Assembly and operating instructions
"Do - It - Yourself - Barbecue"
Foreword
Please read this assembly and operation manual
carefully before you start using your GRILLCHEF
barbecue.
You will quickly determine:
The assembly and operation processes are simple
and straightforward. Malfunctions can be excluded if
the barbecue is operated properly as a charcoal grill
outdoors.
Proper utilisation
The barbeque may only be used for preparing
suitable foods. All requirements of this assembly and
operation manual must be complied with.
Only for private use!
2GRILLCHEF
General information for successful assembly
Please read the assembly instructions carefully and
follow the safety precautions. Allow sucient time
for assembly. Before starting assembly, clear an
area measuring approximately two to three square
metres. Remove the item from the packaging! Lay out
all of the parts and any necessary tools so that they
are within easy reach.
Parts List
A. Cooking Grill 1
B. Grill Handle 2
C. Charcoal Grid 1
D. Heavy Duty Charcoal Hearth 1
Preparing assembly
Please check to make sure that all of the components
have been supplied using the following list and
drawing. Lay out all of the parts and any necessary
tools so that they are ready for assembly.
WARNING - risk of burning!
➱The barbecue must be positioned on a stable and
secure surface when it is in use, otherwise it may
tip over.
➱CAUTION! This barbecue becomes very hot and
should not be moved while it is being used!
➱Wear oven gloves or use grilling tongs when
barbecuing.
➱Allow the barbecue to cool down completely
before cleaning it.
➱CAUTION! Do not use spirit or petrol to light or
re-light the re!
➱CAUTION! Only use relighters that correspond
to the European Standard for relighters (EN
1860-3)!
➱Never use water to extinguish the charcoal.
WARNING - risk of suocation!
➱Do not use indoors!
DANGER to children and pets!
➱Never leave the hot barbecue unattended.
➱CAUTION! Keep children and pets at a safe
distance!
1
2
3
4
5
6
7
8
9
A
B
C
D
10
11
12
3
GRILLCHEF
Assembly procedure
The barbecue must be positioned on a stable and
secure surface when it is in use.
Do not use in enclosed areas or on covered surfaces.
Only use safe lighting materials (such as
LANDMANN solid relighters).
The fuel container has a capacity of approximately 2
kg.
Before using the barbecue for the rst time,
it should be heated with fuel (charcoal or
briquette) for approximately 30 minutes.
Information for safe operation of the barbecue
1. Having made the decision where to erect the
barbecue (it requires a strong and even base)
you need approx. 135 bricks and the following
material and tools to build the barbecue:
• 8 - 10 kg cement
• 40 - 50 kg sand
• Water
• Brick trowel
2. Place the rst course of bricks in position
around the three sides of the cooking grill. Score
or mark their positions on the foundation.
3. Build six courses of normal brickwork above
ground level according to the shown pattern in
sketches 1 and 2.
4. The seventh course needs to be built according
to . This course will support the sketch 3
charcoal grid. For the eighth course see sketch
2.
5. Ninth and eleventh course need to be built as
shown in . These courses will provide sketch 3
the lower and higher cooking grill position.
Twelfth course to be built as shown in sketch 2.
6. After having erected the masonry barbecue and
a certain period of drying and hardening you
can slide the metal parts into position as shown
in the exploded diagram and the assembled
diagram below. To provide dierent cooking
heights and dierent temperatures there are
two positions for the cooking grill.
Courses 1, 3 , 5
690mm
Sketch 1
Courses 2, 4 , 6, 8, 10, 12
690mm
Sketch 2
Courses 7, 9, 11
Sketch 3
