SPLIT SYSTEM AIR CONDITIONER
INSTALLATION INSTRUCTIONS
IMPORTANT SAFETY INFORMATION 2 .................
AIR CONDITIONER INSTALLATION 3 ....................
General Information 3 ..............................................
Before You Install this Unit 3 .....................................
Locating the Air conditioner...................................3
Packaging Removal 3 ..............................................
Ground Level 3 .........................................................
Roof Mount............................................................3
Connecting Refrigerant Tubing between the
Indoor & Outdoor Unit 4 ...........................................
ELECTRICAL WIRING ........................................... 4
Pre - Electrical Checklist 4 .......................................
Line Voltage ........................................................... 4
Comfort AlertTM Diagnostics Module 5 .....................
24VAC Power Wiring ........................................... 5
Thermostat Demand Wiring ................................ 5
Interpreting the Diagnostic LED’s 5 .......................
LED Description 6 ..................................................
Grounding 6 .............................................................
Thermostat Low / Voltage Connections 6 .................
AIR CONDITIONER MAINTENANCE 6 ....................
STARTUP & ADJUSTMENTS 7 ...............................
Pre - Start Checklist 7 ..............................................
Start-up Procedures 7 ..............................................
Air Circulation - Indoor Blower 7 ..............................
System Cooling 7 .....................................................
System Heating 7 .....................................................
DO NOT DESTROY. PLEASE READ CAREFULLY & KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
IMPORTANT
ATTENTION INSTALLERS:
It is your responsibility to know this product better than your customer. This includes
being able to install the product according to strict safety guidelines and instructing
the customer on how to operate and maintain the equipment for the life of the product.
Safety should always be the deciding factor when installing this product and using
common sense plays an important role as well. Pay attention to all safety warnings and
any other special notes highlighted in the manual. Improper installation of the furnace
or failure to follow safety warnings could result in serious injury, death, or property
damage.
These instructions are primarily intended to assist qualified individuals experienced in
the proper installation of this appliance. Some local codes require licensed installation/
service personnel for this type of equipment. Please read all instructions carefully
before starting the installation. Return these instructions to the customer’s package
for future reference.
S4BD SERIES - 018, 024, 030, 036, 042, 048, & 060 (1.5, 2, 2.5, 3, 3.5, 4, & 5 Ton)
13 SEER, SINGLE PHASE MODELS
Refrigerant Charging 7 .............................................
Charging the Unit in AC Mode with
Outdoor Temperatures Above 55° F 8 ......................
Application Notes for Using Charging Charts 8 .......
S4BD CHARGING CHARTS 8 .................................
Figure 3. Charging Chart for 1.5 Ton Units 8 ..........
Figure 4. Charging Chart for 2 Ton Units 9 .............
Figure 5. Charging Chart for 2.5 Ton Units 9 ..........
Figure 6. Charging Chart for 3 Ton Units 10 ...........
Figure 7. Charging Chart for 3.5 Ton Units 10 ........
Figure 8. Charging Chart for 4 Ton Units 11 ...........
Figure 9. Charging Chart for 5 Ton Units 11 ...........
S4BD CHARGING TABLES ................................. 12
Table 3. Charging Table for 1.5 Ton Units 12 ..........
Table 4. Charging Table for 2 Ton Units 12 .............
Table 5. Charging Table for 2.5 Ton Units 13 ..........
Table 6. Charging Table for 3 Ton Units 13 .............
Table 7. Charging Table for 3.5 Ton Units 14 ..........
Table 8. Charging Table for 4 Ton Units 14 .............
Table 9. Charging Table for 5 Ton Units 15 .............
ELECTRICAL DIAGRAMS & TABLES 16 ................
Figure 10. W.D., Single Phase (1.5 - 5 Ton) 16 ......
Table 10. Comfort Alert LED Diagnostics 17 ..........
Table 11. Module Wiring Troubleshooting 18 ..........
INSTALL. / PERFORMANCE CHECKLIST 20 .........
REPLACEMENT PARTS 20 ......................................
2
WARNING:
The information listed below must be followed
during the installation, service, and operation
of this unit. Unqualified individuals should
not attempt to interpret these instructions or
install this equipment. Failure to follow safety
recommendations could result in possible
damage to the equipment, serious personal
injury or death.
• The installer must comply with all local codes and
regulations which govern the installation of this type
of equipment. Local codes and regulations take
precedence over any recommendations contained in
these instructions. Consult local building codes and
the National Electrical Code (ANSI CI) for special
installation requirements.
• Allelectricalwiringmustbecompletedinaccordance
with local, state and national codes and regulations
and with the National Electric Code (ANSI/NFPA 70)
or in Canada the Canadian Electric Code Part 1 CSA
C.22.1.
• Thisequipmentcontainsliquidandgaseousrefrigerant
under high pressure. DO NOT USE ANY PORTION OF
THE CHARGE FOR PURGING OR LEAK TESTING.
Installation or servicing should only be performed by
qualified trained personnel thoroughly familiar with this
type equipment.
• Fullyannealed,refrigerantgradecoppertubingshould
be used when installing the system. Refrigerant suction
line tubing should be fully insulated.
• Installation of equipment may require brazing
operations. Installer must comply with safety codes
and wear appropriate safety equipment (safety glasses,
work gloves, fire extinguisher, etc.) when performing
brazingoperations.
• Followallprecautionsintheliterature,ontags,and
on labels provided with the equipment. Read and
thoroughly understand the instructions provided with
the equipment prior to performing the installation and
operational checkout of the equipment.
• Refrigerantandelectricallineshouldberoutedthrough
suitably waterproofed openings to prevent water from
leaking into the structure.
IMPORTANT SAFETY INFORMATION
INSTALLER: Please read all instructions before servicing
this equipment. Pay attention to all safety warnings and
any other special notes highlighted in the manual. Safety
markings are used frequently throughout this manual to
designate a degree or level of seriousness and should
not be ignored.
WARNING indicates a potentially hazardous situation
that if not avoided, could result in personal injury or death.
CAUTIONindicatesapotentiallyhazardoussituationthat
if not avoided, may result in minor or moderate injury or
property damage.
WARNING:
Shut o all electrical power to the unit before
performing any maintenance or service on the
system. Failure to comply may result in personal
injury or death.
WARNING:
Unless noted otherwise in these instructions,
only factory authorized parts or accessory
kits may be used with this product. Improper
installation, service, adjustment, or maintenance
may cause explosion, fire, electrical shock or
other hazardous conditions which may result
in personal injury or property damage
WARNING:
S4BD Split System Air Conditioners are shipped
charged with R410A refrigerant and ready
for installation. If repairs make it necessary
for evacuation and charging, it should only
be attempted by qualified trained personnel
thoroughly familiar with this equipment. Under
no circumstances should the owner attempt to
install and/or service this equipment. Failure to
comply with this warning could result in property
damage, personal injury, or death.
CAUTION:
This unit uses refrigerant R-410A. DO NOT use
any other refrigerant in this unit. Use of another
refrigerant will damage the unit.
3
AIR CONDITIONER INSTALLATION
General Information
The S4BD series air conditioner is designed only for
outdoor rooftop or ground level installations. This unit has
been tested for capacity and efficiency in accordance
with AHRI Standards and will provide many years of safe
and dependable comfort, providing it is properly installed
and maintained. Abuse, improper use, and/or improper
maintenance can shorten the life of the appliance and
createunsafehazards.
Toachieveoptimumperformanceandminimizeequipment
failure, it is recommended that periodic maintenance be
performed on this unit. The ability to properly perform
maintenance on this equipment requires certain
mechanical skills and tools.
Before You Install this Unit
√ The cooling load of the area to be conditioned must be
calculated and a system of the proper capacity selected.
It is recommended that the area to be conditioned be
completely insulated and vapor sealed.
√ Check the electrical supply and verify the power supply
is adequate for unit operation. The system must be wired
and provided with circuit protection in accordance with
local building codes. If there is any question concerning
the power supply, contact the local power company.
√ The indoor section (air handler, furnace, etc) should be
installed before routing the refrigerant tubing. Refer to
the indoor unit's installation instructions for installation
details.
√ All units are securely packed at the time of shipment and
upon arrival should be carefully inspected for damage
prior to installing the equipment at the job site. Verify
coil fins are straight. If necessary, comb fins to remove
flattened or bent fins. Claims for damage (apparent or
concealed) should be filed immediately with the carrier.
√ Please consult your dealer for maintenance information
and availability of maintenance contracts. Please read
all instructions before installing the unit.
Locating the Air Conditioner
• Surveythejobsitetodeterminethebestlocationfor
mounting the outdoor unit.
• The outdoorunitshouldbe installednocloserthan
18 inches from the outside walls of the facility and in
an area free from overhead obstructions to ensure
unrestricted airflow through the outdoor unit.
• Sufcientclearanceforunobstructedairowthroughthe
outdoor coil must be maintained in order to achieve rated
performance. See Figure 1 for minimum clearances to
obstructions.
• Overhead obstructions (Figure 1), poorly ventilated
areas, and areas subject to accumulation of debris
should be avoided.
• Considerationshouldbegiventoavailabilityofelectric
power, service access, noise, and shade.
Packaging Removal
NOTE: To prevent damage to the tubing connections,
carefully remove the carton and user’s manual from the
equipment. Discard the shipping carton.
Ground Level
Ground level installations must be located according to
local building codes or ordinances and these requirements:
• Clearancesmustbeinaccordancewiththoseshown
in Figure 1.
• Asuitablemountingpad(Figure1)mustbeprovided
and separate from the building foundation. The pad
must be level and strong enough to support the weight
of the unit. The slab height must be a minimum of 2”
(5 cm) above grade and with adequate drainage.
Roof Mount
• Themethodofmountingshouldbedesignedsothatit
does not overload roof structures or transmit noise to
the interior of the structure. The roof must be structurally
capable of handling the weight of the unit.
• Full perimeter support is required under the unit.
Support must be made of weather resistant materials
and installed prior to unit installation.
• Thesupportmust bebuilttoraisetheunit6"above
the roof.
Figure 1. Clearance Requirements
2” Mounting dPa
24" for
Service Access
12" or 18”
See Note
12" or 18”
See Note
DO NOT
OBSTRUCT
TOP OF UNIT
NOTE: Units require full perimeter clearances.
Installer must maintain 18” between two units
or 12” between single unit and structure.
6” from Building
or Structure
48”

Produktspecifikationer

Varumärke: Kelvinator
Kategori: Luftkonditionering
Modell: JS4BD018KB

Behöver du hjälp?

Om du behöver hjälp med Kelvinator JS4BD018KB ställ en fråga nedan och andra användare kommer att svara dig


Luftkonditionering Kelvinator Manualer

Kelvinator

Kelvinator KSD80HRG Bruksanvisning

19 September 2024
Kelvinator

Kelvinator KSV80HRF Bruksanvisning

19 September 2024
Kelvinator

Kelvinator KSD50HWJ Bruksanvisning

19 September 2024
Kelvinator

Kelvinator KSD25HWJ Bruksanvisning

19 September 2024
Kelvinator

Kelvinator KWH39CRF Bruksanvisning

19 September 2024
Kelvinator

Kelvinator KSD90HRH Bruksanvisning

19 September 2024
Kelvinator

Kelvinator KSD35HWH Bruksanvisning

19 September 2024
Kelvinator

Kelvinator KSD35HRG Bruksanvisning

19 September 2024
Kelvinator

Kelvinator KSV70CRE Bruksanvisning

19 September 2024
Kelvinator

Kelvinator KSV35HRE Bruksanvisning

19 September 2024

Luftkonditionering Manualer

Nyaste Luftkonditionering Manualer

Kenmore

Kenmore 580.77157 Bruksanvisning

27 Oktober 2024
Philco

Philco PSV12HRJ-A2 Bruksanvisning

27 Oktober 2024
BEKO

BEKO BIHPR 120 Bruksanvisning

27 Oktober 2024
General Electric

General Electric AEQ10 Bruksanvisning

27 Oktober 2024
Fujitsu

Fujitsu AIRSTAGE AJY040LBLDH Bruksanvisning

27 Oktober 2024
REMKO

REMKO RM426 Bruksanvisning

27 Oktober 2024
Delonghi

Delonghi Pinguino Arctic Whisper PACEX390LVYN-6AWH Bruksanvisning

26 Oktober 2024
Trisa

Trisa Cool Mate 9362.70 Bruksanvisning

26 Oktober 2024
Hotpoint

Hotpoint AHES09D2XXA Bruksanvisning

26 Oktober 2024
ARCTIC WIND

ARCTIC WIND 3AWTWH120002A Bruksanvisning

26 Oktober 2024
