurate reading, sit on the motorcycle and bring it to

the upright position before turning it on.

The segments of the fuel gauge show the level of fuel in the fuel

tank. When the last segment clears, a low fuel warning is activated.

All segments including the fuel icon will flash. Refuel promptly.

PRE-RIDE INSPECTIONS

OOPPEERRAATTIIOONN

OOVVEERRVVIIEEWW

The operation section of this manual describes how to ensure

maximum performance and longevity through the proper care and

operation of your motorcycle.

Important areas covered by the operation section include:

• Engine Break-In

• Fueling

• Starting the Engine

• Shifting Gears

• Using Cruise Control (if

equipped)

• Accelerating

• Braking

• Stopping the Engine

• Parking

TIP

Even if you’re an experienced motorcycle operator or passenger,

read all of the safety information in this manual before operating

the motorcycle. See page 9.

EENNGGIINNEE BBRREEAAKK--IINN

The engine break-in period for your motorcycle is the first 500

miles (800 km) of operation. During this break-in period, critical

engine parts require special wear-in procedures so they seat and

mate properly. Read, understand and follow all break-in

procedures to ensure the long-term performance and durability of

your engine.

NOTICE

Failure to properly follow the engine break-in procedures

outlined in this manual can result in serious damage to the

engine. Avoid full throttle operation and other conditions that

may place an excessive load on the engine during the break-in

period.

The more cautiously you treat your motorcycle during the break-in

period, the more satisfied you will be with its performance later

on. Overloading the engine at low RPM and/or running the engine

prematurely at high RPM may result in damage to the pistons and/

or other engine components.

Observe the following precautions during the break-in period:

• Upon initial start-up, do not allow the engine to idle for long

periods as overheating can occur.

• Avoid fast starts with wide open throttle. Drive slowly until the

engine warms up.

• Avoid running the engine at extremely low RPM in higher gears

(lugging the engine).

• Drive within the recommended operating speeds and gears.

OPERATION

1. Press the center of the fuel cap unlock button located on the

lower right fairing q.

2. Press the full cap release button w to access the fuel tank.

3. Insert the fuel nozzle into the fuel tank filler neck.

4. Add fuel to the tank until it crests the circular-shaped opening

in the filler neck column. The tank is full at this level. Do not

overfill the fuel tank. Fuel level should not rise into the fill neck.

Overfilling may result in degraded performance of engine and

evaporative emissions control system.

5. Always securely close the fuel cap before remounting the

motorcycle.

OPERATION

NOTICE

Fuel can damage painted surfaces and plastic parts. If gasoline

spills on the any part of the motorcycle, immediately rinse it off

with water or wipe it dry with a clean cloth.

PPRRIIMMIINNGG TTHHEE FFUUEELL SSYYSSTTEEMM

If the motorcycle runs out of fuel, prime the fuel system before

attempting to restart the engine.

1. Fill the fuel tank.

2. Turn the power switch on.

3. Move the engine stop/run switch to the RUN position.

4. Allow the fuel pump to run until it stops (about 2 seconds).

5. Move the engine stop/run switch to the STOP position.

6. Repeat steps 3–5 five times.

7. Move the engine stop/run switch to the RUN position.

8. Start the engine. See page 70.

SSTTAARRTTIINNGG TTHHEE EENNGGIINNEE

The starter interlock system allows the engine to be started only

when the transmission is in neutral, or when the transmission is in

gear with the clutch disengaged (clutch lever pulled in). The

engine should NEVER start in any gear except neutral if the

sidestand is down. See page 50.

TIP

If the motorcycle runs out of fuel, prime the system before

attempting to restart the engine.

1. Perform the Pre-Ride Inspections. See page 57. Properly secure

any cargo.

2. Straddle the motorcycle and bring it to the fully upright

position. Retract the sidestand.

TIP

When the electrical system is activated with either the power

switch or the starter switch, the key fob must be within range.

See page 30.

3. Move the engine stop/run switch to the RUN position.

4. Shift the transmission to neutral.

5. Apply the front brakes. Disengage the clutch (pull the clutch

lever fully toward the handlebar).

6. The motorcycle may be electrically activated by pressing

either the starter switch or power switch. Then with the throttle

closed, press and release the starter switch to start the engine.

The starter motor will crank until the engine starts, but no more

than 3 seconds. If the engine does not start, wait five seconds

and try again.

OPERATION

7. DO NOT open the throttle while If starting a COOL engine,

starting. Idle speed is computer controlled and idle speed will

adjust automatically depending on engine temperature and air

temperature. Allow the engine to warm up for one minute

minimum at low RPM after starting. Do not run the engine above

2500 RPM. If starting a WARM engine, DO NOT open the throttle

while starting.

8. If either the check engine indicator or the low oil pressure

indicator (or display) remains on after the engine starts, stop

the engine immediately. Refer to the low oil pressure indicator/

display information on page 33.

CAUTION

Operating an engine with a misfire or non-firing cylinder can

overheat the catalytic converter, which could result in catalytic

converter damage and loss of emission control. DO NOT

OPERATE the motorcycle if a misfire or non-firing cylinder exists.

9. Leave the throttle closed and allow the engine to idle. Idle

speed will gradually slow to normal as the engine warms to

operating temperature.

TIP

Do not rev the engine or put the transmission in gear

immediately after starting the engine. Allow the engine to idle for

about 30 seconds after a warm start or at least one minute after a

cold start (longer in cold weather). This will allow oil to reach all

areas before the engine is put under load.

NOTICE

Do not run the engine at high RPM with the clutch disengaged or

the transmission in neutral. Maximum safe engine speed is 5400

RPM. Never exceed the maximum safe RPM as this could result in

serious engine damage.

OPERATION

SSHHIIFFTTIINNGG GGEEAARRSS

WARNING

Forced shifting (without clutch lever pulled in) could cause

damage to the engine, transmission and drive train. Such damage

could cause loss of control, which could result in serious injury or

death. Always pull the clutch lever fully toward the handlebars to

disengage the clutch before shifting gears.

This motorcycle is equipped with a six-speed transmission.

Neutral is located between first and second gear.

Press downward on the toe lever to shift to a lower gear. Lift

upward on the toe lever to shift to a higher gear. Release the clutch

lever after each gear shift.

Shifting to neutral is easiest if the motorcycle is rolling slowly. To

shift from first gear to neutral, gently lift the toe lever a half stroke.

TIP

The transmission is in neutral if you can move the motorcycle

forward or rearward freely without disengaging the clutch. If the

power switch is ON, the neutral indicator illuminates when the

transmission is in neutral.

SSHHIIFFTTIINNGG GGEEAARRSS WWHHIILLEE SSTTAATTIIOONNAARRYY

To locate neutral when the motorcycle is stationary, use one of the

following techniques to load and unload the transmission:

1. With the clutch disengaged (lever pulled inward), shift into

neutral while rocking the motorcycle forward and rearward.

2. With the transmission in first gear, gently release the clutch

until it just begins to engage. Apply upward pressure on the toe

lever and quickly pull the clutch inward.

NOTE

There is a Neutral indicator light on the instrument cluster.

OPERATION

RREECCOOMMMMEENNDDEEDD SSHHIIFFTT PPOOIINNTTSS

UUPPSSHHIIFFTTIINNGG ((AACCCCEELLEERRAATTIINNGG))

GEAR CHANGE RECOMMENDED SPEED

1 to 2 15 MPH (24 km/h)

2 to 3 25 MPH (40 km/h)

3 to 4 35 MPH (56 km/h)

4 to 5 45 MPH (72 km/h)

5 to 6 50 MPH (80 km/h)

DDOOWWNNSSHHIIFFTTIINNGG ((DDEECCEELLEERRAATTIINNGG))

GEAR CHANGE RECOMMENDED SPEED

6 to 5 40 MPH (64 km/h)

5 to 4 35 MPH (56 km/h)

4 to 3 25 MPH (40 km/h)

3 to 2 15 MPH (24 km/h)

2 to 1 10 MPH (16 km/h)

BBRRAAKKIINNGG

Always allow sufficient stopping distance so that brakes can be

applied gradually.

TIP

Applying slightly more front brake than rear brake generally

provides the best braking performance.

1. To slow the motorcycle with the brakes, close the throttle and

apply the front and rear brakes evenly and gradually.

TIP

If the anti-lock brakes engage during a braking event, the rider

will feel pulsing at the brake levers. Continue to apply steady

pressure to the brakes for the best stopping performance.

2. As the motorcycle slows, disengage the clutch, or downshift

each time vehicle speed reaches a downshift point.

WARNING

Braking improperly could result in loss of control, which could

result in serious injury or death. Avoid braking abruptly. Always

apply the brakes gradually, especially on wet, slippery or other

low traction surfaces. Avoid braking in a curve or turn. Bring the

motorcycle to the upright position before applying the brakes.

OPERATION

AACCCCEELLEERRAATTIINNGG

Accelerate by opening the throttle (rolling the throttle control grip

rearward). For even acceleration, open the throttle with a smooth,

continuous motion. When you reach the recommended speed for

upshifting, shift up one gear.

WARNING

Accelerating abruptly could cause your body to shift rearward

suddenly, which could result in loss of control. Accelerating

abruptly could also cause loss of control on low traction surfaces.

Loss of control could result in serious injury or death. Always

accelerate gradually, especially on wet, slippery or other low

traction surfaces.

SSTTOOPPPPIINNGG TTHHEE EENNGGIINNEE

Before stopping the engine, bring the motorcycle to a complete

stop. Shift to neutral or disengage the clutch.

WARNING

Stopping the engine with the transmission in gear while the

motorcycle is moving could cause loss of rear wheel traction or

engine and transmission damage, which could cause loss of

control and serious injury or death. Always stop the engine after

the motorcycle is fully stopped and the transmission is in neutral.

If the engine stops unexpectedly while the motorcycle is moving,

guide the motorcycle to a safe location off the road and away

from traffic. Turn the power switch off.

1. When fully stopped, shift into neutral.

2. Move the engine stop/run switch to the STOP position.

3. Turn the power switch off.

UUSSIINNGG CCRRUUIISSEE CCOONNTTRROOLL

The cruise control switches are located on the right handlebar.

Read this section and understand how to safely operate this feature

before using the cruise control.

Cruise control can be activated and adjusted from the right control

using the Cruise Control Switch

OPERATION

DDEECCEELLEERRAATTEE

While cruise control is engaged, tap and release left on the cruise

control switch to decrease speed in approximately 1 MPH (1-2 km/

h) increments. Press and hold left on the cruise control switch to

decelerate to a new set speed (resets when switch is released), or

to the minimum cruise speed of 20 MPH (32 km/h).

CCAANNCCEELL CCRRUUIISSEE CCOONNTTRROOLL

To temporarily cancel the cruise control and allow use of the

resume feature:

• Apply the brakes, or

• Pull the clutch lever in, or

• Roll the throttle grip forward past the idle position

To cancel the cruise control and erase the set speed from memory,

press the cruise on/off switch.

PPAARRKKIINNGG

Choose a firm level surface to park the motorcycle.

1. When fully stopped, shift into neutral.

2. Stop the engine.

3. Fully extend the sidestand.

4. Turn the handlebars to the left and lean the motorcycle to the

left until the sidestand firmly supports the motorcycle.

5. Turn the power switch off and ensure the run/stop switch on the

right-hand control is in the position. off

PPAARRKKIINNGG OONN AA SSLLOOPPEE

If parking on a slope is unavoidable, park with the front wheel

uphill from the rear wheel. Place the transmission in first gear and

position the motorcycle so that it is stable when it rests on the

sidestand.

PPAARRKKIINNGG OONN AA SSOOFFTT SSUURRFFAACCEE

If parking on a soft surface is unavoidable, place a sidestand

footrest under the foot of the sidestand to provide a firm surface.

The sidestand footrest must be strong enough and large enough to

support the motorcycle’s weight without sinking into the parking

surface.

Asphalt becomes soft in hot weather. A sidestand can sink into soft

asphalt and the motorcycle may fall. When parking on asphalt in

hot weather, use a sidestand footrest.

CAUTION

Hot engine and exhaust components can cause burns to skin and

can ignite a fire if exposed to flammable materials. Always park

the motorcycle clear of flammable materials and where people

are not likely to contact hot components.

OPERATION

MMAAIINNTTEENNAANNCCEE

SSAAFFEETTYY DDUURRIINNGG SSEERRVVIICCEE PPRROOCCEEDDUURREESS

WARNING

Failure to follow all recommended precautions and procedures could result in severe injury or death. Always heed all safety precautions

and follow all operation, inspection and maintenance procedures outlined in this manual.

• Improperly installed or adjusted components can make the motorcycle

unstable or hard to handle. Improperly installed electrical components

can cause engine or electrical system failure. In either event, damage or

serious injury could result. If you do not have the time, tools and

expertise necessary to complete a procedure properly, please see your

dealer for service.

• Review the safety-related maintenance information in the Safety

Maintenance section.

• Before beginning any maintenance procedure, read the instructions for

the entire procedure.

• Always position the motorcycle on a firm level surface before

performing service. Make sure the motorcycle will not tip or fall while

elevated or while on the sidestand. See the Elevating the Vehicle section

for details.

• Hot engine and exhaust components can cause burns to skin and can

ignite a fire if exposed to flammable materials. Always park the

motorcycle clear of flammable materials and where people are not likely

to contact hot components.

• Wear eye and face protection when using pressurized air.

• Never start the engine or let it run in an enclosed area. Engine exhaust

fumes are poisonous and can cause loss of consciousness or death in a

short time.

• During some procedures you may use potentially hazardous products

such as oil or brake fluid. Always follow the instructions and warnings on

the product packaging.

MAINTENANCE

RROOAADD TTEESSTTSS

Before returning the motorcycle to regular use after performing

service, road test it in a safe environment. Pay special attention to

the proper fit and operation of all serviced components. Make any

corrections or additional adjustments necessary to ensure safe

vehicle performance.

MMAAJJOORR MMAAIINNTTEENNAANNCCEE

Major repairs typically require technical skills and specially

designed tools. Emission system service requires special tools and

training and should be performed by your dealer. See the INDIAN

MOTORCYCLE Service Manual or an authorized INDIAN

MOTORCYCLE dealer or other qualified dealer.

BBRREEAAKK--IINN MMAAIINNTTEENNAANNCCEE

Perform the break-in maintenance procedures when the

motorcycle’s odometer registers 500 miles (800 km). Please see

your authorized dealer for this service.

Performing the break-in maintenance will help ensure optimum

engine performance for the entire service life of the engine. Your

dealer will change engine oil, inspect all fluids and serviceable

components, ensure that all fasteners are tightened and make

other adjustments as needed.

PPEERRIIOODDIICC MMAAIINNTTEENNAANNCCEE

Inspect, clean, lubricate, adjust and replace parts as necessary.

When inspection reveals the need for replacement parts, use

genuine INDIAN MOTORCYCLE parts available from your dealer.

Record service and maintenance information on page 169.

NOTICE

Use of non-recommended lubricants and components can result

in damage to the motorcycle. Damage resulting from the use of

non-recommended products is not covered by warranty.

Perform maintenance at the specified intervals. Vehicles subjected

to severe use must be inspected and serviced more frequently.

SSEEVVEERREE UUSSEE DDEEFFIINNIITTIIOONN

• high speed operation for extended periods

• low speed operation for extended periods

• operation in dusty or otherwise adverse conditions

• operation in cold weather (temperatures below freezing)

MAINTENANCE

MMAAIINNTTEENNAANNCCEE IINNTTEERRVVAALLSS

The maintenance interval charts outline required maintenance and inspection based on vehicle miles. Each table states the number of

miles that service is required on the vehicle. Some items or components may need to be serviced more often due to severe use. When the

vehicle goes beyond 50,000 miles, return to the 500 mile chart and start the interval process over.

KKEEYY

XU - Perform these procedures more often for vehicles subjected to severe use.

D - Have an authorized Indian Motorcycle dealer perform these services.

E - Emission Control System Service (California / International)

550000 MMIILLEE ((880000 KKMM)) SSEERRVVIICCEE

ITEM REMARKS

DCrankcase Ventilation System Inspect; tighten, clean, adjust

D Drive Belt Inspect; tighten, clean, adjust

Damper, Cushion Drive Visual inspection for cracks or deformation is required whenever the rear wheel

is removed. Replace if damage is found.

DEngine Mount Fasteners Inspect; tighten, adjust

XU Engine Oil & Filter Change Change oil and filter, inspect used oil for contaminants

EEvaporative Emission Control System Inspect; clean

EExhaust System Inspect; tighten, adjust

DFuel System Inspect; clean

Key Fob Battery Replace at specified interval or every 2 years

DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary

Battery Check terminals; clean; test

MAINTENANCE

ITEM REMARKS

D Brake Fluid Change every two years (DOT 4)

XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit

D Clutch Lever Lubricate with proper lubricant as directed

DClutch Cable Freeplay Inspect; adjust if necessary

D Control Cable Ends Inspect; lubricate with proper lubricant as directed

D Fasteners Inspect; tighten if necessary

D Front Brake Lever Adjust if necessary, lubricate with proper lubricant as directed

D Front Fork Oil Inspect

D Front Forks and Front Axle Inspect; adjust if necessary

D Gear Shift Pedal Inspect; adjust if necessary

DHead Light Inspect; adjust if necessary

D Rear Brake Pedal Inspect; adjust if necessary

D Rear Shock Absorber Inspect; adjust if necessary

DRear Wheel Alignment Inspect; adjust if necessary

Road Test Perform Road Test

D Sidestand Lubricate with proper lubricant as directed

DSteering Bearings Inspect

DSuspension Linkage, Rear Inspect

DSwing Arm and Rear Axle Inspect

D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns

MAINTENANCE

ITEM REMARKS

DRear Wheel Alignment Inspect; adjust if necessary

Road Test Perform Road Test

D Sidestand Inspect; adjust if necessary, lubricate with proper lubricant as directed

DSteering Bearings Inspect

DSuspension Linkage, Rear Inspect

DSwing Arm and Rear Axle Inspect

D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns

55,,000000 MMIILLEE ((88,,000000 KKMM)) SSEERRVVIICCEE

ITEM REMARKS

XU Air Filter Inspect; clean

DCrankcase Ventilation System Inspect; tighten, clean, adjust

Damper, Cushion Drive Visual inspection for cracks or deformation is required whenever the rear wheel

is removed. Replace if damage is found.

D Drive Belt Inspect; tighten, clean, adjust

XU Engine Oil & Filter Change Change oil and filter, inspect used oil for contaminants

EEvaporative Emission Control System Inspect; clean

EExhaust System Inspect; tighten, adjust

DFuel System Inspect; clean

DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary

Battery Check terminals; clean; test

D Brake Fluid Change every two years (DOT 4)

MAINTENANCE

ITEM REMARKS

XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit

D Clutch Lever Inspect; adjust if necessary

DClutch Cable Freeplay Inspect; adjust if necessary

D Control Cable Ends Inspect; lubricate with proper lubricant as directed

D Fasteners Inspect; tighten if necessary

D Front Brake Lever Adjust if necessary, lubricate with proper lubricant as directed

D Front Fork Oil Replace at specified interval or every 2 years

D Front Forks and Front Axle Inspect; adjust if necessary

D Gear Shift Pedal Inspect; adjust if necessary

D Rear Brake Pedal Inspect; adjust if necessary

D Rear Shock Absorber Inspect; adjust if necessary

DRear Wheel Alignment Inspect; adjust if necessary

Road Test Perform Road Test

D Sidestand Inspect; adjust if necessary, lubricate with proper lubricant as directed

DSteering Bearings Inspect

DSuspension Linkage, Rear Inspect

DSwing Arm and Rear Axle Inspect

D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns

MAINTENANCE

ITEM REMARKS

XU Engine Oil & Filter Change Change oil and filter, inspect used oil for contaminants

EEvaporative Emission Control System Inspect; clean

EExhaust System Inspect; tighten, adjust

DFuel System Inspect; clean

DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary

Battery Check terminals; clean; test

D Brake Fluid Change every two years (DOT 4)

XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit

D Clutch Lever Inspect; adjust if necessary

DClutch Cable Freeplay Inspect; adjust if necessary

D Control Cable Ends Inspect; adjust if necessary

D Fasteners Inspect; tighten if necessary

D Front Brake Lever Adjust if necessary, lubricate with proper lubricant as directed

D Front Fork Oil Replace

D Front Forks and Front Axle Inspect; adjust if necessary

D Gear Shift Pedal Inspect; adjust if necessary

D Rear Brake Pedal Inspect; adjust if necessary

D Rear Shock Absorber Inspect; adjust if necessary

DRear Wheel Alignment Inspect; adjust if necessary

Road Test Perform Road Test

D Sidestand Inspect; adjust if necessary, lubricate with proper lubricant as directed

MAINTENANCE

ITEM REMARKS

XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit

D Clutch Lever Lubricate with proper lubricant as directed

DClutch Cable Freeplay Inspect; adjust if necessary

D Control Cable Ends Lubricate with proper lubricant as directed

D Fasteners Inspect; tighten if necessary

D Front Brake Lever Adjust if necessary, lubricate with proper lubricant as directed

D Front Fork Oil Inspect

D Front Forks and Front Axle Inspect; adjust if necessary

D Gear Shift Pedal Inspect; adjust if necessary

D Gear Position Switch Inspect; clean.

DHead Light Inspect; adjust if necessary

D Rear Brake Pedal Inspect; adjust if necessary

D Rear Shock Absorber Inspect; adjust if necessary

DRear Wheel Alignment Inspect; adjust if necessary

Road Test Perform Road Test

D Sidestand Lubricate with proper lubricant as directed

DSteering Bearings Inspect

DSuspension Linkage, Rear Inspect

DSwing Arm and Rear Axle Inspect

D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns

MAINTENANCE

2255,,000000 MMIILLEE ((4400,,000000 KKMM)) SSEERRVVIICCEE

ITEM REMARKS

XU Air Filter Inspect; clean

DCrankcase Ventilation System Inspect; tighten, clean, adjust

Damper, Cushion Drive Visual inspection for cracks or deformation is required whenever the rear wheel

is removed. Replace if damage is found.

D Drive Belt Inspect; tighten, clean, adjust

XU Engine Oil & Filter Change Change oil and filter, inspect used oil for contaminants

EEvaporative Emission Control System Inspect; clean

EExhaust System Inspect; tighten, adjust

DFuel System Inspect; clean

DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary

Battery Check terminals; clean; test

D Brake Fluid Change every two years (DOT 4)

XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit

D Clutch Lever Inspect; adjust if necessary

DClutch Cable Freeplay Inspect; adjust if necessary

D Control Cable Ends Inspect; adjust if necessary

D Fasteners Inspect; tighten if necessary

D Front Brake Lever Adjust if necessary, lubricate with proper lubricant as directed

D Front Fork Oil Inspect

D Front Forks and Front Axle Inspect; adjust if necessary

MAINTENANCE

ITEM REMARKS

D Gear Shift Pedal Inspect; adjust if necessary

D Rear Brake Pedal Inspect; adjust if necessary

D Rear Shock Absorber Inspect; adjust if necessary

DRear Wheel Alignment Inspect; adjust if necessary

Road Test Perform Road Test

D Sidestand Inspect; adjust if necessary, lubricate with proper lubricant as directed

DSteering Bearings Inspect

DSuspension Linkage, Rear Inspect

DSwing Arm and Rear Axle Inspect

D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns

3300,,000000 MMIILLEE ((4488,,000000 KKMM)) SSEERRVVIICCEE

ITEM REMARKS

XU Air Filter Replace

DCrankcase Ventilation System Inspect; tighten, clean, adjust

Damper, Cushion Drive Visual inspection for cracks or deformation is required whenever the rear wheel

is removed. Replace if damage is found.

D Drive Belt Replace

DEngine Compression Inspect; correct if necessary

XU Engine Oil & Filter Change Change oil and filter, inspect used oil for contaminants

EEvaporative Emission Control System Inspect; clean

EExhaust System Inspect; tighten, adjust

MAINTENANCE

ITEM REMARKS

D Control Cable Ends Inspect; adjust if necessary

D Fasteners Inspect; tighten if necessary

D Front Brake Lever Adjust if necessary, lubricate with proper lubricant as directed

D Front Fork Oil Inspect

D Front Forks and Front Axle Inspect; adjust if necessary

D Gear Shift Pedal Inspect; adjust if necessary

D Rear Brake Pedal Inspect; adjust if necessary

D Rear Shock Absorber Inspect; adjust if necessary

DRear Wheel Alignment Inspect; adjust if necessary

Road Test Perform Road Test

D Sidestand Lubricate with proper lubricant as directed

DSteering Bearings Inspect

DSuspension Linkage, Rear Inspect

DSwing Arm and Rear Axle Inspect

D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns

4400,,000000 MMIILLEE ((6644,,000000 KKMM)) SSEERRVVIICCEE

ITEM REMARKS

XU Air Filter Replace

DCrankcase Ventilation System Inspect; tighten, clean, adjust

Damper, Cushion Drive Visual inspection for cracks or deformation is required whenever the rear wheel

is removed. Replace if damage is found.

MAINTENANCE

ITEM REMARKS

D Drive Belt Inspect; tighten, clean, adjust

DEngine Compression Inspect; correct if necessary

XU Engine Oil & Filter Change Change oil and filter, inspect used oil for contaminants

EEvaporative Emission Control System Inspect; clean

EExhaust System Inspect; tighten, adjust

DFuel System Inspect; clean

Key Fob Battery Replace

DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary

D / E Spark Plugs Inspect; torque to specification

Battery Check terminals; clean; test

D Brake Fluid Replace (DOT 4)

XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit

D Clutch Lever Lubricate with proper lubricant as directed

DClutch Cable Freeplay Inspect; adjust if necessary

D Control Cable Ends Lubricate with proper lubricant as directed

D Fasteners Inspect; tighten if necessary

D Front Brake Lever Adjust if necessary, lubricate with proper lubricant as directed

D Front Fork Oil Inspect

D Front Forks and Front Axle Inspect; adjust if necessary

D Gear Shift Pedal Inspect; adjust if necessary

D Gear Position Switch Inspect; clean.

MAINTENANCE

ITEM REMARKS

DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary

Battery Check terminals; clean; test

D Brake Fluid Change every two years (DOT 4)

XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit

D Clutch Lever Lubricate with proper lubricant as directed

DClutch Cable Freeplay Inspect; adjust if necessary

D Control Cable Ends Inspect; lubricate with proper lubricant as directed

D Fasteners Inspect; tighten if necessary

D Front Brake Lever Lubricate with proper lubricant as directed

D Front Fork Oil Replace

D Front Forks and Front Axle Inspect; adjust if necessary

D Gear Shift Pedal Inspect; adjust if necessary

D Rear Brake Pedal Inspect; adjust if necessary

D Rear Shock Absorber Inspect; adjust if necessary

DRear Wheel Alignment Inspect; adjust if necessary

Road Test Perform Road Test

D Sidestand Lubricate with proper lubricant as directed

DSteering Bearings Inspect

DSuspension Linkage, Rear Inspect

DSwing Arm and Rear Axle Inspect

D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns

MAINTENANCE

5500,,000000 MMIILLEE ((8800,,000000 KKMM)) SSEERRVVIICCEE

ITEM REMARKS

XU Air Filter Replace

DCrankcase Ventilation System Inspect; tighten, clean, adjust

Damper, Cushion Drive Visual inspection for cracks or deformation is required whenever the rear

wheel is removed. Replace if damage is found.

D Drive Belt Inspect; tighten, clean, adjust

DEngine Compression Inspect; correct if necessary

DEngine Mount Fasteners Inspect; tighten, adjust

Coolant Replace Coolant

XU Engine Oil & Filter Change Change oil and filter, inspect used oil for contaminants

EEvaporative Emission Control System Inspect; clean

EExhaust System Inspect; tighten, adjust

DFuel System Replace

DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary

D / E Spark Plugs Inspect; torque to specification

Battery Check terminals; clean; test

D Brake Fluid Replace (DOT 4)

XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit

D Clutch Lever Lubricate with proper lubricant as directed

DClutch Cable Freeplay Inspect; adjust if necessary

D Control Cable Ends Lubricate with proper lubricant as directed

MAINTENANCE

EENNGGIINNEE OOIILL//FFIILLTTEERR CCHHAANNGGEE

Change the engine oil at the intervals specified in the Periodic

Maintenance Table beginning on page 81. Change the oil more

frequently if the motorcycle is subjected to severe use, especially

operation in cold weather. See page 80.

NOTICE

Failure to perform frequent oil changes during cold weather

operation can result in condensation forming. Freezing

condensation can result in plugged oil lines and serious engine

damage.

The total amount of oil required for the oil and filter change is

approximately 5 qts. (4.7 l). Follow all instructions carefully. Do not

overfill.

NOTICE

After an oil change, the low oil pressure indicator may illuminate

when the engine is started. If this occurs, do not increase RPM

above idle speed until the indicator turns off. Operating above

idle speed could result in damage to the engine.

1. Change the oil and filter when the engine is warm. If the engine

is cold, start the engine and allow it to run at idle for at least 5

minutes.

2. Park the motorcycle with the sidestand down on a firm, level

surface. If using a service lift, the motorcycle should be

centered.

3. Clean the area around the scavenge area drain plug

q. Place a

drain pan under drain plug.

CAUTION

Hot oil can cause burns to skin. Do not allow hot oil to contact

skin.

4. Remove the drain plug. Allow the oil to drain completely.

NOTE

Remove sidestand bumper bracket for improved clearance to

drain plug.

101

MAINTENANCE

5. Install new sealing washer and o-ring on the drain plug. The

sealing surfaces on drain plug and engine should be clean and

free of burrs, nicks or scratches.

6. Reinstall the drain plug. Torque to Specification. If sidestand

bumper bracket was removed, reinstall. Torque fastener to

specification.

TORQUE

Drain Plug: 15 ft. lbs. (20 Nm)Bracket fastener: 84 in-lbs (9.5 Nm)

CAUTION

Hot oil can cause burns to skin. Do not allow hot oil to contact

skin. Wear leather gloves when handling hot components.

7. Place oil pan beneath the oil filter. Using an oil filter wrench,

turn the filter counter-clockwise to remove it.

8. Using a clean dry cloth, clean the filter sealing surface on the

engine.

9. Lubricate the o-ring on the new filter with a film of fresh engine

oil. Check to make sure the o-ring is in good condition.

10. Install the new filter and rotate it clockwise by hand until the

filter gasket contacts the sealing surface, then turn it an

additional 3/4 to one full turn.

11. Remove the dipstick. Add only 4 qts. (3.8 l) of the

recommended oil at this step. Do not overfill.

12. Reinstall the dipstick securely.

13. With the motorcycle in an upright, centered position, start the

engine and idle for approximately 30 seconds.

14. Stop the engine and add an additional 1 qts. (0.95 l) of engine

oil. Do not overfill. Overfilling can result in loss of engine

performance and an oil-saturated air filter. Use a suction device

to remove excess oil if overfilled.

15. To ensure the oil level is within the safe operating range, re-

check the oil level as outlined in page 59.

NOTICE

After an oil change, the low oil pressure indicator may illuminate

when the engine is started. If this occurs, do not increase RPM

above idle speed until the indicator turns off. Operating above

idle speed could result in damage to the engine.

16. Dispose of used filter and oil properly.

17. Reset the oil change life in the instrument gauge.

102

MAINTENANCE

AAIIRR FFIILLTTEERR

NOTICE

If the motorcycle is operated in wet or dusty conditions, more

frequent servicing is required.

The air filter element cannot be cleaned. Replace the filter when

necessary.

1. Remove Fuel Tank. See page 114.

2. Remove the zip-ties from harness retention as well as the the

brake line retention clips. Remove the wiring harness

and

the brake lines w

from airbox filter cover retention features.

3. Remove the airbox filter cover fasteners

and remove from

the unit.

4. Installation of new filter is performed by reversing the removal

procedure.

TORQUE

Airbox Filter Cover Fastener:

84 in-lbs (10 N m)·

103

MAINTENANCE

AADDDDIINNGG CCOOOOLLAANNTT

To add coolant, do the following:

1. Remove the seat and rubber lid.

2. Remove he overflow bottle cap

to add coolant. Add coolant

until level is within the marked values.

NOTE

The rubber and formed nylon can be left connected while

performing this procedure.

CAUTION

Do not fill the coolant bottle to full. 0.3 L of air must remain in the

bottle to account for thermal expansion. Failure to do so can

result in coolant overflow.

RREEAARR DDRRIIVVEE BBEELLTT CCLLEEAANNIINNGG

TIP

Do not inspect or adjust drive belt tension when the belt or drive

system is wet or hot. Improper adjustment will result.

Cleaning the drive belt will maximize belt and sprocket life and

minimize drive line noise. Clean the belt at every tire change.

Clean the belt more often if riding in dirty, dusty or high debris

environments.

1. Mix a few drops of mild dish soap with a cup of warm water.

2. Use a soft nylon brush to clean the belt and sprocket teeth with

the soapy water. Clean well in corner areas where road debris

and belt dust can collect.

3. Rinse the belt with clear water, then dry thoroughly.

105

MAINTENANCE

1. Place the motorcycle in an upright position with the front wheel

clamped in a wheel vise.

2. Remove saddlebags.

3. Make note of adjuster locations q

and w.

4. Raise the rear of the motorcycle so the rear tire can be freely

rotated.

5. Loosen axle nut e.

6. Turn the RIGHT SIDE adjuster nut r

to achieve proper belt

tension

BELT DEFLECTION

Model Deflection @ 10 lbs force

Challenger 0.6” (15 mm) - New Belt

0.79” (20 mm) - Belt with 1000

+ miles

108

MAINTENANCE

1. Disconnect the cable at the clutch lever and at the primary

cover.

2. Lubricate the barrel ends with all-purpose grease.

3. Reconnect the cable and adjust freeplay as needed.

BBRRAAKKEE HHOOSSEESS//CCOONNNNEECCTTIIOONNSS

Inspect all brake hoses and connections for dampness or stains

from leaking or dried fluid. Tighten any leaking connections and

replace components as necessary. See the INDIAN MOTORCYCLE

Service Manual or an authorized INDIAN MOTORCYCLE dealer can

assist.

RREEAARR BBRRAAKKEE PPEEDDAALL

1. Lubricate the pivot bushing at the intervals recommended in

the Periodic Maintenance Table beginning on page 81. Also

lubricate any time binding is evident. Use all-purpose grease.

2. Inspect brake pads as outlined in the Brake Pads section.

BBRRAAKKEE FFLLUUIIDD PPRREECCAAUUTTIIOONNSS

WARNING

Using the wrong fluid or allowing air or contaminants into the

fluid system can damage the system seals or result in a

malfunction that could lead to serious injury or death. Use only

DOT 4 brake fluid from a sealed container.

Do not operate the front brake with the reservoir cover removed.

Fluid could overflow from the reservoir and allow air to enter the

system. Air in the brake system could cause the brakes to

malfunction.

An over-full reservoir may cause brake drag or brake lock-up,

which could result in serious injury or death. Maintain brake fluid

at the recommended level. Do not overfill.

NOTICE

Brake fluid will damage painted surfaces and plastic parts.

Always clean spilled brake fluid immediately with water and a

mild detergent.

118

MAINTENANCE

RREEAARR BBRRAAKKEE FFLLUUIIDD

Change the brake fluid at the intervals recommended in the

Periodic Maintenance Chart on page 81. Always add brake fluid

from a new, unopened container. Always use the recommended

fluid. See page 155.

1. Position the motorcycle on level ground in the fully upright

position.

2. The rear brake fluid reservoir is located near the rear brake

pedal. View the reservoir from the right side of the vehicle.

3. Wipe the fluid container and the area around the reservoir

cover with a clean cloth.

4. If the fluid level is low, inspect brake pads as outlined on page

122. If pads are not worn beyond the service limit, inspect the

brake system for leaks.

5. Remove the cover and diaphragm. The fluid level should be

above the minimum indicator mark w

on the reservoir body q.

Add brake fluid as needed. Do not overfill.

6. Reinstall the cover and diaphragm.

7. Wipe away any fluid spills. Check for signs of brake fluid leaks

around hoses, fittings, reservoir, and brake calipers.

119

MAINTENANCE

Produktspecifikationer

Varumärke:	Indian
Kategori:	Motor
Modell:	Challenger Dark Horse (2020)

Behöver du hjälp?

Om du behöver hjälp med Indian Challenger Dark Horse (2020) ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Motor Indian Manualer

Indian Sport Scout (2025) Bruksanvisning

15 Februari 2025

Indian Chieftain Elite (2023) Bruksanvisning

26 Oktober 2024

Indian Ride Command+ (2025) Bruksanvisning

24 September 2024

Indian Sport Chief (2024) Bruksanvisning

16 September 2024

Indian Chieftain (2024) Bruksanvisning

16 September 2024

Indian Scout Sixty (2024) Bruksanvisning

16 September 2024

Indian Scout Bobber (2024) Bruksanvisning

16 September 2024

Indian Scout Sixty (2022) Bruksanvisning

9 September 2024

Indian Roadmaster (2019) Bruksanvisning

7 September 2024

Indian Chief Classic (2015) Bruksanvisning

7 September 2024

Motor Manualer

Nyaste Motor Manualer

Suzuki GSX-R750 (2017) Bruksanvisning

22 Februari 2025

Husqvarna 801 Svartpilen (2024) Bruksanvisning

18 Februari 2025

Husqvarna EE 2 (2025) Bruksanvisning

17 Februari 2025

Yamaha Ténéré 700 (2024) Bruksanvisning

16 Februari 2025

Honda NX500 (2013) Bruksanvisning

16 Februari 2025

Hero Glamour Xtec (2024) Bruksanvisning

14 Februari 2025

Honda Goldwing (2020) Bruksanvisning

8 Februari 2025

Honda CB400 SUPER BOL D'OR (2011) Bruksanvisning

8 Februari 2025

Honda XL750 (2023) Bruksanvisning

8 Februari 2025

Honda Shadow Phantom (2010) Bruksanvisning

3 Februari 2025
