Sida 1/16

IMPORTANT SAFETY INSTRUCTIONS

1. READ these instructions.

2. KEEP these instructions.

3. HEED all warnings.

4. FOLLOW all instructions.

5. DO NOT use this apparatus near water.

6. CLEAN ONLY with dry cloth.

7. DO NOT block any ventilation openings. Install in accordance

with the manufacturer's instructions.

8. Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that

produce heat.

9. ONLY USE attachments/accessories specified by the

manufacturer.

10. USE only with a cart, stand, tripod, bracket, or table specified by

the manufacturer, or sold with the apparatus. When a cart

is used, use caution when moving the cart/apparatus

combination to avoid injury from tip-over.

11. DO NOT expose this apparatus to dripping or splashing and

ensure that no objects filled with liquids, such as vases, are placed

on the apparatus.

The exclamation point, within an equilateral triangle, is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying the product.

The lightning flash with arrowhead symbol within an

equilateral triangle, is intended to alert the user to the

presence of uninsulated “dangerous voltage” within

the product's enclosure that may be of sufficient magnitude to con-

stitute a risk of electrical shock to persons.

WARNING: To reduce the risk of fire or electrical shock, do not

expose this apparatus to rain or moisture.

WARNING: No naked flame sources - such as candles - should be

placed on the product.

WARNING: Do Not Open! Risk of Electrical Shock. Voltages in this

equipment are hazardous to life. No user-serviceable parts inside.

Refer all servicing to qualified service personnel.

PLACEMENT

Before You Start – Some Klipsch speakers have feet and other

accessories that may need to be installed prior to use. Please

refer to Diagrams 1, 2, 3 and 4 for installation.

Left and Right Main Channel Speakers – For optimum

performance, place your speakers 6 to 15 feet (2 to 4.5m) apart

and at least 24 inches (60.8cm) from side walls. They may also

be toed-in slightly for better stereo imaging. The listening

position should be approximately 1 to 1.5 times the distance

separating the speakers. Refer to figures 1, 2, 3 and 4 for

connection and placement.

Center Channel Speakers – Center channel speakers are

designed to place dialogue and primary sounds so that they

appear to come from the video screen. The speakers should

therefore be placed as close to the screen as possible, preferably

directly on top of or below the screen. Refer to figures 2, 3 and 4

for connection and placement.

Rear Surround Channel Speakers – Rear surround speakers

are designed to recreate the sense of space and ambiance that

many of today’s surround sound technologies provide. QUINTET

surround speakers can be placed on the wall directly adjacent to

or on the wall behind the listening position using the foot as the

mounting bracket. Refer to Diagram 3 and Figures 2 and 4 for

connection and placement. Not intended to be hung from

the ceiling.

CONNECTIONS

Conventional Connection – Using 16-gauge or larger speaker

wire, connect the RED “positive” (+) terminal of the LEFT speaker

to the RED “positive” (+) terminal of your amplifier’s LEFT

channel. Connect the BLACK “negative” (-) terminal of the LEFT

speaker to the BLACK “negative” (-) terminal of your amplifier’s

LEFT channel. Repeat this procedure for connecting all remaining

speakers to the appropriate amplifier channels. Refer to Figure 4.

Make sure no bare wires from any of the connections touch any

other bare wires or terminals as this could cause a short and

damage your equipment.

Amplifier Requirements – Klipsch speakers are highly

efficient and will work well with a wide variety of ampli-

fiers. Due to the high output levels Klipsch speakers are capable

of reproducing, exercise caution with the volume control.

Excessive volume over long periods of time can permanently

damage your hearing. Overdriving your amplifier could also

damage your speakers. Check with your dealer to make sure

your particular amplifier is best suited to your application. We

want you listening for a lifetime.

CARE AND CLEANING

Your speakers have a durable finish that should only require dry

dusting. Avoid use of abrasive or solvent-based cleaners and

harsh detergents. The brush attachment of your vacuum or a

damp cloth should remove any dust from your speaker grilles.

QUINTET SPEAKER SYSTEM

English

EU Compliance Information

Eligible to bear the CE mark, Conforms to European Union Low

Voltage Directive 73/23/EEC and 2006/95/EC; Conforms to

European Union EMC Directives 89/336/EEC and 2004/108/EC.

WEEE Notice

Note: This mark applies only to countries within the European

Union (EU) and Norway.

This application is labeled in accordance with

European Directive 2002/96/EC concerning waste

electrical and electronic equipment (WEEE). This

label indicates that this product should not be dis-

posed of with household waste. It should be

deposited at an appropriate facility to enable

recovery and recycling

Product Registration Benefits:

• Klipsch will keep you up-to-date on new products

and promotions

• Klipsch will keep your information for future warranty service

• Your personal information will never be resold
