PASSIVE INFRARED MOTION SENSOR
SEN SR501-HC-
1. GENERAL INFORMATION
Dear customer,
thank you for choosing our product. In the following, we will show you
how to use this device.
Should you encounter any unexpected problems during use, please do
not hesitate to contact us.
www.joy it.net-
Pascalstr. 8 47506 Neukirchen Vluyn-
2. ADJUSTING THE SENSOR
This passive infrared motion sensor has the possibility to adjust the sen-
sitivity, hold time and pulse rate.
Sensitivity
The sensitivity of the infrared sensor can be adjusted with one of the po-
tentiometers. The sensitivity will be lower if you turn the potentiometer
clockwise.
Hold time
For this sensor, the hold time sets how long the sensor will remain active
when motion is detected and the signal output remains set as active. You
can set this with the second potentiometer. If you turn the potentiometer
clockwise, the holding time becomes longer.
www.joy it.net-
Pascalstr. 8 47506 Neukirchen Vluyn-
Pulse rate
The pulse rate describes how oen the sensor can trigger. The sensor can
detect a movement only once or several times. The default setting is mul-
tiple detection of movements. You can set this with a jumper on the back
of the board.
3. USAGE WITH RASPBERRY PI
Connection
Raspberry Pi SEN SR501 -HC-
5V VCC
Pin 7
(GPIO4)
DATA
GND GND
