Sida 1/2

S P E C I F I C A T I O N S S U B J E C T T O C H A N G E W I T H O U T N O T I C E . D S 1 1 0 7 0 6

CAMERA GLOVE

MATERIALS



Neoprene foam laminated between two

layers of elastic cloth



Clear PU UV protected windows



Nylon hook & loop material



Silent action YKK® zippers



Fastex-ITW® nylon or acetal buckles

KATA's new camera glove is custom fitted to your camera

so that it fits like a glove:



Protection against cold, dirt, bumps and scratches



Attractive design



Improved product engineering: overlapping closure design



Accommodates batteries in several sizes



Designed not to interfere with camera operation

   systemPull to open!



Advanced materials:

The gloves are made of a specially engineered lamination:

A External layer of nylon elastic knit, which enables

ventilation and is not abrasive to your skin.

B Middle layer of shock resistant advanced closed cell

neoprene perforated foam, prevents overheating of your

camera.

C Internal knit layer protects the camera body.

This non-fray lamination enables you to cut open additional

slots to fit your exact working configuration.

K T / VA - 6 0 1 - 4 c g - 4

KATA. A SIMPLE CASE

OF BET TER DESIGN.

Development & production by Ltd.KATA

POB 45078 Jerusalem , Israel 91450

Tel: + 972-2-5911000

Fax: + 972-2-5400504

www.kata-bags.com

Info: technical@kata-bags.com

Sales: video@kata-bags.com

Detachable pouch

holds emergency

Rain Hood

Vinyl window

Clear vinyl windows reveal

necessary display and press

buttons.

(For DSR-500 - take off the

camera front button cover)

Easy access to all

bottom areas

Hook & loop adjustment

ensures a snug fit on a wide

range of batteries, and

protects the battery well

For full access to

control panel use

top and bottom

(No.12) zippers

Easily zips open giving

access to playb ack

controls

Flexible viewfinder glove

allows f ull rota tion.

Zipper access to buttons

Back buckle

Front

buckle

Quick and

easy access

to battery

Easy access to control

panel and alarm & monitor

buttons by folding the

overlapping flaps inward

Pull to open!

Pull in this direction

to open

The Pull to open! system allows opening

in one fast movement, quick closing with

hook & loop or tight closing by zipper

Hook & loop

quick closing

Fold flap inwards to reveal

internal light connector

Bottom panel

zipper

17 18

includes Rain hood and flexible VF cover

SPARE PARTS (If lost or damaged)



VA-601-1-RH Rain Hood with pouch



VA-601-1-VF Flexible Viewfinder Cover

for DSR-300, 370/500, 570 camcordersSONY

JVC Panasonic GY-DV-500/550/700/5000 AG-DVC200

S P E C I F I C A T I O N S S U B J E C T T O C H A N G E W I T H O U T N O T I C E . D S 1 1 0 7 0 6

CAMERA GLOVE

K T / VA - 6 0 1 - 4 c g - 4

KATA. A SIMPLE CASE

OF BET TER DESIGN.

Development & production by Ltd.KATA

POB 45078 Jerusalem , Israel 91450

Tel: + 972-2-5911000

Fax: + 972-2-5400504

www.kata-bags.com

Info: technical@kata-bags.com

Sales: video@kata-bags.com

Overlapping

flaps

Emergency

Rain Hood

Free access to all

bottom areas

Rain Hood

pouch

Right hook

strap

Top panel zip

Main zip

Viewfinder glove

Back buckle

Front

buckle

Closing pullers

Bottom

panel zip

Pull to open!

Vinyl

windows

Vinyl window for

cassette viewing

Pull in this direction

to open

Hook & loop

quick closing

4. For access to covered buttons, fold

overlapping flaps inward (No.14).

5. CONTROL PANEL

Top and bottom panel zippers (No.9, No.12)

give access to full control panel.

6. VIEW FINDER GLOVE

Open buckle and zip and pull over VF.

If necessary, cut out a window to expose

the Tally light.

7. Rain hood

Emergency Rain Hood (No.19) in pouch

(No.4).

1. Dressing the camera

Open the main zipper (No.2) and buckles (No.3, No.5).

Put the camera in the glove.

Pull up and close zipper (No.2).

Close buckles (No.3) and (No.5).

For DSR-500 take off the camera front button cover.

2. Adjustment to battery

First close left hook strap, (No. 11) then adjust back part

to your battery with right hook strap (No.10)

Use the left hook strap for changing battery (No.11)

Note:

do not open right hook strap (No.10) each time you change

the battery.

3. Changing tape - Pull to open! system.

For changing tape pull strap (No.1) in a diagonal direction

(No.17), opening the whole zipper in one movement.

The hook & loop (No.16) enables quick temporary closing.

GENERAL INSTRUCTIONS

Left hook

strap

2 1

Internal light

connector

includes Rain hood and flexible VF cover

for DSR-300, 370/500, 570 camcordersSONY

JVC Panasonic GY-DV-500/550/700/5000 AG-DVC200
