Installation Instructions
MODELS:
CLS- / - AOCH 60 XX (Low Smoke & Halogen Free
Version)
CP AOCH- / - 60 XX (Plenum Version)
Active Optical UHD Pluggable HDMI Cable
SAFETY WARNING
Disconnect the unit the from power supply before opening and servicing
For the information on our products and distributors, our Web where latest a list of Kramer visit site
updates to this user manual may be found.
We welcome your questions, comments, and feedback.
www.kramerAV.com
info@kramerel.com
P/N:
2900- 300646
Rev:
1
CLS AOCH/60 AOCH/60- - -XX / CP - XX Active Optical UHD Pluggable HDMI
Cable
Congratulations on purchasing your Kramer CLS- -AOCH/60 XX / CP- - AOCH/60 XX P Plug and lay
active Fiber Optic UHD Pluggable HDMI Cable which is suited for critical and versatile installations.
The CLS AOCH/60- - - -XX / CP AOCH/60 XX provides an
extremely high quality signal over a wide range of
resolutions, up to 4K@60Hz (4:4:4). This cable is available
in f ( m). different lengths rom 33ft (10m) to 328ft 100 The
CLS AOCH/60 AOCH/60- - -XX / CP -XX has a slim design to
let you pull the cables easily (together with the supplied
pulling tool) through small sized conduit- s.
Figure 1 : HDMI Connector plugs
(Source and Display)
The CLS AOCH/60- - - -XX / CP AOCH/60 XX is ideal for long distance transmission in professional AV
systems, indoor and outdoor digital signage and kiosks, home theater systems, surgical theaters,
facility automation systems and whenever high resolution video and audio are required.
Features
The CLS AOCH/60- - - -XX / CP AOCH/60 XX:
• Supports a wide range of resolutions up to Hz (color space 4:4K@60 4:4) 3D and Deep Color
• Supports Multi- - channel audio, Dolby True HD, DTS HD Master Audio
• Is HDMI compliant: EDID, CEC, HDCP (2.2), HDR (High Dynamic Range)
• Reduced EMI and RFI
• Includes a micro USB port to an external 5V power optionally connect supply (if required, this is
typically connected on the display side)
• Has high pulling strength and compression load
• Has Source / Display clearly printed on the connector as well as tagged on the cable for easy
identification
Cable Dimensions
The CLS AOCH/60- - - -XX / CP AOCH/60 XX includes four optical fibers and six AWG 28 wires with
compact size HDMI connectors. On the source side, the micro HDMI connector enables smooth
pulling of the cable. The SOURCE end connects to the source (for example, a DVD, Blu ray or ga- me
console box) and DISPLAY end to the acceptor (for example, a projector, an LCD display or a the
tablet device), see Figure 2 (note that SOURCE appears here as an example).
Figure 2 – ) : HDMI Connectors SOURCE and DISPLAY (with Dimensions in mm
CLS AOCH/60 AOCH/60- - -XX / CP - XX Plug and Play Installation
Before installing the cable, make sure that you have a HDMI graphic card or devices with n an HDMI
port (for example, a PC, laptop, DVD/Blue ray player or any other video/audio signal source device- ) .
Optical fiber cable is not robust physically compared to conventional copper cable
materials. Even though on this cable is designed to be resistant to artificial strengths
the cable, CLS- -AOCH/60 XX / CP- - AOCH/60 XX can be damaged if it is excessively
pinched, twisted or kinked when being installed and after being installed. Take care
not to bend or twist the cable tightly.
When CLS- - -AOCH/60 XX / CP AOCH/60- XX is installed into the conduit, the fiber
pulling strength and the bending radius are the key conditions to safe installation of the
cable.
Do . not disassemble or modify the products, especially the HDMI connector head parts
To install the CLS-AOCH/60 AOCH/60- -XX / CP - :XX
1. . Unpack the cable from the package with care and remove the cable tie
2. - Place the micro HDMI (Type D) connector inside the Pulling Tool and close its cover.
Note that you can pull the cable either from the display side or the source side (as
shown in Figure 3), but you have to make sure that the cable polarity is correct
(tagged Source if pulling the source side or Display if pulling the display side).
3. c Attach the pulling able to the Pulling Tool.
Figure 3 : Attaching the Pulling Tool
4. Carefully install the cable (for example, in the wall or conduit or under the floor).
