Sida 1/3
ODC 89 BA- - -e-2313
KERN & Sohn GmbH
Ziegelei 1
D-72336 Balingen
E-Mail: info@kern sohn.com -
Tel: - - +49 [0]7433 9933-0
Fax: +49 - -[0]7433 9933- 149
Interne sohn.comt: -www.kern
User instructions
USB microscope
KERN - ODC 89
ODC 895
Version 1.3
09/2023
2
ODC 89 BA- - -e-2313
KERN
ODC- 89
Version 1.3 09 3 /202
User instructions
USB microscope
Before use
You should ensure that the device is not exposed to direct sunlight, temperatures which
are too high or too low, vibrations, dust or a high level of humidity.
The ideal temperature range is between 0 and 40°C and a relative humidity of 85%
should not be exceeded.
Always make sure that you use an approved power cable. possible damages by Thus,
reason of the development of overheating (fire hazard) or an electric shock can be
prevented.
Do not open housin touch the g and the internal component. There is the risk of damaging
them and affecting the functionality of the camera.
In order to carry out cleanings always disconnect the power cable from the mains supply.
Always keep the sensor clear from dust and do not touch it. Therefore, do not remove its
protective housing. Otherwise, there of affecting is the risk microscopic the image. In
case of non use always attach the protective covers.-
Technical data
Model
KERN Resolution Sensor Interface Frame Rate Colour/
Monochrome
Supported
Operating Systems
ODC 895 2 MP USB 2.0 1/3.2“
CMOS 15 Colour-30 fps Win XP, Vista,
Win 7, 8, 10
Model
KERN
Magnification
Levels
Focusing
Stand Illumination
ODC 895 10x, 200x Focus Wheel 8x LED
GB
ODC 89 BA- - -e-2313
3
Scope of delivery
-
USB microscope (USB cable incl.)
-
Microscope stand
-
Software CD
Free download:
www.kern DOWNLOADS- > sohn.com > SOFTWARE > Microscope VIS Pro
Mounting + functionalities
1. Remove the cover at the bottom of the microscope.
2. Mount the microscope stand and put it onto an even table
surface. Afterwards attach the microscope on the ring holder of
the stand.
3. Establish USB connection to a PC via USB cable.
4. Installing the software with help of the CD.
Detailed instructions can be found in the supplied "readme"- file.
5. - -Both the supplied "Help" files and the software internal "User
Guide" include all information and instructions about the
operation of the software or of digital microscopy.
6. As soon as the software has been started and the image
transmission launched, adjust the illumination level by using the
control wheel, located on the cable.
7. The adjustment of the magnification level is done by using of the
control wheel, located on the side of the microscope.
8. The height adjustment of the microscope stand is done by using
the focus wheels. For the KERN ODC 894 it is aligned coaxial
and for the KERN ODC 895 double sided on the stand pillar.-
9. The USB microscope can also be used without microscope
stand. It can be easily directed towards the specimen by hand.
10. For capturing a snapshot the knob, located on the side of the
microscope (above the control wheel for the magnification
adjustment), needs to be pressed.
