1
Version: 2 1.
Updated: October 2022
Abstract:
This guide contains instrucons and system limitaons for adding expansion
enclosures to Infortrend storage system without affecng its exisng storage
operaons.
Expansion Enclosure Guide
EonStor DS/GS U.2 Family
2
Contents
Contents ........................................................................................................................ 2
Introducon ................................................................................................................... 3
Overview of Maximum Drives ............................................................................................... 3
Hybrid Expansion Enclosures ............................................................................................... 3
Expansion Enclosure Number 4..............................................................................................
Expansion Enclosure Connecons .................................................................................. 5
Expansion Enclosure On-line Expanding ......................................................................... 7
1. Setting the expansion enclosure ID .................................................................................. 7
2. Installing the newly-added expansion enclosure ............................................................... 7
3. Reconnecting the redundant SAS path (for redundant models only) 8..............................
4. Connecting new SAS cable 8..............................................................................................
5. Turning on the newly-added expansion enclosure ............................................................ 8
6. Installing the newly added drives ...................................................................................... 9
3
Introducon
Infortrend storage systems are made of high quality and durable components based on a high-scalable hardware design,
providing support in terms of scalability and upgradeability. You also have the opon to expand your storage system's
capacity with Infortrend's expansion enclosures in dierent form factors, allowing you more storage and provide quicker and
more ecient storage services without downme.
The secons in this chapter list the expansion rules that you must follow when conguring the expansion enclosures with SAS
12 Gb/s drive-side models.
Overview of Maximum Drives
Infortrend provides various form factors that you can select for storage systems and expansion enclosures. The maximum
number of drives can be calculated based on the dierent models. Infortrend always uses SAS expansion technology to
implement massive drive scalability. Most of the products have onboard SAS ports to connect expansion enclosures and
some models support SAS expansion board to connect more expansion systems.
Take a look at the table below for Infortrend s products, the maximum number of drives, and their supported interfaces: ’
All-Flash U.2 Interface
On-board SAS Ports
SAS Expansion Board
Maximum Drives
EonStor DS U.2 Family
N/A
448 within 15 mixed expansion enclosures
( 3 B/JB3060) JB 024
448
EonStor GS 2024U/ 3024U
EonStor GSe 2024U/ 3024U
N/A
896 within 15 mixed expansion enclosures
(JB3012/JB3016/JB3024B/JB3025B/JB3060L)
896
EonStor GS 3025U/ 4025UT
N/A
896 within 15 mixed expansion enclosures
(JB3012/JB3016/JB3024B/JB3025B/JB3060L)
896
EonStor GS 3024UT/ 4024U
EonStor GSe 3024UT/ 4024U
N/A
896 within 15 mixed expansion enclosures
(JB3024B/JB3060L)
896
Table 1: Maximum Drives of Current Models
Hybrid Expansion Enclosures
Infortrend allows -Flash U.2 models support hybrid expansion enclosure connecons. The onboard SAS expansion port All to
(either dual or single port) supports up to drives for each expansion chain, which is limited by the SAS chip used. 448
Infortrend also oers SAS 12 Gb/s expansion board for some models, which uses the same SAS chip as the onboard
expansion ports. You can use twice the supported number of drives of up by cascading the second expansion chain via to 896
the expansion host boards. Do note that not every model supports hybrid expansion enclosures conguraon.
For the supported number of drives, see secon . Overview of Maximum Drives
