Sida 1/5
1
®
PowerPipe TOE KICK OPTIONS
Example:
TK4-3X14-2
Toe kick with a 4 inch diameter
tube with a 3x14 frontal dimension,
and a 2 inch space from the front
to the flex tube.
ORDERING OPTIONS
Model Description Photo
4 Inch Toe Kicks
TK4-3X14-2
• Included with all PowerPipes (minus 1500PT)
• 4” port size - 90 degree entry
• 3” x 14” approximate in-room opening
• 2” clearance from edge to tube - Behind wall
mounting
• Overall Toe Kick depth: 8.7” / 221mm
TK4-3X14-6
• 4” port size - 90 degree entry
• 3” x 14” approximate in-room opening
• 6” clearance from edge to tube - Behind wall
mounting
• Overall Toe Kick depth: 13.5” / 343 mm
TK4-3X14-8
• 4” port size - 90 degree entry
• 3” x 14” approximate in-room opening
• 8” clearance from edge to tube - Behind wall
mounting
• Overall Toe Kick depth: 15.5” / 394 mm
Distance from the front of the toe kick to the flex tube location. In some cases,
this sets the wall thickness limit that the toe kick can pass through.
The nominal toe kick frontal dimensions. Height x width.
“S” indicates a straight through toe kick. Part numbers that are absent of is “S”
are built with a 90 degree bend. A “2” in this position indicates 2 ports.
The diameter of the tube in inches.
Toe Kick Naming Convention
TKDS-HXW-d
W
H
d
2
Model Description Photo
4 Inch Toe Kicks
TK4S-3X14-6
• 4” racetrack PowerPipe port - straight entry
• 3” x 14” approximate in-room opening
• 12” clearance from edge to tube - Up to 6”
through wall mounting.
• Racetrack tube connection.
• Overall Toe Kick depth: 10.25” / 260 mm
TKAD-4-E
The TKAD-4-E adapter allows a 4” flex-tube to be
mounted to the racetrack tube
connection end of
some toe kicks that have this this connection such
as the TK4S-3X14-6 (above).
TK4S-6X14-3
Floor Register
• 4” PowerPipe port size - straight entry
• 6” x 14” approximate in-room opening
• 4” clearance from edge to tube - Behind wall
mounting
• Overall Toe Kick depth: 4.13” / 105 mm
8 Inch Toe Kicks
TK8S-10X10-4
• Standard toe kick supplied with 1500PT
• 8” PowerPipe port size - straight entry
• 10” x 10” approximate in-room opening
• 6” clearance from edge to tube.
• Overall Toe Kick depth: 4.13” / 105 mm
QXC Toe Kick Mounting Style
(Flush or Proud Styles available - pre-construction board required for flush look)
TK4S-QX320
• 4” PowerPipe port size - straight entry
• 6.6” x 11” approximate in-room opening
• Overall Toe Kick depth: 1.6” / 41 mm
3
Model Description Photo
QXC Toe Kick Mounting Style
(Flush or Proud Styles available - pre-construction board required for flush look)
TK4S-QXC620R
• 4” port size - straight entry
• 9” diameter approximate in-room opening
• Overall Toe Kick depth: 1.6” / 41 mm
TK4S-QXC620S
• 4” port size - straight entry
• 9” x 9” approximate in-room opening
• Overall Toe Kick depth: 1.6” / 41 mm
TK4S-QXC820R
• 4” port size - straight entry
• 10” diameter approximate in-room opening
• Overall Toe Kick depth: 1.6” / 41 mm
TK4S-QXC820S
• 4” port size - straight entry
• 11” x 11” approximate in-room opening
• Overall Toe Kick depth: 1.6” / 41 mm
PowerPipe Small Aperture® Adapter
TK4-PP-SA*
*TK4-PP-SA includes one trim kit at no charge.
Specify at time of order.
• Allows PowerPipes to be ported through 4”
Small Aperture trim kits.
• 4” port size - straight entry
• 4” square/round approximate in-room opening
• Overall Toe Kick depth: 1.6” / 41 mm
3
