Sida 1/9
KK T KOLBE Küche nte chnik G mb H & Co. KG
Ohmstraße 17 | D-96175 Pettstadt | +49 (0) 9502 667930 | info@kolbe.de
Installation Manual
Adjustable Triangle Rack Mounting
KK T KOLB E Küche nte ch nik G mb H & Co. KG
Ohmstraße 17 | D-96175 Pettstadt | +49 (0) 9502 667930 | info@kolbe.de
Catalog
1. Product Introduction 1
2. Installation Tools 1
3. Components 2
4. Installation Guide 3
4.1 Installation of Adjustable Triangle Rack 3
4.2 Installation of Rail 5
4.3 Installation of Solar Panels 6
4.4 Installation of Grounding Lug 6
5. Installation Notes 7
5.1 Safety Precautions 7
5.2 Stainless Steel Fasteners Notes 7
5.3 Notes after Finishing Work 7
1
1. Product Introduction
The main material of this mounting structure is a uminum alloy AL6005-T5.
The surface of the product has been anodized. The product has strong corro-
sion resistance and is suitable for installation of residential projects and large-
sized photovoltaic power plants. It has high pre-assembled characteristics and
saves installation time and cost greatly. High-quality design elements and few
kinds of accessories make it an efcient solution for photovoltaic engineering.
Please kindly read the whole manual carefully before installation.
2. Installation Tools
String Electric tool
(M8/M10)
Hexagon sleeve
(M8/M10) Drilling Bit 9mm Tape measure
Marking pen Torque wrench
(M8)
6# hexagonal
wrench Monkey wrench Rubber Hammer
