MODEL* CABLE DESCRIPTION MAX. RESOLUTION
(BIT ERROR RATE)
HDMI
ETHERNET
CHANNEL/
HEC
AUDIO
RETURN
CHANNEL/
ARC
SUPPORTED
HD AUDIO
FORMATS
PRO K-LOCK RETENTION
FORCE
CONDUCTORS
AWG
TRIPLE
SHIELDING O.D. (mm)
JACKET
RATING
UL/CSA
JACKET
COLOR
C-HM/HM/FLAT/ETH-3 Flat High-Speed HDMI™ Cable with Ethernet
4KX2K
6.6lb (3.0kg) 28 –3*14.5 CL3/FT4 Black
C-HM/HM/FLAT/ETH-6 Flat High-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 28 –3*14.5 CL3/FT4 Black
C-HM/HM/FLAT/ETH-10 Flat High-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 28 –3*14.5 CL3/FT4 Black
C-HM/HM/FLAT/ETH-15 Flat High-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 26 –3.8*17 CL3/FT4 Black
C-HM/HM/FLAT/ETH-25 Flat Standard-Speed HDMI™ Cable with Ethernet
1080p@60Hz/12-bit
6.6lb (3.0kg) 26 –3.8*17 CL3/FT4 Black
C-HM/HM/FLAT/ETH-35 Flat Standard-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 26 –3.8*17 CL3/FT4 Black
C-HM/HM/FLAT/ETH-50 Flat Standard-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 24 –4.2*18.6 CL3/FT4 Black
C-HM/HM/FLAT/ETH-75 Flat Standard-Speed HDMI™ Cable with Ethernet 1080p@60Hz/8-bit 6.6lb (3.0kg) 24 –4.2*18.6 CL3/FT4 Black
C-HM/HM/PRO-3 High-Speed HDMI™ Cable with Ethernet
4KX2K
6.6lb (3.0kg) 26 8±0.2 CL3/FT4 Black
C-HM/HM/PRO-6 High-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 26 8±0.2 CL3/FT4 Black
C-HM/HM/PRO-10 High-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 26 8±0.2 CL3/FT4 Black
C-HM/HM/PRO-15 High-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 26 8±0.2 CL3/FT4 Black
C-HM/HM/PRO-25 Standard-Speed HDMI™ Cable with Ethernet
1080p@60Hz/12-bit
6.6lb (3.0kg) 26 8±0.2 CL3/FT4 Black
C-HM/HM/PRO-35 Standard-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 26 8±0.2 CL3/FT4 Black
C-HM/HM/PRO-50 Standard-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 24 9.5±0.2 CL3/FT4 Black
C-HM/HM/PRO-65 Standard-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 24 9.5±0.2 CL3/FT4 Black
C-HM/HM/ETH-3 High-Speed HDMI™ Cable with Ethernet
4KX2K
6.6lb (3.0kg) 28 7.3±0.2 CL3/FT4 Gray
C-HM/HM/ETH-6 High-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 28 7.3±0.2 CL3/FT4 Gray
C-HM/HM/ETH-10 High-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 28 7.3±0.2 CL3/FT4 Gray
C-HM/HM/ETH-15 High-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 28 7.3±0.2 CL3/FT4 Gray
C-HM/HM/ETH-25 Standard-Speed HDMI™ Cable with Ethernet
1080p@60Hz/8-bit
6.6lb (3.0kg) 28 7.3±0.2 CL3/FT4 Gray
C-HM/HM/ETH-35 Standard-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 28 7.3±0.2 CL3/FT4 Gray
C-HM/HM/ETH-50 Standard-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 26 8.5±0.2 CL3/FT4 Gray
C-MHM/MHM-1 FleXible High-Speed HDMI™ Cable with Ethernet
4KX2K
6.6lb (3.0kg) 30 –5.8±0.2 VW-1 Gray
C-MHM/MHM-3 FleXible High-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 30 –5.8±0.2 VW-1 Gray
C-MHM/MHM-6 FleXible High-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 30 –5.8±0.2 VW-1 Gray
C-MHM/MHM-10 FleXible High-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 30 –5.8±0.2 VW-1 Gray
C-MHM/MHM-15 FleXible Standard-Speed HDMI™ Cable with Ethernet
1080p@60Hz/12-bit
6.6lb (3.0kg) 30 –5.8±0.2 VW-1 Gray
C-MHM/MHM-25 FleXible Standard-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 30 –5.8±0.2 VW-1 Gray
C-MHMA/MHMA-1 FleXible High-Speed HDMI™ Cable with Ethernet & 3.5mm Stereo Audio
4KX2K
6.6lb (3.0kg) 30 –5.8±0.2 VW-1 Gray
C-MHMA/MHMA-3 FleXible High-Speed HDMI™ Cable with Ethernet & 3.5mm Stereo Audio 6.6lb (3.0kg) 30 –5.8±0.2 VW-1 Gray
C-MHMA/MHMA-6 FleXible High-Speed HDMI™ Cable with Ethernet & 3.5mm Stereo Audio 6.6lb (3.0kg) 30 –5.8±0.2 VW-1 Gray
C-MHMA/MHMA-10 FleXible High-Speed HDMI™ Cable with Ethernet & 3.5mm Stereo Audio 6.6lb (3.0kg) 30 –5.8±0.2 VW-1 Gray
C-MHMA/MHMA-15 FleXible Standard-Speed HDMI™ Cable with Ethernet & 3.5mm Stereo Audio
1080p@60Hz/12-bit
6.6lb (3.0kg) 30 –5.8±0.2 VW-1 Gray
C-MHMA/MHMA-25 FleXible Standard-Speed HDMI™ Cable with Ethernet & 3.5mm Stereo Audio 6.6lb (3.0kg) 30 –5.8±0.2 VW-1 Gray
C-HM/HM-3 High-Speed HDMI™ Cable
4KX2K
––– 6.6lb (3.0kg) 28 7±0.2 CL3/FT4 Gray
C-HM/HM-6 High-Speed HDMI™ Cable ––– 6.6lb (3.0kg) 28 7±0.2 CL3/FT4 Gray
C-HM/HM-10 High-Speed HDMI™ Cable ––– 6.6lb (3.0kg) 28 7±0.2 CL3/FT4 Gray
C-HM/HM-15 High-Speed HDMI™ Cable ––– 6.6lb (3.0kg) 28 7±0.2 CL3/FT4 Gray
C-HM/HM-25 Standard-Speed HDMI™ Cable
1080p@60Hz/12-bit
––– 6.6lb (3.0kg) 28 7±0.2 CL3/FT4 Gray
C-HM/HM-35 Standard-Speed HDMI™ Cable ––– 6.6lb (3.0kg) 28 7±0.2 CL3/FT4 Gray
C-HM/HM-50 Standard-Speed HDMI™ Cable ––– 6.6lb (3.0kg) 26 8.5±0.2 CL3/FT4 Gray
CP-HM/HM/ETH-15 Plenum High-Speed HDMI™ Cable with Ethernet 4KX2K 6.6lb (3.0kg) 24 10.5±0.2 CMP Black
CP-HM/HM/ETH-25 Plenum Standard-Speed HDMI™ Cable with Ethernet
1080p@60Hz/12-bit
6.6lb (3.0kg) 24 10.5±0.2 CMP Black
CP-HM/HM/ETH-35 Plenum Standard-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 24 10.5±0.2 CMP Black
CP-HM/HM/ETH-50 Plenum Standard-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 24 10.5±0.2 CMP Black
CP-HM/HM/ETH-75 Plenum Standard-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 24 10.5±0.2 CMP Black
CLS-HM/HM/ETH-3 Low Smoke & Halogen Free High-Speed HDMI™ Cable with Ethernet
4KX2K
–4.4 lbs (2 Kg) 28 8±0.15 VW-1 Black
CLS-HM/HM/ETH-6 Low Smoke & Halogen Free High-Speed HDMI™ Cable with Ethernet –4.4 lbs (2 Kg) 28 8±0.15 VW-1 Black
CLS-HM/HM/ETH-10 Low Smoke & Halogen Free High-Speed HDMI™ Cable with Ethernet –4.4 lbs (2 Kg) 28 8±0.15 VW-1 Black
CLS-HM/HM/ETH-15 Low Smoke & Halogen Free High-Speed HDMI™ Cable with Ethernet –4.4 lbs (2 Kg) 28 8±0.15 VW-1 Black
CLS-HM/HM/ETH-25 Low Smoke & Halogen Free Standard-Speed HDMI™ Cable with Ethernet
1080p@60Hz/12-bit
–4.4 lbs (2 Kg) 28 8±0.15 VW-1 Black
CLS-HM/HM/ETH-35 Low Smoke & Halogen Free Standard-Speed HDMI™ Cable with Ethernet –4.4 lbs (2 Kg) 28 8±0.15 VW-1 Black
CLS-HM/HM/ETH-50 Low Smoke & Halogen Free Standard-Speed HDMI™ Cable with Ethernet –4.4 lbs (2 Kg) 28 8±0.15 VW-1 Black
C-HM/HM-KRTL-1M High-Speed HDMI™ Cable with Ethernet
4KX2K
6.6lb (3.0kg) 26 7.3±0.3 VW-1 Gray (Braid)
C-HM/HM-KRTL-2M High-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 26 7.3±0.3 VW-1 Gray (Braid)
C-HM/HM-KRTL-3M High-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 25 7.3±0.3 VW-1 Gray (Braid)
C-HM/HM/FLAT-KRTL-1M Flat High-Speed HDMI™ Cable with Ethernet
4KX2K
6.6lb (3.0kg) 28 –3*14.5 CL3/FT4 Gray
C-HM/HM/FLAT-KRTL-2M Flat High-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 28 –3*14.5 CL3/FT4 Gray
C-HM/HM/FLAT-KRTL-3M Flat High-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 28 –3*14.5 CL3/FT4 Gray
C-HM/HM/FLAT-KRTL-5M Flat High-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 28 –3*14.5 CL3/FT4 Gray
C-HM/HM/FLAT-KRTL-7M Flat Standard-Speed HDMI™ Cable with Ethernet
1080p@60Hz/12-bit
6.6lb (3.0kg) 28 –3*14.5 CL3/FT4 Gray
C-HM/HM/FLAT-KRTL-10M Flat Standard-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 28 –3*14.5 CL3/FT4 Gray
C-HM/HM/FLAT-KRTL-15M Flat Standard-Speed HDMI™ Cable with Ethernet 6.6lb (3.0kg) 28 –3*14.5 CL3/FT4 Gray
ALL CABLES FEATURE: • Support for all HDMI Mandated 3D Formats • Support for x.v.Colour™ • 24K Gold-Plated Connectors • RoHS Compliance
* Cable lengths are in feet. A final M means length in meters.
