Press to toggle between Rider Screens.
1
To customize your rider screens, press icon on motorcycle display screen and select among available options.
2
Press icon on motorcycle display screen to save and return.
3
AUDIO
NAVIGATION
RIDER SCREENS
1Press to access Audio Section.
DISPLAY ON/OFF SCREEN
BLUETOOTH SMARTPHONE PAIRING
Press once to display INDIAN® logo Screen.
1
Press any button to turn on display.
3
Press to access Bluetooth Section on the display.
1
To pair phone, enable Bluetooth on your phone, make phone visible, and press icon.
2
Press to access Navigation Section.
1
Press on screen to re-center map, or change map view.
2
Press on screen to enter address, search for point of interest, and access favorites.
3
2To select audio source, press again , or select the red circle icon in upper left corner. Current source is shown
inside of circle .
FM
BUTTONS
While in an active route, press for navigation volume options.
4
HOLD for 3 seconds to turn off display (audio remains on). Press for 5 seconds to turn off display and mute audio.
2
Press OK, and select your phone on motorcycle display screen.
3
Agree to all notifications on your phone.
4
You must enable Bluetooth on your phone and make it visible to complete this process.
While accepting notifications, remember to select the “Do Not Show Again” box (if applicable).
QUICK START GUIDE
NOTE
NOTE
9928702 Rev 1
Indi Motcycle Ride Commd
® ™
QUICK START GUIDE
HAND CONTROLS
AUDIO CONTROLS
1
Use right hand trigger, or center push on switch , to accept selection.
2
MAP CONTROLS
Press right/left on the 5 position joystick to advance/go back.
1
TRIGGER CONTROLS
2
Press up/down on the switch to zoom in/out of the map.
1
DOWNLOAD NEW SOFTWARE
Go to www.my.indianmotorcycle.com.
1
Log into your account, or create a new account.
2
Using the Vehicle Identification Number (VIN), add your new Indian Motorcycle® to your Garage.
3
4Locate and download the latest software to a USB flash drive (8 GB) (File cannot be in a folder).
5
Connect the USB flash drive to the USB cable located within the storage area above display.
6
Power up your Indian Motorcycle®.
7
Navigate to the Settings Menu (shown in document above).
8
Select General Settings, then select Update Software.
9
Select the file you wish to load (use date listed in the file name to determine most recent file).
10
Select Yes to restart display (restart required).
11
ON YOUR PERSONAL COMPUTER
ON YOUR MOTORCYCLE
ON YOUR RIDE COMMAND™ SCREEN
Properly eject USB flash drive from your personal computer.
SETTINGS
Time Audio Vehicle
General
To access the settings menu on the touchscreen, press
at the top of the motorcycle display, then press .
Press on the left hand control to mute, play or pause audio.
Press up/down on the 5 position joystick to increase/decrease volume.
3
Use left hand trigger to decline selection, or switch infotainment screens.
1
2
3
Indi Motcycle Ride Commd
® ™
3
4Hold to activate voice control features for Bluetooth connected smart
phone (if supported by phone and headset is connected).
