Sida 1/181
MFL70520315
Rev.00_191125
OWNER'S &
INSTALLATION MANUAL
Original instruction
AIR
CONDITIONER
www.lg.com
Please read this installation manual completely before installing the product.
Installation work must be performed in accordance with the national wiring
standards by authorized personnel only.
Please retain this installation manual for future reference after reading it thoroughly.
Copyright © 2015 - 2019 LG Electronics Inc. All Rights Reserved.
[Representative] LG Electronics Inc. EU Representative :
LG Electronics European Shared Service Center B.V.
Krijgsman 1, 1186 DM Amstelveen, The Netherlands
[Manufacturer] LG Electronics Tianjin Appliances co.,Ltd.
No.09,Jinwei Road,Beichen District,Tianjin,China.
This manual is the simpli ed version of original manual. fi
You can obtain the original manual from www.lg.com.
ENGLISH ITALIANO DEUTSCH ČEŠTINA
NEDERLANDS
POLSKI
ESPAÑOL FRANÇAIS
ΕΛΛΗΝΙΚΆ
LIMBA ROMÂNĂ
2MODEL DESIGNATION
ENGLISH
MODEL DESIGNATION
- Product Name : Air conditioner
- Product Name : Air conditioner
- Product Name : Air conditioner
- Product Name : Air conditioner- Product Name : Air conditioner
- Model Name :
- Model Name :
- Model Name :
- Model Name :- Model Name :
- Additional Information : serial number is
- Additional Information : serial number is
- Additional Information : serial number is
- Additional Information : serial number is- Additional Information : serial number is
refer to the barcode on the product.
refer to the barcode on the product.
refer to the barcode on the product.
refer to the barcode on the product.refer to the barcode on the product.
- Maximum allowable pressure
- Maximum allowable pressure
- Maximum allowable pressure
- Maximum allowable pressure- Maximum allowable pressure
High side : 4.2 MPa / 4.32 MPa
High side : 4.2 MPa / 4.32 MPa
High side : 4.2 MPa / 4.32 MPa
High side : 4.2 MPa / 4.32 MPa High side : 4.2 MPa / 4.32 MPa
(it can be different by model)
(it can be different by model)
(it can be different by model)
(it can be different by model)(it can be different by model)
Low side : 2.4 MPa
Low side : 2.4 MPa
Low side : 2.4 MPa
Low side : 2.4 MPaLow side : 2.4 MPa
- Refrigerant : R32
- Refrigerant : R32
- Refrigerant : R32
- Refrigerant : R32- Refrigerant : R32
Product information
Serial number
Indoor Unit / Outdoor Units
Detailed product type only
for M- series models
AQ : Wall mounted Libero-R
SQ : Wall mounted Libero-E
AH* : ARTCOOL
AW* : ART COOL Mirror
AH : Ceiling Cassette
AHL : Ceiling Concealed Duct
(Low Static)
Detailed product type for
U- / C- series models
L : Low Static
H : High COP
E : Econo
F : Free combination
FH : Free combination high COP
Nominal Capacity
Ex) 7 000 Btu/h Class '07',→
18 000 Btu/h Class '18' →
Product type
Connectable Outdoor unit type
Chassis name
SQSM N B 015
S : Wall mounted /
ARTCOOL mirror
J : Wall mounted
A : ARTCOOL
T : Ceiling Cassette
B, M, L : Ceiling Concealed Duct
V : Ceiling Suspended & floor
Q : Console
P : Floor Standing
M : Indoor units only for
Multi systems
U : Indoor units only for
Single CAC
C : Common Indoor Unit for
Multi and Single CAC
N : Indoor Unit
U : Outdoor Unit
The A-weighted sound pressure emitted by
this product is below 70 dB.
** The noise level can vary depending on the
site.
The figures quoted are emission level and are
not necessarily safe working levels.
Whilst there is a correlation between the
emission and exposure levels, this cannot be
used reliably to determine whether or not
further precautions are required.
Factor that influence the actual level of
exposure of the workforce include the
characteristics of the work room and the other
sources of noise, i.e. the number of
equipment and other adjacent processes and
the length of time for which an operator
exposed to the noise. Also, the permissible
exposure level can vary from country to
country.
This information, however, will enable the
user of the equipment to make a better
evaluation of the hazard and risk.
Airborne Noise Emission
SAFETY INSTRUCTIONS 3
ENGLISH
WARNING
• Installation or repairs made by unqualified persons can result in hazards to you and
others.
• Installation work must be performed in accordance with the National Electric Code
by qualified and authorized personnel only.
• The information contained in the manual is intended for use by a qualified service
technician familiar with safety procedures and equipped with the proper tools and
test instruments.
• Failure to carefully read and follow all instructions in this manual can result in
equipment malfunction, property damage, personal injury and/or death.
• Ducts connected to an appliance shall not contain an ignition source. (for R32)
• This equipment shall be provided with a supply conductor complying with the
national regulation.
!
Read the precautions in this manual
carefully before operating the unit.
This appliance is filled with
flammable refrigerant (for R32)
This symbol indicates that the
Operation Manual should be read
carefully.
This symbol indicates that a service
personnel should be handling this
equipment with reference to the
Installation Manual.
WARNING
This indicates that the failure to follow the instructions can cause serious
injury or death.
CAUTION
This indicates that the failure to follow the instructions can cause the minor
injury or damage to the product.
This symbol is displayed to indicate matters and operations that can
cause risk.
Read the part with this symbol carefully and follow the instructions in
order to avoid risk.
!
!
!
SAFETY INSTRUCTIONS
The following symbols are displayed on indoor and outdoor units.
The following safety guidelines are intended to prevent unforeseen risks or
damage from unsafe or incorrect operation of the appliance.
The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described
below.
