Sida 1/4
GUV303
UpStream™ Pro Video
Production Switch
Capture, preview, monitor live video, record, edit & stream
with a single device
Easily create pro-quality video content and dual livestream it
to a global audience
6-In-1 Video production solution simplifies your workflow,
reducing hardware needs
Built-in 1080p/4K video capture, switch, splitter, converter,
streaming encoder & audio mixer
Connect, capture up to 3 HDMI sources with 4K & 1080p
cameras; 1080p output
Professional-Quality Livestreaming Simplified
The UpStream™ Pro Video Production Switch is a 6-in-1 solution that combines and simplifies the hardware and software tools you
need to livestream like a pro! Along with UpStream Studio™, a robust iPad app, you can control, preview and monitor live video,
record, edit and add a variety of professional effects that enhance your program content.
Whether you're an aspiring YouTuber, an up and coming Twitch streamer or an experienced content creator, you too can stream like
a pro with UpStream Pro.
Requirements
•iPad Pro (3rd gen) with iOS
11 or later
The following iPad with iOS
11 or later (Additional Apple
Lightning USB 3 Camera
Adapter is required):
•iPad Pro (1st & 2nd gen)
•iPad (5th,6th & 7th gen)
•iPad Air (3rd gen)
•iPad Mini (5th gen)
Package Contents
1x GUV303
1x USB-A to USB-C
Cables (Custom)
1x USB-A to USB-A
Cables (Custom)
1x AC Power Cable
1x QSG
1x Warranty card
Specifications
Function GUV303
Video connections
Input 1 x 4K HDMI Type-A Female (up to 4K@60,
no HDCP support) 2 x HDMI Type-A Female
(up to 1080p@60, switcher, no HDCP
support )
Output 1 x 4K Loop-Thru HDMI Type-A Female (up
to 4K@60, no HDCP support) 1 x PGM
HDMI Type-A Female (up to 1080p@60, no
HDCP support)
Audio
Audio Output HDMI outputs (stereo)
Environment
Humidity 0 - 80% RH, Non-Condensing
Operation Temperature 0 - 40 ºC
Storage Temperature -20 ? 60 ºC
Operating System Requirements
iOS The 3rd Gen iPad Pro with iOS 11 and above
Connectors
Audio Input HDMI captured inputs (stereo)
Connectors-Audio(console)
Line In RCA Line in
Microphone 1/4 inch input
Upstream Port
USB-A 1 x USB 3.2 Gen 1
Downstream Port
USB-A 1 x USB 2.0
Ethernet 1 x GbE
Dimensions GUV303
Unit Dimensions
Height 3.54" (9cm)
Depth 6.29" (16cm)
Length 11.22" (28.5 cm)
Unit Package Dimensions
Width 14.5" (37 cm)
Height 11.41" (29 cm)
Depth 5.23" (13.3 cm)
Master Carton
Width 12" (30.5 cm)
Height 14.9" (38 cm)
Depth 6.1" (15.7cm)
Master Carton Qty. 1
Weight
Master Carton Wt. 6.8 lbs
Unit Pack Wt. 5.3 lbs
Unit Wt. 4.25 lbs

Produktspecifikationer

Varumärke: IOGEAR
Kategori: Inte kategoriserad
Modell: Upstream Pro GUV303
