Sida 1/4
Installation Instructions
MODEL:
CRS-AOCH/COLOR
Fiber Opc HDMI Cable
SAFETY WARNING
Disconnect the unit from the power supply before opening servicingand
For the latest information products a list Kramer distributors, visit our Web site where on our and of
updates to this user manual may be found.
We welcome your questions, comments, feedback.and
www.kramerAV.com
info@kramerel.com
P/N:
2900- 300699
Rev:
2
CRS-AOCH/COLOR Fiber Optic High Speed Pluggable HDMI Cable
Congratulations on purchasing your Kramer Plug and Play active Fiber Optic CRS-AOCH/COLOR
High Speed Pluggable HDMI Cable. The provides an extremely high quality CRS-AOCH/COLOR
signal over a wide range of resolutions, up to 4K@30Hz. This cable is available in various lengths
from 33ft (10m) up to 328ft (100m).
Features
The CRS-AOCH/COLOR:
Supports a wide range of resolutions up to 4K@30Hz Full HD, 3D, Deep Color
Supports Multi-channel audio, Dolby True HD, DTS- Master Audio HD
Is HDMI compliant: EDID, CEC, HDCP
Inherently provides protection from electromagnetic interference (EMI) and radio frequency
interference (RFI)
Has built-in powering with low power consumption
Has high pulling strength
Cable Dimensions
The CRS-AOCH/COLOR includes four optical fibers and six AWG 28 wires with compact size HDMI
connectors. The cable has a SOURCE color end to which the source is connected (for green ed
example, a DVD, Blu-ray or game console box) and a DISPLAY colored end to which the acceptor red
is connected (for example, a projector, an LCD display or a tablet device), see . Figure 1
Figure 1: HDMI Connectors SOURCE and DISPLAY (with Dimensions) –
CRS-AOCH/COLOR Plug and Play Installation
Before installing the cable, make sure that you have an HDMI graphic card or devices with an HDMI
port (for example, a PC, laptop, DVD/Blue-ray player or any other video/audio signal source devices).
Kramer CRS-AOCH/COLOR Fiber Optic HDMI cables are designed to take
+5V DC power from the source devices to the HDMI pin #18 of the SOURCE
side connector on the cable.
Optical fiber cable is not robust physically compared to conventional copper
cable materials. Even if this cable is designed to be seamlessly resistant at
certain levels of artificial strengths to the cable, CRS-AOCH/COLOR can be
damaged if it is excessively pinched, twisted or kinked when being installed
and after being installed. Be careful not to bend or twist the cable tightly.
When is installed into the conduit, the fiber pulling CRS-AOCH/COLOR
strength and the bending radius are the key conditions to safe installation of
the cable:
Maximum fiber bending radius: 90mm
Maximum fiber pulling/tensile strength: 50kg (500N)
Crush Resistance: 50kg (500N)
Do not disassemble or modify the products, especially the HDMI connector
head parts. Do not remove the dust plug before the cable laying process is
completed. HDMI connector heads are very critical parts. Remove the head at
the last moment just before the connector is plugged into the source or the
display devices after the installation is complete.
To install the CRS-AOCH/COLOR:
1. Unpack the cable from the package with care and remove the cable tie.
We recommend that you save the original box and packaging materials for possible future
shipment.
2. Install the cable (for example, an in-wall or conduit installation or under-floor installations).
3. Once the cable installation is complete, remove the dust cap and plug the SOURCE green
connector head of the cable into the source devices.
Do not plug the SOURCE green connector to the display device.
4. Remove the dust cap and plug the DISPLAY connector head of the cable into the display red
devices.
Do not plug the DISPLAY connector to the source devicered .
5. Switch on the power of source and display devices.
Troubleshooting
If you have encountered a problem, check that:
The source and display devices are both switched on
Both HDMI connector heads are fully plugged into the devices
The cable or its jacket not physically damaged is
The cable is not bent or kinked
