Sida 1/2
05/04 1820
1. It is recommended that the inset sink is fi tted to the
worktop before being permanently fi xed to the cabi-
net.
2. Place the sink upside down on worktop. Position the
sink relative to the worktop as required, ensuring
that the cabinet framework will be clear of all parts of
the sink, or alternatively where provided use cut-out
template found on sink wrapper.
With sharp soft pencil
draw round sink as ac-
curately as possible.
3. Remove the sink and draw another line 10mm inside
the outline of the sink top.
This is the cutting line for the aperture.
4. Drill as large a hole as possible inside the cutting
line. Using a pad saw, jig saw or similar, cut out the
aperture to the cutting line.
5. Remove the paper backing from the quadrant section
and apply to all 4 corners of the sink.
Remove the protective back from the main seal and
stick to the underside of sink.
6. Attach the fi xing clips to the sink rail ensuring that
the two ‘prongs’ of the clip face inwards. Open the
hinge on the clip.
Stainless Steel Inset Sinks with Fixed Position Clips
7. Turn the sink upside down and lay the worktop over
the sink. Swing the clip into position. (This is the most
effective method although if the worktop has been
fi xed to the cabinet, the sink can be placed in the
aperture and the fi xing effected from underneath).
8. Loosely tighten the corner fi xing clips to centralise
the sink in the cut-out.
9. Tighten the fi xing screws.
Do not overtighten the fi xing clamps once the sink is
fully bedded in the sealing tape. Do not tighten fully
at the fi rst attempt.
10. In certain circumstances it may not be possible to fi t
a clip to all the fi xed positions; provided a good seal
is achieved it is not detrimental to omit clips where
diffi culty arises.
Recommended tightening sequence for sink
fi xing clips
05/04 1820
After Care Stainless Sinks
Day to Day Care
Routine cleaning of your stainless steel sink is
easy if the following simple procedure is followed
After use wipe the bowl and drainer with a soft
damp soapy cloth, rinse with clean water. In hard-
water areas, an application of Jif will avoid any
build-up of dull fi lm of waterborne deposits.
Although stainless steel is an extremely durable
material and will withstand a great deal of hard
use, it can be scratched by hard or sharp objects.
If the surfaces are to be kept in a blemish free
condition reasonable care should be taken when
handling such items.
Discolouration and Heavy Staining
Staining of stainless steel in most cases is due
to something being deposited on the steel rather
than an attack on the material itself. The most
common cause of staining is the build up of a thin
fi lm of water borne deposits on the sink surface,
often fi rst seen as a rainbow effect. The build up of
such a fi lm can be avoided by drying the surface
of the sink after use as described above. How-
ever, should such a fi lm appear, it can be readily
removed with a soft damp cloth and Jif. To remove
the fi lm, apply the Jif neat and rub vigorously with
a damp cloth along the length of the sink surface.
After cleaning rinse thoroughly with clean water
and dry. Wire wool products and ferrous water
supply pipes can leave minute ferrous particles
adhered to the sink surface. Since stainless steel
under normal conditions does not rust, these par-
ticles can cause the appearance of small brown
rust stains. These stains can be removed using
the procedure described above.
CAUTION :
Certain household products contain substances
which will attack the stainless steel surface, they
are :
1. Bleaches :
Most common domestic bleaches contain Chlorine
in the form of a hypochlorite. Chlorine attacks the
microscopic Chromium Oxide fi lm on the surface
and can cause pitting of the surface. Bleaches
should always be used in the prescribed strength
specifi ed by the manufacturers. Undiluted bleach-
es can cause pitting and staining of the surface
and should be immediately rinsed off with plenty
of clean water. All cleaning agents containing
hypochlorites are unsuitable for use with stainless
steel and, even highly diluted, can cause pit-
ting under certain conditions. For this reason it is
strongly recommended that the sink is not used for
soaking clothes or cleaning clothes in hypochlorite
solutions for long periods.
2. Silver Dip Cleaners :
These are particularly harmful since they contain
strong acids which can cause discolouration and
pitting. The fi rst sign of this is an iridescent rain-
bow stain which turns an etched dull grey colour.
Should any Silver Dip Cleaner come into contact
with the surface of the sink it should be immedi-
ately rinsed off with plenty of clean water.
3. Corrosive Foodstuffs :
Fruit juices, damp salt, vinegar, readymade mus-
tards, pickle and mayonnaise can cause pitting
and corrosion if left in contact with the stainless
steel surface for long periods.
4. Acids :
Sulphuric, Hydrochloric and other strong acids will
cause pitting corrosion, as will photographic devel-
oping liquids. All should be immediately washed
off with plenty of clean water if contact occurs.
Cleaning :
Always use a soft cloth. The use of coarse grit
scouring powders or soap fi lled wire wool cleaning
pads is not recommended, since both will mark the
surface of the sink. Wire wool pads can leave tiny
fragments of wire embedded in the surface and
these can rust and leave small brown rust stains.
Vigorous rubbing with a soft cloth, JIF, neat deter-
gent, cleaning cream or liquid will remove these
stains. Always remove wet cleaning aids (cloths,
containers, etc.) from the sink surface after use in
order to avoid the formation of water marks and
rust stains.
Produktspecifikationer
| Varumärke: | Leisure |
| Kategori: | Sjunka |
| Modell: | LE95SB |
