Take the time to read through this instruction manual.
Familiarity with installation and operation procedures will help you obtain the best performance from your new power amplier.
For your records
Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the space provided below. Refer to the
model and serial numbers whenever you call upon your KENWOOD dealer for information or service on the product.
Model XM69R Serial number
© 2023 JVCKENWOOD Corporation
XM69R
6” X 9” COAXIAL SPEAKERS DESIGNED AND ENGINEERED TO CONNECT
AND MOUNT TO KENWOOD CA-CUT14, CA-LID98, & OTHER BRANDS
OF 6” x 9” LIDS FOR HARLEY-DAVIDSON® MOTORCYCLES
INSTRUCTION MANUAL
JVCKENWOOD Corporation
US Residents Only
Register Online
Register your KENWOOD product at https://registerkenwood.us.jvckenwood.com/
Contents
Section 1: Installation Instructions to KENWOOD CA-CUT14 for 2014-Current Bikes..........3
Section 2: Installation Instructions to KENWOOD CA-LID98 Lids for 1998-2013 Bikes.....3
Section 3: Installation Instructions for another brand of 6" x 9" lids.................................4
Warranty Info.................................................................................................................................5
KENWOOD XM69R speakers will work best when
powered by an amplier. They have an impedance
of 2 ohm and will cause damage if wired directly to
the built-in power of a non-2 ohm stable radio.
The speaker’s magnets are POWERFUL! Credit
cards and electronics can be sensitive to magnets,
so please exercise caution in how you pack your
saddlebags. Metal objects packed into your bags
may end up stuck to the magnet, so please use
caution when opening the lids.
2
Safety precautionsSafety precautions
CAUTION
To avoid the risk of human injury or property
damage, be sure to read and observe the following
safety precautions:
• Consult a professional technician for installing and
connecting the speaker. — Incorrect installation may
lead to trac accidents or malfunctions.
• Avoid installation where the speaker in unstable. —
Make sure that the speaker is stationary and does not
rattle. Displacement of the speaker may cause injury.
• Do not modify the speaker. — Doing so may result in
smoke or re.
• Keep the volume of sound at an optimum level. —
Not being able to hear sounds from your surroundings
can lead to trac accidents.
• In case of abnormality, stop the use and disconnect
the speaker. — If operation is continued, smoke or re
may result. Disconnect the speaker and ask servicing.
• Always wear protective eyewear during installation.
• To prevent short-circuit, keep all wiring away from
moving parts, sharp edges, cut metal, etc.
• When removing or installing the grille, be careful not
to brush the unit with the edge of the grille.
• Do not switch ON power until wiring is completed.
FOR PROPER INSTALLATION AND USE
Please read the instructions carefully before using
this speaker:
• Be careful not to accidentally kick or apply any sort of
strong impact to the speaker.
• To prevent damaging the speaker, turn o the power
of the amplier before connecting it to the speaker.
• Do not use the provided parts for other purposes
Otherwise malfunction or re hazard could result.
NOTE
Observe the following cautions to prevent damage
to the speakers:
• You cannot input the same power as “peak power”
continually.
• When the volume is set too high, the sound may be
distorted or abnormal. Reduce the volume promptly in
case of such phenomena.
Section 1 - Installation Instructions to KENWOOD
CA-CUT14 for 2014-Current Bikes
Section 2 - Installation Instructions to KENWOOD
CA-LID98 Lids for 1998-2013 Bikes
Installation procedure
The CA-CUT14 (sold separately) enables you to install the XM69R speakers into select
hard saddlebag lids without a pre-existing speaker option. Please reference the CA-CUT14
instruction manual for detailed installation instructions.
Note: This is written as if you already had the lids on and are simply changing the speakers.
With the speakers that were in the lids removed, locate the bag in the box for 98-13 “AA”
lids. These are soft black silicone gaskets that go between the speakers and the lids and
MUST be installed correctly to keep water out. One side of the gaskets has a groove on the
inside, and the other side has a groove on the outside. On the underside of the lid, you will
see a “lip” that goes around the speaker opening. The side of the gasket with the groove
on the inside will “mate” to the lip around the speaker opening on the lid.
3
IMPORTANT: The gasket will come close to one of the 2 holes where screws go through to
secure the grille as shown by the arrow in Fig 1.1 (below).
The gasket MUST be oriented so the “notch” in the silicone gasket goes around this screw
boss.
Figure 1.1
