Sida 1/94

DDX9903S

DDX9703S

MONITOR WITH DVD RECEIVER

INSTRUCTION MANUAL

DDX6903S

DDX6703S

DDX9716BTS

DDX916WSL

Take the time to read through this instruction manual.

Familiarity with installation and operation procedures will help you obtain the best performance from your new DVD-receiver.

For your records

Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the space provided below. Refer to the model and serial

numbers whenever you call upon your Kenwood dealer for information or service on the product.

Model DDX9903S/DDX9703S/DDX6903S/DDX6703S Serial number

US Residents Only

CONTENTS

BEFORE USE............................................................ 2

INITIAL SETTINGS 4 ..................................................

Initial setup 4 .........................................................................

Setting the security function 4 .......................................

Calendar/clock settings 6 .................................................

BASICS 7 ....................................................................

Component names and functions 7 .............................

Common operations 9 .......................................................

Common screen operations 10 .......................................

Selecting the playback source/option 13 ...................

Using the pop-up short-cut menu 14 ...........................

DISCS 15 ....................................................................

USB........................................................................ 19

iPod/iPhone 22 .........................................................

APPS—Android Auto™/Apple CarPlay/

Mirroring 25 ..............................................................

HD Radio™ tuner 28 ..................................................

Radio 34 .....................................................................

SiriusXM® Satellite Radio 36 ....................................

OTHER EXTERNAL COMPONENTS 47 ......................

Using a camera 47 ................................................................

Using external audio/video players—AV-IN 48 ........

Using a smartphone—HDMI/MHL 49 ...........................

Watching a TV 49 ..................................................................

Using ADS adapter features 50 .......................................

Using the external navigation unit 51 ..........................

BLUETOOTH 52 .........................................................

SETTINGS 63 ..............................................................

Settings for using applications of iPod/iPhone/

Android/BlackBerry 63 .......................................................

Selecting different sources for the front and rear

monitors—Zone Control 64 .............................................

Sound adjustment—Audio 65 ........................................

Adjustment for video playback 70 .................................

Changing the display design 71 .....................................

Customizing the system settings 73 .............................

Setting menu items—SETUP 74 .....................................

REMOTE CONTROLLER 77 ........................................

CONNECTION/INSTALLATION 79 ............................

REFERENCES 87 .........................................................

Maintenance 87 ....................................................................

More information 87 ...........................................................

Error message list 91 ...........................................................

Troubleshooting 92 .............................................................

Specifications 94 ...................................................................

How to read this manual:

• Illustrations of DDX9903S are mainly used for explanation. The displays and panels shown in this manual

are examples used to provide clear explanations of the operations. For this reason, they may be different

from the actual displays or panels.

• This manual mainly explains operations using the buttons on the monitor panel and touch panel. For

operations using the remote controller (RC-DV340: supplied only for DDX9716BTS/DDX916WSL), see

page77.

• < > indicates the various screens/menus/settings that appear on the touch panel.

• [ ] indicates the buttons/selectable items on the touch panel.

• Indication language: English indications are used for the purpose of explanation. You can select the

indication language from the menu. (Page75)<SETUP>

• Updated information (the latest Instruction Manual, system updates, new functions, etc.) is available

from <http://www.kenwood.com/cs/ce/>.

BEFORE USE

IMPORTANT

To ensure proper use, please read through this

manual before using this product. It is especially

important that you read and observe WARNINGS

and CAUTIONS in this manual. Please keep the

manual in a safe and accessible place for future

reference.

◊ WARNINGS: (To prevent accidents and

damage)

• DO NOT install any unit or wire any cable in a

location where;

– it may obstruct the steering wheel and gearshift

lever operations.

– it may obstruct the operation of safety devices

such as air bags.

– it may obstruct visibility.

• DO NOT operate the unit while driving.

If you need to operate the unit while driving, be

sure to look around carefully.

• The driver must not watch the monitor while

driving.

For DDX9716BTS/DDX916WSL:

The marking of products using lasers

The label is attached to the chassis/case and says

that the component uses laser beams that have

been classified as Class 1. It means that the unit is

utilizing laser beams that are of a weaker class. There

is no danger of hazardous radiation outside the unit.

ENGLISH 3

For DDX9903S/DDX9703S/DDX6903S/DDX6703S:

◊ CAUTION

Use of controls or adjustments or performance of

procedures other than those specified herein may result

in hazardous radiation exposure. In compliance with

Federal Regulations, the following are reproductions of

labels on, or inside the product relating to laser product

safety.

JVCKENWOOD Corporation

2967-3, ISHIKAWA-MACHI, HACHIOJI-SHI, TOKYO,

JAPAN

THIS PRODUCT COMPLIES WITH DHHS RULES

21CFR SUBCHAPTER J IN EFFECT AT DATE OF

MANUFACTURE.

Location : Top plate

FCC WARNING

This equipment may generate or use radio

frequency energy. Changes or modifications to this

equipment may cause harmful interference unless

the modifications are expressly approved in the

instruction manual. The user could lose the authority to

operate this equipment if an unauthorized change or

modification is made.

FCC NOTE

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful

interference in a residential installation.

This equipment may cause harmful interference to

radio communications, if it is not installed and used in

accordance with the instructions. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful

interference to radio or television reception, which can

be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference

by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV

technician for help.

For DDX9903S/DDX9703S/DDX6903S/DDX6703S:

IC (Industry Canada) Notice

This device complies with Industry Canada license-

exempt RSS standard(s).

Operation is subject to the following two conditions:

(1) This device may not cause interference, and (2)

this device must accept any interference, including

interference that may cause undesired operation of the

device.

The term “IC: ” before the certification/registration

number only signifies that the Industry Canada

technical specification were met.

CAUTION

This equipment complies with FCC/IC radiation

exposure limits set forth for an uncontrolled

environment and meets the FCC radio frequency (RF)

Exposure Guidelines in Supplement C to OET65 and

RSS-102 of the IC radio frequency (RF) Exposure rules.

This equipment has very low levels of RF energy that

it deemed to comply without maximum permissive

exposure evaluation (MPE). But it is desirable that it

should be installed and operated keeping the radiator

at least 20 cm or more away from person’s body

(excluding extremities: hands, wrists, feet and ankles).

Under Industry Canada regulations, this radio

transmitter may only operate using an antenna of a

type and maximum (or lesser) gain approved for the

transmitter by Industry Canada. To reduce potential

radio interference to other users, the antenna type

and its gain should be so chosen that the equivalent

isotropically radiated power (e.i.r.p.) is not more than

that necessary for successful communication.

• Contains Transmitter Module

FCC ID : ZWY8811X

• Contains Transmitter Module

IC: 12033A-8811X

◊ Cautions on the monitor:

• The monitor built into this unit has been

produced with high precision, but it may have

some ineffective dots. This is inevitable and is not

considered defective.

• Do not expose the monitor to direct sunlight.

• Do not operate the touch panel using a ball-point

pen or similar tool with a sharp tip.

Touch the buttons on the touch panel with your

finger directly (if you are wearing a glove, take it

off).

• When the temperature is very cold or very hot...

– Chemical changes occur inside, causing

malfunction.

– Pictures may not appear clearly or may move

slowly. Pictures may not be synchronized with

the sound or picture quality may decline in such

environments.

For safety...

• Do not raise the volume level too much, as this

will make driving dangerous by blocking outside

sounds, and may cause hearing loss.

• Stop the car before performing any complicated

operations.

Temperature inside the car...

If you have parked the car for a long time in hot or

cold weather, wait until the temperature in the car

becomes normal before operating the unit.

BEFORE USE
