Jackery Explorer 240 Bruksanvisning

Jackery Generator Explorer 240

Läs nedan 📖 manual på svenska för Jackery Explorer 240 (5 sidor) i kategorin Generator. Denna guide var användbar för 3 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF

Sida 1/5

Jackery Explorer 240

U S E R M A N U A L

Congratulations on your new Jackery Explorer 240!

FEATURES • TECHNICAL SPECIFICATIONS • HOW TO CHARGE • FAQs • WHAT’S IN THE BOX

CHARGE FIRST! Before reading through the manual, you can

begin to charge up you Explorer 240 by connecting it to the

power supply provided and plugging into a wall socket.

S P E C I F I C A T I O N S

Capacity Weight Dimensions Input DC Output AC Output USB Output

240Wh

(16.8Ah, 14.4V) 3 kg / 6.6 lbs 231mm x 199mm x 132mm

9.0 ” x 7.8” x 5.2”

8mm 12V~30V

42W Max DC 13.3V 10A 110V 60Hz 200W 2 @ 5V 2.4A

Battery Lifecycles

Operating

Temperature

Recharging

Temperature Management System Warranty Certications

Technical

Support

Lithium-ion >500 -10 to 40 oC 0 to 40 oC

Temperature control,

Surge protection,

Short circuit protection

24 Months FCC, RoHS,

UN38.3, CE Lifetime

Jackery Explorer 240 Car Charger

Cable

AC & AC Cable

(2 Parts)

W H A T ’ S I N T H E B O X

User

Manual

For AC Adapter (included) and Solar Panel (optional)

D C I N P U T

LCD Screen Switch

Press the power button to check the remaining battery.

Turn o each output by pressing its power button, as it

does not turn o automatically.

P O W E R

L C D S C R E E N

Power of Input & Output (W)

If the Jackery Explorer’s total output

exceeds 200W, it will automatically

shut o.

Please ensure the power

consumption is less than 200W,

then press the power button.

Low & High Temperature Alarm

The Explorer 240 can power your

devices at temperatures ranging

from 0 - 40°C (32 - 104 °F).

If your working temperature is

outside this range, the Explorer 240

may stop working.

Power Level Percentage

Check the battery level by pressing

the display button before use. If

battery is at a low level, charge rst.

INPUT

OUTPUT

Produktspecifikationer

Varumärke:	Jackery
Kategori:	Generator
Modell:	Explorer 240
Färg på produkten:	Zwart
Vikt:	73 g
Bredd:	23 mm
Djup:	23 mm
Höjd:	96 mm
LED-indikatorer:	Bezig met opladen
Batterikapacitet:	2600 mAh
Nuvarande:	0.5 A
Medföljande kablar:	Micro-USB
Antal USB-anslutningar:	1
Inspänning:	5 V
Laddningskälla:	USB
Utström:	1 A
Spännande:	5 V
Laddare kompatibilitet:	Universeel
Antal samtidigt anslutna enheter (max):	1
Ingångsgränssnitt:	Micro-USB
Batteriteknik:	Lithium-Ion (Li-Ion)
