Sida 1/6

Take the time to read through this instruction manual.

Familiarity with installation and operation procedures will help you obtain the best performance from your new power amplier.

For your records

Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the space provided below. Refer to the

model and serial numbers whenever you call upon your KENWOOD dealer for information or service on the product.

Model XM65F Serial number

Model XM65R Serial number

XM65F

XM65R

6.5” COAXIAL SPEAKERS DESIGNED AND ENGINEERED TO CONNECT

AND MOUNT TO HARLEY-DAVIDSON® RUSHMORE PLATFORM

TOURING MODEL MOTORCYCLES

INSTRUCTION MANUAL

JVCKENWOOD Corporation

US Residents Only

Contents

Section 1: XM65F Front Speaker Installation Instructions in FLH (Batwing) Models....2

Section 2: XM65F Road Glide Specific Front Speaker Installation Instructions.............4

Section 3: XM65R Rear Speaker Installation Instructions..................................................4

Warranty Info...............................................................................................................................5

KENWOOD XM65F and XM65R speakers will work best when powered by

an amplier. They have an impedance of 2 ohm and will cause damage if

wired directly to the built-in power of a non-2 ohm stable radio.

Section 1 - XM65F Front Speaker Installation

Instructions in FLH (Batwing) Models

Installation procedure

1. With your ignition switch in the “OFF” position, remove your outer fairing/headlamp

assembly and set it aside. Refer to a service manual if you need help with this. NOTE:

Placing a towel on the front fender can help prevent scratches or “dings” from dropped

tools or fasteners, etc.

2. Speaker Cabinet Removal: On the brake side speaker cabinet, carefully remove the

cable going into the power port/cigarette lighter assembly. If your bike has the CB module

(mounted “sideways” on the clutch side cabinet), undo the antenna cable and main

harness. The CB module will stay attached to the clutch side cabinet when removed. Undo

the speaker wire plugs going into each cabinet (pink & pink with black stripe wires).

Safety precautionsSafety precautions

CAUTION

To avoid the risk o f human injury or propert y

damage, be sure to read and observe the following

safety precautions:

• Consult a professional technician for installing and

connecting the speaker. — Incorrect installation may

lead to trac accidents or malfunctions.

• Avoid installation where the speaker in unstable. —

Make sure that the speaker is stationary and does not

rattle. Displacement of the speaker may cause injury.

• Do not modify the speaker. — Doing so may result in

smoke or re.

• Keep the volume of sound at an optimum level. —

Not being able to hear sounds from your surroundings

can lead to trac accidents.

• In case of abnormality, stop the use and disconnect

the speaker. — If operation is continued, smoke or re

may result. Disconnect the speaker and ask servicing.

• Always wear protective eyewear during installation.

• To prevent short-circuit, keep all wiring away from

moving parts, sharp edges, cut metal, etc.

• When removing or installing the grille, be careful not

to brush the unit with the edge of the grille.

• Do not switch ON power until wiring is completed.

FOR PROPER INSTALLATION AND USE

Please read the instructions carefully before using

this speaker:

• Be careful not to accidentally kick or apply any sort of

strong impact to the speaker.

• To prevent damaging the speaker, turn o the power

of the amplier before connecting it to the speaker.

• Do not use the provided parts for other purposes

Otherwise malfunction or re hazard could result.

NOTE

Observe the following cautions to prevent damage

to the speakers:

• You cannot input the same power as “peak power”

continually.

• When the volume is set too high, the sound may be

distorted or abnormal. Reduce the volume promptly in

case of such phenomena.

Section 1 - XM65F Front Speaker Installation Instructions in FLH

(Batwing) Models - Cont.

NOTE: We STRONGLY suggest completing the speaker swap on one side and then moving

to the other side. Figures 1.1 and 1.2 have arrows that point to the factory fasteners that

will be removed to allow the cabinets to come out of the bike. Although the brake side is

shown below, fastener locations are common for both brake and clutch side cabinets.

3. Installing the New Speaker: With the cabinet removed from the bike, undo the 4

screws that hold the factory speaker to the cabinet. Carefully take o each speaker wire

by disconnecting one at a time. Take the KENWOOD speaker and attach the factory

speaker wires, noting they will only go on one way. Using the factory screws, attach the

KENWOOD speaker to the cabinet. The factory speaker grille can be left in or replaced

with the supplied metal mesh grille using the 3 factory screws on the inside of the fairing.

In the KENWOOD grille, you will see two holes and one “keyhole” where the screws go

through and into the fairing. The keyhole in the KENWOOD grille needs to be oriented so

it is closest to the radio on each side for proper tment. Using the factory grilles will cause

a slight reduction in high-frequency volume. With the grilles in place and the speaker

properly attached to the speaker cabinet, the cabinet can be re-installed.

Repeat Step 3 for the second cabinet. Plug the factory speaker wires back into the

cabinet’s speaker wires and your speakers will be ready to test. Make sure to plug the

power cable back into the power port/cigarette lighter assembly on the brake side. If your

bike has the CB module, make sure to re-install the antenna cable and main harness. Then,

re-install your fairing and windshield.

Figure 1.1 - Side view of

brake side cabinet

Figure 1.2 - Back view of

brake side cabinet
