Kern TGC 150-2 Bruksanvisning

Kern Vågen TGC 150-2

Läs nedan 📖 manual på svenska för Kern TGC 150-2 (3 sidor) i kategorin Vågen. Denna guide var användbar för 8 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF

Sida 1/3

KERN & Sohn GmbH

Ziegelei 1

D-72336 Balingen

E- -Mail: info@kern sohn.com

Tel.: +49- - -0 [0]7433 9933

Fax: 9933 149 - -+49 [0]7433 -

internet: - www.kern sohn.com

Operating manual

Electronic pocket scales

KERN TGC

Version 1.0

2018-07

TGC-BA-e- 1810

TGC- -e- 2BA 1810

KERN TGC

Version 1.0 2018- 07

Operating manual

Electronic pocket scales

1. Technical data

KERN -2 -1-A -3 TGC 150 TGC 500 TGC 1K

Item no./ Type -2-A -1-A -3-A TTGC 150 TGC 500 TGC 1K

Readability (d) 0.1 g 1 g 0.01 g

Weighing range 000 g(max) 500 150 g g 1

Adjustment weight, not added (class) / 150 g 00 g (M3) 0 g (M3) 50 g (M2) 5 100

Operating temperature 0+ °....+ 40°C

Humidity of air 20% 8 - ∼0% air humidity (non condensing)

Batteries 2 x CR2032

2. Scope of delivery

• Pocket scale

• Balance cover

• Batteries (2 x CR2032)

• Operating manual

3. Keyboard overview

Switch-over weighing unit

Background illumination of the display on/off

Taring / Setting to zero

Switch on/off

4. Operation

Weighing:

 Place the balance on a firm, level surface.

 Press ON/OFF button, the balance completes a self check. As soon as the weight display appears,

the balance is ready for weighing. If required, set to zero by using TARE button.

 Place load on pan and read the weighing result.

 If necessary, use the button to switch over into the available weighing units.UNIT

3 - -e- TGC BA 1810

Taring:

 Deposit empty weighing container.

 Press the TARE button, the zero display disappears.

 Weigh the material, the net weight will be displayed.

 When the balance is unloaded the saved taring value is displayed with negative sign.

 To delete the stored tare value, remove load from weighing pan and press the TARE button.

5. Adjustment

 Arrange adjustment weight (see chap. 1).

Info about adjustment weights can be found on the Internet at: http://www.kern-sohn.com

 Ensure that there are no objects on the weighing pan.

 In weighing mode keep the button pressed until UNIT <CAL> appears.

 Press the ON/OFF button again and wait until the weight value of the required adjustment weight

will appear flashing.

 Place adjustment weight. Wait until <PASS>, followed by the weight value of the placed

adjustment weight will be displayed. After that the adjustment will be finished successfully.

 In case of a diverging display the adjustment has failed. Repeat adjustment process.

6. Important Notes

• Do not overload balance.

• The occurrence of electromagnetic fields may result in major display deviations. Then change

location.

• Avoid high air humidity, vapours and dust.

• Do not bring the balance directly in contact with liquids.

• Do not leave permanent load on the weighing pan.

• Never operate balance in explosive environment. The serial version is not

explosion protected.

• Check the balance regularly with external test weights.

• Warranty claims will be voided when the housing is opened.

7. Declaration of conformity

The current EC/EU Conformity declaration can be found online in:

www.kern-sohn.com/ce
