Sida 1/8
JBL Consumer Products, Inc.
80 Crossways Park West
Woodbury, NY 11797
8500 Balboa Blvd.
Northridge, CA 91329
800 336 4JBL (4525)
A Harman International Company
Part No. JGS10OWN
G SERIES LOUDSPEAKERS
Specifications G SUB10
Amplifier Power (RMS)* 80 Watts
Low Frequency Woofer 10"
Voice Coil Diameter 2"
Cone Material Poly-fiber Laminate
Inputs Line Level & Speaker Level
Outputs Full-Range Speaker
Crossover Frequency 50–200 Hz (Continuously Variable)
Frequency Response (–6dB) 30 Hz to (62–250 Hz)**
External Dimensions (HxWxD) 17-1/4" x 13-1/4" x 14-1/4"
External Dimensions (mm) 438 x 337 x 362mm
Weight (each) 35 lbs (15.9kg)
Shipping Weight 40 lbs (18.1kg)
*ALC circuit defeated.
**Determined by crossover setting.
JBL continually strives to improve its products. New materials, production methods and design
refinements are introduced into existing models without notice as a routine expression of our design
philosophy. For this reason, JBL loudspeakers may differ in some respect from their published
specifications and descriptions, but will always equal or exceed the original specifications unless
otherwise stated.
SERVICE
Should your subwoofer ever need
service, return it to the JBL dealer
from whom it was purchased. If for
some reason this is impractical, in the
USA, call 800-336-4JBL for the
nearest warranty station. Do not
return products to the JBL factory
without prior authorization.
G SERIES
LOUDSPEAKERS
OWNER’S
MANUAL
G
SUB10
INTRODUCTION
Congratulations on choosing JBL
loudspeakers. Their highly accurate,
uncolored and balanced sound
character will greatly increase your
enjoyment of recorded music. We
build JBL speakers with careful
attention to detail, using only the
highest quality materials. They will
provide many years of excellent
performance.
Your G Sub10 is easy to set up. We
recommend that you take a few
minutes to read this owner's manual
before you begin, and that you follow
instructions carefully.
Amplified Subwoofer
Your G Sub10 subwoofer has both
line-level and speaker-level stereo
inputs for versatility and ease of use.
We've also provided speaker outputs
to let you hook up satellite speakers.
Adjustable level and crossover
controls let you balance the
subwoofer with your main speakers.
Poly-fiber Laminate Woofer
Provides tight bass and well-de nedfi
sound reproduction without
harshness, stridency, or listener
fatigue.
Acoustically Optimized Cabinet
Optimized to produce an extended
and level bass response in
conjunction with the internal amplifier.
The cabinet may be placed either
vertically or horizontally. The grille
logo may be turned to match either
orientation of the subwoofer.
2
CONNECTIONS
CAUTION: Before making any
connections to your subwoofer,
make sure the power to your
entire system is OFF.
POWER
Plug the power cord into a grounded
wall outlet or the accessory outlet on
the back of your ampli er/receiver.fi
INPUTS
Your G Sub10 subwoofer has
both line-level and speaker-level
input connections. Review your
receiver/TV/source amplifier
instruction manual to see which
outputs your equipment provides,
then follow the appropriate
instructions below.
Line Input –Use the RCA (phono)
input jacks labeled "Line Input" when
connecting from a line-level device,
such as a pre-amp, crossover, signal
processor, or when using any of the
line-level outputs on the rear of your
receiver/TV/source amplifier. If your
receiver has a single RCA output for
sending the signal to the subwoofer,
you may connect it to both Right &
Left input jacks by using a "Y" adapter
(not included). Many stereo/ large
screen TVs have stereo (Right & Left)
RCA jacks for sending the signal to
external audio equipment. Your
subwoofer connects to these using
both the Right & Left input jacks
(see Figure 1).
Speaker Level Input (from
ampli er)fi– Use these inputs when
connecting to the Speaker Out“ ”
(speaker mains) of the receiver/
TV/source ampli er. Run speakerfi
wires from the speaker output
terminals (usually coded red and
black) on the rear of the
receiver/TV/source amplifier to the
red and black input terminals labeled
"Speaker Level Input (from amplifier)"
on the subwoofer (see Figure 2).
Preparing the Hookup Wire
Your JBL dealer can recommend
suitable cables, or you can buy wire at
most hardware or electronic stores.
High-quality connectors and cable
offer consistent performance that does
not deteriorate over time. We
recommend #16 AWG two-conductor
insulated wire as a minimum size. If
your subwoofer is more than 30 feet
(10m) from your receiver/TV/source
ampli er, use larger diameter, lowerfi
gauge wire.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: To reduce the risk of electric shock, do not remove amplier back.
No user serviceable parts inside. Refer servicing to qualied service personnel.
Warning – To reduce the risk of re or electric shock, do not expose this appliance to rain or moisture.
Caution: To prevent electric shock do not use this (polarized) plug with an extension cord, receptacle
or other outlet unless the blade can be fully inserted to prevent blade exposure.
The lightning ash with arrowhead symbol,
within equilateral triangle, is intended to alert
the user to the presence of uninsulated
“ ” ’dangerous voltage within the product s
enclosure that may be of sucient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
