FTR 1200
TM
OWNER’S MANUAL
BE LEGENDARY®
For Maintenance and Safety
©2019 Indian Motorcycle Inc. All Rights Reserved.
WARNING
Operating, servicing, and maintaining a passenger vehicle or off-road
vehicle can expose you to chemicals including engine exhaust, carbon
monoxide, phthalates, and lead, which are known to the State of California
to cause cancer and birth defects or other reproductive harm. To minimize
exposure, avoid breathing exhaust, do not idle the engine except as
necessary, service your vehicle in a well-ventilated area and wear gloves
or wash your hands frequently when servicing your vehicle.
For more information go to www.P65Warnings.ca.gov/passenger-vehicle.
!WARNING
Read, understand, and follow all of the instructions and safety
precautions in this manual and on all product labels.
Failure to follow the safety precautions
could result in serious injury or death.
!
2020 Owner’s Manual
Indian® FTR 1200
Indian® FTR 1200 Rally
Indian® FTR 1200 S Carbon
Copyright 2019 Indian Motorcycle International, LLC
All information contained within this publication is based on the latest product information available at the time of publication. Product
improvements or other changes may result in differences between this manual and the motorcycle. Depictions and/or procedures in this
publication are intended for reference use only.
No liability can be accepted for omissions or inaccuracies. Indian Motorcycle Company reserves the right to make changes at any time,
without notice and without incurring obligation to make the same or similar changes to motorcycles previously built. Any reprinting or
reuse of the depictions and/or procedures contained within, whether whole or in part, is expressly prohibited.
INDIAN®, INDIAN MOTORCYCLE®, INDIAN CHIEF®, CHIEF®, CHIEF DARK HORSE®, INDIAN SPRINGFIELD®, INDIAN SPRINGFIELD®
DARK HORSE®, CHIEFTAIN DARK HORSE® , CHIEFTAIN®, CHIEF ROADMASTER®, ROADMASTER®, and RIDE COMMAND® are
trademarks of Indian Motorcycle Company.
iPhone®, iPod®, iPod nano®, and iPod touch® are trademarks of Apple Inc., registered in the U.S. and other countries.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by INDIAN
MOTORCYCLE is under license. Other trademarks and trade names are those of their respective owners.
Garmin® and zumo® are registered trademarks of Garmin Ltd. or its subsidiaries.
JCASE® is a registered trademark of Littelfuse, Inc.
9931391 R02
Congratulations on your purchase of a new INDIAN motorcycle. You have joined an elite family of motorcycle riders who have acquired a
celebrated piece of American history by choosing to own an INDIAN motorcycle.
Your new motorcycle is the end result of true dedication and craftsmanship by our engineering, design and assembly teams. It was
designed and manufactured to meet our goal of providing you with a high quality motorcycle that you can ride trouble-free for many years
to come. We hope you will take as much pride in riding your new motorcycle as our team did in building it for you.
We urge you to read this rider’s manual thoroughly. It contains information essential to safe riding and proper maintenance of your
motorcycle.
Your authorized INDIAN MOTORCYCLE dealer knows your motorcycle best and should be consulted for service and assistance. Skilled
technicians using advanced equipment and methods are best qualified to perform all major repairs and service your motorcycle may
require.
INDIAN motorcycles comply with all federal, state and local safety and emission regulations for the area of intended sale.
3
CONGRATULATIONS!
The following signal words and symbols appear throughout this manual. Your safety and the safety of others is involved when these words
and symbols are used. Become familiar with their meanings before reading the manual.
DANGER
DANGER indicates a hazardous situation which, if not avoided, WILL result in death or serious injury.
WARNING
WARNING indicates a hazardous situation that, if not avoided, result in death to the operator, bystanders or person(s) inspecting or may
servicing the vehicle.
CAUTION
SAFETY ALERT CAUTION indicates a potential hazard that may result in minor personal injury or damage to the vehicle.
IMPORTANT
IMPORTANT provides key reminders during disassembly, assembly, and inspection of components.
4
SAFETY SYMBOLS AND SIGNAL WORDS
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Reporting Safety Defects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Features and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Pre-Ride Inspections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Cleaning and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Maintenance Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
5
TABLE OF CONTENTS
6
IINNTTRROODDUUCCTTIIOONN
SSEERRVVIICCEE AANNDD WWAARRRRAANNTTYY IINNFFOORRMMAATTIIOONN
Some procedures are beyond the scope of this manual. See your
dealer to purchase an INDIAN MOTORCYCLE Service Manual. Some
procedures provided in the service manual require specialized
knowledge, equipment, and training. Be sure you have the
required technical skills and tools that are needed before you
attempt ANY service on your motorcycle. Please contact your
authorized dealer before attempting any service work that is
beyond your level of technical knowledge or experience, or if the
work requires specialized equipment.
OOPPEERRAATTIINNGG MMOOTTOORRCCYYCCLLEE OOUUTTSSIIDDEE TTHHEE UU..SS..AA..
If you plan to operate your motorcycle in countries other than the
USA and Canada:
• Service facilities or replacement parts may not be readily
available.
• Unleaded gasoline may not be available. The use of leaded fuels
will cause engine damage, damage to your emissions systems
and voiding of your warranty.
• Gasoline may have a considerably lower octane rating.
Improper fuel can cause engine damage.
KKEEYY IIDDEENNTTIIFFIICCAATTIIOONN NNUUMMBBEERR
The key identification number is stamped on the metal key tag
attached to the key ring. If it becomes necessary to replace the
ignition key for any reason, provide the key number to your
INDIAN dealer.
EENNGGIINNEE IIDDEENNTTIIFFIICCAATTIIOONN NNUUMMBBEERR
The engine number q
is stamped into the bottom of the left
crankcase near the sidestand.
7
INTRODUCTION
IIDDEENNTTIIFFIICCAATTIIOONN NNUUMMBBEERR RREECCOORRDD
RECORD IMPORTANT IDENTIFICATION NUMBERS BELOW.
Vehicle Identification Number (VIN)
Engine Identification Number
Ignition Key Number
IINNDDUUSSTTRRYY CCAANNAADDAA IICCEESS--000022 ((IINNTTEERRFFEERR--
EENNCCEE--CCAAUUSSIINNGG EEQQUUIIPPMMEENNTT SSTTAANNDDAARRDD
This vehicle complies with the Canadian standard ICES-002.
TTOOUUCCHHSSCCRREEEENN DDIISSPPLLAAYY CCOOMMPPLLIIAANNCCEE
SSTTAATTEEMMEENNTT
Notice: This device complies with part 15 of the FCC Rules and
with Industry Canada license-exempt RSS standard(s). Operation
is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any
interference received including interference that may cause
undesired operation.
Per RSS-Gen, Section 8.4, this device complies with Industry
Canada license-exempt RSS standard(s). Operation is subject to
the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the
device.”
Polaris International hereby declares that the radio equipment in-
vehicle display unit is in compliance with the following directives:
• 2014/53/EU European Radio Equipment Directive
• 2011/65/EU RoHS 2011/65/EU (Recast)
• 2015/863 RoHS July 22, 2019
The full text of the EU declaration of conformity is available at the
following internet address: www.polaris.com/compliance
Per 47 CFR 15.21, the user’s manual for instruction or an intentional
or unintentional radiator shall caution the user that changes or
modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the
equipment.
CAUTION
This equipment complies with part 15 of the Federal
Communications Commission (FCC) rules.
These requirements are intended to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
8
INTRODUCTION
CAUTION
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
Changes or modifications to this equipment not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
9
INTRODUCTION
10
SSAAFFEETTYY
AABBOOUUTT TTHHEE RRIIDDEERR’’SS MMAANNUUAALL
WARNING
Failure to follow all recommended precautions and procedures
could result in severe injury or death. Always heed all safety
precautions and follow all operation, inspection and maintenance
procedures outlined in this manual.
All references to RIGHT, LEFT, FRONT or REAR are from the
operator’s perspective when seated in a normal riding position. If
you have questions about the operation or maintenance of your
motorcycle after you've read this manual, please see your
authorized dealer. To locate the nearest authorized INDIAN
MOTORCYCLE dealer, visit the INDIAN MOTORCYCLE web site at
www.indianmotorcycle.com.
Carefully read and understand the information found in the Safety
section beginning on this page. To keep your motorcycle in peak
condition on the road or in storage, understand and follow the
procedures outlined in the section beginning on page Maintenance
73.
Bring the manual along when you ride. Following the precautions
and procedures in the manual will add to your enjoyment and help
keep you safe. If you lose or damage this manual, please purchase
a new one through any authorized INDIAN MOTORCYCLE dealer.
This rider’s manual should be considered part of the motorcycle
and should remain with the motorcycle when ownership changes.
SSAAFFEE RRIIDDIINNGG PPRRAACCTTIICCEESS
WARNING
Improper use of this motorcycle can result in serious injury or
death. To minimize the risk, read and understand the information
contained in this section before operating the motorcycle. This
section contains safety information specific to the INDIAN
motorcycle, as well as information about general motorcycle
safety. Anyone who rides the motorcycle (operators and
passengers) must follow these safety precautions.
MMOOTTOORRCCYYCCLLIINNGG HHAASS IINNHHEERREENNTT RRIISSKKSS
You can minimize those risks, but you can't eliminate them
completely. Even if you’re an experienced motorcycle operator or
passenger, read all of the safety information in this manual before
operating the motorcycle.
• Take a rider education course from a qualified instructor. The
course will help you develop or refresh your expertise in safe
riding habits through instruction and riding.
• Read and understand all information in this rider’s manual.
• Observe all maintenance requirements specified in this manual.
See the INDIAN MOTORCYCLE Service Manual or an authorized
INDIAN MOTORCYCLE dealer.
11
SAFETY
DDEESSIIGGNN CCHHAARRAACCTTEERRIISSTTIICCSS AAFFFFEECCTT HHOOWW YYOOUU
SSHHOOUULLDD RRIIDDEE TTHHEE MMOOTTOORRCCYYCCLLEE
• The motorcycle is designed for on-road use with one rider (and
one passenger if the motorcycle is equipped with a passenger
seat and pegs). Never exceed the GVWR or the GAWR. Refer to
the chapter or the Manufacturing Information/VIN Specifications
label on the motorcycle frame for model-specific information.
• Riding off-road, riding with more than one passenger, or
carrying weight exceeding the maximum weight rating can
make handling difficult, which could cause loss of control.
• During the first 500 miles (800 km) of operation, follow all
break-in procedures as outlined on page 63. Failure to do so can
result in serious engine damage.
• If your motorcycle is equipped with saddlebags, a windshield or
a passenger backrest, be prepared to reduce operating speed
to maintain stability.
FFOOLLLLOOWW TTHHEESSEE GGEENNEERRAALL SSAAFFEE RRIIDDIINNGG
PPRRAACCTTIICCEESS
• Before each ride, perform the pre-ride inspections. Failure to do
so may result in damage to the motorcycle or an accident.
• Until you're thoroughly familiar with the motorcycle and all of its
controls, practice riding where there is little or no traffic.
Practice riding at a moderate speed on various road surfaces
and in different weather conditions.
• Know your skills and limits, and ride within them.
• Allow only licensed, experienced operators to ride your
motorcycle, and then only after they have become familiar with
its controls and operation. Make sure all riders read and
understand this rider’s manual before riding.
• Do not ride when you're fatigued, ill or under the influence of
alcohol, prescription drugs, over-the-counter drugs or any other
drugs. Fatigue, illness, alcohol and drugs can cause drowsiness,
loss of coordination and loss of balance. They can also affect
your awareness and judgment.
• If your motorcycle operates abnormally, correct the problem
immediately. See the or INDIAN MOTORCYCLE Service Manual
an authorized INDIAN MOTORCYCLE dealer or other qualified
dealer.
• Ride defensively, as if you are invisible to other motorists, even
in broad daylight. A motorist's failure to see or recognize a
motorcycle is the leading cause of automobile/motorcycle
accidents. Ride where you're clearly visible to other motorists,
and observe their behavior carefully.
• Be especially cautious at intersections, as these are the most
likely places for an accident.
• To prevent loss of control, keep your hands on the handlebars
and your feet on the footrests.
• Obey the speed limit and adjust your speed and riding
technique based on road, weather and traffic conditions. As you
travel faster, the influence of all other conditions increases,
which can affect the motorcycle's stability and increase the
possibility of losing control.
• Do not move or operate the motorcycle with the steering locked
(if equipped), as the severely restricted steering could result in
loss of control.
12
SAFETY
• Reduce speed when:
– The road has potholes or is otherwise rough or uneven.
– The road contains sand, dirt, gravel or other loose
substances.
– The road is wet, icy or oily.
– The road contains painted surfaces, manhole covers, metal
grating, railway crossings or other slippery surfaces.
– The weather is windy, rainy or otherwise causing slippery or
rapidly changing conditions.
– Traffic is heavy, congested, not allowing sufficient space
between vehicles or otherwise not flowing smoothly.
– You are being passed in either direction by a large vehicle
that may produce a wind blast in its wake.
• When approaching a curve, choose a speed and lean angle that
allows you to pass through the curve in your own lane without
applying the brakes. Excessive speed, improper lean angle or
braking in a curve can cause loss of control.
• Ground clearance is reduced when the motorcycle leans. Do not
allow components to contact the road surface when leaning the
motorcycle in a curve, as this could cause loss of control.
• Do not tow a trailer. Towing a trailer can make the motorcycle
hard to handle.
• Retract the sidestand fully before riding. If the sidestand is not
fully retracted, it could contact the road surface and cause loss
of control.
• To maximize braking effectiveness, use the front and rear brakes
together. Be aware of the following braking facts and practices:
– The rear brake provides 40% of the motorcycle's stopping
power, at most. Use the front and rear brakes together.
– To avoid skidding, apply the brakes gradually when the road
is wet or rough, or contains loose or other slippery
substances.
– If possible, avoid applying the brakes while making a turn.
Motorcycle tires have less traction during turns, so braking
will increase the possibility of skidding. Bring the motorcycle
to the upright position before applying the brakes.
– With new pads and rotors, allow up to 250 miles (500 km) of
operation in urban driving conditions (not highway cruising)
to allow pads to mate with new rotors. Brakes should be used
frequently. During this time brake performance will be less
effective. Avoid using brakes harshly unless in an
emergency. Brake efficiency will gradually increase during
this seating period.
13
SAFETY
PPRROOTTEECCTTIIVVEE AAPPPPAARREELL
IMPORTANT
Wear protective apparel to decrease the risk of injury and
increase riding comfort.
• Always wear a helmet that meets or exceeds established safety
standards. Approved helmets in the USA and Canada bear a U.S.
Department of Transportation (DOT) label. Approved helmets in
Europe, Asia and Oceania bear the ECE 22.05 label. The ECE
mark consists of a circle surrounding the letter E, followed by
the distinguishing number of the country which has granted
approval. The approval number and serial number will also be
displayed on the label. Laws in some areas that you wear require
an approved helmet. Head injuries are the leading cause of
fatalities in accidents involving motorcycles. Statistics prove that
an approved helmet is the most effective protection in
preventing or reducing head injuries. The helmet should fit
snugly, be securely fastened, have no obvious defects, and have
not previously been involved in an accident/crash.
• Wear eye protection to protect eyes from wind or airborne
particles and objects. Wearing a face shield can help protect
your face in an accident/crash and protect face from wind or
airborne particles or objects. Laws in some areas that require
you wear eye protection. We recommend that you wear
approved Personal Protective Equipment (PPE) bearing
markings such as VESC 8, V-8, Z87.1, or CE. Make sure
protective eyewear is kept clean.
• All riders should wear bright or light-colored and/or reflective
clothing to improve visibility to other motorists. A motorist's
failure to see or recognize a motorcycle is the leading cause of
automobile/motorcycle accidents.
• Wear gloves, a jacket, heavy boots and long pants to prevent or
reduce injury from abrasions, lacerations or burns should the
motorcycle fall. Wear boots with low heels, as high heels can
catch on pedals or footrests. The combination of boots and pants
should completely cover legs, ankles and feet, protecting skin
from engine and exhaust system heat.
• Do not wear loose, flowing clothing or long boot laces, as they
can catch on handlebars, levers or footrests, or they can become
entangled in the wheels, causing loss of control and serious
injury.
AANNTTII--LLOOCCKK BBRRAAKKEE SSYYSSTTEEMM RREESSPPOONNSSEE
When the anti-lock brakes engage during a braking event, the
rider will feel pulsing at the brake levers. Continue to apply steady
pressure to the brakes for the best stopping performance.
14
SAFETY
CCAARRRRYYIINNGG AA PPAASSSSEENNGGEERR
WARNING
Do not carry a passenger unless the motorcycle is equipped with
passenger seat and passenger footrests.
• Do not exceed the gross vehicle weight rating (GVWR) for your
motorcycle. Refer to the section of this manual or Specifications
the Manufacturing Information/VIN label on the motorcycle
frame for model-specific information.
• Adjust ride height as needed. See the Rear Shock Preload (Ride
Height) Inspection Rear Shock Preload (Ride Height) and
Adjustment sections for details.
• Direct the passenger to hold onto you or to the passenger hand-
holds with both hands and to keep both feet on the passenger
footrests. Do not carry a passenger who cannot place both feet
firmly on the passenger footrests. A passenger who is not
holding on properly, or who cannot reach the passenger
footrests, can shift their body erratically, which can make the
motorcycle hard to handle and cause loss of control.
• Before riding, be sure your passenger knows safe riding
procedures. Discuss any safety information unfamiliar to your
passenger. A passenger who is unaware of safe riding
procedures may distract you or make movements that make the
motorcycle hard to handle.
• Adjust your riding style to compensate for the differences in
handling, acceleration and braking caused by the additional
weight of the passenger. Failure to do so can cause loss of
control.
UUSSEE OOFF AACCCCEESSSSOORRIIEESS
Because INDIAN MOTORCYCLE cannot test and make specific
recommendations concerning every accessory or combination of
accessories sold, the operator is responsible for determining that
the motorcycle can be safely operated with any accessories or
additional weight. Use the following guidelines when choosing and
installing accessories:
• Do not install accessories that impair operator visibility or the
stability, handling or operation of the motorcycle. Before
installing an accessory, be sure that it does not:
– reduce ground clearance when the motorcycle is either
leaned or in a vertical position;
– limit suspension or steering travel or your ability to operate
controls;
– displace you from your normal riding position;
– obscure lights or reflectors.
• Bulky, heavy or large accessories can cause instability (due to
the lifting or buffeting effects of wind) and loss of control.
• Do not install electrical accessories that exceed the capacity of
the motorcycle’s electrical system. Never install higher wattage
light bulbs than those supplied as original equipment. An
electrical failure could result and cause hazardous loss of engine
power or lights, or damage to the electrical system. See the
Electrical Precautions section for details.
• Use only genuine INDIAN MOTORCYCLE accessories designed
for your model.
• Do not exceed the gross vehicle weight rating (GVWR) for your
motorcycle.
15
SAFETY
MMOODDIIFFIICCAATTIIOONNSS
Modifying the motorcycle by removing any equipment or by
adding equipment not approved by the manufacturer may void
your warranty. Such modifications could make the motorcycle
unsafe to ride and could result in severe injury to operator or
passenger, as well as damage to the motorcycle. Some
modifications may not be legal in your area of operation. If in
doubt, contact your authorized INDIAN MOTORCYCLE dealer.
PPAARRKKIINNGG TTHHEE MMOOTTOORRCCYYCCLLEE
When leaving the motorcycle unattended, turn the engine off. Your
motorcycle is equipped with a keyed ignition. Remove the ignition
key to prevent unauthorized use.
Park the motorcycle where people are not likely to touch the hot
engine or exhaust system or place combustible materials near
these hot areas. Do not park near a flammable source such as a
kerosene heater or an open flame, where hot components could
ignite combustible materials.
Park the motorcycle on a firm, level surface. Sloped or soft
surfaces may not support the motorcycle. If you must park on a
slope or soft surface, follow the precautions outlined on page 71.
SSAADDDDLLEEBBAAGG
Whenever operating with a saddlebag or while carrying cargo:
• Never ride at excessive speeds. Saddlebags and cargo,
combined with the lifting or buffeting effects of wind, can make
the motorcycle unstable and cause loss of control.
• Do not exceed the individual weight limit of the saddlebag.
• NEVER EXCEED GROSS VEHICLE WEIGHT RATING (GVWR) or
the GROSS AXLE WEIGHT RATING (GAWR), regardless of
whether or not the saddlebag is loaded to capacity. Exceeding
the weight rating can reduce stability and handling and cause
loss of control.
CCAARRRRYYIINNGG CCAARRGGOO
Use the following guidelines when attaching cargo or accessories
to the motorcycle. Where applicable, these guidelines also refer to
the contents of any accessories.
• Keep cargo and accessory weight to a minimum, and keep items
as close to the motorcycle as possible to minimize a change in
the motorcycle’s center of gravity. Changing the center of
gravity can cause loss of stability and handling and could cause
loss of control.
• Do not exceed the gross vehicle weight rating (GVWR) for your
motorcycle.
• Distribute weight evenly on both sides of the motorcycle.
Maintain even weight distribution by checking accessories and
cargo to make sure they’re securely attached to the motorcycle
before riding and whenever you take a break from riding.
Uneven weight distribution or sudden shifting of accessories or
cargo while you’re riding may cause difficult handling, loss of
control and driving hazards for other motorists (if cargo falls
from the motorcycle).
16
SAFETY
• For riding comfort and to ensure proper ground clearance,
adjust rear shock preload. See the Rear Shock Preload (Ride
Height) Inspection section for details.
• Do not attach large or heavy cargo such as sleeping bags, duffle
bags or tents to the handlebars, front fork area or front fender.
Cargo or accessories placed in these areas can cause instability
(due to improper weight distribution or aerodynamic changes)
and could cause loss of control.
• Do not exceed the maximum cargo weight limit of any accessory
(see accessory instructions and labels). Do not attach cargo to
an accessory not designed for that purpose. Either circumstance
could result in an accessory failure that could cause loss of
control.
• Always obey posted speed limits.
• Do not attach anything to the motorcycle unless specifically
designed for that purpose by INDIAN MOTORCYCLE.
TTRRAANNSSPPOORRTTIINNGG TTHHEE MMOOTTOORRCCYYCCLLEE
If you must transport the motorcycle:
• Use a truck or trailer. Do not tow the motorcycle with another
vehicle, as towing will impair the motorcycle’s steering and
handling.
• Position and restrain the motorcycle in an upright position.
• Do not restrain the motorcycle using the handlebars.
• Loop tiedown straps (from the front) up and over the lower triple
clamp, using care to not interfere with wiring and brake lines.
Place tiedowns as wide apart as possible on the truck or trailer
bed for best stability.
• Do not engage the side stand during truck or trailer
transportation.
FFUUEELL AANNDD EEXXHHAAUUSSTT SSAAFFEETTYY
Always heed these fuel safety warnings when refueling or
servicing the fuel system.
WARNING
Gasoline is highly flammable and explosive under certain
conditions.
• Always exercise extreme caution whenever handling gasoline.
• Always turn off the engine before refueling.
• Always refuel outdoors or in a well-ventilated area.
• Open the fuel cap slowly. Do not overfill the tank. Do not fill the
tank neck.
• Do not smoke or allow open flames or sparks in or near the
area where refueling is performed or where gasoline is stored.
17
SAFETY
WARNING
Gasoline and gasoline vapors are poisonous and can cause
severe injury.
• Do not swallow gasoline, inhale gasoline vapors, or spill
gasoline. If you swallow gasoline, inhale more than a few
breaths of gasoline vapor, or get gasoline in your eyes, see a
physician immediately.
• If gasoline spills on your skin or clothing, immediately wash it
off with soap and water and change clothing.
• Exhaust gases contain carbon monoxide, a colorless, odorless
gas that can cause loss of consciousness or death in a short
time.
• Never start the engine or let it run in an enclosed area.
• Never inhale exhaust gases.
SSAAFFEETTYY MMAAIINNTTEENNAANNCCEE
WARNING
Failure to perform safety maintenance as recommended can
result in difficult handling and loss of control, which could result
in serious injury or death. Always perform the safety
maintenance procedures as recommended in this manual.
Perform maintenance and repairs promptly. See the INDIAN
MOTORCYCLE Service Manual or an authorized INDIAN
MOTORCYCLE dealer or other qualified dealer.
• Before each ride, perform the .Pre-Ride Inspections
• Perform all periodic maintenance at the recommended intervals
outlined in the section.Periodic Maintenance
• Always maintain proper tire pressure, tread condition and wheel
and tire balance. Inspect tires regularly and replace worn or
damaged tires promptly. Use only approved replacement tires.
See the section. Specifications
• Always ensure proper steering head bearing adjustment.
Regularly inspect the rear shock absorber and the front forks for
fluid leaks or damage. Make any necessary repairs promptly.
See page 110.
• Clean the motorcycle thoroughly to reveal items in need of
repair.
• Always ensure all exhaust heat shields are present and in good
condition.
• Fasteners must meet original specifications for quality, finish
and type to ensure safety. Use only genuine INDIAN
MOTORCYCLE replacement parts, and ensure that all fasteners
are tightened to the proper torque.
18
SAFETY
GGRROOSSSS VVEEHHIICCLLEE WWEEIIGGHHTT RRAATTIINNGG ((GGVVWWRR))
WARNING
Exceeding the gross vehicle weight rating of your motorcycle can
reduce stability and handling and could cause loss of control.
NEVER exceed the GVWR of your motorcycle.
The maximum load capacity of your motorcycle is the maximum
weight you may add to your motorcycle without exceeding the
GVWR. This capacity is determined by calculating the difference
between your motorcycle’s GVWR and wet weight.
Refer to the section of this manual or the Specifications
Manufacturing Information/VIN label on the motorcycle frame for
model-specific information.
When determining the weight you will be adding to your
motorcycle, and to ensure you do not exceed the maximum load
capacity, include the following:
• Operator body weight
• Passenger body weight
• Weight of all rider’s apparel and items in or on apparel
• Weight of any post-production accessories and their contents
• Weight of any additional cargo on the motorcycle
RREEPPOORRTTIINNGG SSAAFFEETTYY DDEEFFEECCTTSS
If you believe that your vehicle has a defect that could result in a
crash or cause injury or death, you should immediately inform the
National Highway Traffic Safety Administration (NHTSA) in
addition to notifying INDIAN MOTORCYCLE in writing.
If NHTSA receives similar complaints, it may open an investigation,
and if it finds that a safety defect exists in a group of vehicles, it
may order a recall and remedy campaign. However, NHTSA cannot
become involved in individual problems between you, your
INDIAN MOTORCYCLE dealer or Indian Motorcycle Company.
To contact NHTSA, or obtain other information about motor vehicle
safety, you may either call the Vehicle Safety Hotline toll-free at 1-
888-327-4236 (TTY: 1-800-424-9153), visit the NHTSA web site at
www.safercar.gov, or write to:
ADMINISTRATOR, NHTSA
1200 New Jersey Avenue, SE
West Building
Washington, DC 20590
19
SAFETY
SSAAFFEETTYY AANNDD IINNFFOORRMMAATTIIOONN LLAABBEELLSS
Labels are model-specific and market-specific. Your motorcycle
may not contain all of the labels shown.
VVEEHHIICCLLEE IIDDEENNTTIIFFIICCAATTIIOONN NNUUMMBBEERR
The Vehicle Identification Number (VIN) is stamped on the right-
hand side of the steering head q, and printed on a VIN sticker
located on the left-hand side of the steering head.
VVEEHHIICCLLEE EEMMIISSSSIIOONN IINNFFOORRMMAATTIIOONN
The Vehicle Emission Control Information (VECI) and Noise
Emission Control Information (NECI) can be found on the emission
information label. The label w
is located on the swing arm on the
left-hand side of the vehicle.
20
SAFETY
OOPPEERRAATTOORR WWAARRNNIINNGG//FFUUEELL CCAAUUTTIIOONN
The Operator Warning/Fuel Caution is located on the right-hand
side panel e.
WARNING
• Read Owner’s Manual and, during use, follow all safety
precautions.
• Always wear an approved helmet, eye protection, and protective
clothing.
• If your Owner’s Manual is missing, contact an Indian Motorcycle
dealer for a replacement.
CAUTION
Never overfill fuel tank. Fuel level should not rise into fill neck
funnel. Overfilling may result in degraded performance of engine
and evaporative emission control system.
21
SAFETY
22
FFEEAATTUURREESS AANNDD CCOONNTTRROOLLSS
OOVVEERRVVIIEEWW
q
Fuel Tank u
Headlight f
Rear Turn Signal 1(
Sidestand
w
Driver’s Seat i
Front Fork g
Ignition Switch 2)
Shifter
e
Fuse Box (under cover) o
Oil Cooler h
Carbon Canister 2!
Carbon Canister
r
Air Filter a
Rear Brake Pedal j
Passenger Hand-hold 2@
Main/ABS Fuses
t
Mirror s
Driver’s footrest k
Tail and Brake Light 2#
Battery
y
Front Turn Signal d
Muffler l
License Plate Bracket 2$
Radiator
23
FEATURES AND CONTROLS
CCOONNSSOOLLEE
FFTTRR 11220000//FFTTRR 11220000 RRAALLLLYY
q
Clutch Lever
w
Instrument Cluster
e
Front Brake Master Cylinder Reservoir
r
Front Brake Lever
t
Electronic Throttle Control
y
Fuel Cap
u
USB
FFTTRR 11220000 SS CCAARRBBOONN
q
Clutch Lever
w
Instrument Cluster
e
Front Brake Master Cylinder Reservoir
r
Front Brake Lever
t
Electronic Throttle Control
y
Fuel Cap
u
USB
24
FEATURES AND CONTROLS
SSWWIITTCCHH SSYYMMBBOOLLSS
SYMBOL SWITCH DESCRIPTION
Horn Switch Press the horn switch to sound the horn. See
page 29.
High
Headlight
Beam Switch
The high headlight beam switch activates the
high headlight beam. See page 30.
Low
Headlight
Beam Switch
The low headlight beam switch activates the
low headlight beam. Press down momentarily
to activate Flash to Pass. See page 30.
Turn Signal
Switch
Move the switch to the left to activate the left
turn signals. Move the switch to the right to
activate the right turn signals. A signal will
deactivate automatically when speed or
distance reach predetermined levels. To
cancel a signal manually, move the switch to
the center position and push it inward.
Momentary Feature: Move the turn signal switch
left or right and hold it in that position for at
least one second. The momentary feature will
activate and the signal will then cancel when the
switch is released. See page 28.
Emergency
Flasher
Switch
(Hazard
Switch)
The hazard switch activates and cancels the
emergency flashers. Press and hold on the
center of the switch to activate emergency
flashers. See page 28. To activate, move press
and hold switch while in the center position
until hazards activate. To cancel, press and
release switch while in the center position.
SYMBOL SWITCH DESCRIPTION
Screen List
Select Switch
The Screen List Select Switch (if equipped) is
used to navigate through rider screens. See
page 38.
Back Switch Use the back switch to back out of menus,
decline dialog boxes. See page 38.
Stop Switch Press the bottom of the switch (RUN) to allow
the engine to start and run. Press the top of the
switch (STOP) to stop the engine. See page 29.
Starter
Switch
Use the starter switch to start the engine. The
engine stop/run switch must be in the RUN
position. See page 29.
Right-Hand
Trigger
Switch
On models equipped with analog gauge, use
the right-hand trigger switch to cycle through
the multi-function display. On models
equipped with a Ride Command display, use
the right-hand switch to navigate through
menus. See page 37.
25
FEATURES AND CONTROLS
SSWWIITTCCHH LLOOCCAATTIIOONNSS
LLEEFFTT CCOONNTTRROOLL
q
Cruise Control Switch
w
Turn Signal/Hazard Signal
e
Horn Switch
r
High/Low Beam and Flash to Pass
RRIIGGHHTT CCOONNTTRROOLL
t
Engine Stop/Run/Start Switch
y
Right Trigger Switch
26
FEATURES AND CONTROLS
CCRRUUIISSEE CCOONNTTRROOLL SSWWIITTCCHH
Cruise control can be activated and adjusted from the left hand
control using the Cruise Control Switch
q.
Toggle Position Function
Down Set/Decelerate
Center Off/On
Up Resume/Accelerate
TTUURRNN SSIIGGNNAALL//HHAAZZAARRDD SSWWIITTCCHH
TTUURRNN SSIIGGNNAALLSS
To activate the turn signal, press the turn signal switch w
in the
corresponding direction. To activate the right turn signal, press the
turn signal switch to the right. To activate the left turn signal, press
the turn signal switch to the left.
HHAAZZAARRDD SSIIGGNNAALL
The power switch must be ON to activate the flashers, but once
activated, the flashers will continue to flash when the power switch
is turned off. When the flashers are active, all four turn signals
flash.
28
FEATURES AND CONTROLS
TTRRIIGGGGEERR SSWWIITTCCHHEESS
All models are equipped with trigger switches on the front side of
the left and right handlebar controls y.
NOTE
The ignition switch must be in the ON position for the trigger
switches to function.
HHIIGGHH//LLOOWW HHEEAADDLLIIGGHHTT SSWWIITTCCHH
The headlights automatically come on when the engine is started.
The high/low headlight switch u
toggles the headlight between
high beam and low beam. To momentarily flash headlights (Flash
to Pass), press and hold the left-hand trigger switch. To activate
high beams for an extended period of time, push the trigger
forward until it clicks into place. Pull the lever back to the neutral
position to return to low beams.
RRIIGGHHTT--HHAANNDD TTRRIIGGGGEERR
On models equipped with analog gauge, use the right-hand
trigger switch to cycle through the multi-function display. See
page 33. On models equipped with a Ride Command display, use
the right-hand switch to navigate through menus. See page 37.
30
FEATURES AND CONTROLS
LAMP INDICATES CONDITION
Check
Engine
If this lamp illuminates while the engine is
running, see your dealer promptly. The light
will remain on if the tilt sensor shuts down the
engine. If abnormal sensor or engine
operation is detected the light will remain on
as long as the fault condition exists. Retrieve
the error codes for diagnosis. If a misfire is
detected, the check engine lamp will begin
to flash and fuel will be cut to the affected
cylinder(s). See page 34.
Side Stand
Light
The sidestand light will turn on anytime the
sidestand is down.
MMFFDD TTEELLLL--TTAALLEESS
LAMP INDI-
CATES
CONDITION
Low Oil
Pressure
The Low Oil Pressure lamp illuminates when
oil pressure drops below a safe operating
pressure while the engine is running. If this
lamp illuminates while the engine is
running above idle speed, turn the engine
off as soon as safely possible and check the
oil level. If the oil level is correct and the
lamp remains on after the engine is
restarted, turn the engine off immediately.
See your dealer.
Battery
Voltage
The Battery Voltage lamp illuminates if high
or low battery voltage is detected, or if
there is a charging system fault. Turn non-
LAMP INDI-
CATES
CONDITION
essential accessories off to conserve power.
Make sure the charging system is operating
properly. See page 137.
Vehicle
Speed
When standard mode is selected, speed
displays in miles per hour.
When metric mode is selected, speed
displays in kilometers per hour.
Cruise
Control
Status
When the is visible, cruise control Dial Icon
is enabled, but not set. The Arrow Icon
becomes visible when cruise control is set
to the desired speed. Read the safety and
operation procedures before using cruise
control. See page 70.
32
FEATURES AND CONTROLS
MMUULLTTII--FFUUNNCCTTIIOONN DDIISSPPLLAAYY MMOODDEESS
With the ignition switch on, use the right-hand trigger switch to
toggle through the modes of the multi-function display and to
change settings in the display.
The following display modes are available:
• Odometer
• Trip Odometer
• Engine Speed
• Gear Indicator
• Battery Voltage
• Engine Error Codes
• Average Fuel Economy
• Instant Fuel Economy
• Engine Temperature
OODDOOMMEETTEERR
The odometer displays total distance traveled.
TTRRIIPP OODDOOMMEETTEERR
The trip odometer displays total distance traveled since being
reset. To reset, toggle to the trip odometer, then press and hold the
MODE button until the trip odometer resets to zero.
EENNGGIINNEE SSPPEEEEDD
Engine speed displays in revolutions per minute (RPM).
GGEEAARR IINNDDIICCAATTOORR
The vehicle’s current gear position is displayed on the MFD.
BBAATTTTEERRYY VVOOLLTTAAGGEE
Battery voltage displays real-time, regulated charge voltage
supplied to the battery. The voltage level may fluctuate depending
on electrical load and engine RPM.
AAVVEERRAAGGEE FFUUEELL EECCOONNOOMMYY
Average Fuel Economy displays the vehicle’s average fuel
economy as of the last time the mode was reset. To reset, press and
hold the right hand trigger while viewing the fuel economy
display.
IINNSSTTAANNTTAANNEEOOUUSS FFUUEELL EECCOONNOOMMYY
Instantaneous Fuel Economy displays the vehicle’s current fuel
economy at the moment the mode was selected.
EENNGGIINNEE CCOOOOLLAANNTT TTEEMMPPEERRAATTUURREE
The temperature area displays the temperature of the engine
coolant.
33
FEATURES AND CONTROLS
DDIISSPPLLAAYY UUNNIITTSS ((SSTTAANNDDAARRDD//MMEETTRRIICC))
The display can be changed to display either standard or metric
units of measurement.
STANDARD
DISPLAY
METRIC DISPLAY
Distance Miles Kilometers
Temperature Fahrenheit Celsius
Time 12-Hour Clock 24-Hour Clock
Volume Gallons Imperial Gallons, Liters
1. Turn the ignition off.
2. Wait 10 seconds.
3. Press and the right-hand trigger switch while turning the hold
key to the ON or PARK position.
4. When the display flashes the distance setting, tap the right-
hand trigger switch to advance to the desired setting.
5. Press and the right-hand trigger switch to save the setting hold
and advance to the next display option.
6. Repeat the procedure to change remaining display settings.
CCLLOOCCKK
NOTE
The clock must be reset any time the battery has been
disconnected or discharged.
1. Use the right-hand trigger switch to toggle to the odometer
display.
2. Press and the right-hand trigger switch until the hour hold
segment flashes. Release the switch.
3. With the segment flashing, tap the right-hand trigger switch to
advance to the desired setting.
4. Press and the right-hand trigger switch until the next hold
segment flashes. Release the switch.
5. Repeat steps 3–4 twice to set the 10-minute and 1-minute
segments. After completing the 1-minute segment, step 4 will
save the new settings and exit the clock mode.
MMIISSFFIIRREE DDEETTEECCTTIIOONN
If a misfire is detected, the check engine indicator lamp will begin
to flash and fuel will be cut to the affected cylinder(s). The check
engine indicator lamp will continue to flash until the ignition switch
has been moved to the off position. Restarting the engine will clear
the flashing indicator and restore fuel to both cylinders. If another
misfire occurs, the check engine indicator lamp will resume
flashing and fuel will once again be cut to the affected cylinder(s).
After the 3rd misfire, P0314 misfire fault is determined & set, the
check engine light will remain on and fuel will be cut to the
affected cylinder(s). If this occurs, your INDIAN dealer can assist.
34
FEATURES AND CONTROLS
EENNGGIINNEE EERRRROORR CCOODDEESS
The error screen displays only when the CHECK ENGINE light is
on or when it goes on and off during one ignition cycle. Error
codes display only during the current ignition cycle. When the
ignition switch is turned OFF, the code and message is lost, but will
reappear if the fault reoccurs after restarting the engine.
If the CHECK ENGINE indicator lamp illuminates, retrieve the
error codes from the display.
1. If the error codes are not displayed, use the right-hand trigger
switch to toggle until “Ck ENG” displays on the main line of the
display.
2. Press and hold the right-hand trigger switch to enter the
diagnostics code menu.
3. Record the three numbers displayed in the gear position, clock
and odometer displays.
4. See an authorized dealer for code details and diagnosis.
q
Error Code Number (0–9)
w
Suspect Parameter Number (SPN)
e
Failure Mode Indicator (FMI)
DDIIAAGGNNOOSSTTIICC FFUUNNCCTTIIOONNAALLIITTYY
Certain conditions will cause the battery indicator to illuminate
and an error message to display in the screen. If this occurs,
please see your authorized dealer.
MESSAGE LOCATION INDICATES
LO DC Voltage
Screen
Voltage remains below 11.0 volts for
more than 10 seconds
OV DC Voltage
Screen
Voltage remains above 15.0 volts for
more than 10 seconds
ERROR All Checksum error (gauge malfunction)
35
FEATURES AND CONTROLS
OOVVEERR TTEEMMPPEERRAATTUURREE DDIISSPPLLAAYY AANNDD WWAARRNNIINNGG
IINNDDIICCAATTOORR
“HOT” displays and the CHECK ENGINE indicator lamp
illuminates under the following conditions.
CONDITION INDICATES ACTION REQUIRED
Engine coolant
temperature
approaches
unsafe
operating
condition while
the engine is
running.
Engine coolant
temperature is
above a safe
operating
temperature.
Stop the engine as soon as safely
possible. Check the coolant level.
Check the radiator for debris.
Check cooling fan operation. If the
warning continues to display after
restarting the engine, stop the
engine immediately.
RRIIDDEE CCOOMMMMAANNDD DDIISSPPLLAAYY ((IIFF EEQQUUIIPPPPEEDD))
For the latest information about your Ride Command display,
including software updates, please visit:
https://ridecommand.indianmotorcycle.com
WARNING
Do not enter information while operating your vehicle. Failure to
pay attention to operating your vehicle could result in loss of
control, personal injury, or death. You assume all risks associated
with using this device. Read your User Guide.
36
FEATURES AND CONTROLS
WARNING
Driving while distracted can result in loss of vehicle control,
crash, and injury. We strongly recommend that you use extreme
caution when using any device that may take your focus off the
road. Your primary responsibility is the safe operation of your
vehicle. We recommend against the use of any hand-held device
while driving and encourage the use of voice-operated systems
when possible. Make sure you are aware of all applicable local
laws that may affect the use of electronic devices while driving.
Before riding with your new display, do the following:
• Read this entire manual.
• Familiarize yourself with the features and operations of the
display while the vehicle is stationary.
• Download the Indian Ride Command app from the Apple/
Google Play store and create your personalized account.
• Check http://www.polaris.com/en-us/rider-support/owners-
manual for the latest updates to the owner’s manual.
NOTE
Using the display for an extended period of time while the
vehicle’s engine is off can drain the battery.
RRIIDDEE CCOOMMMMAANNDD HHAANNDD CCOONNTTRROOLLSS
RRIIGGHHTT TTRRIIGGGGEERR
Press the right-hand trigger switch
q
to toggle through the Ride
Command display screens.
37
FEATURES AND CONTROLS
SSEELLEECCTT JJOOYYSSTTIICCKK
The 5–way Select Joystick w
allows you to navigate through the
display screen from the left-hand switch cube.
Use the 5–way select joystick to do the following:
• Long press to show App Tray
• Navigate through menu gauge/menu screens
• Enter/Select
• Change gauge style
BBAACCKK BBUUTTTTOONN
Press the back button e
to do the following:
• Close Pop-ups
• Navigate back in menu
• Long press to return to gauges screen
• When viewing a top-level display screen, press the back button
to cycle through the Ride Command display screens.
38
FEATURES AND CONTROLS
RRIIDDEE CCOOMMMMAANNDD DDIISSPPLLAAYY SSCCRREEEENNSS
The Ride Command display has four top-level display screens:
• Gauge Screen
• Music Screen
• Phone Screen
• App Tray
To cycle through the display screens, do one of the following:
• Press the physical up q
or down w
button on the gauge.
• Press the right trigger switch.
• While viewing one of the four top-level screens, press the back
button on the left hand control.
GGAAUUGGEE SSCCRREEEENN
The gauge screen displays the vehicle’s speed, current gear, fuel
level and range, ambient and engine temperature, odometer, trip
meter, and compass. You have two different gauge styles to choose
from, round or linear (both shown above). The display style can be
changed by swiping up or down on the touchscreen, or by
pressing up or down on the select joystick.
MMUUSSIICC SSCCRREEEENN
The music screen allows you to
access music stored on your smart-
phone or other music device. You
can pair your device using
Bluetooth, or by connecting it to
the display’s USB port.
USB audio playback is only
available on flash drives formatted
to ex-FAT or FAT32. Playback from
an iOS devices is only available on
iPhone 5S models or later.
39
FEATURES AND CONTROLS
PPHHOONNEE SSCCRREEEENN
The phone screen displays recent
calls, contact list, key pad, and
messages. The display will only
show messages received while
smart-phone is paired via
Bluetooth.
AAPPPP TTRRAAYY
From the App Tray you can access
settings, adjust display brightness,
select ride mode, and enable/
disable ride mode.
You can access the App Tray at
anytime by pressing the center
button on the gauge.
RRIIDDEE CCOOMMMMAANNDD RRIIDDEE MMOODDEESS
You can choose between three ride modes, Rain, Standard, or
Sport, for an experience customized to your riding style. The
throttle map for each ride mode was designed with a specific
application in mind, resulting in one motorcycle with three distinct
personalities.
40
FEATURES AND CONTROLS
3. A prompt will appear asking you to confirm that you want to
disable the Traction Control/Anti-Lock Brake System. Press
DISABLE to confirm.
NOTE
The ABS indicator lamp will illuminate when TC/ABS is disabled.
NOTE
TC/ABS will not become disabled until vehicle speed is at zero.
4. To re-enable TC/ABS, press the TC/ABS toggle switch again, or
press TC/ABS OFF button in sidebar from any screen.
RRIIDDEE CCOOMMMMAANNDD SSEETTTTIINNGGSS
From the Settings Menu you can view important details about your
vehicle and personalize your touchscreen display. The settings
menu is comprised of four categories: Information, General, Time,
and Vehicle.
GGEENNEERRAALL IINNFFOORRMMAATTIIOONN
From the Information settings menu you can view the following:
• Vehicle Identification Number (VIN)
• Mileage
• Installed Software Version
• Oil Change Interval
GGEENNEERRAALL SSEETTTTIINNGGSS
From the General settings menu you can do the following:
• Themes (Day/Night/Auto)
• Manage Bluetooth Devices
• Change the Language
• Set the Speed Units of Measure (MPH or KPH)
• Set the Temperature Units (F or C)
• Update Software
CCLLOOCCKK
From the Time Settings you can do the following:
• Set the Time Format (12 hour or 24 hour)
• Enable GPS Time (automatically sets the time to the time zone
you are currently in)
• Set Time (if GPS Time is not enabled)
VVEEHHIICCLLEE IINNFFOORRMMAATTIIOONN
From the Vehicle Settings you can do the following:
• Oil Life/ Service Reset
• Access Vehicle Diagnostics
42
FEATURES AND CONTROLS
UUSSBB PPOORRTT
The USB Port makes it easy to power devices, such as phones,
audio sources, or GPS units, in addition to allowing you to stream
music through the LCD display to your Bluetooth headset. On
models equipped with a Ride Command display, the USB port is
also used to update the display software. For the latest software, go
to https://ridecommand.indianmotorcycle.com.
IMPORTANT
Due to harsh riding environments, Indian Motorcycle
recommends using USBs with retention features
TTHHRROOTTTTLLEE CCOONNTTRROOLL GGRRIIPP
The throttle control grip is located on the right handlebar. Use the
throttle control grip to control engine speed.
While seated in the proper riding position:
• Roll the grip rearward q to open the throttle (increase engine
speed and power).
• Roll the grip forward w to close the throttle (decrease engine
speed and power).
• Roll the grip forward, past idle position, to cancel cruise control.
The control grip is spring loaded. When you release the grip, the
throttle returns to the idle position.
44
FEATURES AND CONTROLS
GGEEAARR SSHHIIFFTT LLEEVVEERR
The gear shift lever e is located on the left side of the motorcycle.
Operate the lever with your foot.
• Press downward on the toe lever to shift to a lower gear.
• Lift upward on the toe lever to shift to a higher gear.
• Release the lever after each gear shift.
• See page 66 for gear shifting procedures.
CCLLUUTTCCHH LLEEVVEERR
The clutch lever r is located on the left handlebar. Disengage the
clutch before shifting gears. For smooth clutch operation, pull the
lever quickly and release it in a brisk but controlled manner.
• To disengage the clutch, pull the lever toward the handlebar.
• To engage the clutch, release the lever in a brisk but controlled
manner.
45
FEATURES AND CONTROLS
SSIIDDEE--SSTTAANNDD
The FTR 1200 is equipped with a side-stand safety switch to
prevent operation of the motorcycle if the side-stand is deployed.
WARNING
An improperly retracted side-stand could contact the ground and
cause a loss of control resulting in serious personal injury or
death. Always retract the side stand fully before operating the
motorcycle.
To park the motorcycle, swing the end of the side-stand downward
and away from the motorcycle until it is fully extended. Always
turn the handlebars to the left for maximum stability. Lean the
motorcycle to the left until the side-stand firmly supports the
motorcycle.
CAUTION
If the motorcycle weight is not resting on the side-stand, it will
not lock. In this situation, any movement of the motorcycle could
cause the side stand to retract slightly. If the side-stand is not in
the full forward position when the motorcycle weight is rested on
it, the motorcycle could fall over, possibly causing personal
injury and damage to the motorcycle.
To retract the side-stand, straddle the motorcycle and bring it to
the fully upright position. Swing the end of the side-stand upward
and toward the motorcycle until it is fully retracted.
See page 71 for parking instructions, including parking on slopes
and soft surfaces.
WARNING
Do not sit on the motorcycle when it is supported on the side-
stand.
FFEEEELLEERR PPEEGGSS
Your bike is equipped with small feeler pegs extending from the
end of both footpegs to help protect against damage. A wear notch
has been etched near the base of both feeler pegs. Once either
feeler peg has been eroded up to the wear notch, a replacement
feeler peg is recommended.
46
FEATURES AND CONTROLS
WWHHEEEELLIIEE MMIITTIIGGAATTIIOONN
Wheelie mitigation is a feature that allows maximum acceleration
while keeping the front wheel on or near the ground. The feature is
active when the vehicle is in “Rain” or “Standard” ride modes, but
not when the vehicle is in ‘Sport’ mode or the ABS/TC system is
disabled.
NOTE
The wheelie mitigation feature cannot prevent the front wheel
from losing contact with the ground in all situations.
• If the wheelie mitigation feature is disabled and the front wheel
loses contact with the road surface long enough to become
stationary, a wheel speed sensor fault may be set.
• If a fault code is set, the ABS/TC system will become
deactivated and the display will illuminate the ABS/MTC
lights. If this occurs, a power cycle will be required to re-
initialize the ABS/MTC system.
MMIIRRRROORRSS
Your vehicle is equipped with convex mirrors. Objects seen in a
mirror may be closer than they appear. Always adjust mirrors
before riding.
To adjust the mirrors, sit on the motorcycle in the anticipated
riding position. Adjust the mirrors so that you can see a small
portion of your shoulders in each mirror.
BBRRAAKKEESS
AANNTTII--LLOOCCKK BBRRAAKKEE SSYYSSTTEEMM ((AABBSS))
The anti-lock brake system automatically reduces brake pressure
as needed to provide optimum braking control, reducing the
chance of wheel lock-up during hard braking events or when
braking on rough, uneven, slippery or loose surfaces. See the Safe
Riding Practices starting page 11.
1. The anti-lock brake system cannot be turned off on models
equipped with an analog gauge. On models equipped with the
Ride Command touchscreen display, ABS can be disabled
through the touchscreen menu when the vehicle is in TRACK
mode.
2. ABS must not be deactivated when traveling on public roads.
Deactivation is only suitable for off-road use (race tracks or dirt
roads).
3. The ABS indicator always illuminates when vehicle power is
turned on. It remains illuminated until the anti-lock system
activates, which occurs when vehicle speed exceeds 6 MPH (10
km/h).
4. When the lamp is illuminated, the anti-lock brakes will not
activate, but the conventional brake system will continue to
operate normally.
47
FEATURES AND CONTROLS
5. When the anti-lock brakes engage during a braking event, the
rider will feel pulsing at the brake levers. Continue to apply
steady pressure to the brakes for the best stopping performance.
6. If the ABS light does not come on when the key is turned to the
ON or PARK position, see your authorized INDIAN
MOTORCYCLE dealer for service.
• If the lamp continues to illuminate after vehicle speed exceeds 6
MPH (10 km/h), the ABS system is not functioning. See your
INDIAN MOTORCYCLE dealer promptly for service.
• Operating with non-recommended tires or improper tire
pressure may reduce the effectiveness of the anti-lock brake
system. Always use the recommended size and type of tires
specified for your vehicle. Always maintain the recommended
tire pressure.
• The anti-lock brake system will not prevent wheel lockup, loss of
traction or loss of control under all conditions. Always adhere to
all safe motorcycle-riding practices as recommended.
• It is not unusual to leave tire marks on the road surface during a
hard braking event.
• The anti-lock brake system does not compensate for or reduce
the risks associated with:
– excessive speed
– reduced traction on rough, uneven or loose surfaces
– poor judgment
– improper operation
FFRROONNTT BBRRAAKKEE LLEEVVEERR
The front brake lever t
is located on the right handlebar. This
lever controls only the front brakes. The front brakes should be
applied simultaneously with the rear brakes. To apply the front
brake, pull the lever toward the handlebar. See page 68 for
braking procedures.
48
FEATURES AND CONTROLS
RREEAARR BBRRAAKKEE PPEEDDAALL
WARNING
Resting your foot on the brake pedal will cause excessive and
premature wear of brake pads and reduced braking efficiency,
which could result in severe injury or death.
The rear brake pedal y
is located on the right side of the
motorcycle. Press downward on the rear brake pedal to apply the
rear brake. See page 68 for braking procedures.
RREEAARR BBRRAAKKEE PPEEDDAALL FFRREEEEPPLLAAYY
WARNING
Free travel must be present on the brake pedal lever or pressure
could build up in the rear brake system causing overheating and
failure. The brake pedal free travel is adjusted at the factory and
must always be set in accordance with the specification.
Changing this adjustment could cause brake damage or failure. If
adjustments are needed, see your dealer.
Free travel at brake lever peg: 3 - 7 mm
49
FEATURES AND CONTROLS
50
PPRREE--RRIIDDEE IINNSSPPEECCTTIIOONNSS
OOVVEERRVVIIEEWW
To keep your motorcycle in safe operating condition, always
perform the recommended pre-ride inspections before each ride.
This is especially important before making a long trip and when
removing the motorcycle from storage.
WARNING
Failure to perform the recommended pre-ride inspections could
result in component failure while riding, which could result in
serious injury or death. Always perform the preride inspections
before each ride. When inspection reveals the need for
adjustment, replacement or repair, perform the service promptly,
or see your authorized INDIAN MOTORCYCLE dealer or other
qualified dealer for service.
WARNING
Read the entire Instruments, Features and Controls section of this
manual before riding your motorcycle. A complete
understanding of the features and capabilities of your motorcycle
is essential to its safe operation. Anything less may result in
serious injury or death.
You must be familiar with all instruments and controls to perform
the pre-ride inspections.
TIP
During the pre-ride inspections you may use products that are
potentially hazardous, such as oil or brake fluid. When using any
of these products, always follow the instructions and warnings on
the product packaging.
When inspections reveal the need for adjustment, replacement or
repair:
• refer to the maintenance section of this manual
• refer to the INDIAN MOTORCYCLE Service Manual
• or see your authorized INDIAN MOTORCYCLE dealer or other
qualified dealer
51
PRE-RIDE INSPECTIONS
EELLEECCTTRRIICCAALL IINNSSPPEECCTTIIOONNSS
Turn the ignition key to the ON position and move the stop/run
switch to RUN before performing the following electrical
inspections. Return the ignition key to the OFF position after
completing these inspections. If inspection of any electrical item
reveals component failure, repair or replace the component before
operating the motorcycle.
ITEM INSPECTION PROCEDURE
Headlight Start engine to activate headlights. Once
headlamp illuminates, switch to high beam.
Verify that the high beam indicator comes on
and that lamp brightness increases.
Taillight/
Brakelight
Verify that the taillight and license plate light
illuminate. Verify that the taillight lamps
increase in brightness when the front brake
lever is applied and also when the rear brake
pedal is applied.
Turn Signals Move the turn signal switch to the left. Verify that
front and rear left turn signals flash, as well as
the corresponding light on the indicator panel.
Move the switch to the center position and push
it inward to cancel the signal. Verify that the
signals and the indicator light stop flashing.
Repeat the procedure for the right turn signals.
ITEM INSPECTION PROCEDURE
Hazard
Warning
Flashers
Press and hold the hazard warning flashers
switch for 1-2 seconds to activate the hazard
warning flashers. Verify that all four turn signals
flash, as well as the lamps on the indicator
panel. Turn the hazard warning flashers off.
Verify that all signals and indicator lamps stop
flashing.
Horn Press the horn switch. Verify that the horn
sounds loudly.
Neutral
Indicator
Place the transmission in neutral. Verify that the
neutral indicator lamp illuminates and that the
letter "N" displays in the gear position display.
Low Oil
Pressure
Indicator
Start the engine. Verify that the low oil pressure
indicator is not illuminated.
Engine Stop/
Run Switch
Start the engine. Move the stop/run switch to the
STOP position. Verify that the engine stops.
52
PRE-RIDE INSPECTIONS
GGEENNEERRAALL IINNSSPPEECCTTIIOONNSS
ITEM INSPECTION PROCEDURE
Engine Oil Check the oil level.
Fuel Check the fuel level
Coolant
Level
Check the coolant level in the recovery bottle.
Fluid Leaks Check the vehicle and the ground/floor for any
fuel, oil, coolant or hydraulic fluid leaks.
Tires Inspect condition, pressure and tread depth.
Brake
Operation
Inspect pedal and lever movement.
Brake Fluid
Levels
Check front and rear brake fluid levels.
Brake
Components
Inspect hoses and connections.
Throttle Inspect hand grip and throttle movement.
Clutch Check lever operation and freeplay.
Front
Suspension
Check for leaks, debris and damage.
Steering Check for smooth operation by turning
handlebars full left and full right.
ITEM INSPECTION PROCEDURE
Rear
Suspension
Check mounting and inspect for leaks.
Rear Drive
Chain
Check for wear or damage.
Side Stand Verify smooth operation, inspect pivot bolt and
spring.
Fasteners Inspect for loose, damaged or missing fasteners.
Mirrors Adjust for proper rear view.
Heat Shields Ensure all exhaust heat-shields are present and
in good condition.
53
PRE-RIDE INSPECTIONS
TTIIRREESS
WARNING
Operating the motorcycle with incorrect tires, incorrect tire
pressure or excessively worn tires could cause loss of control or
accident. Underinflation can cause a tire to overheat and result in
a tire failure. Only use tires approved by Indian for the model of
the motorcycle. See your dealer. Use of unapproved or an
improperly mixed front and rear tire can result in decreased
handling performance and stability, potentially leading to
reduced control of the motorcycle. Always maintain proper tire
pressure as recommended in the rider’s manual and on safety
labels.
TTIIRREE PPRREESSSSUURREE
Improper tire pressure can result in irregular tire wear, tire failure,
reduced fuel economy and a poor riding experience. It can also
affect handling and stopping ability.
Slow tire pressure loss over time is normal for a functional tire.
Always inspect tire pressure and condition before each ride.
Check tire pressure before riding, when the tires are cold. This will
provide the most accurate reading, as riding warms the tires and
increases tire air pressure. Tires remain warm for at least 3 hours
after a ride. Do not adjust tire pressure immediately after riding.
As tires cool, the pressure will drop and result in underinflation.
Always check and adjust tire pressure when tires are cold.
Using a good quality pocket-style gauge, adjust tire pressure to the
recommended pressure.
TTIIRREE CCOONNDDIITTIIOONN
Inspect the tire sidewalls, road contact surface and tread base. If
inspection reveals cuts, punctures, cracks or other wear or
damage, replace the tire before riding. Only use tires approved by
Indian for the model of the motorcycle. See your dealer. Use of
unapproved or an improperly mixed front and rear tire can result
in decreased handling performance and stability, potentially
leading to reduced control of the motorcycle.
TTIIRREE TTRREEAADD DDEEPPTTHH
Measure the tread depth near the center of the tread on both tires.
See page 122. Replace any tire with a tread depth of less than 1/16
inch (1.6 mm).
BBRRAAKKEE FFLLUUIIDD LLEEVVEELL IINNSSPPEECCTTIIOONN
IMPORTANT
The brake fluid level in the reservoir will go down as brake pads
wear. If you notice a sudden lowering of the brake fluid level,
inspect brake pads for wear and brake system for leaks.
NOTE
When installing new brake pads, fill the reservoir to the MAX
mark. This reservoir can be used as a wear indicator, as the pads
wear out, the level will decrease. When it is close to or at the MIN
mark, inspect brake pads and replace if necessary. While this
can be used as a indicator, the BEST way to inspect brake wear is
to inspect the pads themselves.
55
PRE-RIDE INSPECTIONS
FFRROONNTT BBRRAAKKEE FFLLUUIIDD IINNSSPPEECCTTIIOONN
1. Turn handlebars or adjust the motorcycle until top of reservoir
is level.
2. View front brake fluid level through the fluid reservoir. The
fluid should be clear and between the MIN q
and MAX w
markings.
3. Wipe area around reservoir cover with a clean cloth.
4. Wipe brake fluid container with a clean cloth.
5. Remove screws e, reservoir cover r.
6. Carefully add enough DOT 4 brake fluid to bring level to
between the MIN q
and MAX w
markings. Always add brake
fluid from a new, unopened container.
7. Reinstall reservoir cover and torque screws to specification.
TORQUE
Front Master Cylinder Cap Screws:
10 in-lbs (1 N m)·
56
PRE-RIDE INSPECTIONS
RREEAARR BBRRAAKKEE FFLLUUIIDD IINNSSPPEECCTTIIOONN
1. Fluid level is checked at the rear brake master cylinder
reservoir.
2. Ensure vehicle is upright, then view fluid level through the fluid
reservoir. The fluid should be clear and between the MIN
t
and MAX y
markings.
3. Wipe area around reservoir cover with a clean cloth.
4. Wipe brake fluid container with a clean cloth.
5. Remove reservoir cover
u.
6. Carefully add enough DOT 4 brake fluid to bring level to
between the MIN t
and MAX y
markings. Always add brake
fluid from a new, unopened container.
7. Install diaphragm and cover.
57
PRE-RIDE INSPECTIONS
FFRROONNTT BBRRAAKKEE LLEEVVEERR
1. Pull the front brake lever toward the handlebar and hold it. The
lever should move freely and smoothly. The lever should feel
firm and continue to feel firm until released.
2. Release the lever. It should return to its rest position quickly
when released.
3. If the front brake lever fails to perform as stated, service the
brake lever before riding.
RREEAARR BBRRAAKKEE PPEEDDAALL
1. Press downward on the rear brake pedal. It should move freely
and smoothly. The pedal should feel firm and continue to feel
firm until released.
2. Release the pedal. It should return to its rest position quickly
when released.
3. If the rear brake pedal fails to perform as stated or travels too
far before beginning to engage the brake, service the brakes
before riding.
BBRRAAKKEE LLIINNEESS
Inspect all brake hoses and connections for dampness or stains
from leaking or dried fluid. Tighten any leaking connections to the
proper torque values and replace components as necessary. See
the INDIAN MOTORCYCLE Service Manual or an authorized INDIAN
MOTORCYCLE dealer or other qualified dealer.
WARNING
Brake fluid leaks or low brake fluid levels could cause brake
system failure, which could result in serious injury or death. Do
not operate the vehicle with low brake fluid levels or when leaks
are evident (dampness or stains from dried fluid). See your
authorized INDIAN MOTORCYCLE dealer or other qualified
dealer.
58
PRE-RIDE INSPECTIONS
MMEECCHHAANNIICCAALL CCLLUUTTCCHH
1. Squeeze the clutch lever
q
toward the handlebar and release
it. It should move freely and smoothly, and it should return to
the rest position quickly when released. If the lever fails to
perform as stated, service the clutch lever before riding.
2. Freeplay (gap) is the amount of lever movement from the rest
position to the point of cable resistance. Clutch lever freeplay
w
should be 0.5-1.5 mm. Measure the gap between the clutch
lever and the lever housing. Adjust clutch lever freeplay if
necessary.
NOTE
The starter interlock switch is dependent on the clutch lever
freeplay being set correctly to ensure activation of the clutch
safety switch.
TTHHRROOTTTTLLEE
Rotate the throttle control grip. It should rotate smoothly from the
rest position to the completely open position. It should return to
the rest position quickly when released.
FFRROONNTT SSUUSSPPEENNSSIIOONN
Inspect the front forks for oil leaks or damage, and verify smooth
suspension operation. See the Front Fork / Suspension Inspection
section for details.
RREEAARR SSUUSSPPEENNSSIIOONN
Check the rear shock absorber mounting and inspect for leaks.
See your dealer for service if you discover leaks or malfunction of
any kind. See the Rear Shock Preload (Ride Height) sections
regarding inspection and adjustments for details.
WARNING
Inadequate ground clearance could result in components
contacting the ground, causing loss of control and serious injury
or death. Always ensure ground clearance is at specification.
59
PRE-RIDE INSPECTIONS
SSPPRROOCCKKEETT IINNSSPPEECCTTIIOONN
NOTICE
Drive chain and sprocket service life are maximized and drive
line noise minimized by proper cleaning. Cleaning interval is
approximately every tire change, or more often if operated in
dirty, dusty, or high debris environments.
Clean the chain using a chain brush or clean rag to remove any
dirt or grit. The chain must be lubricated using Indian Motorcycle
chain lube (2884172).
CAUTION
Always have the motorcycle off and the transmission in neutral
when performing this procedure.
CAUTION
Do not use a de-greaser to clean the chain. De-greaser may
damage the chain o-rings and cause premature wear.
1. Inspect front and rear sprocket teeth for wear or damage from
foreign material.
2. Closely inspect drive chain condition.
Things to look for:
• wear pattern - ensure even wear throughout sprocket
• cracks
• missing teeth
• uniform teeth size
60
PRE-RIDE INSPECTIONS
DDRRIIVVEE CCHHAAIINN
1. Inspect drive chain for excessive wear or sag, foreign
substance (grit), or any other damage.
2. If any damage is found, chain should be replaced.
3. If the drive chain or sprocket is being replaced due to damage,
replace chain and both sprockets as a set if drive system has
more than 5000 miles (8000 Km) of use.
FFUUEELL LLEEVVEELL
1. Position the motorcycle on level ground on its side stand.
2. Slowly open the fuel cap.
3. View the fuel level in the tank.
4. Refuel as needed to the bottom of the filler neck. See the
Fueling section for fueling instructions. See the Fuel
Recommendations section for fuel specifications.
SSIIDDEE--SSTTAANNDD
1. On level ground, straddle the motorcycle and bring it to the
fully upright position.
2. Move the side-stand up to the stored position and down to the
fully extended position several times. It should move smoothly
and quietly. Make sure the return spring holds the side-stand
tightly in place when the side-stand is in the stored position.
Adjust or replace a loose spring.
3. Inspect the side-stand pivot bolt for looseness or wear. Tighten
or replace a loose or worn bolt.
4. Periodically test the side-stand safety switch for proper
operation. With the transmission in gear and brakes applied,
attempt to start the engine while the side-stand is down. The
engine should NEVER start in any gear except neutral if the
side-stand is down. If the engine starts during this test, see your
dealer for service.
FFAASSTTEENNEERRSS
1. Inspect the entire motorcycle chassis and engine for loose,
damaged or missing fasteners.
2. Tighten loose fasteners to the proper torque. See the INDIAN
MOTORCYCLE Service Manual or an authorized INDIAN
MOTORCYCLE dealer or other qualified dealer.
TIP
Always replace stripped, damaged or broken fasteners before
riding. Use genuine INDIAN MOTORCYCLE fasteners of equal
size and strength.
61
PRE-RIDE INSPECTIONS
62
OOPPEERRAATTIIOONN
OOVVEERRVVIIEEWW
The operation section of this manual describes how to ensure
maximum performance and longevity through the proper care and
operation of your motorcycle.
Important areas covered by the operation section include:
• Engine Break-In
• Fueling
• Starting the Engine
• Shifting Gears
• Accelerating
• Braking
• Stopping the Engine
• Parking
TIP
Even if you're an experienced motorcycle operator or passenger,
read all of the safety information in this manual before operating
the motorcycle.
NOTICE
Failure to properly follow the engine break-in procedures
outlined in this manual can result in serious damage to the
engine. Follow all break-in procedures carefully. Avoid full
throttle operation and other conditions that may place an
excessive load on the engine during the break-in period.
EENNGGIINNEE BBRREEAAKK--IINN
The engine break-in period for your motorcycle is the first 500
miles (800 km) of operation. During this break-in period, critical
engine parts require special wear-in procedures so they seat and
mate properly. Read, understand and follow all break-in
procedures to ensure the long-term performance and durability of
your engine.
The more cautiously you treat your motorcycle during the break-in
period, the more satisfied you will be with its performance later
on. Overloading the engine at low RPM and/or running the engine
prematurely at high RPM may result in damage to the engine
components.
Observe the following precautions during the break-in period:
• Upon initial start-up, do not allow the engine to idle for long
periods as overheating can occur.
• Avoid fast starts with wide open throttle. Drive slowly until the
engine warms up.
• Avoid running the engine at extremely low RPM in higher gears
(lugging the engine).
• Drive within the recommended operating speeds and gears.
See page 64 and page 67.
63
OPERATION
OOPPEERRAATTIINNGG SSPPEEEEDDSS AANNDD GGEEAARRSS
ODOMETER
BREAK-IN PROCEDURE
MILES KM
0-90 0-145 Do not operate for extended periods above 1/3
throttle or at any one throttle position. Vary engine
speed frequently.
91-300 146-483 Do not operate for extended periods above 1/2
throttle or at any one throttle position. Vary engine
speed frequently.
301-500 484-800 Do not operate for extended periods above 3/4
throttle.
At 500 At 800 Perform the break-in maintenance outlined in the
maintenance section of this manual. Break-in
maintenance should be performed by a dealership.
Break-in maintenance must include inspection,
adjustments, fastener tightening and an engine oil
and filter change. Performing break-in maintenance
at the required odometer reading helps ensure peak
engine performance, minimal exhaust emissions and
maximum service life of the engine.
FFUUEELLIINNGG
Always dismount the motorcycle and refuel on level ground with
the sidestand down. Review the fuel warnings. See page 17. Use
only the recommended fuel. See page 150.
WARNING
Overflows or spilled gasoline could contact a hot engine or
exhaust system and cause a fire, which could result in serious
injury or death. Do not allow gasoline to contact hot components.
WARNING
Always open the fuel cap slowly and fill the fuel tank slowly to
prevent spillage. Do not overfill the fuel tank. Leave space in the
tank to allow for the fuel to expand.
64
OPERATION
1. To open the fuel tank cap
q, insert the ignition key into the cap
lock and turn it counter-clockwise.
2. Insert the fuel nozzle into the fuel tank filler neck.
3. Hold the nozzle while filling. Do not rest the weight of the nozzle
and hose on the filler neck. Do not leave the nozzle unattended.
4. Add fuel to the tank until it crests the oval-shaped opening in
the filler neck. The tank is full at this level. Do not overfill the
fuel tank. Fuel level should not rise into fill neck funnel.
Overfilling may result in degraded performance of engine and
evaporative emissions control system.
5. Always close and lock the fuel cap before remounting the
motorcycle. With the key rotated counter-clockwise, close the
fuel cap with your opposite hand and press it down firmly. Turn
the key clockwise to secure the lock.
6. If the motorcycle runs out of fuel, prime the system before
attempting to restart the engine. See page 65.
NOTICE
Fuel can damage painted surfaces and plastic parts. If gasoline
spills on the any part of the motorcycle, immediately rinse it off
with water or wipe it dry with a clean cloth.
PPRRIIMMIINNGG TTHHEE FFUUEELL SSYYSSTTEEMM
If the motorcycle runs out of fuel, prime the fuel system before
attempting to restart the engine.
1. Fill the fuel tank.
2. Turn the ignition key to the ON position.
3. Move the engine stop/run switch to the RUN position.
4. Allow the fuel pump to run until it stops (about 2 seconds).
5. Move the engine stop/run switch to the STOP position and wait
15 seconds.
6. Repeat steps 3–5 four to five times.
7. Turn the key to the OFF position.
8. Start the engine. See page 65.
SSTTAARRTTIINNGG TTHHEE EENNGGIINNEE
The starter interlock system allows the engine to be started only
when the transmission is in neutral, or when the transmission is in
gear with the clutch disengaged (clutch lever pulled in).
1. Perform the Pre-Ride Inspections. See page 51. Properly secure
any cargo.
2. Straddle the motorcycle and bring it to the fully upright
position. Retract the sidestand.
3. Turn the ignition key to the ON position.
4. Move the engine stop/run switch to the RUN position.
5. Shift the transmission to neutral.
6. Apply the front brakes. Disengage the clutch (pull the clutch
lever fully toward the handlebar).
65
OPERATION
1. To slow the motorcycle with the brakes, close the throttle and
apply the front and rear brakes gradually.
TIP
When the anti-lock brakes engage during a braking event, the
rider will feel pulsing at the brake lever. Continue to apply
steady pressure to the brakes for the best stopping performance.
2. As the motorcycle slows, disengage the clutch, or downshift
each time vehicle speed reaches a downshift point.
WARNING
Braking improperly could result in loss of control, which could
result in serious injury or death. Avoid braking abruptly. Always
apply the brakes gradually, especially on wet, slippery or other
low traction surfaces. Avoid braking in a curve or turn. Bring the
motorcycle to the upright position before applying the brakes.
AACCCCEELLEERRAATTIINNGG
Accelerate by opening the throttle (rolling the throttle control grip
rearward). For even acceleration, open the throttle with a smooth,
continuous motion. When you reach the recommended speed for
upshifting, shift up one gear.
WARNING
Accelerating abruptly could cause your body to shift rearward
suddenly, which could result in loss of control. Accelerating
abruptly could also cause loss of control on low traction surfaces.
Loss of control could result in serious injury or death. Always
accelerate gradually, especially on wet, slippery or other low
traction surfaces.
SSTTOOPPPPIINNGG TTHHEE EENNGGIINNEE
Before stopping the engine, bring the motorcycle to a complete
stop. Shift to neutral or disengage the clutch.
WARNING
Stopping the engine with the transmission in gear while the
motorcycle is moving could cause loss of rear wheel traction or
engine and transmission damage, which could cause loss of
control and serious injury or death. Always stop the engine after
the motorcycle is fully stopped and the transmission is in neutral.
If the engine stops unexpectedly while the motorcycle is moving,
pull the clutch and guide the motorcycle to a safe location off the
road and away from traffic. Turn the ignition switch off.
1. When fully stopped, shift into neutral.
2. Move the engine stop/run switch to the STOP position.
3. Turn the ignition switch off. Remove the ignition key.
69
OPERATION
UUSSIINNGG CCRRUUIISSEE CCOONNTTRROOLL
The cruise control switches are located on the left hand control.
Read this section and understand how to safely operate this feature
before using the cruise control.
Cruise control can be activated and adjusted from the left-hand
control using the Cruise Control Switch. See page 28.
WARNING
Improper operation of cruise control could cause loss of control
and result in serious injury or death. Follow all cruise operation
procedures carefully. Never use cruise control when roads are
wet or slippery. Do not use cruise control when riding in heavy or
congested traffic.
CCRRUUIISSEE CCOONNTTRROOLL TTIIPPSS
• Cruise control can be set in gears 3-6.
• Vehicle speed must be above 20 MPH (32 km/h).
• Set speed will vary slightly in hilly terrain.
• Cruise control will not resume a pre-set speed if the resulting
acceleration or deceleration rate is too high or too low. For
example, resuming a set speed of 70 MPH from 40 MPH (64 km/
h), while in 6th gear, may cause cruise to disengage.
• Cruise control will not engage if brake lights are not operating
properly.
• The clutch or either brake must have been activated at least
once since the engine was started for the cruise control to
function.
SSEETT SSPPEEEEDD
1. Press and release the center of the cruise control switch
q. The
cruise control indicator will illuminate in the instrument cluster.
Cruise control is enabled, but not set.
2. Accelerate to the desired speed and press down on the cruise
control switch to activate cruise control. The Cruise Control Set
indicator lamp will illuminate. Cruise control is set to the
desired speed.
RREESSUUMMEE SSPPEEEEDD
After disengaging the cruise control with the brake, throttle or
clutch, press up on the cruise control switch to return to the set
speed.
AACCCCEELLEERRAATTEE
While cruise control is engaged, tap up on the cruise control
switch to increase speed in approximately 1 MPH (1-2 km/h)
increments. Press and hold up on the cruise control switch to
accelerate to a new set speed (resets when switch is released).
TIP
If you use the throttle to accelerate and then release it, the cruise
control will resume the previously set speed.
70
OPERATION
DDEECCEELLEERRAATTEE
While cruise control is engaged, tap and release down on the
cruise control switch to decrease speed in approximately 1 MPH
(1-2 km/h) increments. Press and hold the down on the cruise
control switch to decelerate to a new set speed (resets when
switch is released), or to the minimum cruise speed of 20 MPH (32
km/h).
CCAANNCCEELL CCRRUUIISSEE CCOONNTTRROOLL
To temporarily cancel the cruise control and allow use of the
resume feature:
• Apply the brakes, or
• Pull the clutch lever in, or
• Roll the throttle grip forward past the idle position
To cancel the cruise control and erase the set speed from memory,
press the cruise on/off switch.
PPAARRKKIINNGG
Choose a firm level surface to park the motorcycle.
1. When fully stopped, shift into neutral.
2. Stop the engine.
3. Fully extend the sidestand.
4. Turn the handlebars to the left and lean the motorcycle to the
left until the sidestand firmly supports the motorcycle.
5. Remove the ignition key.
PPAARRKKIINNGG OONN AA SSLLOOPPEE
If parking on a slope is unavoidable, park with the front wheel
uphill from the rear wheel. Place the transmission in first gear and
position the motorcycle so that it is stable when it rests on the
sidestand.
NOTICE
Always park with the front wheel uphill from the rear wheel when
parking on a slope. If the front wheel is downhill from the rear
wheel, the sidestand could retract and cause a tipover.
PPAARRKKIINNGG OONN AA SSOOFFTT SSUURRFFAACCEE
If parking on a soft surface is unavoidable, place a sidestand
footrest under the foot of the sidestand to provide a firm surface.
The sidestand footrest must be strong enough and large enough to
support the motorcycle’s weight without sinking into the parking
surface.
Asphalt becomes soft in hot weather. A sidestand can sink into soft
asphalt and the motorcycle may fall. When parking on asphalt in
hot weather, use a sidestand footrest.
CAUTION
Hot engine and exhaust components can cause burns to skin and
can ignite a fire if exposed to flammable materials. Always park
the motorcycle clear of flammable materials and where people
are not likely to contact hot components.
71
OPERATION
72
MMAAIINNTTEENNAANNCCEE
SSAAFFEETTYY DDUURRIINNGG SSEERRVVIICCEE PPRROOCCEEDDUURREESS
WARNING
Failure to follow all recommended precautions and procedures could result in severe injury or death. Always heed all safety precautions
and follow all operation, inspection and maintenance procedures outlined in this manual.
• Improperly installed or adjusted components can make the motorcycle
unstable or hard to handle. Improperly installed electrical components
can cause engine or electrical system failure. In either event, damage or
serious injury could result. If you do not have the time, tools and
expertise necessary to complete a procedure properly, please see your
dealer for service.
• Review the safety-related maintenance information in the Safety
Maintenance section.
• Before beginning any maintenance procedure, read the instructions for
the entire procedure.
• Always position the motorcycle on a firm level surface before
performing service. Make sure the motorcycle will not tip or fall while
elevated or while on the sidestand. See the Elevating the Vehicle section
for details.
• Hot engine and exhaust components can cause burns to skin and can
ignite a fire if exposed to flammable materials. Always park the
motorcycle clear of flammable materials and where people are not likely
to contact hot components.
• Wear eye and face protection when using pressurized air.
• Never start the engine or let it run in an enclosed area. Engine exhaust
fumes are poisonous and can cause loss of consciousness or death in a
short time.
• During some procedures you may use potentially hazardous products
such as oil or brake fluid. Always follow the instructions and warnings on
the product packaging.
73
MAINTENANCE
PPRROOPPEERR MMAAIINNTTEENNAANNCCEE
Proper maintenance assures the highest level of safety, durability
and dependability for your motorcycle. Break-in maintenance is
required to ensure warranty coverage and proper emissions
system operation.
• Perform the break-in maintenance procedures when the
motorcycle’s odometer registers 500 miles (800 km). Please see
your authorized dealer for this service.
• Perform the recommended at the intervals periodic maintenance
specified in the Periodic Maintenance Table beginning on page
75.
RROOAADD TTEESSTTSS
Before returning the motorcycle to regular use after performing
service, road test it in a safe environment. Pay special attention to
the proper fit and operation of all serviced components. Make any
corrections or additional adjustments necessary to ensure safe
vehicle performance.
BBRREEAAKK--IINN MMAAIINNTTEENNAANNCCEE
Perform the break-in maintenance procedures when the
motorcycle’s odometer registers 500 miles (800 km). Please see
your authorized dealer for this service.
Performing the break-in maintenance will help ensure optimum
engine performance for the entire service life of the engine. Your
dealer will change engine oil, inspect all fluids and serviceable
components, ensure that all fasteners are tightened and make
other adjustments as needed.
MMAAJJOORR MMAAIINNTTEENNAANNCCEE
Major repairs typically require technical skills and specially
designed tools. Emission system service requires special tools and
training and should be performed by your dealer. See the INDIAN
MOTORCYCLE Service Manual or an authorized INDIAN
MOTORCYCLE dealer or other qualified dealer.
PPEERRIIOODDIICC MMAAIINNTTEENNAANNCCEE
Inspect, clean, lubricate, adjust and replace parts as necessary.
When inspection reveals the need for replacement parts, use
genuine INDIAN MOTORCYCLE parts available from your dealer.
Record service and maintenance information in the Maintenance
Log beginning on page 163.
Perform maintenance at the intervals specified in the Periodic
Maintenance Interval Chart. Vehicles subjected to severe use must
be inspected and serviced more frequently.
SSEEVVEERREE UUSSEE DDEEFFIINNIITTIIOONN
• high speed operation for extended periods
• low speed operation for extended periods
• operation in dusty or otherwise adverse conditions
• operation in cold weather (temperatures below freezing)
74
MAINTENANCE
ITEM REMARKS
EEvaporative Emission Control System Inspect; clean
EExhaust System Inspect; tighten, adjust
DFuel System Inspect; clean
DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary
Battery Check terminals; clean; test
D Brake Fluid Change every two years (DOT 4)
XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit
DClutch Cable Freeplay Inspect; adjust if necessary
D Fasteners Inspect; tighten if necessary
D Front Brake Lever Inspect; adjust if necessary, lubricate with proper lubricant as directed
D Front Forks and Front Axle Inspect; adjust if necessary
D Gear Shift Pedal Inspect; adjust if necessary
DHead Light Inspect; adjust if necessary
D Rear Brake Pedal Inspect; adjust if necessary
D Rear Shock Absorber Inspect; adjust if necessary
DRear Wheel Alignment Inspect; adjust if necessary
Road Test Perform Road Test
D Sidestand Inspect; adjust if necessary, lubricate with proper lubricant as directed
DSteering Bearings Inspect
DSuspension Linkage, Rear Inspect
77
MAINTENANCE
ITEM REMARKS
DSwing Arm and Rear Axle Inspect
D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns
55,,000000 MMIILLEE ((88,,000000 KKMM)) SSEERRVVIICCEE
ITEM REMARKS
XU Air Filter Inspect; clean
DCrankcase Ventilation System Inspect; tighten, clean, adjust
D Drive Chain Inspect; clean, lubricate
D Chain Sliders Inspect; replace as needed
EEvaporative Emission Control System Inspect; clean
EExhaust System Inspect; tighten, adjust
DFuel System Inspect; clean
DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary
Battery Check terminals; clean; test
D Brake Fluid Change every two years (DOT 4)
XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit
D Clutch Lever Inspect; adjust if necessary
DClutch Cable Freeplay Inspect; adjust if necessary
D Control Cable Ends Inspect; lubricate with proper lubricant as directed
D Fasteners Inspect; tighten if necessary
D Front Brake Lever Adjust if necessary, lubricate with proper lubricant as directed
78
MAINTENANCE
ITEM REMARKS
D Front Fork Oil Replace at specified interval or every 2 years
D Front Forks and Front Axle Inspect; adjust if necessary
D Gear Shift Pedal Inspect; adjust if necessary
D Rear Brake Pedal Inspect; adjust if necessary
D Rear Shock Absorber Inspect; adjust if necessary
DRear Wheel Alignment Inspect; adjust if necessary
Road Test Perform Road Test
D Sidestand Inspect; adjust if necessary, lubricate with proper lubricant as directed
DSteering Bearings Inspect
DSuspension Linkage, Rear Inspect
DSwing Arm and Rear Axle Inspect
D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns
1100,,000000 MMIILLEE ((1166,,000000 KKMM)) SSEERRVVIICCEE
ITEM REMARKS
XU Air Filter Inspect; clean
DCrankcase Ventilation System Inspect; tighten, clean, adjust
D Drive Chain Inspect; clean, lubricate
D Chain Sliders Inspect; replace as needed
DEngine Compression Inspect; correct if necessary
XU Engine Oil & Filter Change Change oil and filter, inspect used oil for contaminants
EEvaporative Emission Control System Inspect; clean
79
MAINTENANCE
ITEM REMARKS
EExhaust System Inspect; tighten, adjust
DFuel System Inspect; clean
DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary
D / E Spark Plugs Inspect; replace as needed; torque to specification
Battery Check terminals; clean; test
D Brake Fluid Replace (DOT 4)
XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit
D Clutch Lever Lubricate with proper lubricant as directed
DClutch Cable Freeplay Inspect; adjust if necessary
D Control Cable Ends Lubricate with proper lubricant as directed
D Fasteners Inspect; tighten if necessary
D Front Brake Lever Adjust if necessary, lubricate with proper lubricant as directed
D Front Fork Oil Replace at specified interval or every 2 years
D Front Forks and Front Axle Inspect; adjust if necessary
D Gear Shift Pedal Inspect; adjust if necessary
DHead Light Inspect; adjust if necessary
D Rear Brake Pedal Inspect; adjust if necessary
D Rear Shock Absorber Inspect; adjust if necessary
DRear Wheel Alignment Inspect; adjust if necessary
Road Test Perform Road Test
D Sidestand Lubricate with proper lubricant as directed
80
MAINTENANCE
ITEM REMARKS
DSteering Bearings Inspect
DSuspension Linkage, Rear Inspect
DSwing Arm and Rear Axle Inspect
D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns
1155,,000000 MMIILLEE ((2244,,000000 KKMM)) SSEERRVVIICCEE
ITEM REMARKS
XU Air Filter Replace
DCrankcase Ventilation System Inspect; tighten, clean, adjust
D Drive Chain Replace
D Chain Sliders Inspect; replace as needed
EEvaporative Emission Control System Inspect; clean
EExhaust System Inspect; tighten, adjust
DFuel System Inspect; clean
DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary
Battery Check terminals; clean; test
D Brake Fluid Change every two years (DOT 4)
XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit
D Clutch Lever Inspect; adjust if necessary
DClutch Cable Freeplay Inspect; adjust if necessary
D Control Cable Ends Inspect; adjust if necessary
81
MAINTENANCE
ITEM REMARKS
D Fasteners Inspect; tighten if necessary
D Front Brake Lever Adjust if necessary, lubricate with proper lubricant as directed
D Front Fork Oil Replace
D Front Forks and Front Axle Inspect; adjust if necessary
D Gear Shift Pedal Inspect; adjust if necessary
D Rear Brake Pedal Inspect; adjust if necessary
D Rear Shock Absorber Inspect; adjust if necessary
DRear Wheel Alignment Inspect; adjust if necessary
Road Test Perform Road Test
D Sidestand Inspect; adjust if necessary, lubricate with proper lubricant as directed
DSteering Bearings Inspect
DSuspension Linkage, Rear Inspect
DSwing Arm and Rear Axle Inspect
D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns
2200,,000000 MMIILLEE ((3322,,000000 KKMM)) SSEERRVVIICCEE
ITEM REMARKS
XU Air Filter Inspect; clean
DCrankcase Ventilation System Inspect; tighten, clean, adjust
D Drive Chain Inspect; clean, lubricate
D Chain Sliders Inspect; replace as needed
DEngine Compression Inspect; correct if necessary
82
MAINTENANCE
ITEM REMARKS
XU Engine Oil & Filter Change Change oil and filter, inspect used oil for contaminants
EEvaporative Emission Control System Inspect; clean
EExhaust System Inspect; tighten, adjust
DFuel System Inspect; clean
DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary
D / E Spark Plugs Inspect; replace as needed; torque to specification
D Valve Lash Clearance Inspect; adjust if necessary
Battery Check terminals; clean; test
D Brake Fluid Replace (DOT 4)
XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit
D Clutch Lever Lubricate with proper lubricant as directed
DClutch Cable Freeplay Inspect; adjust if necessary
D Control Cable Ends Lubricate with proper lubricant as directed
D Fasteners Inspect; tighten if necessary
D Front Brake Lever Adjust if necessary, lubricate with proper lubricant as directed
D Front Fork Oil Inspect
D Front Forks and Front Axle Inspect; adjust if necessary
D Gear Shift Pedal Inspect; adjust if necessary
DHead Light Inspect; adjust if necessary
D Rear Brake Pedal Inspect; adjust if necessary
D Rear Shock Absorber Inspect; adjust if necessary
83
MAINTENANCE
ITEM REMARKS
DRear Wheel Alignment Inspect; adjust if necessary
Road Test Perform Road Test
D Sidestand Lubricate with proper lubricant as directed
DSteering Bearings Inspect
DSuspension Linkage, Rear Inspect
DSwing Arm and Rear Axle Inspect
D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns
2255,,000000 MMIILLEE ((4400,,000000 KKMM)) SSEERRVVIICCEE
ITEM REMARKS
XU Air Filter Inspect; clean
DCrankcase Ventilation System Inspect; tighten, clean, adjust
D Drive Chain Inspect; clean, lubricate
D Chain Sliders Inspect; replace as needed
EEvaporative Emission Control System Inspect; clean
EExhaust System Inspect; tighten, adjust
DFuel System Inspect; clean
DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary
Battery Check terminals; clean; test
D Brake Fluid Change every two years (DOT 4)
XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit
D Clutch Lever Inspect; adjust if necessary
84
MAINTENANCE
ITEM REMARKS
DClutch Cable Freeplay Inspect; adjust if necessary
D Control Cable Ends Inspect; adjust if necessary
D Fasteners Inspect; tighten if necessary
D Front Brake Lever Adjust if necessary, lubricate with proper lubricant as directed
D Front Fork Oil Inspect
D Front Forks and Front Axle Inspect; adjust if necessary
D Gear Shift Pedal Inspect; adjust if necessary
D Rear Brake Pedal Inspect; adjust if necessary
D Rear Shock Absorber Inspect; adjust if necessary
DRear Wheel Alignment Inspect; adjust if necessary
Road Test Perform Road Test
D Sidestand Inspect; adjust if necessary, lubricate with proper lubricant as directed
DSteering Bearings Inspect
DSuspension Linkage, Rear Inspect
DSwing Arm and Rear Axle Inspect
D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns
3300,,000000 MMIILLEE ((4488,,000000 KKMM)) SSEERRVVIICCEE
ITEM REMARKS
XU Air Filter Replace
DCrankcase Ventilation System Inspect; tighten, clean, adjust
D Drive Chain Replace
85
MAINTENANCE
ITEM REMARKS
D Chain Sliders Inspect; replace as needed
DEngine Compression Inspect; correct if necessary
XU Engine Oil & Filter Change Change oil and filter, inspect used oil for contaminants
EEvaporative Emission Control System Inspect; clean
EExhaust System Inspect; tighten, adjust
DFuel System Inspect; clean
DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary
D / E Spark Plugs Replace
Battery Check terminals; clean; test
D Brake Fluid Replace (DOT 4)
XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit
D Clutch Lever Lubricate with proper lubricant as directed
DClutch Cable Freeplay Inspect; adjust if necessary
D Control Cable Ends Lubricate with proper lubricant as directed
D Fasteners Inspect; tighten if necessary
D Front Brake Lever Lubricate with proper lubricant as directed
D Front Fork Oil Replace
D Front Forks and Front Axle Inspect; adjust if necessary
D Gear Shift Pedal Inspect; adjust if necessary
DHead Light Inspect; adjust if necessary
D Rear Brake Pedal Inspect; adjust if necessary
86
MAINTENANCE
ITEM REMARKS
D Rear Shock Absorber Inspect; adjust if necessary
DRear Wheel Alignment Inspect; adjust if necessary
Road Test Perform Road Test
D Sidestand Lubricate with proper lubricant as directed
DSteering Bearings Inspect
DSuspension Linkage, Rear Inspect
DSwing Arm and Rear Axle Inspect
D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns
3355,,000000 MMIILLEE ((5522,,000000 KKMM)) SSEERRVVIICCEE
ITEM REMARKS
XU Air Filter Inspect; clean
DCrankcase Ventilation System Inspect; tighten, clean, adjust
D Drive Chain Inspect; clean, lubricate
D Chain Sliders Inspect; replace as needed
EEvaporative Emission Control System Inspect; clean
EExhaust System Inspect; tighten, adjust
DFuel System Inspect; clean
DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary
Battery Check terminals; clean; test
D Brake Fluid Change every two years (DOT 4)
XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit
87
MAINTENANCE
ITEM REMARKS
D Clutch Lever Inspect; adjust if necessary
DClutch Cable Freeplay Inspect; adjust if necessary
D Control Cable Ends Inspect; adjust if necessary
D Fasteners Inspect; tighten if necessary
D Front Brake Lever Adjust if necessary, lubricate with proper lubricant as directed
D Front Fork Oil Inspect
D Front Forks and Front Axle Inspect; adjust if necessary
D Gear Shift Pedal Inspect; adjust if necessary
D Rear Brake Pedal Inspect; adjust if necessary
D Rear Shock Absorber Inspect; adjust if necessary
DRear Wheel Alignment Inspect; adjust if necessary
Road Test Perform Road Test
D Sidestand Lubricate with proper lubricant as directed
DSteering Bearings Inspect
DSuspension Linkage, Rear Inspect
DSwing Arm and Rear Axle Inspect
D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns
4400,,000000 MMIILLEE ((6644,,000000 KKMM)) SSEERRVVIICCEE
ITEM REMARKS
XU Air Filter Inspect; clean
DCrankcase Ventilation System Inspect; tighten, clean, adjust
88
MAINTENANCE
ITEM REMARKS
D Drive Chain Inspect; clean, lubricate
D Chain Sliders Inspect; replace as needed
DEngine Compression Inspect; correct if necessary
XU Engine Oil & Filter Change Change oil and filter, inspect used oil for contaminants
EEvaporative Emission Control System Inspect; clean
EExhaust System Inspect; tighten, adjust
DFuel System Inspect; clean
DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary
D / E Spark Plugs Inspect; replace as needed; torque to specification
D Valve Lash Clearance Inspect; adjust if necessary
Battery Check terminals; clean; test
D Brake Fluid Replace (DOT 4)
XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit
D Clutch Lever Lubricate with proper lubricant as directed
DClutch Cable Freeplay Inspect; adjust if necessary
D Control Cable Ends Lubricate with proper lubricant as directed
D Fasteners Inspect; tighten if necessary
D Front Brake Lever Adjust if necessary, lubricate with proper lubricant as directed
D Front Fork Oil Inspect
D Front Forks and Front Axle Inspect; adjust if necessary
D Gear Shift Pedal Inspect; adjust if necessary
89
MAINTENANCE
ITEM REMARKS
DHead Light Inspect; adjust if necessary
D Rear Brake Pedal Inspect; adjust if necessary
D Rear Shock Absorber Inspect; adjust if necessary
DRear Wheel Alignment Inspect; adjust if necessary
Road Test Perform Road Test
D Sidestand Lubricate with proper lubricant as directed
DSteering Bearings Inspect
DSuspension Linkage, Rear Inspect
DSwing Arm and Rear Axle Inspect
D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns
4455,,000000 MMIILLEE ((7722,,000000 KKMM)) SSEERRVVIICCEE
ITEM REMARKS
XU Air Filter Replace
DCrankcase Ventilation System Inspect; tighten, clean, adjust
D Drive Chain Replace
D Chain Sliders Inspect; replace as needed
EEvaporative Emission Control System Inspect; clean
EExhaust System Inspect; tighten, adjust
DFuel System Inspect; clean
DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary
Battery Check terminals; clean; test
90
MAINTENANCE
ITEM REMARKS
D Brake Fluid Change every two years (DOT 4)
XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit
D Clutch Lever Lubricate with proper lubricant as directed
DClutch Cable Freeplay Inspect; adjust if necessary
D Control Cable Ends Inspect; lubricate with proper lubricant as directed
D Fasteners Inspect; tighten if necessary
D Front Brake Lever Lubricate with proper lubricant as directed
D Front Fork Oil Replace
D Front Forks and Front Axle Inspect; adjust if necessary
D Gear Shift Pedal Inspect; adjust if necessary
D Rear Brake Pedal Inspect; adjust if necessary
D Rear Shock Absorber Inspect; adjust if necessary
DRear Wheel Alignment Inspect; adjust if necessary
Road Test Perform Road Test
D Sidestand Lubricate with proper lubricant as directed
DSteering Bearings Inspect
DSuspension Linkage, Rear Inspect
DSwing Arm and Rear Axle Inspect
D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns
91
MAINTENANCE
5500,,000000 MMIILLEE ((8800,,000000 KKMM)) SSEERRVVIICCEE
ITEM REMARKS
XU Air Filter Inspect; clean
DCrankcase Ventilation System Inspect; tighten, clean, adjust
D Drive Chain Inspect; clean, lubricate
D Chain Sliders Inspect; replace as needed
DEngine Compression Inspect; correct if necessary
DEngine Mount Fasteners Inspect; tighten, adjust
XU Engine Oil & Filter Change Change oil and filter, inspect used oil for contaminants
EEvaporative Emission Control System Inspect; clean
EExhaust System Inspect; tighten, adjust
DFuel System Inspect; clean
DOil Lines / Oil System Inspection Inspect; clean, adjust if necessary
D / E Spark Plugs Inspect; replace as needed; torque to specification
Battery Check terminals; clean; test
D Brake Fluid Replace (DOT 4)
XU / D Brake Pads Inspect pad wear; replace if worn beyond service limit
D Clutch Lever Lubricate with proper lubricant as directed
DClutch Cable Freeplay Inspect; adjust if necessary
D Control Cable Ends Lubricate with proper lubricant as directed
D Fasteners Inspect; tighten if necessary
D Front Brake Lever Adjust if necessary, lubricate with proper lubricant as directed
92
MAINTENANCE
ITEM REMARKS
D Front Fork Oil Inspect
D Front Forks and Front Axle Inspect; adjust if necessary
D Gear Shift Pedal Inspect; adjust if necessary
DHead Light Inspect; adjust if necessary
D Rear Brake Pedal Inspect; adjust if necessary
D Rear Shock Absorber Replace
DRear Wheel Alignment Inspect; adjust if necessary
Road Test Perform Road Test
D Sidestand Lubricate with proper lubricant as directed
DSteering Bearings Inspect
DSuspension Linkage, Rear Inspect
DSwing Arm and Rear Axle Inspect
D Tires / Wheels Inspect tread depth, sidewall cracking, wear patterns
XU - Perform these procedures more often for vehicles subjected to severe use.
D - Have an authorized Indian Motorcycle dealer perform these services.
E - Emission Control System Service (California)
When the vehicle goes beyond 50,000 miles, return to the 500 mile chart and start the interval process over.
93
MAINTENANCE
EENNGGIINNEE OOIILL && FFIILLTTEERR CCHHAANNGGEE
IMPORTANT
Engine MUST BE WARMED before performing the following
procedure.
CAUTION
HOT COMPONENTS
Wear insulated gloves and use caution handling these parts.
1. Run engine until warm, then turn engine off.
2. Securely support the motorcycle in a vertical “centered”
position.
3. Place an oil drain pan under the engine oil drain plugs q and
w.
4. Remove the drain plugs and sealing washers.
5. Allow oil to drain completely. Dispose of oil properly.
6. Remove oil filter e and allow oil to drain. Dispose of oil filter
properly.
7. Clean the engine oil filter mount sealing surface and
surrounding area.
8. Place a small amount of oil on the new oil filter seal and spin
filter on until the filter seal contacts the sealing surface. Tighten
oil filter to specification.
TORQUE
Oil Filter:
115 in-lbs (13 N m) or approximately 3/4 to 1 full turn after ·
seal contacts the filter mount sealing surface.
94
MAINTENANCE
9. Use new sealing washers and reinstall the drain plugs. Torque
to specification.
TORQUE
Engine Oil Drain Plug:
15 ft-lbs (20 N m)·
10. Use a funnel to add 3 US quarts (2.8 Liters) of Indian Motorcycle
15W–60 Full Synthetic engine oil through the engine oil fill
port.
NOTICE
3 US quarts will bring the engine oil level at or near the “FULL”
mark on the sight glass. For a new or rebuilt (dry) engine add an
additional .5 US quart (.47 Liters).
11. Securely support the motorcycle in a vertical “centered”
position, idle engine for approximately 30 seconds.
12. Turn the engine off.
13. Inspect the oil level by looking at the oil sight glass. The oil
level should be in the middle of the sight glass between the two
indicator marks. DO NOT OVERFILL!
IMPORTANT
Total engine oil fill volume with oil filter change will be
approximately 3.0 - 4.0 US quarts (2.8 - 3.8 Liters). Total engine
oil fill volume with a new or rebuilt (dry) engine will be
approximately 4.5 quarts (4.25 Liters).
14. Refer to the page 54 section in this chapter for setting proper
oil level.
CAUTION
If the low oil pressure indicator remains illuminated longer than
usual after an oil change, do not increase RPM above idle until
indicator lamp goes out or engine may be damaged.
15. Check for leaks around drain plug and oil filter.
NOTICE
Recycle used oil and oil filter in accordance with local
regulations.
95
MAINTENANCE
CCOOOOLLIINNGG SSYYSSTTEEMM
The engine coolant level is controlled by the recovery system.
Recovery system components are the recovery bottle, the radiator
filler neck, the radiator pressure cap and the connecting hose.
As coolant operating temperature increases, the expanding
(heated) excess coolant is forced out of the engine, past the
pressure cap, and into the recovery bottle. As engine coolant
temperature decreases the contracting (cooled) coolant is drawn
back up from the bottle, past the pressure cap, and into the
radiator.
Some coolant level drop on new vehicles is normal as the system is
purging itself of trapped air. Check the coolant level and maintain
as recommended by adding coolant to the recovery bottle.
INDIAN recommends the use of Antifreeze 50/50 Premix. This
antifreeze is already premixed and ready to use. Do not dilute with
water.
To ensure that the coolant maintains its ability to protect the
engine, we recommend that the system be completely drained
every five (5) years or 50,000 miles, whichever comes first. Please
see your dealer for this service.
CCOOOOLLAANNTT LLEEVVEELL IINNSSPPEECCTTIIOONN
The Coolant Overflow bottle is located under the airbox cover. The
level can be viewed without the need to disassemble any
components.
1. Locate the coolant bottle level window located on the left side
of the unit.
2. Ensure the coolant is in between the marked values.
3. If the coolant level is below the bottom line, coolant will need to
be added to the system.
96
MAINTENANCE
AADDDDIINNGG CCOOOOLLAANNTT
To add coolant, do the following:
1. Remove the seat and airbox covers.
2. Remove he overflow bottle cap q to add coolant. Add coolant
until level is within the marked values.
AAIIRR FFIILLTTEERR RREEPPLLAACCEEMMEENNTT
NOTICE
If the motorcycle is operated in wet or dusty conditions, more
frequent servicing is required. The air filter element cannot be
cleaned. Replace the filter when necessary.
1. Remove the seat. See page 123.
2. Remove four fasteners q securing air box bezel.
97
MAINTENANCE
NOTE
Do not loosen or reinstall fasteners without compression limiters
in place.
3. Remove the center console cover from the alignment bracket.
4. Remove the gas cap and relocate to clean, safe location.
5. Remove the two fasteners securing the air box cover w.
6. Remove the 2 air box covers.
NOTICE
Pull air box cover up and out to remove.
7. Remove three fasteners e to remove alignment bracket.
98
MAINTENANCE
8. Remove seven fasteners r securing air filter access cover. 9. Remove the air filter from the airbox.
10. Inspect filter element and replace if dirty, wet, or oil fouled.
11. Install New filter with same orientation as old filter.
12. Install air filter access cover and secure with seven fasteners.
TORQUE
Air Filter Access Cover Fastener:14 in-lbs (2 N m)·
99
MAINTENANCE
13. Install the alignment bracket and secure with fasteners.
TORQUE
Bodywork Alignment Bracket Fastener:
96 in-lbs (11 Nm)
14. Install airbox cover.
TORQUE
Airbox Cover Fastener:
36 in-lbs (4 N m)·
15. Install gas cap.
16. Install center console cover.
17. Install airbox bezel and secure with fasteners.
TORQUE
Airbox Bezel Fastener:
36 in-lbs (4 N m)·
18. Reinstall seat. See page 123
CAUTION
A loose fitting cover or improperly installed filter element may
allow debris to enter the engine which may cause premature
engine wear.
CCHHAAIINN TTEENNSSIIOONN
To measure the chain tension, do the following:
100
MAINTENANCE
1. With motorcycle on side stand and in neutral, using a chain
tension gauge push up on the lower string of the chain in the
center with 10 lbs. of force.
2. Measure to the bottom of the swing arm behind the chain slider
q. The distance to the top of the chain should measure 33–40
mm.
3. If drive chain tension appears to be out of specification or
misaligned, see page 102, or your authorized Indian
Motorcycle dealer for maintenance and service
recommendations.
DDRRIIVVEE CCHHAAIINN SSTTRREETTCCHH IINNSSPPEECCTTIIOONN
With a 20-25 lbs. weight hung on the lower string of the chain,
measure the distance from the center of one pin to the center of the
21st pin on the top string of the chain. If the length exceeds 319
mm, chain must be replaced.
DDRRIIVVEE CCHHAAIINN TTEENNSSIIOONN -- SSPPEECCIIFFIICCAATTIIOONNSS
CHAIN DEFLECTION
MODEL DEFLECTION AT 10 LBS FORCE
All Models 33 mm – 40 mm
DRIVE CHAIN STRETCH SPECIFICATION
MODEL Value
All Models 319 mm or less
101
