USER GUIDE
50” SMART HDR 4K TV
SERIES 9 RN9220
2
CONTENTS
Thank you for buying this Kogan product. Please read all safety instructions before using your TV.
THIS USER GUIDE COVERS THE FOLLOWING MODELS
Kogan 50” Smart HDR 4K TV (Series 9 RN9220)
SAFETY AND WARNINGS
Safety and warnings 02 ............................
Components 04 ..........................................
Product overview 05 ...................................
Inputs 05 .................................................
Assembly and installation................... 06
Stand assembly .............................. 06
Connect to antenna .......................06
Using remote / power button ............. 07
Remote control overview .....................08
...............................09 - 10
Basic operation 11 .......................................
Selecting channels ............................11
Volume / mute 11 ..................................
Input Source 11 .......................................
Navigating menus 11 ............................
Colour buttons 11 ...................................
Settings 12 ....................................................
Quick menu
.......................................12
Global settings
PVR mode 15 ...............................................
Instant recording 15 ..............................
Schedule recording .......................... 15
Timeshi mode 16 ................................
Media playback 16 ......................................
Wall-mounting ......................................17
Specifications .......................................... 18
Troubleshooting 19 ......................................
First time setup
........................12-13-14
• To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
• The apparatus shall not be exposed to dripping or splashing, and no objects filled with liquids,
(for example, vases), shall be placed on the apparatus.
• When discarding used batteries, always be mindful of the environment. Ensure you follow any
guidelines for recycling and safe disposal of batteries that apply in your local area. Don’t throw
used batteries in rubbish bin.
• When installing your TV, maintain a distance of at least 10 cm between the TV and other
objects (walls, cabinet sides, etc.) to ensure proper ventilation. Failing to maintain proper
ventilation may result in a fire or a problem with the product caused by an increase in its
internal temperature.
• The openings/slots on the back of the apparatus have been provided for necessary ventilation.
Ventilation should not be impeded by blocking these openings in any way (for example,
newspapers, table-cloths, curtains, etc.)
• No naked flame sources, such as lit candles, should be placed on the apparatus. To prevent
the spread of fire, keep candles or other open flames away from this product at all times.
• The device may malfunction when under electrostatic discharge. It can be manually resumed
by switching power o completely (at wall outlet), then switching power on again.
• To avoid any injury caused by overturn of the product when installed with base stands, please
always ensure the whole product is placed horizontally within the supporting surface and that
the television is not overhanging the edge of the supporting furniture.
• If not using with base stands, use only a wall or ceiling mount which has been recommended
by the manufacturer of the television.
Never place a television set in an unstable location. A television set may fall, causing serious
personal injury or death. Many injuries, particularly to children, can be avoided by taking
simple precautions such as:
• Using cabinets or stands recommended by the manufacturer of the television set.
• Only using furniture that can safely support the television set.
• Ensuring the television set is not overhanging the edge of the supporting furniture.
• Not placing the television set on tall furniture (for example, cupboards or bookcases) without
anchoring both the furniture and the television set to a suitable support.
• Not placing the television set on cloth or other materials that may be located between the
television set and supporting furniture.
• Educating children about the dangers of climbing on furniture to reach the television set or
its controls.
If your existing television set is being retained and relocated, the same considerations as
above should be applied.
3
• Keep small accessories out of reach of children so they are not mistakenly swallowed.
CAUTION: Connecting the power cord
Most appliances recommend they be placed upon a dedicated circuit; that is, a single outlet
circuit which powers only that appliance and has no additional outlets or branch circuits.
Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension
cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these
conditions could result in electric shock or fire. Periodically examine the cord of your appliance,
and if appearance indicates damage or deterioration, immediately discontinue use of the
appliance until the cord is replaced with an exact replacement part by an authorized servicer.
Protect the power cord from physical or mechanical abuse, such as being twisted, kinked,
pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the
point where the cord exits the appliance.
The MAINS plug is used as the disconnect device, and the disconnect device shall remain
readily operable.
Operating Temperature: 5°C to 45°C
Operating Humidity: ≤80%
Storage Temperature: -15°C to 45°C
Storage Humidity: ≤90%
CAUTION
Do not attempt to modify this product in any way without written authorization from supplier.
Unauthorized modification could void the user’s authority to operate this product.
It is not recommended to keep a certain still image displayed on the screen for a long time as
well as displaying extremely bright images on screen.
SAFETY AND WARNINGS cont’d
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE
COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the products enclosure that may be of sucient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
Class II product: This symbol indicates that a safety connection to electrical
earth (ground) is not required. If this symbol is not present on a product with a
mains lead, the product MUST have a reliable connection to protective earth
(ground).
~AC voltage: Rated voltage marked with this symbol is AC voltage.
⎓DC voltage: Rated voltage marked with this symbol is DC voltage.
Caution. Consult instructions for use: This symbol instructs the user to consult
the user manual for further safety related information.
Refer to the table below as a guide to the symbols and warnings which may be on your TV.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Figures and illustrations in this User Manual are provided for reference only and may dier
from actual product appearance. Product design and specifications may be changed without
notice.
4
COMPONENTS
NOT INCLUDED
Phillips head screwdriver, antenna
cable, broadband internet connection.
A
D
E G
C
B Remote control
C Stand (x2)
F Quick-start guide
G Warranty card
F
5
PRODUCT OVERVIEW
Inputs
Audio in Stereo (2.0) audio input.
Composite
video in
Usually paired with stereo audio inputs
(red and white cables), the single-wire
composite cable provides video signal.
Component
video in
Three cables (“Y,” “Pb” and “Pr”) provide a
higher quality connection than the single-
wire composite cable (“Y”) commonly
used to hook up earlier AV equipment.
HDMI
Connect an HDMI cable between the
HDMI port on the TV and the HDMI port
on the DVD player/Set-Top Box.
Ports marked ‘ARC’ also support Audio
Return Channel.
USB 2.0
USB storage devices can be inserted to
record and pause live TV in PVR mode, or
to watch media files stored on device in
media mode.
VGA Connect to a desktop or laptop computer.
ANT
For free-to-air TV, use an antenna cable
(not supplied) to connect to a working
antenna, either via an antenna wall
socket, or directly.
LAN
For a wired internet connection via a
broadband modem or router, connect an
Ethernet cable to the LAN port.
Digital
audio out
(optical) Audio out for digital audio devices. Port
and cable may look different depending
on an optical or coaxial input. Please use
the cable appropriate for your device.
Digital
audio out
(coaxial)
3.5mm
audio out
Line audio out port for use with
headphones, amplifier, soundbar or any
other audio device via an AUX cable (not
supplied).
This is a general guide to inputs and ports, your TV may not feature all of the above.
3 Inputs/Ports
4 Power button
1 HDR 4K LED display screen
2 Remote sensor / Standby light
1
2
3
4
6
BEFORE YOU GET STARTED
Spread cushioning flat to lay the TV on. This will help to prevent damage.
ASSEMBLY AND INSTALLATION
2. Connect to antenna
a. Connect an antenna cable (not supplied) via the ‘ANT’ input port at the
back of the TV.
b. Ensure the antenna cable is also connected to a working antenna, either
via an antenna wall socket in your home, or directly.
1. Stand assembly
a. Attach stands to base of TV, ensuring ‘L’ and ‘R’ markings on the TV
and stands match.
b. Insert two 20mm screws for each stand and use Phillips head
screwdriver (not supplied) to tighten. Antenna
wall socket
2b
USB 2.0
AUDIO OUT
Antenna cable
(not supplied)
2a
1b
1a
7
TURNING TV OFF
Press the POWER ( ) button on the remote control to enter
standby mode.
To power down the TV completely, unplug the power cord from
the power outlet.
Do not leave your set in standby mode for long periods of time. If you
will not use the TV for a long time, it is recommended to unplug the
set from both the power outlet and aerial.
3. Remote control assembly
a. Open the battery compartment cover on the back side.
b. Insert two 1.5V AAA size batteries, making sure to match the polarity
markings (+ / -) of the batteries with the diagram inside
the compartment.
c. Replace battery compartment cover.
USING REMOTE CONTROL / POWER BUTTON
WARNINGS
• One loading of batteries will last for 1 year under normal use.
• If you do not intend to use the remote controller for a long period of time,
remove them to avoid damage due to leakage.
• Do not use old and new batteries together.
• The batteries (battery pack or batteries installed) shall not exposed to
excessive heat such as sunshine, fire or the like.
TIPS
Do not block the path between the sensor
and the remote control.
4. Using remote control without bluetooth
Your Android TV remote control has bluetooth
capability, but until this is paired with your TV, you
will need to ensure the distance between the remote
control and the TV is no greater than 8 metres, at an
angle of no more that 30 degrees on either side . (4a)
Point the remote towards the sensor at the front of
the TV (this may dier from the illustration).
4a
5. Turning TV on
a. Plug the power cord into a suitable power outlet. The standby will display
a light, showing that the TV is receiving power.
b.
c. The standby light will turn o when the TV is on.
Standby mode
Red light on
5a
TV on
Red light o
5c
5b
3a3b3c
8
REMOTE CONTROL OVERVIEW
Quick Menu to display TV options
with optional, adjustable settings
Device preferences show sound
and image options under apps
/ / / Direction buttons for
navigating menus and settings
8
ok Enter select the current item
or confirm selection, display Channel
list in DTV mode
9
Back to the previous menu
10
11
TV Option show TV Option under
live tv
Display the Settings menuSettings
under the home page
long press to appear soft Note:
keyboard
12
Electronic Program Guide DTV
mode
13
9
FIRST TIME SETUP
Terms of Service
This page will allow you to read each
of the Google Terms of Service, Privacy
Policy, and Google Play Terms of Service
in full, and to accept.
Choose a name for your TV
Give you TV a name to help identify it
when casting or connecting to it from
other devices. Select a preset option or
enter a custom name.
Install additional apps
Get started with some of our handpicked
selections from the Play Store.
Following this you will be shown a brief
overview of Android TV’s features.
Password
Set a default password.
Select TV mode
The ‘home mode’ is optimized for ecient
usage for home use. The ‘retail mode’
is optimized for store Demo with fixed
settings.
When turning the TV on for the first time,
the Welcome screen will appear. Use the
, and buttons to navigate the OK
following options.
Language and Location
Select your menu language, and select
your country/region from the list.
Bluetooth
Your Android TV remote control has
bluetooth capabilities. Follow the
onscreen prompts to pair the remote
with the TV, holding the - Volume and
buttons simultaneously. Your Back
remote’s LED light will flash while pairing,
and the TV will display ‘Remote control
paired’ when successful. This will allow
you to use voice commands with your
remote via the Google Assistant button.
Quickly set up with Android phone
If you have an Android smartphone, you
can easily transfer your phone’s Wi-Fi
network and Google account to your TV.
If not, select ‘Skip’.
Select Wi-Fi network
Your Android TV will automatically scan
for wireless networks nearby. Ensure
the TV is within range of your wireless
modem or router, and have your password handy. Follow the prompts to input
your password and connect your TV to your selected network.
If you’d prefer to connect an Ethernet cable to connect to the internet, simply
insert the cable (not supplied) to the ‘LAN’ input port at the back of the TV( ,
next page), and ensure that it is correctly connected to the internet.
Google Account sign-in
Linking your Google Account to your
Android TV will allow you to install new
apps from the Play store, as well as
receive recommendations from Google.
Sign in to your Google account here. If you
use Gmail, you already have a Google
account.
Pairing your bluetooth remote control with
your Android TV will enable your remote’s
Google Assistant voice control function.
Connect to Wi-Fi by selecting your network
and entering your password. A broadband
internet connection is required for this step.
Select ‘home mode’ or ‘retail mode’.
Installing additional apps from
the Google Play Store.
Select a name for your TV.
6a
a
10
FIRST TIME SETUP (cont’d)
1 Google Assistant
Click to launch the built-in virtual
assistant, which will begin listening
for voice commands. Give it a try, ask
“What’s the weather today?”
2 Text search
Enter text manually to search TV apps.
3 System notifications
This option will only appear when
notifications are present.
4 Source
Access free-to-air channels (‘DTV’)
or other input source channels.
5 Internet connection
This will display as a Wi-Fi or LAN icon,
depending on your connection. Select for
connectivity options.
6 Settings
Access the global settings menu.
7 Clock
Time and date settings can be adjusted
in the global settings.
8 Apps
Access the App Centre to display all
installed apps. Free-to-air channels can
be accessed under the ‘Live TV’ option.
9 Favourites list
A customisable list of apps available at a
single click.
10 Play next
Displays the program you are watching
or have queued to play next. You can
add to this list by long pressing the ok
button, then selecting “Add to play next”.
If the play next queue is empty, it will not
be shown on the home page.
11 Pinned channels
Show the program list of pinned
channels. The order of this list can be
adjusted by pressing from the channel
icon and selecting the “<>” icon. Empty
channels will not be shown on the home
page.
12 Customise channels
Add or remove pinned channels from the
home page.
Following these options, the Channel
Scan screen will appear. Ensure you have
an antenna cable connected to the ‘ANT’
input port at the back of the TV (6a).
The auto tuning function will search
for and save all available free-to-air TV
channels. Aer confirming your settings,
the
process will automatically begin. The number of searched channels will bed
displayed on the screen.
6a
12
SETTINGS
Quick menu
Options for your TV (picture, Sound,power) can be accessed by
pressing the Quick Menu button on your remote control. Use buttons
to navigate through the submenus, and buttons to access Channel and
Recording/Time Shi options (7a).
Global settings
To access the global settings menu, simply navigate to the ‘ ’ icon on the
Home screen. Here you will find all of the adjustable options for Android TV’s
interface, connectivity, and apps.
7a
/
/
In mode you can also press the button on your
remote control and use the / buttons to navigate to the 'Settings'
option.
Settings
13
SETTINGS (cont’d)
GLOBAL SETTINGS
Network & Internet
Here you will find the options for Wi-Fi and Ethernet internet connections.
Wi-Fi
Available Wi-Fi networks are listed, with the option to manually add a new
network.
Scanning always available
Toggle on/o.
WOW
Toggle on/o for Wake On Wi-Fi function.
WOL
Toggle on/o for Wake On LAN function.
Ethernet
The TV will display whether a LAN connection is active or not. If LAN is
connected, status will show IP address.
Proxy settings
HTTP proxy is used by the browser but may not be used by other apps. Select
between no proxy, or manually entering proxy address details.
IP settings
Select between DHCP or static.
Auto channel update
Toggle on/o.
Parental controls
Enter PIN to access. Here you will find options for blocking channels, restricting
content based on ratings, and blocking inputs (TV, AV, and all four HDMIs).
Here you find the same Google account sign-in screen from the start-up
wizard.
APPS
View all recently used apps.
See all apps
Display a list of all installed apps.
View and adjust settings for app permissions, special app access, and security
& restrictions.
DEVICE PREFERENCES
About
View system information.
Date & Time
Set clock and date information.
Timer
Adjust auto power-on and auto power-o settings.
Language
Interface language settings for on-screen display.
Keyboard
Adjust keyboard options. Third party keyboards can be added from the Play
store. By default, Google’s GBoard keyboard is installed.
Inputs
HDMI CEC (Consumer Electronic Control) settings can be adjusted here.
Option to rename inputs (for example, ‘HDMI 1’ can be set as ‘Blu-ray’ or even
a custom name, which will appear on the source inputs list) are also located in
this submenu.
Power
Adjust power settings here.
Adjust picture settings here, in more detail than the Quick Menu’s picture
mode presets.
Sound
Locate settings for sound balance, speakers, digital output, SPDIF
and more in this submenu.
CHANNEL
ACCOUNT & SIGN-IN
14
Storage
View and adjust device storage information and set up external drives for use.
Home screen
Adjust options such as enabling video or audio previews, customising
channels, and app order for the home screen. You can also view app licenses.
Retail mode
Toggle on/o. The ‘home mode’ is optimized for ecient usage for home use.
The ‘retail mode’ is optimized for store Demo with fixed settings. By default the
TV is set to home mode.
Google Assistant
Access options for Google Assistant and voice controls.
Chromecast built-in
View license details for Chromecast functionality. By default, Chromecast is
enabled for your TV and does not require adjusting.
Screen saver
Adjust the screensaver usage and time settings.
Location
Enable location settings.
Usage & diagnostics
Enable permission to share usage and diagnostic data.
REMOTES & ACCESSORIES
All compatible Bluetooth devices will appear here. You can connect and
disconnect from devices here.
SETTINGS (cont’d)
.
Produktspecifikationer
| Varumärke: | Kogan |
| Kategori: | Tv |
| Modell: | KALED50RN9220STB |
Behöver du hjälp?
Om du behöver hjälp med Kogan KALED50RN9220STB ställ en fråga nedan och andra användare kommer att svara dig
Tv Kogan Manualer
14 Februari 2025
31 Januari 2025
9 Januari 2025
7 Januari 2025
6 Januari 2025
6 Januari 2025
24 December 2024
24 December 2024
24 December 2024
24 December 2024
Tv Manualer
- Tv Sony
- Tv Samsung
- Tv Xiaomi
- Tv Casio
- Tv LG
- Tv AEG
- Tv Philips
- Tv Panasonic
- Tv BEKO
- Tv Daewoo
- Tv Grundig
- Tv JVC
- Tv Medion
- Tv Nokia
- Tv Pioneer
- Tv Siemens
- Tv Toshiba
- Tv Abus
- Tv Ag Neovo
- Tv Acer
- Tv Aiwa
- Tv AOC
- Tv Akai
- Tv Alden
- Tv Alphatronics
- Tv Aldi
- Tv Allview
- Tv Airis
- Tv Arcelik
- Tv Aristona
- Tv Apex
- Tv Strong
- Tv Icy Box
- Tv BenQ
- Tv Lexibook
- Tv Sharp
- Tv Techwood
- Tv Loewe
- Tv Brandt
- Tv Telefunken
- Tv Palsonic
- Tv Walker
- Tv Funai
- Tv Hitachi
- Tv Nedis
- Tv Thomson
- Tv Saba
- Tv Antarion
- Tv Lenco
- Tv Pyle
- Tv Kernau
- Tv Manta
- Tv Tevion
- Tv SereneLife
- Tv OK
- Tv Hisense
- Tv Hyundai
- Tv Vox
- Tv Proscan
- Tv Westinghouse
- Tv Vestel
- Tv ECG
- Tv Bush
- Tv RCA
- Tv Clatronic
- Tv Tucson
- Tv Sencor
- Tv GPX
- Tv Blaupunkt
- Tv Megasat
- Tv Lenovo
- Tv Manhattan
- Tv Svan
- Tv Logik
- Tv Polaroid
- Tv Sagem
- Tv Salora
- Tv Denver
- Tv Optoma
- Tv Finlux
- Tv Schneider
- Tv Sanyo
- Tv Sunstech
- Tv Bang And Olufsen
- Tv Philco
- Tv TCL
- Tv Nabo
- Tv Infiniton
- Tv Sylvania
- Tv Mitsubishi
- Tv Aspes
- Tv Schaub Lorenz
- Tv Nec
- Tv Emerson
- Tv Sunny
- Tv Technisat
- Tv GoGEN
- Tv Marquant
- Tv Orima
- Tv Luxor
- Tv Nordmende
- Tv AudioAffairs
- Tv Magnum
- Tv Haier
- Tv Krüger And Matz
- Tv Iiyama
- Tv Oki
- Tv Audiosonic
- Tv Proline
- Tv Coby
- Tv Muse
- Tv Marantz
- Tv Seg
- Tv Metz
- Tv Vivo
- Tv Element
- Tv Qilive
- Tv Kuppersbusch
- Tv Continental Edison
- Tv Uniden
- Tv Insignia
- Tv Daitsu
- Tv Peerless-AV
- Tv Dual
- Tv Terris
- Tv AYA
- Tv Dell
- Tv Changhong
- Tv Planar
- Tv Alba
- Tv Naxa
- Tv Technika
- Tv Chiq
- Tv Star-Light
- Tv Fantec
- Tv Nextbase
- Tv Zenith
- Tv Teac
- Tv Mpman
- Tv Sweex
- Tv Trevi
- Tv Vizio
- Tv Tesla
- Tv Cello
- Tv Sogo
- Tv Mx Onda
- Tv Orion
- Tv Wharfedale
- Tv Viewsonic
- Tv Nikkei
- Tv Peaq
- Tv Vivax
- Tv Hannspree
- Tv Nevir
- Tv Yasin
- Tv Jensen
- Tv Roadstar
- Tv Humax
- Tv Newstar
- Tv XD Enjoy
- Tv MT Logic
- Tv Superior
- Tv Kunft
- Tv ITT
- Tv Grunkel
- Tv ILive
- Tv Oppo
- Tv Intenso
- Tv Inovia
- Tv Odys
- Tv NPG
- Tv Furrion
- Tv Cecotec
- Tv Bluesky
- Tv Videocon
- Tv Xoro
- Tv Durabase
- Tv HKC
- Tv Edenwood
- Tv Monster
- Tv Woxter
- Tv Premier
- Tv Onn
- Tv Packard Bell
- Tv Opera
- Tv LTC
- Tv JTC
- Tv Zalman
- Tv Orava
- Tv Horizon
- Tv Ferguson
- Tv Reflexion
- Tv Viewpia
- Tv JGC
- Tv Online
- Tv Dyon
- Tv DirecTV
- Tv Tele 2
- Tv Graetz
- Tv Telesystem
- Tv Kemo
- Tv Jay-tech
- Tv Doffler
- Tv EKO
- Tv E-motion
- Tv Mitsai
- Tv Selfsat
- Tv High One
- Tv V7
- Tv Tve
- Tv ISymphony
- Tv Pantel
- Tv Magnavox
- Tv ATYME
- Tv HCI
- Tv Inno-Hit
- Tv Lin
- Tv Engel
- Tv Bang Olufsen
- Tv TechLine
- Tv Elements
- Tv Digihome
- Tv Englaon
- Tv Reflex
- Tv Astar
- Tv Visco
- Tv Tivax
- Tv H&B
- Tv Norcent
- Tv TELE System
- Tv United
- Tv TIM
- Tv Oyster
- Tv Belson
- Tv Vision Plus
- Tv Sbr
- Tv Bauhn
- Tv Voxx
- Tv Rm 2000
- Tv Hoher
- Tv Majestic
- Tv Felson
- Tv SEIKI
- Tv Mach Power
- Tv Elbe
- Tv MBM
- Tv Axing
- Tv FFalcon
- Tv CGV
- Tv Smart Tech
- Tv SunBriteTV
- Tv Séura
- Tv Mitzu
- Tv Caratec
- Tv JTC24
- Tv Coocaa
- Tv SYLVOX
- Tv Kivi
- Tv Smart Brand
- Tv RevolutionHD
- Tv Voxicon
- Tv QBell Technology
- Tv Aconatic
- Tv Mitchell & Brown
- Tv FOX Electronics
- Tv Mystery
- Tv Linsar
Nyaste Tv Manualer
28 Mars 2025
28 Mars 2025
27 Mars 2025
26 Mars 2025
19 Mars 2025
19 Mars 2025
14 Mars 2025
13 Mars 2025
13 Mars 2025
13 Mars 2025
