RF OUT
12V DC IN
400MA MAX
RF OUT
UMC16B
UHF Antenna Multicouplers
INSTRUCTION MANUAL
Rio Rancho, NM, USA
www.lectrosonics.com
Fill in for your records:
Serial Number:
Purchase Date:
Includes updated models:
UMC16B
UMC16BL
UMC16B-A1B1
UMC16B-941
(all models same appearance except for front panel engraving)
UMC16B
LECTROSONICS, INC.
2
UHF Antenna Multicoupler
Rio Rancho, NM 3
UMC16B RF Signal Distribution
A
IN
Ceramic Resonator
Filter
A OUT
Strip Line
RF Power
Divider
B
IN
Ceramic Resonator
Filter
Low Noise
Amp
Strip Line
RF Power
Divider
Low Noise
Amp
B OUT
Introduction
The UMC16B multi-coupler is used to distribute the
signals from two antennas to eight diversity receiv-
ers to minimize the amount of cabling and antennas
needed in multi-channel wireless systems. The design
combines broad band ceramic filtering with low noise,
high intercept point RF distribution to provide outstand-
ing performance and flexibility. Up to eight diversity
receivers or up to 16 non-diversity receivers can be
utilized across a 230 MHz passband.
Various models are available, covering different fre-
quency bands in the UHF spectrum.
The UMC16B can be powered from an external supply,
10 to 18 VDC for mobile applications, or from 100 to
240 VAC for installations using the regulated power
supply furnished with the unit. A locking connector on
the rear panel secures the power connection.
The RF signals at the inputs first pass through a
ceramic filter to block energy above and below the
passband. The signal is then fed to a high current
amplifier to apply the gain needed ahead of the splitter.
The amplifier is a high current type with a very high
IP3 (third order intercept) that minimizes intermodula-
tion products.
The amplifier output is then distributed to the output
jacks using a Wilkinson “strip line” RF splitter. Unused
outputs should be terminated with 50 Ohm dummy
loads for maximum performance, however, the splitter
design allows unused jacks to remain un-terminated
with only a slight effect on other channels (+/- 1 to 2
dB in the level at the outputs).
The unit is housed in a standard 19 inch rack mount
assembly with rugged connectors.
Table of Contents
Introduction 3 ............................................................................
Antenna Use and Placement 5 ................................................
Accessory Antennas 5 .............................................................
Specifications 6 ........................................................................
Service and Repair 6 ................................................................
