Quick Reference
Lexmark C720
Operator Panel
Press <Menu> to:
• Enter the menus from the ready state
• Scroll through menus or values
• Increase or decrease a numerical value
• Display the Job Menu or the Supplies Menu while the printer is busy
Press Select to:
• Select the item on the second line of the display
• Save the selection as a new default setting
Press Return to:
• Back up to the previous menu level
Press Stop to:
• Temporarily stop all print activity without losing data
Press Go to:
• Exit printer menus and return to the ready state
• Clear messages
Ready
1 Menu 2 Select 3
Go 5
Return 4
Stop 6
© Copyright Lexmark International, Inc. 2000. All rights reserved.
Printed in U.S.A.
This document is printed on recycled paper. 10/00
E.C. 5W0006 P/N 15W0171
Overview of Printer Menus
Paper Menu
Paper Source
Paper Size
Paper Type
Custom Types
Substitute Size
Paper Weight
Paper Loading
Supplies Menu
<color>Toner
Tray <x> Status
Photo Dev Cart
Oil Bottle
Waste Bottle
Fuser
Fuser Cleaner
Replace Supplies
Supplies Life
Maintenance
Finishing Menu
Duplex
Duplex Bind
Copies
Blank Pages
Collation
Separator Sheets
Separator Source
Multipage Border
Multipage Print
Multipage Order
Multipage View
Job Menu
Confidential Job
Reset Printer
Cancel Fax
Held Jobs
Utilities Menu
Print Menus
Print Net <x>
Setup
Print Fonts
Print Directory
Factory Defaults
Format Flash
Defragment Flash
Format Disk
Job Acct Stat
Hex Trace
Serial Menu
PCL SmartSwitch
PS SmartSwitch
NPA Mode
Serial Buffer
Job Buffering
RS-232/RS-422
RS-422 Polarity
Serial Protocol
Robust XON
Baud
Data Bits
Parity
Honor DSR
Network Menu
PCL SmartSwitch
PS SmartSwitch
NPA Mode
Network Buffer
Job Buffering
MAC Binary PS
Network <x> Setup
Infrared Menu
Infrared Port
PCL SmartSwitch
PS SmartSwitch
NPA Mode
Infrared Buffer
Job Buffering
Window Size
Transmit Delay
Max Baud Rate
LocalTalk Menu
LocalTalk Port
PCL SmartSwitch
PS SmartSwitch
NPA Mode
LocalTalk Buffer
Job Buffering
NPA Hosts
LocalTalk Name
LocalTalk Addr
LocalTalk Zone
USB Menu
PCL SmartSwitch
PS SmartSwitch
NPA Mode
USB Buffer
MAC Binary PS
Job Buffering
Parallel Menu
PCL SmartSwitch
PS SmartSwitch
NPA Mode
Parallel Buffer
Job Buffering
Advanced Status
Protocol
Honor Init
Parallel Mode 1
Parallel Mode 2
Color Menu
Photo Enhance
Print Quality
Color Correction
Setup Menu
Printer Language
Power Saver
Resource Save
Download Target
Print Timeout
Auto Continue
Wait Timeout
Jam Recovery
Page Protect
Display Language
Alarm Control
Job Buffer Size
Job Accounting
Print Area
Toner Saver
Left Margin
PostScript Menu
Print PS Error
Font Priority
Image Smoothing
PCL Emul Menu
Font Source
Font Name
Point Size
Pitch
Symbol Set
Orientation
Lines per Page
A4 Width
Auto CR after LF
Auto LF after CR
Tray Renumber
Troubleshooting
37 Insufficient Memory
What this message means:
The printer memory is full and cannot continue processing current print
jobs.
What you can do:
• Press Go to clear the message and continue the current print job.
The printer frees memory by deleting the oldest held job and
continues deleting held jobs until there is enough printer memory to
process the job.
• Press Stop to clear the message without deleting any held jobs. The
current job may not print correctly.
• Press Menu> or <Menu to open the Job Menu and cancel the
current job.
• To avoid this error in the future:
– Delete fonts, macros, and other data in printer memory.
– Install additional printer memory.
Note: The messages 37 Insufficient Memory and Held Jobs may
be lost alternate on the display.
38 Memory Full
What this message means:
The printer is processing data, but the memory used to store pages is
full.
What you can do:
• Press Go to clear the message and continue printing the job. The
job may not print correctly.
• Press Menu> or <Menu to open the Job Menu and cancel the
current job.
• To avoid this error in the future:
– Simplify the print job by reducing the amount of text or graphics on
a page and deleting unnecessary downloaded fonts or macros.
– Install additional printer memory.
39 Complex Page
What this message means:
The page may not print correctly because the print information on the
page is too complex.
What you can do:
• Press Go to clear the message and continue printing the job. The
job may not print correctly.
• Press Menu> or <Menu to open the Job Menu and cancel the
current job.
• To avoid this error in the future:
– Reduce the complexity of the page by reducing the amount of text
or graphics on the page and deleting unnecessary downloaded
fonts or macros.
– Set Page Protect to On in the Setup Menu.
– Install additional printer memory.
900–999 Service <message>
What these messages mean:
Messages labeled 900–999 relate to printer problems that may require
printer service.
What you can do:
Turn the printer off and check all cable connections. Turn the printer
back on. If the service message recurs, call for service and report the
message number and description of the problem.
Supply messages
Oil Bottle Low
What you can do:
Press Go to clear the message
81 Oil Bottle Empty or Missing
What you can do:
You must replace the oil bottle to continue printing.
88 <color> Toner Low
What you can do:
Press Go to clear the message.
88 <color> Toner Empty / Open Door Replace <color>
(alternating messages)
What you can do:
You must replace the toner cartridge to continue printing.
82 Photo Dev Cart Exhausted
What you can do:
Press Go to clear the message.
Photo Dev Cart Exhausted
What you can do:
You can continue printing however, you may experience print quality
problems.
85 Fuser Cleaner Life Warning
What you can do:
Press Go to clear the message.
85 Fuser Cleaner Exhausted
What you can do:
You must replace the cleaning roll to continue printing.
83 Waste Toner Bottle Near Full
What you can do:
Press Go to clear the message.
83 Waste Bottle Full or Missing
What you can do:
You must replace the waste toner bottle to clear this message and
continue printing.
87 Fuser Exhausted
What you can do:
Press Go to clear the message.
Fuser Exhausted
What you can do:
You can continue printing however, you may experience paper jams
and print quality problems.
80 Scheduled Maintenance
What you can do:
Press Go to clear the message.
Scheduled Maintenance
You can continue printing however, you may experience paper jams
and print quality problems.
Loading paper, transparencies and
envelopes
Important! Move the front and side guides to properly position the
guides for the media size you are using.
Note: Transparencies, envelopes, labels, and card stock can only be
used in tray 1.
Important! Recommended Lexmark transparencies are P/N 12A5590
(letter) or P/N 12A5591 (A4).
Clearing paper jams
When a paper jam occurs, the Paper Jam message appears and
indicates the location of the jammed paper. You must clear the paper
from this area, but you must also clear all paper from the entire paper
path. The illustration of the paper path may help you.
After you have cleared all the paper, close the printer rear door and top
door, and then press Go to clear the message.
Note: If you feel you have cleared all the paper from the paper path,
but the paper jam message is still displayed, remove the paper
trays and check for jammed paper inside the paper tray cavity,
replace the paper trays, open and close the rear and top door,
and then press Go.
201 Paper jam (rear door)
CAUTION! The inside of the printer may be hot. Allow the printer to
cool before touching any internal components.
202 Paper jam (fuser and output rollers)
202 Paper jam (continued)
Note: Paper jammed in the fuser rollers must be removed from the
back of the printer to avoid contaminating the fuser rollers.
24x Paper jam (Open the paper tray) Clearing duplex unit paper jams
Duplex unit paper path
230 Paper jam (Open the duplex unit top door)
231 Paper jam (Open the duplex unit lower door)
Load media
Adjust guides
Flex media
231 Paper jam
230 Paper jam
Message Location
201 Paper Jam Open the rear door
202 Paper Jam Open the top door
24x Paper Jam Open the paper tray
230 Paper Jam Open the duplex unit top door
231 Paper Jam Open the duplex unit lower door
202 Paper jam
201 Paper jam
24x Paper jam
Printer paper path
Duplex unit paper path
1 Pull the rear door release
latch toward the rear of the
printer.
2 Lower the rear door and
carefully remove any paper
from the back of the printer.
3 Close the rear door and press Go..
1 Carefully remove any jammed
paper from the output rollers.
2 Pull the rear door release
latch toward the rear of the
printer.
3 Lower the rear door. 4 Slide the top door release
latch toward the front of the
printer and lift the top door.
5 Move the green roller locking
levers toward the rear of the
printer.
6 Remove the jammed paper
from the rear of the printer.
7 Move the green roller locking
levers to center position.
8 Close the top and rear doors
and press Go.
1 Pull the paper tray completely
out of the printer and set it on
a flat surface.
2 Remove any wrinkled or
damaged paper.
3 Examine inside the paper tray
cavity and remove any paper
inside the printer.
4 Place the paper in the paper
tray and place the tray into the
printer.
5 Pull the rear door release
latch toward the rear of the
printer..
6 Lower the rear door and
carefully remove any paper
from the back of the printer.
7 Close the rear door and press
Go.
230 Paper Jam
231 Paper Jam
1 Open the top duplex door. 2 Carefully remove any jammed
paper from the top of the
duplex unit.
3 Close the top duplex door and press Go.
1 Open the outer lower duplex
access door.
2 Carefully remove any jammed
paper from the rear of the
duplex unit.
3 Lower the inner rear duplex
door.
4 Lift the inner rear duplex
access panel.
5 Carefully remove any jammed
paper from inside the duplex
unit.
6 Close the inner and outer rear
duplex access doors and
press Go.
Produktspecifikationer
| Varumärke: | Lexmark |
| Kategori: | Skrivare |
| Modell: | C720 |
Behöver du hjälp?
Om du behöver hjälp med Lexmark C720 ställ en fråga nedan och andra användare kommer att svara dig
Skrivare Lexmark Manualer
27 Oktober 2024
17 Oktober 2024
17 Oktober 2024
17 Oktober 2024
14 Oktober 2024
14 Oktober 2024
13 Oktober 2024
11 Oktober 2024
11 Oktober 2024
8 Oktober 2024
Skrivare Manualer
- Skrivare Sony
- Skrivare Samsung
- Skrivare Xiaomi
- Skrivare LG
- Skrivare HP
- Skrivare Panasonic
- Skrivare Epson
- Skrivare Honeywell
- Skrivare Olympus
- Skrivare Toshiba
- Skrivare Xerox
- Skrivare Canon
- Skrivare Brother
- Skrivare Sharp
- Skrivare Renkforce
- Skrivare Kodak
- Skrivare Lenovo
- Skrivare Polaroid
- Skrivare Roland
- Skrivare Citizen
- Skrivare Fujifilm
- Skrivare Konica Minolta
- Skrivare Mitsubishi
- Skrivare Seiko
- Skrivare Argox
- Skrivare Oki
- Skrivare Royal Sovereign
- Skrivare Fujitsu
- Skrivare Bixolon
- Skrivare Ricoh
- Skrivare Dell
- Skrivare Olivetti
- Skrivare Zebra
- Skrivare D-Link
- Skrivare Kyocera
- Skrivare DNP
- Skrivare GoDEX
- Skrivare Triumph-Adler
- Skrivare Oce
- Skrivare Testo
- Skrivare Pantum
- Skrivare Tomy
- Skrivare StarTech.com
- Skrivare Toshiba TEC
- Skrivare Frama
- Skrivare Kogan
- Skrivare Brady
- Skrivare Star Micronics
- Skrivare Posiflex
- Skrivare Datamax-O'neil
- Skrivare Panduit
- Skrivare Dascom
- Skrivare HiTi
- Skrivare Primera
- Skrivare DTRONIC
- Skrivare TSC
- Skrivare Star
- Skrivare EC Line
- Skrivare Equip
- Skrivare Approx
- Skrivare Fichero
- Skrivare Raspberry Pi
- Skrivare Epson 7620
- Skrivare IDP
- Skrivare Evolis
- Skrivare Fargo
- Skrivare Microboards
- Skrivare Tally Dascom
- Skrivare Custom
- Skrivare CSL
- Skrivare Nisca
Nyaste Skrivare Manualer
26 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
