Sida 1/18

P/N 0930-7206-02 EN

SIGNALING

LISTED

ATTENTION: Please take a few minutes to thoroughly read this

User Guide which should be saved for future reference and

passed on to any subsequent owner.

Smoke Alarm

User Guide

i9040

and

i9040RV

• 9 Volt Battery Operated

Model: i9030, i9040, i9040RV i9050, i9060,

i9060RV and i9080

i9030

i9050 i9080

i9060

and

i9060RV

Smoke Alarm Procedure

NEVER IGNORE THE SOUND OF THE ALARM!

Smoke alarms are designed to minimize false alarms. Cigarette

smoke will not normally set off the alarm, unless the smoke is

blown directly into the alarm. Combustion particles from cook-

ing may set off the alarm if it is located too close to the cook-

ing area. Large quantities of combustion particles are generat-

ed from spills or when broiling. Using the fan on a range hood

which vents to the outside (non-recirculating type) will also

help remove these combustion particles from the kitchen.

If the alarm sounds, check for fires first. If a fire is discovered,

follow these steps. Become thoroughly familiar with these

steps and review with all family members:

• Alert small children in the home.

• Leave immediately by your escape plan. Every second

counts, so don’t waste time getting dressed or picking up

valuables.

• In leaving, don’t open any inside door without first feeling its

surface. If hot, or if you see smoke seeping through cracks,

don’t open that door! Instead, use your alternate exit. If the

inside of the door is cool, place your shoulder against it,

open it slightly and be ready to slam it shut if heat and

smoke rush in.

• If the air is smoky, stay close to the floor. Breathe shallowly

through a cloth, wet if possible.

• Once outside, go to your selected meeting place and make

sure everyone is there.

• Call the fire department from your neighbor’s home - not

from yours!

• Don’t return to your home until the fire officials say that it is

all right to do so.

What to do When the Alarm Sounds!

Welcome

i9030, i9040, i9040RV, i9050, i9060, i9060RV, - 9 Volt Battery

Operated Smoke Alarm with “HUSH” Control to temporarily

silence nuisance alarms.

i9080 - 9 Volt Battery Operated Smoke Alarm with “HUSH”

Control to temporarily silence nuisance alarms and with Battery

Powered Safety Light.

Thank you for purchasing this smoke alarm. It is an important part

of your family’s home safety plan. You can trust this product to pro-

vide the highest quality safety protection. We know you expect

nothing less when the lives of your family are at stake.

Important Warning Statements

IMPORTANT! READ ALL INSTRUCTIONS BEFORE INSTALLATION

AND KEEP THIS USER GUIDE NEAR THE ALARM FOR FUTURE

REFERENCE.

WARNING: BATTERY DOOR WILL NOT CLOSE AND/OR ALARM

WILL NOT ATTACH TO MOUNTING BRACKET UNLESS BATTERY IS

INSTALLED CORRECTLY.

REMOVAL OF BATTERY WILL RENDER THE SMOKE ALARM INOPERATIVE.

WARNING: TEST YOUR SMOKE ALARM OPERATION AFTER RV OR

MOBILE HOME VEHICLE HAS BEEN IN STORAGE, BEFORE EACH TRIP

AND AT LEAST ONCE A WEEK DURING USE.

CAUTION: DUE TO THE LOUDNESS OF THE ALARM (85 DECIBELS),

ALWAYS STAND AN ARMS-LENGTH AWAY FROM THE UNIT WHEN

TESTING.

CAUTION: BEFORE USING THE ALARM HUSH FEATURE, IDENTIFY

THE SOURCE OF THE SMOKE AND BE CERTAIN A SAFE CONDITION

EXISTS. NOTE: DENSE SMOKE WILL OVERRIDE THE HUSH CONTROL

FEATURE AND SOUND A CONTINUOUS ALARM.

LEADING AUTHORITIES RECOMMEND THAT BOTH IONIZATION AND

PHOTOELECTRIC SMOKE ALARMS BE INSTALLED TO HELP INSURE MAXI-

MUM DETECTION OF THE VARIOUS TYPES OF FIRES THAT CAN OCCUR

WITHIN THE HOME. IONIZATION SENSING ALARMS MAY DETECT INVISI-

BLE FIRE PARTICLES (ASSOCIATED WITH FAST FLAMING FIRES) SOONER

THAN PHOTOELECTRIC ALARMS. PHOTOELECTRIC SENSING ALARMS

MAY DETECT VISIBLE FIRE PARTICLES (ASSOCIATED WITH SLOW SMOL-

DERING FIRES) SOONER THAN IONIZATION ALARMS.
