INSTALLATION, MAINTENANCE

AND USE INSTRUCTIONS FOR

FREE-STANDING COOKERS

90x60 cm (TYPE M9/M9V)

PLEASE READ THE INSTRUCTIONS BOOKLET BEFORE INSTALLING AND USING THE APPLIANCE.

These instructions are only for those countries whose symbols appear on the front of the booklet

and on the serial no. plate of the appliance.

The manufacturer may not be held liable for any damage to objects or people, resulting from the

improper or erroneous installation of the appliance.

The manufacturer is not responsible for any inaccuracies, due to printing or typing errors, in this booklet.

The drawings (in the figures) are indicative only.

The manufacturer may make product modifications when considered necessary and useful, without this

changing essential safety and operating characteristics.

code 310373

HEIGHT-ADJUSTABLE FEET (figure) 1)

The feet are packed in the top box.

The feet should be installed with the cooker close to its final installation position; the feet are not safe to

move the cooker long distances.

After unpacking the cooker, lift it with your foot, to fit the cooker feet in the bases at the bottom. Slowly lower

the cooker so its weight is resting on the feet and on the assembly fixings. We recommend using a lifting

device or pallet instead of tilting the cooker.

INSTALLING THE TOEKICK PANEL (only available for some models)

After installing the feet, install the cooker skirt as shown in the pictures in Figure 2. 2

INSTALLING THE (UPSTAND) RISER

Remove the 2 screws securing the hob at the rear, as shown in (figure 3)

Put the upstand in place and secure at the bottom with the two screws, as shown in (figure 3)

Secure the middle of the upstand using the screws provided with the upstand (figure 3)

INSTALLING THE HOB RAIL AND OVEN HANDLE

The rail and handle are packed with the upstand.

The rail is only available on some models.

Assemble the hob rail and oven handle as shown in the pictures (figures 4A – 4B- 4C)

INSTALLING THE SYSTEM TO PREVENT OVERTURNING

To prevent the appliance from accidentally overturning, the system provided must be installed. Install the

system as shown in the figures. Figures 5 – 5A

CONNECTING THE APPLIANCE TO THE GAS MAINS

Before connecting the appliance to the gas mains, make sure the data on the rating plate affixed inside the

warming drawer or at the rear of the oven correspond to those of the gas mains.

A label on the last page of this booklet and inside the warming drawer (or at the rear) of the appliance

gives information for adjusting the appliance: type of gas and operating pressure.

IMPORTANT: this appliance must be installed in compliance with current national standards in force and

used only in a well-ventilated room.

NOTE: The gas union of the appliance has a ½ cylindrical male gas thread, conforming to UNI-ISO 228-1

standards.

To connect the appliance to the gas mains using a flexible rubber pipe, an additional rubber union is

required (Figure 6 ) supplied with the appliance, conforming to the UNI 7141 standard.

ADJUSTMENT FOR DIFFERENT TYPES OF GAS

BEFORE CARRYING OUT ANY MAINTENANCE, UNPLUG THE APPLIANCE FROM THE GAS AND

ELECTRICITY MAINS

REPLACING NOZZLES FOR OPERATION WITH ANOTHER TYPE OF GAS:

To change the hob burner nozzles, proceed as follows:

1. Unplug the appliance from the mains, to avoid all electrical contact.

2. Remove the pan supports from the hob (Figure 7).

3. Remove the burner heads (Figure 7).

4. Use a 7 mm tubular hex wrench to loosen the nozzles and replace them with those suitable for the new type of

gas (Figure 8) as indicated in table no. 1.

To change the oven burner nozzle proceed as follows:

1. Remove the hob by removing screws G (Figure 9) and then the hob.

2. Loosen screw and remove the burner from its housing, taking care to avoid damaging the spark ignition and V

thermocouple (Figure 10).

3. Use a 7 mm tubular hex wrench to replace nozzle R with a nozzle suitable for the new type of gas as indicated

in table no. 1.

To change the grill burner nozzle proceed as follows:

1. Loosen the grill screw and remove the burner from its housing, taking care to avoid damaging the spark ignition

and thermocouple (Figure 11).

2. Use a 7m tubular hex wrench to replace nozzle R with a nozzle suitable for the new type of gas as indicated in

table no. 1.

NOTE: After replacing the nozzles, the installer shall adjust the burners as described below, seal any

regulation and pre-regulation devices, and affix the new gas regulation label, to replace the existing one.

This new label is in the bag with the spare nozzles.

TABLE NO. 1

Burner Gas type Pressur

Nozzle

diameter

Nominal flow rate

mbar 1/100 mm g/h l/h kw kcal/h

Natural Gas G20 20 72 - 95 1 860

Auxiliary Butane G30 30 50 73 - 1 860

Propane G31 37 50 71 - 1 860

Natural Gas G20 20 97 - 167 1,75 1505

Semirapid Butane G30 30 65 127 - 1,75 1505

Propane G31 37 65 125 - 1,75 1505

Natural Gas G20 20 115 - 286 3 2580

Rapid Butane G30 30 85 218 - 3 2580

Propane G31 37 85 214 - 3 2580

Natural Gas G20 20 120 - 276 2,9 2494

Fish burner Butane G30 30 85 211 - 2,9 2494

Propane G31 37 85 207 - 2,9 2494

Ultra Natural Gas G20 20 13 3,5 3010 1 - 334

Rapid Butane G30 30 95 254 - 3,5 3010

Propane G31 37 95 250 - 3,5 3010

(model with gas oven and gas grill with double controls)

Natural Gas G20 20 135 - 352 3,7 3182

Oven Butane G30 30 90 269 - 3,7 3182

Propane G31 37 90 264 - 3,7 3182

Natural Gas G20 20 115 - 191 2 1720

Grill Butane G30 30 68 145 - 2 1720

Propane G31 37 68 143 - 2 1720

(model with gas oven and gas grill with single control, or gas oven and electric grill)

Natural Gas G20 20 150 - 429 4,5 3870

Oven Butane G30 30 90 327 - 4,5 3870

Propane G31 37 90 321 - 4,5 3870

Natural Gas G20 20 115 - 191 2 1720

Grill Butane G30 30 68 145 - 2 1720

Propane G31 37 68 143 - 2 1720

ADJUSTING THE BURNERS

Adjusting the ”MINIMUM” of the burners:

Hob burner adjustment: follow the instructions below to adjust the minimum of the hob burners:

1. Light the burner setting the knob to the MINIMUM position (small flame).

2. Turn the knob of the tap, secured by simple pressure on the rod.

3. If the cooker does not have safety valves on the hob burners, insert a small slotted screwdriver in the hole of

the tap rod (Figure 12) and turn the choke screw to the right or left, until the burner flame is at the minimum; if

the cooker has safety valves, the choke screw is not situated on the rod hole, but on the body of the tap (Figure

13).

4. Make sure the flame does not go out, when switching quickly from the MAXIMUM to the MINIMUM position.

Oven burner adjustment: follow the instructions below to adjust the minimum of the burners:

1. Unplug the appliance before making the adjustment

2. Remove the knobs

3. Remove the control panel by removing the screws from the below the panel

4. Insert the thermostat knob

5. Light the burner setting the knob to the MAXIMUM position (manual lighting with a match)

6. Close the oven door and operate the oven for at least 10 minutes.

7. Set the knob to the MINIMUM position (120°) and then remove it.

8. Use a slotted screwdriver on the choke screw (Figure

9. 14) and, while observing the flame at the same time through the cooker porthole, evaluate the consistency of

the flame so it remains on when switching quickly from the MINIMUM to the MAXIMUM position.

10. Reassemble the front panel, proceeding as above in point 3, in reverse

Grill burner adjustment: follow the instructions below to adjust the minimum:

1) Light the burner setting the knob to the MAXIMUM position.

2) Close the oven door and operate the oven for at least 10 minutes.

3) Set the knob to the MINIMUM position (small flame) and then remove it.

4) The cooker is equipped with safety valves, use a small slotted screwdriver on the valve body (see fig. 13) and

turn the choke screw to the right or left, while observing the flame at the same time through the cooker porthole,

evaluate the consistency of the flame so it remains on when switching quickly from the MINIMUM to the MAXIMUM

position.

WARNING: The above-mentioned adjustment should be made only with natural gas burners, while for

those operating with liquid gas the screw must be locked at the end in a clockwise direction.
