M-Audio Sputnik Bruksanvisning

M-Audio Inte kategoriserad Sputnik

Läs nedan 📖 manual på svenska för M-Audio Sputnik (20 sidor) i kategorin Inte kategoriserad. Denna guide var användbar för 7 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/20
Sputnik
User Guide
English ( 3 – 5 )
Guía del usuario
Español ( 6 – 8 )
Guide d'utilisation
Français ( 9 – 11 )
Guida per l'uso
Italiano ( 12 – 14 )
Benutzerhandbuch
Deutsch ( 15 – 17 )
3
User Guide (English)
Introduction
Congratulations on your purchase of M-Audio's Sputnik multi-pattern vacuum tube large-diaphragm
condenser microphone. Studio artists around the world rely on M-Audio microphones to capture acoustic
performances with clarity and accurate tonal balance. The Sputnik tube microphone from M-Audio improves
upon that reputation as a top-of-the-line solution for applications requiring the smoothest, world-class sound.
Engineered to the highest sonic standards, the Sputnik addresses the needs of the most critical professional
users.
The Sputnik microphone represents the culmination of over a year of design and development. Based on a
classic vacuum tube design and manufactured in modern facilities to exacting standards, this multi-pattern,
dual-sided large-diaphragm studio condenser mic delivers the lush, classic sound normally associated with
rare and expensive vintage mics like the Neumann U47 and AKG C12. In fact, its rich low-mid and smooth
upper-mid response makes it a good bridge between these two venerable mics.
The Sputnik's combination of military-grade vacuum tube, ultra-sensitive gold evaporated Mylar diaphragm,
solid brass construction, and multiple polar patterns make y of voices, instruments, s it ideal for a wide variet
and applications—especially putting that signature sound in the spotlight. Engineered from scratch, we
designed Sputnik with input from some of L.A.'s top recording engineers and producers—and it's an instant
classic in their hands. We are pleased to present what we believe to be the most versatile and natural-
sounding microphone solution for professional and high-end applications.
Box Contents
y Sputnik microphone y Grounded IEC power cable y Soft cloth bag
y Power supply y Flight case y User guide
y 7-pin cable y Shock mount y Safety & warranty manual
Support
For complete system requirements, compatibility information, and product registration, visit the support
section of the M-Audio website: www.m-audio.com/support.
Using the Sputnik Microphone
Even if you're a seasoned expert in microphone use and placement, we recommend you read the following
instructions when setting up the Sputnik for the first time.
BEFORE YOU GET STARTED:
The Sputnik power supply comes factory-programmed for 100V~50/60Hz, 120V~50/60Hz, or
230V~50/60Hz operation. The label on the bottom face of the power supply indicates the AC mains
voltage operation. The only way to change it is by altering the internal circuitry, but you (the customer)
cannot do that without voiding your warranty. Before using the mic, please check the label on the
bottom of the power supply unit to make sure it is set up to accept the AC line voltage in your location.
(This should not be a problem if you bought it in the country in which you are using it.)
However, if you need to use it in another location with a different AC mains voltage, we recommend
you use a high-quality general-purpose step-up or step-down transformer, rather than one of those
inexpensive voltage converters suitable for an electric razor. If you use the latter, rather than the
former, the voltage output may be a square wave (rather than a sine wave)—which will probably result
in noisy operation and will eventually cook the mic!
Please note that the mains fuse is user replaceable. If you need to change it, please follow the table
on the bottom of the power supply in order to select an appropriate fuse with the proper current rating.

Produktspecifikationer

Varumärke: M-Audio
Kategori: Inte kategoriserad
Modell: Sputnik
